160-1604

CAMBION Technical Data Sheet ® Wearnes Cambion LTD Castleton, Hope Valley, Derbyshire, S33 8WR, England Telephone: +44(0)1433 621555 Fax: +44(0)1433 621290 Web: www.cambion.com Email: enquiries@cambion.com 160-1604 Solder terminal, turreted Recommended mounting hole .067 (1,70), #51 drill How to order code 160-1604-XX-YY-00 Basic Part No XX = L dimension YY = Plating Finish Basic Part No 160-1604 (XX) -11 -01 -02 -03 DIMENSIONS (XX) L Board Thickness .025 (0,64) .016 (0,40) .045 (1.14) .031 (0,79) .094 (2,39) .062 (1,59) .125 (3,18) .094 (2,38) D .020 (0,51) .040 (1,02) .089 (2,26) .089 (2,26) MATERIALS Component Terminal Material Brass -01 Silver Finish (YY) -05 Electro Solder SWAGE TOOLING Recommended Swaging Tools:Anvil Roll punch Flare Punch Flare Punch Notes 435-6411-01-00-00 435-6611-01-00-00 435-6657-01-00-00 435-6692-01-00-00 For 160-1604-11/01 For 160-1604-02/03 Copyright© Cambion® Wednesday, 28 May 2003 Page 1 of 1
