CAMBION Technical Data Sheet ® Wearnes Cambion LTD Castleton, Hope Valley, Derbyshire, S33 8WR, England Telephone: +44(0)1433 621555 Fax: +44(0)1433 621290 Web: www.cambion.com Email: enquiries@cambion.com 460-1524 Swage mount, .080 (2,03) diameter pin Recommended mounting hole .094 (2,39) ± .002 (0,05). How to order code 460-1524-XX-YY-00 Basic Part No XX= L dimension, YY = Plating Finish Component Pin Material Brass MATERIALS Finish (-03) Gold over Nickel Finish (-04) Electro-tin over copper DIMENSIONS Basic Part Number 460-1524 (XX) -01 -02 -03 L .051 (1,30) .081 (2,08) .113 (2,87) Board Thickness .031 (0,79) .061 (1,57) .094 (2,39) SWAGE TOOLING Recommended Swaging Tools:Anvil Punch 435-6523-01-00-00 435-6663-01-00-00 Due to pin length, these pins cannot be swaged using bench press 435-3803-01-00-00 Copyright© Cambion® Thursday, 13 February 2003 Page 1 of 1
