MX
n Features • Subminiature Size: 17.5 x 6.5 x 12.5 mm (lwh)
• • • • Large Capacity: 5A, 250VAC/30VDC High Dielectric: 3000VAC, 1 minute, coil/contact High Sensitivity: 100mW pull-in power with non-polarized structure Sealed Cover: Suitable for immersion cleaning
n
Rating Performance
Contact Arrangement: 1 Form A (1a) Contact Material: AgCuNi Rated Load: 250VAC/30VDC 5A (Resistive Load) Contact Resistance: Max. 50mOhm (at 6VDC 1A, voltage drop method) Switching Current (max): 5A Carrying Current (max): 10A at 20 C within 10 minutes Dielectric Strength: 3,000VAC for 1 minute (Coil to Contact) 750VAC for 1 minute ( between open contacts) Insulation Resistance: 100mOhm @ 500VDC (min) Operate Time: 10ms, max. at rated voltage Release Time: 4ms, max. at rated voltage Shock Resistance: False Operation 10G min. (shock wave 11ms) Endurance 100G min. (shock wave 11ms) Vibration Resistance: False Operation 10 to 55Hz (Double amplitude 1.5mm) Endurance 10 to 55Hz (Double amplitude 1.5mm) Mechanical Life: 10x10 6 Ops. (Switching Freq. 300 ops/min) 6 Electrical Life: 0.1x10 Operations at rated load ( On: 1 sec/Off: 1 sec) o Ambient Temperature: -40 C to +85o C Weight: 3 grams, approx.
n
Coil Rating
Part Number MX-5(N) MX-6(N) MX-9(N) MX-10(N) MX-12(N) MX-24(N) Rated Voltage 5VDC 6VDC 9VDC 10VDC 12VDC 24VDC Coil Resistance +/- 10% 125 180 405 500 720 2,880 Pull-in Voltage 3.5V 4.2V 6.3V 7.0V 8.4V 16.8V Drop-out Voltage 0.5V 0.6V 0.9V 1.0V 1.2V 2.4V Rated Power
200mW
65 SHARK RIVER ROAD, NEPTUNE, NEW JERSEY 07753-7423 USA
TOLL FREE (732) 922-8330 FX (732) 922-6363
n Characteristics
n
Dimensions, Wiring, Drilling Diagram
n
How to Order
MX - 12
Model Coil Voltage (DC)
3, 4.5, 5, 6, 9, 10, 12, 18, 21, 24
G
C
Terminal: Blank = Standard Contacts: Blank = Standard
G = Low level loads
65 Shark River Road, Neptune, New Jesrey, 07753-7423 USA PH (732) 922-6333 FX (732) 922-6363 E-mail: globalcomponents@msn.com
