AS431
ADJUSTABLE PRECISION SHUNT REGULATORS
Description
Pin Assignments
The AS431 is a three-terminal adjustable shunt regulator with
guaranteed thermal stability over a full operation range. It features
sharp turn-on characteristics, low temperature coefficient and low
output impedance, which make it ideal substitute for Zener diode in
applications such as switching power supply, charger and other
adjustable regulators.
(Top View)
(Top View)
ANODE
3
NC
1
*
2
CATHODE
3
(Note 4)
The output voltage of AS431 can be set to any value between VREF
(2.5V) and the corresponding maximum cathode voltage (36V).
1
2
REF
The AS431 precision reference is offered in two voltage tolerance:
0.5% and 1.0%.
This IC is available in 4 packages: TO92 (Ammo Packing), SOT23,
SOT25 and SOT89.
5
ANODE
4
REF
CATHODE
SOT23
SOT25
Note 4: * Pin 2 is attached to substrate and must be connected to ANODE or
open.
(Top View)
(Top View)
Features
Programmable Precise Output Voltage from 2.5V to 36V
High Stability under Capacitive Load
Low Temperature Deviation: 4.5mV Typical
Low Equivalent Full-range
20PPM/°C Typical
Sink Current Capacity from 1mA to 100mA
Low Output Noise
Wide Operating Range of -40 to +125°C
Lead-Free Packages: SOT23, SOT25, TO92 (Ammo Packing),
SOT89
Temperature
Coefficient
with
1
REF
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Charger
Voltage Adapter
Switching Power Supply
Graphic Card
Precision Voltage Reference
Notes:
ANODE CATHODE
1
REF
2
3
ANODE CATHODE
SOT89 (Option 2)
(Top View)
Lead-Free Packages, Available in “Green” Molding Compound:
SOT23, SOT25, TO92 (Ammo Packing), SOT89
3
SOT89 (Option 1)
Totally Lead-Free; RoHS Compliant (Notes 1 & 2)
Applications
2
3
CATHODE
2
ANODE
1
REF
TO92 (Ammo Packing)
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS), 2011/65/EU (RoHS 2) & 2015/863/EU (RoHS 3) compliant.
2. See https://www.diodes.com/quality/lead-free/ for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and
Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain
