TCH-C7-12

ECM Flat Mains Transformer TCH - TNC Series § § § § § § VDE and UL Approvals 110V X 2 Universal Primary Dual 115V Primary Option Up to 42VA Power Rating Low Leakage Current High Reliability These low profile transformers have high dielectric strength and very low leakage current. The core is laminated using UI type grain orientated magnetic plates. OUTLINE AND DIMENSIONS Package TCH - A TCH - B TCH - C TCH - D TNC - F TNC - G TNC - H Outline A (Fig.) (mm) 1 53.0 1 53.0 2 68.0 2 68.0 2 73.5 2 73.5 3 89.0 B 44.0 44.0 57.5 57.5 54.0 54.0 69.0 C 7x5.0 7x5.0 4X5.0 4X5.0 4x5.0 4x5.0 5X5.0 D 35.0 35.0 45.0 45.0 45.0 45.0 52.0 E 6.0 6.0 5.0 5.0 7.5 H 19 22 22 27 26 35 37 Pin Dia. 0.8 0.8 0.8 0.8 0.8 0.8 0.8 ECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UK Tel: +44(0)1903 892810: Fax: +44(0)1903 892738. Email: ecm@ecmelectronics.co.uk Although we have attempted to accurately reflect the products we market. ECM reserve the right without prior notice to discontinue any product or make design changes we believe necessary. Issue 1 ECM Flat Mains Transformer ECM Part TCH-A 2-6 TCH-A 2-9 TCH-A 2-12 TCH-A 2-15 TCH-A 2-18 TCH-A 2-24 TCH-A 4-6 TCH-A 4-9 TCH-A 4-12 TCH-A 4-15 TCH-A 4-18 TCH-A 4-24 TCH-B 6-6 TCH-B 6-9 TCH-B 6-12 TCH-B 6-15 TCH-B 6-18 TCH-B 6-24 TCH-C 7-6 TCH-C 7-9 TCH-C 7-12 TCH-C 7-15 TCH-C 7-18 TCH-C 7-24 TCH-C 10-6 TCH-C 10-9 TCH-C 10-12 TCH-C 10-15 TCH-C 10-18 TCH-C 10-24 TCH-D 14-6 TCH-D 14-9 TCH-D 14-12 TCH-D 14-15 TCH-D 14-18 TCH-D 14-24 TNC-F 15-6 TNC-F 15-9 TNC-F 15-12 TNC-F 15-15 TNC-F 15-18 TNC-F 15-24 VA Primary 2 X 110V Between Pins1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 1-3 / 6-8 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 Secondary Secondary Output Connection 2X Between Pins6V - 0.166A 9-10 / 15-16 9V - 0.111A 9-10 / 15-16 12V - 0.083A 9-10 / 15-16 15V - 0.066A 9-10 / 15-16 18V - 0.055A 9-10 / 15-16 24V - 0.041A 9-10 / 15-16 6V - 0.333A 9-10 / 15-16 9V - 0.222A 9-10 / 15-16 12V - 0.166A 9-10 / 15-16 15V - 0.133A 9-10 / 15-16 18V - 0.111A 9-10 / 15-16 24V - 0.083A 9-10 / 15-16 6V - 0.500A 9-10 / 15-16 9V - 0.333A 9-10 / 15-16 12V - 0.250A 9-10 / 15-16 15V - 0.200A 9-10 / 15-16 18V - 0.166A 9-10 / 15-16 24V - 0.125A 9-10 / 15-16 6V - 0.583A 11-12 / 19-20 9V - 0.388A 11-12 / 19-20 12V - 0.291A 11-12 / 19-20 15V - 0.233A 11-12 / 19-20 18V - 0.194A 11-12 / 19-20 24V - 0.145A 11-12 / 19-20 6V - 0.833A 11-12 / 19-20 9V - 0.555A 11-12 / 19-20 12V - 0.416A 11-12 / 19-20 15V - 0.333A 11-12 / 19-20 18V - 0.277A 11-12 / 19-20 24V - 0.208A 11-12 / 19-20 6V - 1.166A 11-12 / 19-20 9V - 0.777A 11-12 / 19-20 12V - 0.583A 11-12 / 19-20 15V - 0.466A 11-12 / 19-20 18V - 0.388A 11-12 / 19-20 24V - 0.291A 11-12 / 19-20 6V - 1.250A 11-12 / 19-20 9V - 0.833A 11-12 / 19-20 12V - 0.625A 11-12 / 19-20 15V - 0.500A 11-12 / 19-20 18V - 0.416A 11-12 / 19-20 24V - 0.312A 11-12 / 19-20 Weight (kgs) 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.28 0.28 0.28 0.28 0.28 0.28 0.28 0.28 0.28 0.28 0.28 0.28 0.41 0.41 0.41 0.41 0.41 0.41 0.32 0.32 0.32 0.32 0.32 0.32 2 2 2 2 2 2 4 4 4 4 4 4 6 6 6 6 6 6 7 7 7 7 7 7 10 10 10 10 10 10 14 14 14 14 14 14 15 15 15 15 15 15 ECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UK Tel: +44(0)1903 892810: Fax: +44(0)1903 892738. Email: ecm@ecmelectronics.co.uk Although we have attempted to accurately reflect the products we market. ECM reserve the right without prior notice to discontinue any product or make design changes we believe necessary. Issue 1 ECM Flat Mains Transformer ECM Part TCH-D 18-6 TCH-D 18-9 TCH-D 18-12 TCH-D 18-15 TCH-D 18-18 TCH-D 18-24 TNC-G 25-6 TNC-G 25-9 TNC-G 25-12 TNC-G 25-15 TNC-G 25-18 TNC-G 25-24 TNC-H 42-6 TNC-H 42-9 TNC-H 42-12 TNC-H 42-15 TNC-H 42-18 VA Primary 2 X 110V Between Pins2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-4 / 7-9 2-5 / 8-11 2-5 / 8-11 2-5 / 8-11 2-5 / 8-11 2-5 / 8-11 Secondary Secondary Output Connection 2X Between Pins 6V - 1.500A 11-12 / 19-20 9V - 1.000A 11-12 / 19-20 12V - 0.750A 11-12 / 19-20 15V - 0.600A 11-12 / 19-20 18V - 0.500A 11-12 / 19-20 24V - 0.375A 11-12 / 19-20 6V - 2.080A 11-12 / 19-20 9V - 1.380A 11-12 / 19-20 12V - 1.040A 11-12 / 19-20 15V - 0.830A 11-12 / 19-20 18V - 0.694A 11-12 / 19-20 24V - 0.520A 11-12 / 19-20 6V - 3.500A 13-15 / 22-24 9V - 2.333A 13-15 / 22-24 12V - 1.750A 13-15 / 22-24 15V - 1.400A 13-15 / 22-24 18V - 1.166A 13-15 / 22-24 Weight (kgs) 0.41 0.41 0.41 0.41 0.41 0.41 0.50 0.50 0.50 0.50 0.50 0.50 0.80 0.80 0.80 0.80 0.80 18 18 18 18 18 18 25 25 25 25 25 25 42 42 42 42 42 Customer specifications also welcome ECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UK Tel: +44(0)1903 892810: Fax: +44(0)1903 892738. Email: ecm@ecmelectronics.co.uk Although we have attempted to accurately reflect the products we market. ECM reserve the right without prior notice to discontinue any product or make design changes we believe necessary. Issue 1
