7000-24-1111

7000 Series/High Reliability Reed Relays High Reliability Reed Relays The 7000 Series is ideally suited to the needs of Instrumentation, Data Acquisition, Process Control, Telecommunications and General Purpose requirements. The specification tables allow you to select the appropriate relay for your particular application. These models are specifically designed for high quality and reliability with versatile switching capabilities and contact forms. If your requirements differ, please consult your local representative or Coto’s Factory to discuss a custom reed relay. 7000 Series Features Multi-pole contact forms (Form A, B, and C) Wide range of switching capabilities; Low level, High Voltage, Hg wet Hermetically sealed contacts for long life and high reliability High speed switching compared to electromechanical relays Potted in metal shell - Magnetic Shield Optional Electrostatic Shield for reducing capacitive coupling PCB mounting versatility - 1.0" x 0.100" grid Optional coil suppression diode offered to protect coil drivers * * Height of Model 7003-5193 is .480 (12.2) Dimensions in Inches (Millimeters) Table #1 2 Note: Model #7003-5193 represents a complete part number. 20 COTO TECHNOLOGY (USA) Tel: (401) 943-2686 / Fax (401) 942-0920 6 (Europe) Tel: +31-45-5439343 / Fax +31-45-5427216 7000 Series/High Reliability Reed Relays Dot stamped on top of relay refers to pin #1 location (See following pages for schematic diagrams and coil data.) Notes: 1 Consult factory for life expectancy at other switching loads. 2 Optional coil suppression diode Pin #1 is +. 3 Consists of 56V Zener diode and 1N4148 diode in series, connected in parallel with coil. 4 Hg Content: Form A, 0.04 grams per capsule; Form C, 0.072 grams per capsule. Environmental Ratings: Storage Temp: -35°C to +100°C; Operating Temp: -20°C to +85°C Solder Temp: 270°C max; 10 sec. max The operate and release voltage and the coil resistance are specified at 25°C. These values vary by approximately 0.4% / °C as the ambient temperature varies. Vibration: 20 G’s to 2000 Hz; Shock: 50 G’s 6 E-mail: sales@cotorelay.com For Most Recent Data, Consult the Coto Technology Website: www.cotorelay.com 21 Contact Form Model Number Nominal Coil Voltage VDC 5 12 24 Must Operate Voltage VDC max. 3.75 9.0 18.0 Must Release Voltage VDC min. 0.4 1.0 2.0 Coil Width Schematic Top View 2, 8 Resistance (See Table #1) ±10%_ End to End Same End @25°C Coil Coil 300 1600 4200 A 1A 7101 2A 7102 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 150 1000 3500 B 3A 7103 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 100 800 2400 C 4A 7104 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 80 550 2000 D 1B5 7121 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 150 1000 3500 B 2B5 7122 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 100 800 2400 C 1C 7141 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 175 1100 4200 A 2C 7142 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 65 490 1550 C 3C 7143 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 55 300 1350 D 1A Latch 5, 6 7150 5 12 3.75 9.0 0.4 1.0 550/550 1750/1750 B 1A1B 5, 7 7160 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 80 550 2000 6 D 22 COTO TECHNOLOGY (USA) Tel: (401) 943-2686 / Fax (401) 942-0920 (Europe) Tel: +31-45-5439343 / Fax +31-45-5427216 Contact Form Model Number Nominal Coil Voltage VDC 5 12 24 Must Operate Voltage VDC max. 3.75 9.0 18.0 Must Release Voltage VDC min. 0.4 1.0 2.0 Coil Resistance ±10%_ @25°C 70 450 1785 Width Schematic Top View 2, 8 (See Table #1) End to End Same End Coil Coil A 1A Hg wet9 7201 2A Hg wet9 7202 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 60 340 1330 B 3A Hg wet9 7203 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 50 300 1200 C 4A Hg wet9 7204 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 40 250 960 D 1C Hg wet9 7241 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 50 300 1200 C 1A High Voltage 7301 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 175 1100 4200 A 2A High Voltage 7302 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 100 640 2450 B 3A High Voltage 7303 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 65 490 1550 C 4A High Voltage 7304 5 12 24 3.75 9.0 18.0 0.4 1.0 2.0 55 300 1350 D 1A Current Sensor 7003-5193 N/A 13.0 5.0 8 C (mA Max) (mA Min) Notes: These relays contain bias magnets. Correct coil polarity must be observed. Coil suppression diode is recommended for proper operation. Correct coil polarity must be observed. 7 Break before make not guaranteed. 8 Dot stamped on top of relay refers to pin #1 location. E-pin indicates Electrostatic shield pin. Unused pins omitted. Pin numbers for reference only. 9 All models with Hg wet contacts are position sensitive, must be mounted within 30o of vertical plane. See schematic. 6 5 For Most Recent Data, Consult the Coto Technology Website: www.cotorelay.com 6 E-mail: sales@cotorelay.com 23
