3AW-11

BTCPower BTCPower 3AW Series Features • • • • • • • TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 3W DC-DC Converters 3W Isolated Output 24-Pin DIP Package Efficiency to 80% 4:1 Input Range Regulated Outputs Pi Input Filter Continuous Short Circuit Protection Model Number 3AW-01 3AW-02 3AW-03 3AW-04 3AW-05 3AW-06 3AW-07 3AW-11 3AW-12 3AW-13 3AW-14 3AW-15 3AW-16 3AW-17 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±5 VDC ±12 VDC ±15 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ±5 VDC ±12 VDC ±15 VDC 3.3 VDC Output Current 600 mA 250 mA 200 mA ±300 mA ±125 mA ±100 mA 600 mA 600 mA 250 mA 200 mA ±300 mA ± 125 mA ± 100 mA 6 00mA Input Current No Load Full Load 15 15 15 25 25 25 15 mA mA mA mA mA mA mA 174 mA 165 mA 165 mA 179 mA 174 mA 174 mA 117 mA 87 78 78 88 87 87 58 mA mA mA mA mA mA mA % Efficiency Case 9-36VDC 72 76 76 70 72 72 70 72 80 80 71 72 72 70 A 18-72VDC 7.5 mA 7.5 mA 7.5 mA 12 mA 1 2 mA 1 2 mA 7 .5 mA A Note: Nominal Input Voltage 24 or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com •Email: sales@btcpower.com DS LP 3AW Rev2 16-1-04 3AW Series Specifications Input Specifications: 3W DC-DC Converters BTCPower BTCPower TM Range…………….…………….24V…………...………………..9-36V 48V……………………………18-72V Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy…………….. ………………………….+/- 2.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. Ripple & Noise, 20 MHz BW Single & ±5V...………………………………...………100 mV p-p max. Dual…………………..………………………… 1% p-p max. Temperature Coeffcient………………………… +/- 0.05 % / ºC max. Short Circuit Protection………………………………..……Continuous Line Regulation ¹ Single / Dual Output………….……..+/- 0.5 % max. Load Regulation ² Single ……………...…………….….+/- 0.5 % max. Dual³………………..…..…………+/- 1.0 % max. General Specifications : Efficiency……………………………………………..……...…see table Isolation Resistance…………………………………………..100Mohm Switching Frequency……………………………...….…..100 KHz, min. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature………………………………………….100 ºC max. Cooling……………………………………………....Free air convection Storage Temperature Range……………………..…..-40 ºC ~ +100ºC Isolation Voltage………………………….………………..500VDC min. Suffix “H” Models 4………………….………………...……3K VDC min. Dimensions………….……1.25” x 0.8” x 0.4 “(31.8 x 20.3 x 10.2 mm) Case Material……………….…………..Non-Conductive Black Plastic Suffix “M” Models(Material) 5…………..…..Black Coated Copper with Non-conducted base Outline Information and Pin-out 500VDC PIN 1 2 3 5 9 10 11 12 13 14 15 16 22 23 24 Single Output +V input NC NC NP NP -V output +V output -V input -V input +V output -V output NP NC NC +V input PIN CONNECTION 1.5K & 3K VDC Dual Output +V input -V output Common NP NP Common +V output -V input -V input +V output Common NP Common -V output +V input PIN 1 2 3 5 9 10 11 12 13 14 15 16 22 23 24 Single Output NP -V input -V input NP NC NC NC NP NP +V output NC -V output +V input +V input NP Common NC -V output NP NP +V output NC Common +V input +V input NP Dual Output NP -V input -V input * NP---No Pin * NC---No connection with pin Note: 1. 2. 3. 4. 5. Measured from high line to low line Measured from full load to 10% load Measured from full load to 1/4 load Non-conductive black plastic only Suffix “HM” 1.5KVDC instead of 3KVDC isolation All dimensions are in inches [mm] All pins sizes are dia. 0.02” [0.508mm] and 0.14”[0.35mm] length The information and specifications contained in this brief are believed to be accurate and reliable at the time of publication. Specifications are subject to change without notice. Refer to product specification sheet for performance characteristics and application guidelines. Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com •Email: sales@btcpower.com DS LP 3AW Rev2 16-1-04
