CT10-103-A2

CT10 Series Molded Switch CT10 Series The CT10 is a molded dry reed switch. It is single-pole, single throw (SPST) type, having normally open ruthenium contacts. The sensor is a double-ended type and may be actuated with an electromagnet, a permanent magnet or a combination of both. The device is designed for SMD mounting and is available in three lead configurations. CT10 Series Features Ideal for SMD pick and place Tape and reel packaging 10W rating Rugged encapsulation Excellent life and reliability Applications: Proximity Sensor Security Alarm Sensor Level Sensor Flow Sensor Pulse Counter CT10-XXXX-G1 CT10-XXXX-G4 Dimensions in Inches (Millimeters) ORDERING INFORMATION A complete part number is represented by the digits to the right of the CT10 series prefix followed by a suffix as shown below. Example: CT10-1030-G1 is -- a CT10 sensor (10mm encapsulated switch) -- with a sensitivity range from 10 to 30AT -- lead ends are formed according to the G1 version * CT10XXXX (0001-1999) without a suffix is a customer special. CT10-XXXX-A2 Test Coil The Magnetic sensitivity of the CT10 sensors is defined in the 10k-JK coil 92 COTO TECHNOLOGY (USA) Tel: (401) 943-2686 / Fax (401) 942-0920 6 (Europe) Tel: +31-45-5439343 / Fax +31-45-5427216 CT10 Series Molded Switch *Specifications are based on standard switch. Contact factory for other possibilities. Notes: 1 Surface mount component processing temperature: 500°F(260°C) max for 1 minute dwell time. Temperature measured on leads where lead exits molded package. 2 Surface mount component processing temperature: 438°F(226°C) max for 1 minute dwell time. Temperature measured on leads where lead exits molded package. For Most Recent Data, Consult the Coto Technology Website: www.cotorelay.com 6 E-mail: sales@cotorelay.com 93
