4BE-14

BTCPower BTCPower 4BESeries Features • • • • • • • TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 10W DC-DC Converters 10W Isolated Output 2:1 Input Range 82% Efficiency Pi Input Filter Low Ripple and Noise Continuous Short Circuit Protection Conductive EMI Meet EN55022 Class A Model Number 4BE-01 4BE-02 4BE-03 4BE-04 4BE-05 4BE-06 4BE-11 4BE-12 4BE-13 4BE-14 4BE-15 4BE-16 4BE-21 4BE-22 4BE-23 4BE-24 4BE-25 4BE-26 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 5 VDC 12 VDC Output Current Min. Max. 100 mA 45 mA 35 mA ± 25 mA ± 20 mA ± 50 mA 100 mA 45 mA 35 mA ± 25 mA ± 20 mA ± 50 mA 100 mA 45 mA 35 mA ± 25 mA ± 20 mA ±50 mA 2000 mA 830 mA 666 mA ± 415 mA ± 333 mA ± 1000 mA 2000 mA 830 mA 666 mA ± 415 mA ± 333 mA ± 1000 mA 2000 mA 830 mA 666 mA ± 415 mA ± 333 mA ± 1000 mA Input Current No Load Full Load 30 30 30 40 40 40 20 20 20 20 20 20 mA mA mA mA mA mA mA mA mA mA mA mA 1100 mA 1065 mA 1065 mA 1065 mA 1065 mA 1065 mA 535 mA 520 mA 520 mA 520 mA 520 mA 520 mA 260 mA 254 mA 2 54 mA 2 54 mA 2 54 mA 2 54 mA % Efficiency Case 9-18DC 76 78 78 78 78 78 78 80 80 80 80 80 80 82 82 82 82 82 B 18-36 VDC B 10 mA 10 mA 36-72 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 10 mA 10 mA 10 mA 10 mA B Note: Nominal Input Voltage 12, 24, 28 or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 4BE Rev2 16-1-04 4BE Series Specifications Input Specifications: 10W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………………….12V…………..………..9-18V 24V……………..……18-36V 48V…………………..36-72V Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy……………Single output…...……….+/- 1.0 % max. Dual (+/-) output… ….+/- 1.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. Transient Response Single 25% Step Load Change…………………………….
