RFP-150-50SMA-C

Cable & Coaxial Terminations Coaxial Terminations General Notes: 1. Resistance Tolerance: Standard tolerance is ± 5%. 2. Mechanical Tolerance: ± 0.010 unless otherwise specified. 3. Custom mechanical configurations available upon request. 4. All connectors are female, unless otherwise requested. 5. All dimensions are in inches. Power Derating: RF Power terminations can be derated for flange temperatures up to 150°C. (see chart). This will provide the user with improved reliability and a wide margin of performance under stringent operating conditions. This is a result of a proprietary thick film process allowing for maximum heat transfer from the film to the BeO substrate. .500 .250 .200 x .140 THRU. (2 PLACES) Coaxial Terminations Suggested Mounting Procedures: 1. Make sure that the devices are mounted on flat surfaces to optimize the heat transfer (0.001 in/in under the device). 2. Drill and tap the heatsink for the appropriate thread size to be used. 3. Coat heatsink with a minimum amount of high quality silicone grease (0.001 in/in maximum thickness). 4. Position device on mounting surface and secure using socket head screws, flat and split washers. Torque screws to the appropriate value. Make sure that the device is flat against the heatsink. .380 .190 Case Style A 1.000 Part Number Components Inc. RFP-15-50SMA-A .614 Power Power (Watts) 15 VSWR (Max.) 1.25:1 Freq. (GHz) DC-3 RFP-15-50SMA-A .500 .562 .250 .960 .125 DIA. THRU. (4 PLACES) .190 Case Style B Part Number Power (Watts) 50 100 VSWR (Max.) 1.25:1 1.25:1 Freq. (GHz) DC-3 DC-3 1.375 Components Inc. RFP-100-50SMA-B 1.125 .875 Power .687 RFP-50-50SMA-B RFP-100-50SMA-B .250 .090 .125 .625 Sales Desk USA: Voice: (800) 544-2414 Fax: (315) 432-9121 Sales Desk Europe: Voice: (+44) 23 92 232392 Fax: (+44) 23 92 251369 .125 4.6.3 Cable & Coaxial Terminations 2.000 1.250 1.625 1.000 .375 .180 .375 .875 .187 Components Inc. RFP-200-50N-D 1.000 .800 .100 MOUNT ON SUFFICIENT HEAT SINK USING THERMAL COMPOUND Components Inc. RFP-800-50N-E 1.405 1.970 .985 .345 1.030 MAX. 1.595 3.315 .515 .280 4.6.4 Coaxial Terminations 1.060 .515 1.625 .215 DIA. THRU. (4 PLACES) Case Style C Part Number Power (Watts) 150 250 500 VSWR (Max.) 1.20:1 1.30:1 1.25:1 Freq. (GHz) DC-3 DC-3 DC-1.2 Power Components Inc. RFP-150-50SMA-C RFP-150-50SMA-C RFP-250-50N-C RFP-500-50N-C 3.000 1.000 Power Case Style D Part Number Power (Watts) 200 VSWR (Max.) 1.08:1 Freq. (GHz) DC-1 .410 2.180 .125 DIA. THRU. (4 PLACES) RFP-200-50N-D 3.655 .180 DIA. THRU. (6 PLACES) Power Case Style E Part Number RFP-800-50N-E Power (Watts) 800 VSWR (Max.) 1.15:1 Freq. (MHz) DC-500 PART NUMBERING ORDERING INFORMATION RFP - XXX - XXX - XXX - X Power Dissipation Resistance Value Case Style Connector Type Sales Desk USA: Voice: (800) 544-2414 Fax: (315) 432-9121 Sales Desk Europe: Voice: (+44) 23 92 232392 Fax: (+44) 23 92 251369
