120-1132

CAMBION Technical Data Sheet ® Wearnes Cambion LTD Castleton, Hope Valley, Derbyshire, S33 8WR, England Telephone: +44(0)1433 621555 Fax: +44(0)1433 621290 Web: www.cambion.com Email: enquiries@cambion.com 120-1132 Solder terminal, Pin type Recommended mounting hole .064 (1,61), #52 drill How to order code 120-1132-XX-YY-00 Basic Part No XX = L dimension, YY = Plating Finish Basic Part No 120-1132 (XX) -01 -02 -03 -04 DIMENSIONS (XX) L Board Thickness .063 (1,60) .031 (0,79) .094 (2,39) .062 (1,59) .125 (3,18) .094 (2,39) .156 (3,96) .125 (3,18) D .063 (1,60) .071 (1,80) .071 (1,80) .071 (1,80) Component Terminal MATERIALS Material Brass -03 Gold Finish (YY) -04 Electro-tin SWAGE TOOLING Recommended Swaging Tools:Anvil Roll Punch Flare Punch 435-6479-01-00-00 435-6673-01-00-00 435-6692-01-00-00 Copyright© Cambion® Monday, 24 February 2003 Page 1 of 1
