BTCPower BTCPower 4A Series Features • • • • • • • TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 5W-6W DC-DC Converters 5W-6W Isolated Output 24-Pin DIP Package Efficiency to 82% 2:1 Input Range Regulated Outputs Pi Input Filter Continuous Short Circuit Protection Model Number 4A-01 4A-02 4A-03 4A-04 4A-05 4A-06 4A-07 4A-11 4A-12 4A-13 4A-14 4A-15 4A-16 4A-17 4A-21 4A-22 4A-23 4A-24 4A-25 4A-26 4A-27 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC Output Current 1000 mA 470 mA 400 mA ±230 mA ±190 mA ±500 mA 1000 mA 1000 mA 470 mA 400 m A ±230 mA ±190 mA ±500 mA 1000 mA 1000 mA 470 mA 400 mA ±230 mA ±190 mA ±500 mA 1000 mA Input Current No Load Full Load 7.5 mA 7.5mA 7.5mA 12 mA 12 mA 12mA 7.5 mA 5mA 5mA 5mA 7.5mA 7.5mA 7.5 mA 5mA 2mA 2mA 2mA 3mA 3mA 3 mA 2mA 545 mA 585 mA 625 mA 575 mA 590 mA 545 mA 405 mA 265 mA 285 mA 305 mA 285 mA 2 95 mA 2 65 mA 1 95 mA 133 mA 145 mA 154 mA 142 mA 1 47 mA 2 65 mA 9 8 mA % Efficiency Case 9-18VDC 76 80 80 80 80 76 68 78 82 82 81 81 78 70 78 81 81 81 81 78 70 A 18-36VDC A 36-72VDC A Note: Nominal Input Voltage 12, 24 or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 4A Rev2 16-1-04 4A Series Specifications Input Specifications: 5W-6W DC-DC Converters BTCPower BTCPower TM Dual³……………………………….+/- 1.0 % max. General Specifications : Efficiency………………………………………………....……see table Isolation Resistance…………………………………………..100Mohm Switching Frequency……………………………….…..100 KHz, min. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature………………………………………….100 ºC max. Cooling………………………………………………Free air convection Storage Temperature Range……………………..…..-40 ºC ~ +100ºC Isolation voltage………Standard models…..………..….500VDC min. Suffix “H” Models……………………………………...……3K VDC min. Dimensions………….……1.25” x 0.8” x 0.4 “(31.8 x 20.3 x 10.2 mm) Case Material4………………….……..Non-Conductive Black Plastic Suffix “M” Models(Material) 5…………..…..Black Coated Copper with Non-conducted base Input Voltage Range…………….…………….12V…………...………………..9-18V 24V……………………………18-36V 48V……………………………36-72V Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy………………………………….……..+/- 2.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. Ripple & Noise, 20 MHz BW…………3.3V / 5V….. 100 mV p-p max. 12V / 15V………..1% p-p max. Temperature Coeffcient………………………… +/- 0.05 % / ºC max. Short Circuit Protection………………………………..……Continuous Line Regulation ¹ Single / Dual Output………….……..+/- 0.5 % max. Load Regulation ² Single……………….…………….….+/- 0.5 % max. Outline Information and Pin-out 500VDC PIN 1 2 3 9 10 11 12 13 14 15 16 22 23 24 Single Output +V input NC NC NP -V output +V output -V input -V input +V output -V output NP NC NC +V input PIN CONNECTION 1.5K & 3K VDC Dual Output +V input -V output Common NP Common +V output -V input -V input +V output Common NP Common -V output +V input PIN 1 2 3 9 10 11 12 13 14 15 16 22 23 24 Single Output NP -V input -V input NC NC NC NP NP +V output NC -V output +V input +V input NP Dual Output NP -V input -V input Common NC -V output NP NP +V output NC Common +V input +V input NP * NP---No Pin * NC---No connection with pin Note: 1. 2. 3. 4. 5. Measured from high line to low line Measured from full load to ¼ load Measured from full load to 10% load Non-conductive black plastic only Suffix “HM” 1.5KVDC instead of 3KVDC isolation * NC-NO Connection with Pin * GO-Ground All dimensions are in inches [mm] All pins sizes are dia. 0.02” [0.508mm] and 0.14”[0.35mm] length The information and specifications contained in this brief are believed to be accurate and reliable at the time of publication. Specifications are subject to change without notice. Refer to product specification sheet for performance characteristics and application guidelines. Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 4A Rev2 16-1-04
