5A-12S33

BTCPower BTCPower 5A Series Features • • • • • • 6W-24W Non-isolated Output 24-Pin DIP Package Regulated Outputs Up to 94% Efficiency Input LC Filter Low Ripple and Noise TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 6W-24W Wide Input DC-DC Converters Model Number 5A-05S33 5A-12S33 5A-12S05 5A-12S12 5A-12S15 5A-24S12 5A-24S15 Input Voltage 4.7-6 VDC 9-32 VDC 9-32 VDC 9-32 VDC 9-32 VDC 16-32 VDC 19-32 VDC Output Voltage 3.3 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC 12 VDC 15 VDC Output Current 2000 mA 2000 mA 2000 mA 830 mA 666 mA 1600 mA 1600 mA Input Current No Load Full Load 15 mA 15 mA 15 mA 15 mA 15 mA 15 mA 15 mA 1535 mA 647 mA 947 mA 954 mA 957 mA 860 mA 1053 mA % Efficiency Case 86 85 88 87 87 93 94 A Note: Nominal Input Voltage 5, 12, or 24VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 5A Rev2 16-1-04 5A Series Specifications Input Specifications: 6W-24W Wide Input DC-DC Converters BTCPower BTCPower TM Input Voltage Range……………………..…5V………….……..4.7-6V 12V……………..… 9-32V 24V……………….16-32V 24V……………….19-32V Input Filter……………………………………………………….LC Type Output Specifications: Voltage Accuracy…………….. ………………………….+/- 2.0 % max. Ripple & Noise, 20 MHz BW…….…3.3V/5V…..… 100 mV p-p max. 12V / 15V……………1% p-p max. Temperature Coeffcient………………………… +/- 0.05 % / ºC max. Over current Protection………………………………..……120~150% Line Regulation ¹ ………….………………………..…..+/- 0.5 % max. Load Regulation ² ……………………...…………….….+/- 0.5 % max. General Specifications : Efficiency………………………………………………..……...see table Switching Frequency……………………………………..150 KHz, Typ. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature………………………………………….100 ºC max. Cooling……………………………………..………..Free air convection Storage Temperature Range……………………..…..-40 ºC ~ +100ºC Cooling………………………………………………Free air convection Isolation Voltage(input / output)………………….………Non-isolaltion Dimensions………….……1.25” x 0.8” x 0.4 “(31.8 x 20.3 x 10.2 mm) Standard Models(Material)………………..Black Coated Copper with Non-conducted base Outline Information and Pin-out PIN CONNECTION Pin 1 2 3 9 10 11 12 • • Function NP - V input - V input - V output NC +V output NP NP---No Pin * NC---No connection with pin Pin 24 23 22 16 15 14 13 Function NP + V input + V input -V output NC + V output NP All dimensions are in inches [mm] All pins sizes are dia. 0.02” [0.508mm] and 0.14”[0.35mm] length Note: 1. Measured from high line to low line Measured from full load to 10% load 2. The information and specifications contained in this brief are believed to be accurate and reliable at the time of publication. Specifications are subject to change without notice. Refer to product specification sheet for performance characteristics and application guidelines. Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 5A Rev2 16-1-04
