550-3004

5mm LED CBI® Circuit Board Indicator Top View, Single 6.10 [.240] 550-xx04 PART NO. COLOR Green Yellow Red Red, 5V Green, 5V Yellow, 5V Red Yellow Green Green Yellow Red Orange Red/Green Yellow/Green Red Green Yellow GENERAL PURPOSE A 5.84 [.230] 3.68 [.145] 6.10 [.240] 2.54 [.100] CATHODE Red Cathode for Red/Green Bi-Color Yellow Cathode for Yellow/Green Bi-Color 550-0204 550-0304 550-0404 INTEGRAL RESISTOR B 2.54 [.100] 2.54 [.100] RECOMMENDED P.C. HOLE 2.54 PATTERN [.100] CATHODE 2.54 [.100] 550-0504 550-0704 550-0804 LOW CURRENT A 3.43 [.135] for -0204 to -0404, 5.0 [.197] for all others B .635 [.025] for -0504 to -0704, .508 [.020] for all others Hole diameter: 1.22 [.048] for .635 [.025], 1.02 [.040] for all others Dimensions in mm [inches] 550-1104 550-1204 550-1304 HIGH EFFICIENCY Standard Polarity shown in drawing: Cathode same side as notch Features • Multiple CBIs form horizontal LED arrays on 6.35mm (0.250”) center-lines. • High Contrast, UL 94 V-0 rated, black housing • Oxygen index: 32% • Polymer content: PBT, 0.160 g • Housing stand-offs facilitate PCB cleaning 550-2204 550-2304 550-2404 550-2504 BI-COLOR 550-3004 550-3104 NEW SUPER BRIGHT, DIFFUSED • Solderability per MIL-STD-202F, method 208F 550-5104 • LEDs are safe for direct viewing per IEC 825-1, EN-60825-1 550-5204 • Compatible with: 550-xx04-004 quad block 550-5304 6 Custom • For custom LEDs contact factory. SUPER BRIGHT, WATER CLEAR (Non-tinted, Non-diffused) Tolerance note: As noted, otherwise: • LED Protrusion: ±0.04 mm [±0.016] • CBI Housing: ±0.02mm[±0.008] 550-5504 550-5604 550-5704 Red Green Yellow To order any of the 550-xx04 part numbers with Reverse Polarity (Cathode opposite side of notch), please add -010 to the part numbers shown above. PART NUMBER ORDERING CODE 550 – xx04 –010 Series LED Type Reverse Polarity Option 1) Cathode Opposite Side of notch –010 Ordering Code Suffix required ONLY for Reverse Polarity Option Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com 6-9 Typical Operating Characteristics (TA=25°C) GENERAL PURPOSE Part Number 550-0204 550-0304 550-0404 Color Green Yellow Red Peak Wavelength nm 565 585 635 IV mcd 12.3 12.3 12.3 VF Volts 2.1 2.1 2 See LED data sheet for additional information 550-xx04 Page # 6-51 6-51 6-51 See page 6-55 and 6-56 for Reference Only LED Drive Circuit Examples. See page 6-57 for Pin Out Test Current (mA) 20 20 20 Viewing Angle 2 Θ½ 60° 60° 60° LED Data sheet 5ND-9674 5ND-9673 5ND-9672 INTEGRAL RESISTOR Part Number 550-0504 550-0704 550-0804 LOW CURRENT Part Number 550-1104 550-1204 550-1304 Color Red Yellow Green Peak Wavelength nm 635 583 565 IV mcd 2 1.8 1.8 VF Volts 1.8 1.9 1.8 Test Current (mA) 2 2 2 Viewing Angle 2 Θ½ 50° 50° 50° LED Data sheet 521-9320 521-9321 521-9327 Page # 6-42 6-42 6-42 Color Red Green Yellow Peak Wavelength nm 655 565 583 IV mcd 2 8 8 Test Voltage 5 5 5 Forward Current (mA) 13 12 10 Viewing Angle 2 Θ½ 60° 60° 60° LED Data sheet 5RD-9422 5RD-9423 521-9284 Page # 6-52 6-52 6-41 HIGH EFFICIENCY Part Number 550-2204 550-2304 550-2404 550-2504 BI-COLOR Part Number 550-3004 550-3104 Color Red/Green Yellow/Green Peak Wavelength nm 660/565 585/565 IV mcd 90/40 8.7/8.7 VF Volts 1.8/2.1 2.1/2.1 Test Current (mA) 20 20 Viewing Angle 2 Θ½ 60° 50° LED Data sheet 521-9651 521-9724 Page # 6-46 6-46 Color Green Yellow Red Orange Peak Wavelength nm 563 585 650 600 IV mcd 10 6.3 7 7 VF Volts 2.1 2.1 2.2 1.9 Test Current (mA) 10 10 10 10 Viewing Angle 2 Θ½ 65° 50° 50° 60° LED Data sheet 5HD-9270-5 5HD-9271-5 5HD-9269 521-9704 Page # 6-49 6-49 6-49 6-43 SUPER BRIGHT, DIFFUSED Part Number 550-5104 550-5204 550-5304 Color Red Green Yellow Peak Wavelength nm 650 563 585 IV mcd 34 34 34 VF Volts 2.1 2.2 2.2 Test Current (mA) 20 20 20 Viewing Angle 2 Θ½ 50° 50° 50° LED Data sheet 5SD-9441 5SD-9456 5SD-9455 Page # 6-53 6-53 6-53 SUPER BRIGHT, WATER CLEAR (NON-TINTED, NON-DIFFUSED) Part Number 550-5504 550-5604 550-5704 Color Red Green Yellow Peak Wavelength nm 635 565 583 IV mcd 125 120 140 VF Volts 2.2 2.3 2.2 Test Current (mA) 20 20 20 Viewing Angle 2 Θ½ 24° 24° 24° LED Data sheet 521-9464 521-9465 521-9466 Page # 6-47 6-47 6-47 6-10 Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com 5mm Discrete LED Integral Resistor, 5 Volts Diffused 521-9183, -9284 5.84 [.230] 9.19 [.362] 8.43 [.332] .76 [.030] PART NO. 521-9183 521-9284 2.54 [.100] LED COLOR Red Yellow .64 [.025] 5.08 [.200] 4.57 [.180] 1.0 [.040] MAX 25.1 [1.00] MIN 1.27 [.050] 1.0 [.040] MAX CATHODE Dimensions in mm [inches] MOUNTING CLIP: 515-0004 located on page 6-48 Red Yellow ABSOLUTE MAXIMUM RATINGS (TA=25°C) Forward Voltage (V) Derating (V/°C) From 50°C Operating Temperature (°C) Storage Temperature (°C) Soldering Temperature Solder Adherence per MIL-STD-202E, Method 208C -9183 7.5 .071 -40/+85 -55/+100 -9284 7.5 .071 -40/+85 -55/+100 260°C, 5 seconds, 1.6 mm from case Red Yellow OPERATING CHARACTERISTICS (TA=25°C) Luminous Intensity (mcd) Min. VF = 5V Typical Peak Wavelength (nm) λ Peak Viewing Angle (2Θ ½) Forward Current (I) VF = 5V Reverse Voltage (V), IR=100µA Typical Typical Typical Max Min. -9183 2 8 635 60° 10 15 5 -9284 2 8 583 60° 10 15 5 6 Θ  is the off axis angle at which the luminous intensity is half the axial luminous intensity Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com 6-41 5mm Discrete LED Low Current, 2mA Diffused 8.81 [.347] .76 [.030] .46 [.018] 5.84 [.230] 521-9320, -9321, -9327 PART NO. 521-9320 521-9321 521-9327 COLOR Red Yellow Green 4.83 [.190] 1.0 [.040] MAX 25.1 [1.00] MIN 1.27 [.050] 2.54 [.100] 1.0 [.040] MAX CATHODE Dimensions in mm [inches] MOUNTING CLIP: 515-0004 located on page 6-48 Red Yellow Green ABSOLUTE MAXIMUM RATINGS (TA=25°C) Power Dssipation (mW) Derating (mA/°C) From 92°C Forward Current (mA) Peak Current (mA) Pulse width = 10 µs Operating Temperature (°C) Storage Temperature (°C) Soldering Temperature Solder Adherence per MIL-STD-202E, Method 208C -9320 27 1 7 500 -55/+100 -55/+100 -9321 36 1 7 500 -55/+100 -55/+100 -9327 24 1 7 500 -55/+100 -55/+100 260°C, 5 seconds, 1.6 mm from case Red Yellow Green OPERATING CHARACTERISTICS (TA=25°C) Luminous Intensity (mcd) IF=2mA Peak Wavelength (nm) λ Peak Viewing Angle (2Θ ½) Forward Voltage (V) IF=2mA Reverse Voltage (V), IR=50µA  -9320 Min. Typical Typical Typical Typical Max. Min. 1.2 2 635 50° 1.8 2.2 5 -9321 1.2 1.8 583 50° 1.9 2.7 5 -9327 1.2 1.8 565 50° 1.8 2.2 5 Θ is the off axis angle at which the luminous intensity is half the axial luminous intensity 6-42 Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com 5mm Discrete LED Bi-Color Non-Tinted, Diffused 8.64[.340] 1.50 [.059] MAX 0.51 [.020] 5.59 [.220] 521-9651, -9724 PART NO. 521-9651 2.54 [.100] LED COLOR Red/Green Yellow/Green 5.00 [.197] 1.00 [.04] 521-9724 22.1 [.87] MIN. CATHODE GREEN, RED/GREEN BI-COLOR 521-9651 CATHODE YELLOW, YELLOW/GREEN BI-COLOR 521-9724 MOUNTING CLIP: 515-0005 located on page 6-48 Red/Green Yellow/Green Dimensions in mm [inches] ABSOLUTE MAXIMUM RATINGS (TA=25°C) Power Dissipation (mW) Forward Current (mA) Derating (mA/°C) From 50°C Peak Current (mA) Pulse width = 100 µs -9651 100/100 40/30 .5/.4 200/120 -55/+100 -55/+100 -9724 60/100 20/30 .25/.40 80/120 -55/+100 -55/+100 Operating Temperature (°C) Storage Temperature (°C) Soldering Temperature Solder Adherence per MIL-STD-202E, Method 208C 260°C, 5 seconds, 1.6 mm from case Red/Green Yellow/Green OPERATING CHARACTERISTICS (TA=25°C) Luminous Intensity (mcd) IF=20mA Peak Wavelength (nm) λ Peak Viewing Angle (2Θ ½) Forward Voltage (V) IF=20mA Min. Typical Typical Typical Typical Max. -9651 29/12.6 90/40 660/565 60° 1.8/2.1 2.4/2.8 -9724 2.5/2.5 8.7/8.7 585/565 50° 2.1/2.1 2.8/2.8 Θ  is the off axis angle at which the luminous intensity is half the axial luminous intensity 6-46 Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com 5mm Discrete LED Super Bright, Water Clear Non-Tinted, Non-Diffused 8.81 [.347] 1.0 [.040] MAX 5.84 [.230] 521-9464,-9465,-9466 PART NO. 521-9464 521-9465 521-9466 COLOR Red Green Yellow 4.83 [.190] 2.54 [.100] 1.27 [.050] TYP 25.35 [.998] MIN CATHODE .46 [.018] SQ. Dimensions in mm [inches] MOUNTING CLIP: 515-0004 located on page 6-48 Red Green Yellow ABSOLUTE MAXIMUM RATINGS (TA=25°C) Power Dissipation (mW) Derating (mW/°C) From 25°C Forward Current (mA) Peak Current (mA) Pulse width = 10 µs Operating Temperature (°C) Storage Temperature (°C) Soldering Temperature Solder Adherence per MIL-STD-202E, Method 208C 1. From 50 °C -9464 135 1.8 30 500 -55/+100 -55/+100 -9465 135 1.8 30 500 -20/+100 -55/+100 -9466 85 1.61 20 500 -55/+100 -55/+100 260 °C, 5 seconds, 1.6 mm from case Red Green Yellow OPERATING CHARACTERISTICS (TA=25°C) Luminous Intensity (mcd) IF=20mA Peak Wavelength (nm) λ Peak Viewing Angle (2Θ ½) Forward Voltage (V) IF=20mA Reverse Voltage (V), IR=100µA  -9464 Min. Typical Typical Typical Typical Max. Min. 80 125 635 24° 2.2 3 5 -9465 80 120 565 24° 2.3 3 5 -9466 80 140 583 24° 2.2 3 5 6 Θ is the off axis angle at which the luminous intensity is half the axial luminous intensity Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com 6-47 5mm High Efficiency Diffused TYPE *5HD-9269 *5HD-9270-2 *5HD-9270-5 *5HD-9271-2 *5HD-9271-5 5HD-xxxx COLOR Red Green Green Yellow Yellow * NOT A VALID PART NUMBER. THIS SHEET IS FOR REFERENCE ONLY. ABSOLUTE MAXIMUM RATINGS (TA=25°C) Power Dissipation (mW) Derating (mW/°C) From 50°C 1. From 40°C Forward Current (mA) Derating (mA/°C) From 25°C Peak Current (mA) Pulse width = 1µs Red Green Green Yellow Yellow -9269 60 1 .66 20 60 -25/+85 -30/+100 -9270-2 140 40 .6 500 -55/+100 -55/+100 -9270-5 75 1 .66 25 60 -25/+85 -30/+100 -9271-2 200 60 .8 1000 -55/+100 -55/+100 -9271-5 60 1 .66 20 60 -25/+85 -30/+100 Operating Temperature (°C) Storage Temperature (°C) Soldering Temperature Solder Adherence per MIL-STD-202E, Method 208C 260°C, 5 seconds, 1.6 mm from case 6 OPERATING CHARACTERISTICS (TA=25°C) Luminous Intensity (mcd) IF=10mA Peak Wavelength (nm) λ Peak Viewing Angle (2Θ ½) Forward Voltage (V) I F=10mA, *IF=20mA Reverse Voltage (V), IR=100µA *IR=10µA Min. Typical Typical Typical Typical Max. Min. Red Green Green Yellow Yellow -9269 2.2 7 650 50° 2.2 2.5 5 -9270-2 4 32 565 50° 2* 2.6* 5* -9270-5 3.6 10 563 65° 2.1 3 3* -9271-2 4 10 590 70° 2.4* 3* 5* -9271-5 2.2 6.3 585 50° 2.1 3 3 Θ  is the off axis angle at which the luminous intensity is half the axial luminous intensity Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com 6-49 5mm General Purpose Diffused TYPE *5ND-9672 *5ND-9673 *5ND-9674 5ND-xxxx COLOR Red Yellow Green * NOT A VALID PART NUMBER. THIS SHEET IS FOR REFERENCE ONLY. Red Yellow Green ABSOLUTE MAXIMUM RATINGS (TA=25°C) Power Dissipation (mW) Forward Current (mA) Derating (mA/°C) From 25°C Peak Current (mA) Pulse width = 10 µs -9672 80 40 .5 200 -55/+100 -55/+100 -9673 60 20 .25 80 -55/+100 -55/+100 -9674 100 30 .4 120 -55/+100 -55/+100 Operating Temperature (°C) Storage Temperature (°C) Soldering Temperature Solder Adherence per MIL-STD-202E, Method 208C 260°C, 5 seconds, 1.6 mm from case Red Yellow Green OPERATING CHARACTERISTICS (TA=25°C) Luminous Intensity (mcd) IF=20mA Peak Wavelength (nm) λ Peak Viewing Angle (2Θ ½) Forward Voltage (V) IF=20mA Reverse Voltage (V), IR=100µA Min. Typical Typical Typical Typical Max. Min. -9672 3.5 12.3 635 60° 2 2.8 5 -9673 3.5 12.3 585 60° 2.1 2.8 5 -9674 3.5 12.3 565 60° 2.1 2.8 5 6 Θ  is the off axis angle at which the luminous intensity is half the axial luminous intensity Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com 6-51 5mm Integral Resistor Diffused TYPE *5RD-9378 *5RD-9379 *5RD-9422 *5RD-9423 5RD-xxxx COLOR Green Yellow Red Green VOLTS 12 12 5 5 * NOT A VALID PART NUMBER. THIS SHEET IS FOR REFERENCE ONLY. ABSOLUTE MAXIMUM RATINGS (TA=25°C) Forward Voltage (V) *(TA=70°C) Operating Temperature (°C) Storage Temperature (°C) Soldering Temperature Solder Adherence per MIL-STD-202E, Method 208C Green 12V Yellow 12V Red 5V Green 5V -9378 15* -20/+85 -55/+100 -9379 15 -40/+85 -55/+100 -9422 7.5 -40/+85 -55/+100 -9423 7.5 -20/+85 -55/+100 260°C, 5 seconds, 1.6 mm from case OPERATING CHARACTERISTICS (TA=25°C) Luminous Intensity (mcd) VF=5V, *VF=12V Peak Wavelength (nm) λ Peak Viewing Angle (2Θ ½) Forward Current (mA), VF=5V *VF=12V Reverse Voltage (V), IR=100µA Min. Typical Typical Typical Typical Max. Typical Green 12V Yellow 12V Red 5V Green 5V -9378 1.5* 4* 565 60° 13* 20* 5 -9379 1.5* 4* 583 60° 13* 20* 5 -9422 1 2 655 60° 13 20 5 -9423 2 8 565 60° 12 15 5 Θ  is the off axis angle at which the luminous intensity is half the axial luminous intensity 6-52 Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com
