3490-9

Accessories .100″  .100″ Wiremount Socket Breakaway Tab 3435 .24 [ 6.1 ] .051 [ 1.30 ] .026 [ 0.66 ] Keying Plug 3435-0 Contact Quantity 10 14 16 20 24 26 30 34 36 40 44 50 60 Dim B 0.68 [ 17.3 ] 0.88 [ 22.4 ] 0.98 [ 24.98 ] 1.18 [ 30.0 ] 1.38 [ 35.1 ] 1.48 [ 37.6 ] 1.68 [ 42.7 ] 1.88 [ 50.3 ] 1.98 [ 50.3 ] 2.18 [ 55.4 ] 2.38 [ 60.5 ] 2.68 [ 68.1 ] 3.18 [ 80.8 ] Dim C 0.62 [ 15.7 ] 0.82 [ 20.8 ] 0.92 [ 23.4 ] 1.12 [ 28.4 ] 1.32 [ 33.5 ] 1.42 [ 36.1 ] 1.62 [ 41.1 ] 1.82 [ 46.2 ] 1.92 [ 48.8 ] 2.12 [ 53.8 ] 2.32 [ 58.9 ] 2.62 [ 66.5 ] 3.12 [ 79.2 ] Recessed for Cable Exit 3490-X See Note 1 See Note 2 3.00 [ 76.2 ] .5 [ 13 ] A See Note 3 .24 [ 6.1 ] B .22 [ 5.6 ] .63 [ 16.0 ] .15 [ 3.8 ] Plastic Material: PBT C See Note 1 .08 [ 2.0 ] Standard Pull Tab 3490 3M Part Number 3490-1 3490-2 3490-3 3490-4 3490-5 3490-7 3490-6 Dimension A ± .02 0.50 [ 12.7 ] 1.00 [ 25.4 ] 1.50 [ 38.1 ] 2.00 [ 50.8 ] 2.50 [ 63.5 ] 3.10 [ 78.7 ] 3.25 [ 82.6 ] 1.50 [ 38.1] width 2.00 [ 50.8 ] length .53 Ref [ 13.5 ] 3490-9 “No Product Labeling” Metal Material: Stainless Steel pasivated .10 [ 2.5 ] Inch [mm] Tolerance Unless Noted .0 .00 .000 Notes: Inch ± .1 ± .01 ± .005 1. Matte finish for ink labeling. [ ] Dimensions for 2. Material: Polyester Reference only Thickness: .005 ± .001 Flammability: Oxygen index minimum 28, ASTM D-2863. TS-0720-02 3. Material: Double sided adhesive Sheet 1 of 1 tape with liner. Strain Relief 3448-X0XX Type: 2 = Metal 3 = Plastic XX = ‘‘Contact Quantity’’ of Socket: (i.e. 50 for 50 Position Strain Relief) Note: 1. The notch is non-existent on 40 position and larger. 3M Interconnect Solutions Division 6801 River Place Blvd. Austin, TX 78726-9000 For technical, sales or ordering information call 800-225-5373
