3C-27

BTCPower BTCPower 3C Series Features • • • • • • • High performance 2:1 Input Range 15W Isolated Output 82% Efficiency Six –Sided Shield Low Ripple and Noise 200KHz Switching Frequency Model Number 3C-01 3C-02 3C-03 3C-04 3C-05 3C-06 3C-07 3C-11 3C-12 3C-13 3C-14 3C-15 3C-16 3C-17 3C-21 3C-22 3C-23 3C-24 3C-25 3C-26 3C-27 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 15W DC-DC Converters Output Current 3000 mA 1250 mA 1000 mA ±625 mA ±500 mA ±1500 mA 3000 mA 3000 mA 1250 mA 1000 m A ±625 mA ± 500 mA ± 1500 mA 3 000mA 3 000 mA 1 250 mA 1 000 mA ± 625 mA ± 500 mA ± 1500 mA 3 000 mA Input Current No Load Full Load 30 30 30 35 35 35 30 15 20 20 25 25 25 15 10 15 15 20 20 20 20 mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA 1660 mA 1625 mA 1625 mA 1620 mA 1620 mA 1620 mA 1178 mA 812 mA 772 mA 772 mA 780 mA 7 80 mA 7 80 mA 5 57 mA 3 90 mA 3 81 mA 3 81 mA 3 86 mA 3 86 mA 3 86 mA 2 71 mA % Efficiency Case 9-18 VDC 75 78 78 77 77 77 70 78 81 81 80 80 80 74 80 82 82 81 81 81 76 C/S 18-36 VDC C/S 36-72VDC C/S Note: 1. Nom inal Input Voltage 12, 24, or 48VDC 2. Alternative pin-out version. To order, suffix an “S” to the standard model number. Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 3C Rev2 16-1-04 3C Series Specifications Input Specifications: 15W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………….……12V……...………………9-18V 24V…………………….18-36V 48V…………………….36-72V Input Filter………………………………………………………. .Pi Type Output Specifications: Voltage Accuracy…………….. Single output………….+/- 1.0 % max. Dual + output…………+/- 1.0 % max. Dual – output…………+/- 3.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. Transient Response Single 25% Step Load Change…………………………….
