AMERICAN BRIGHT OPTOELECTRONICS CORP.
NOVALED AlInGaP BL-PPx-SES Series
•
Feature:
1. Super high brightness surface mount LED. 2. High flux output. 3. 120° viewing angle. 4. Compact package outline (LxW) of 6.0 x 6.0 mm. Ultra low height profile – 1.5 mm. 5. Designed for high current drive; typically 175 mA. 6. Low thermal resistance; Rth (js) = 20 K/W. 7. Compatible to IR reflow soldering.
•
Package Dimension:
Solder Pad Design
Recommended Solder Pad Design For Better Heat Dissipation.
V.4 Page: 1 of 5
AMERICAN BRIGHT OPTOELECTRONICS CORP.
•
NOVALED AlInGaP BL-PPx-SES Series
Optical Characteristics: at Ta=25°C, If=175mA, Rja=100K/W.
Wavelength Total Flux @ If=175mA Min (mlm) 3500 3500 Typ. (mlm) 5000 5500 Intensity @ If=175mA Typ. (mcd) 1800 2000 Viewing Angle
Part Number
IV BINs
Color
λdom (nm) 625 589
BL-PPR-SES-C10 W1,W2,X1,X2
Red
120
BL-PPY-SES-C10 X1, X2, Y1, Y2 Yellow
IV Bins W1 W2 X1 X2 Y1 Y2 Note:
Intensity @ If=175mA (mcd) Min 1124 1400 1800 2240 2850 3550 Max 1400 1800 2240 2850 3550 4500
1. Luminous intensity is measured with an accuracy of ±11%. 2. Wavelength binning is carried for all units as per the wavelength-binning table. Only one wavelength group is allowed for each reel.
•
Electrical Characteristics (TA = 25 oC):
Vf @ If=175mA Vr @ Ir=100uA Min.(V) 15 Color Red Typ. (V) 2.2 Max. (V) 2.8
Part Number BL-PPR
BL-PPY Yellow 2.2 2.8 15 Note: An optional Vf binning is also available upon request. Binning scheme is as per following table.
•
Absolute Maximum Ratings:
Maximum Value 175 15 125 -40 … +100 -40 … +100 525 Unit mA V °C °C °C mW
Parameter DC forward current. Reverse voltage. LED junction temperature. Operating temperature. Storage temperature. Power dissipation
V.4 Page: 2 of 5
AMERICAN BRIGHT OPTOELECTRONICS CORP.
NOVALED AlInGaP BL-PPx-SES Series
•
Vf Binning: Vf Bin @ 175mA Standard 01 02 03 Forward voltage (V) 1.9 … 2.8 1.9 … 2.2 2.2 … 2.5 2.5 … 2.8
Forward voltage, Vf is measured with an accuracy of ±0.1 V.
•
Wavelength Grouping: Color
BL-PPR; Red BL-PPY; Yellow
Group
Full Full W X Y Z
Wavelength distribution (nm)
620 - 630 585 - 597 585 - 588 588 - 591 591 - 594 594 - 597
Wavelength is measured with an accuracy of ±1 nm.
V.4 Page: 3 of 5
AMERICAN BRIGHT OPTOELECTRONICS CORP.
•
NOVALED AlInGaP BL-PPx-SES Series
Typical electro-optical characteristics curves:
Fig.1 Intensity vs. Forward Current Fig.2 Flux vs. Forward Current
Intensity vs Forward Current
3500 3000 Total Flux (lm) 2500 IV (mcd) 2000 1500 1000 500 0 0 100 200 IF (mA)
Fig.3 Forward Current vs Forward Voltage
Total Flux vs Forward Current 9 8 7 6 5 4 3 2 1 0
300
400
0
100
200 IF (mA)
300
400
Fig.4 Max Forward Current vs. Ambient Temperature.
Forward Current vs Forward Voltage 350 300 250
Max IF (mA)
Forward Current vs. Ambient Temperature (RJA= 110K/W) 200 180 160 140 120 100 80 60 40 20 0 0 10 20 30 40 50 60 70 80 90 100
If (mA)
200 150 100 50 0 1.4 1.6 1.8 Vf (Volts) 2 2.2
Ambient Temperature
Fig.5 Relative Intensity vs. Wavelength
Fig.6 Radiation Pattern.
Relative Spectra Emission
1.0 0.9 0.8 0.7
30°
20°
10°
0°
1.0
40°
0.8
Relative Intensity
Red
0.6
Yellow
50°
0.6
0.5 0.4 0.3 0.2
60° 70°
0.4
0.1 0.0 500 550 600 650 700 750 800
0.2
80° 90°
0
Wavelength (nm)
V.4 Page: 4 of 5
AMERICAN BRIGHT OPTOELECTRONICS CORP.
NOVALED AlInGaP BL-PPx-SES Series
Fig.7 Recommended IR-Reflow Soldering Profile (acc. To IPC 9501).
•
Taping And Orientation:
Reels come in quantity of 1000 units. Reel diameters are 330 mm.
V.4 Page: 5 of 5
