BAT1000

SPICE MODEL: BAT1000 Lead-free BAT1000 1A SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER Features · · · · Very Low Forward Voltage Drop High Conductance For Use in DC-DC Converter, PCMCIA, and Mobile Telecommunications Applications Lead Free by Design/RoHS Compliant (Note 3) TOP VIEW SOT-23 A Dim A B C Min 0.37 1.20 2.30 0.89 0.45 1.78 2.80 0.013 0.903 0.45 0.085 0° Max 0.51 1.40 2.50 1.03 0.60 2.05 3.00 0.10 1.10 0.61 0.180 8° B C D E G Mechanical Data · · · · · · · · · Case: SOT-23 Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0 Moisture Sensitivity: Level 1 per J-STD-020C Terminals: Solderable per MIL-STD-202, Method 208 Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe). Polarity: See Diagram Marking: K79 and Date Code, See Page 3 Ordering Information: See Page 3 Weight: 0.008 grams (approximate) E D G H K J L M H J K L M a All Dimensions in mm Maximum Ratings @ TA = 25°C unless otherwise specified Symbol VRRM VRWM VR VR(RMS) IO IFSM Pd RqJA Tj TSTG Value 40 28 1.0 5.5 500 200 -40 to +125 -40 to +150 Unit V V A A mW °C/W °C °C Characteristic Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Average Rectified Current Non-Repetitive Peak Forward Surge Current 8.3ms Single half sine-wave superimposed on rated load Power Dissipation (Note 1) Typical Thermal Resistance, Junction to Ambient Air (Note 1) Operating Temperature Range Storage Temperature Range Electrical Characteristics Characteristic Reverse Breakdown Voltage (Note 2) @ TA = 25°C unless otherwise specified Symbol V(BR)R Min 40 Typ ¾ 225 235 290 340 390 420 475 ¾ 175 25 Max ¾ 270 290 340 400 450 500 600 100 ¾ ¾ Unit V IF = IF = IF = IF = IF = IF = IF = Test Condition IR = 300uA 50mA 100mA 250mA 500mA 750mA 1000mA 1500mA Forward Voltage VF ¾ mV Reverse Current (Note 2) Total Capacitance Notes: IR CT ¾ ¾ ¾ mA pF pF VR = 30V VR = 0V, f = 1.0MHz VR = 25V, f = 1.0MHz 1. Part mounted on FR-4 board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf. 2. Short duration pulse test used to minimize self-heating effect. 3. No purposefully added lead. DS30245 Rev. 6 - 2 1 of 3 www.diodes.com BAT1000 ã Diodes Incorporated 0.75 IF, INSTANTANEOUS FORWARD CURRENT (A) 0 25 50 75 100 125 150 1.0 IO, AVERAGE RECTIFIED CURRENT (A) 10 1.0 0.50 0.1 0.25 0 TT, TERMINAL TEMPERATURE (° C) Fig. 1 Forward Current Derating Curve 0.01 0 0.2 0.4 0.6 0.8 1.0 VF, INSTANTANEOUS FORWARD VOLTAGE (V) Fig. 2 Typical Forward Characteristics 1000 f = 1MHz 150 TA, AMBIENT TEMPERATURE (ºC) 125 CT, TOTAL CAPACITANCE (pF) 100 100 75 10 50 1.0 0 5 10 15 20 25 VR, DC REVERSE VOLTAGE (V) Fig. 3 Typ. Total Capacitance vs Reverse Voltage 25 1 10 20 30 40 50 VR, REVERSE VOLTAGE (V) Fig. 4 Typical Safe Operating Area Note: 1. Assumed application thermal conditions. RqJA varies depending on application. DS30245 Rev. 6 - 2 2 of 3 www.diodes.com BAT1000 Ordering Information Device BAT1000-7-F Notes: (Note 4) Packaging SOT-23 Shipping 3000/Tape & Reel 4. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf. Marking Information K79 K79 = Product Type Marking Code YM = Date Code Marking Y = Year ex: N = 2002 M = Month ex: 9 = September Date Code Key Year Code 2002 N 2003 P 2004 R 2005 S 2006 T 2007 U 2008 V 2009 W 2010 X 2011 Y 2012 Z Month Code Jan 1 Feb 2 March 3 Apr 4 YM May 5 Jun 6 Jul 7 Aug 8 Sep 9 Oct O Nov N Dec D IMPORTANT NOTICE Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes without further notice to any product herein. Diodes Incorporated does not assume any liability arising out of the application or use of any product described herein; neither does it convey any license under its patent rights, nor the rights of others. The user of products in such applications shall assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on our website, harmless against all damages. LIFE SUPPORT Diodes Incorporated products are not authorized for use as critical components in life support devices or systems without the expressed written approval of the President of Diodes Incorporated. DS30245 Rev. 6 - 2 3 of 3 www.diodes.com BAT1000
