67-01-YSC-HT2U1B-2T

EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet TOP View LEDs With Black Surface 67-01/YSC-HT2U1B/2T Features ․P-LCC-2 package. ․White package with black top surface. ․Optical indicator. ․Colorless clear window. ․Wide viewing angle. ․Suitable for vapor-phase reflow, Infrared reflow and wave solder processes. ․Computable with automatic placement equipment. ․Available on tape and reel (8mm Tape). ․Pb-free. ․The product itself will remain within RoHS compliant version. Descriptions ․The 67-01 series is available in soft orange, green,blue and yellow. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes the ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium. Applications ․OA Equipment ․Backlighting of Full Color LCD ․Automotive Equipment ․Replacement of Conventional Light Bulbs and Fluorescent Lamps Device Selection Guide Chip Material AlGalnP Emitted Color Brilliant Yellow Resin Color Water Clear Everlight Electronics Co., Ltd. Device No. :DES-671-B13 http://www.everlight.com prepared date:16-Feb-2007 Rev. 1 Page: 1 of 10 Prepared by: Josh Chou EVERLIGHT ELECTRONICS CO.,LTD. 67-01/YSC-HT2U1B/2T Package Outline Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No. :DES-671-B13 http://www.everlight.com prepared date:16-Feb-2007 Rev. 1 Page: 2 of 10 Prepared by: Josh Chou EVERLIGHT ELECTRONICS CO.,LTD. 67-01/YSC-HT2U1B/2T Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current Peak Forward Current (Duty 1/10 @ 1KHZ) Power Dissipation Electrostatic Discharge(HBM) Operating Temperature Storage Temperature Soldering Temperature Symbol VR IF IFP Pd ESD Topr Tstg Tsol Rating 5 50 100 120 2000 -40 ~ +100 -40~ +110 Unit V mA mA mW V ℃ ℃ Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec. Min. 360 --------588 ----1.75 ----Typ. ----120 591 ----20 --------Max. 565 --------594 ----2.35 10 Unit mcd deg nm nm nm V μA Condition IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA VR=5V Electro-Optical Characteristics (Ta=25℃) Parameter Luminous Intensity Viewing Angle Peak Wavelength Dominant Wavelength Spectrum Radiation Bandwidth Forward Voltage Reverse Current Symbol Iv 2θ1/2 λp λd △λ VF IR Notes: 1.Tolerance of Luminous Intensity ±11% 2.Tolerance of Dominant Wavelength ±1nm 3.Tolerance of Forward Voltage ±0.1V Everlight Electronics Co., Ltd. Device No. :DES-671-B13 http://www.everlight.com prepared date:16-Feb-2007 Rev. 1 Page: 3 of 10 Prepared by: Josh Chou EVERLIGHT ELECTRONICS CO.,LTD. 67-01/YSC-HT2U1B/2T Bin Range Of Dominant Wavelength Group Bin Code DD2 H DD3 DD4 Bin Rang Of Luminous Intensity Bin Min T2 U1 360 450 Min 1.75 1.95 2.15 Min. 588 590 592 Max. 590 592 594 Max 450 565 Max 1.95 2.15 2.35 V IF=20mA Unit Condition IF=20mA nm IF=20mA Unit Condition mcd Unit Bin Rang Of Forward Voltage Group Bin 0 B 1 2 Condition Notes: 1.Tolerance of Luminous Intensity ±11% 2.Tolerance of Dominant Wavelength ±1nm 3.Tolerance of Forward Voltage ±0.1V Everlight Electronics Co., Ltd. Device No. :DES-671-B13 http://www.everlight.com prepared date:16-Feb-2007 Rev. 1 Page: 4 of 10 Prepared by: Josh Chou EVERLIGHT ELECTRONICS CO.,LTD. 67-01/YSC-HT2U1B/2T Typical Electro-Optical Characteristics Curves Everlight Electronics Co., Ltd. Device No. :DES-671-B13 http://www.everlight.com prepared date:16-Feb-2007 Rev. 1 Page: 5 of 10 Prepared by: Josh Chou EVERLIGHT ELECTRONICS CO.,LTD. 67-01/YSC-HT2U1B/2T Label explanation CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank Reel Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No. :DES-671-B13 http://www.everlight.com prepared date:16-Feb-2007 Rev. 1 Page: 6 of 10 Prepared by: Josh Chou EVERLIGHT ELECTRONICS CO.,LTD. 67-01/YSC-HT2U1B/2T Carrier Tape Dimensions: Loaded quantity 2000 PCS per reel. 0.23 3.84 2.24 Note: The tolerances unless mentioned is ±0.1mm Unit = mm Moisture Resistant Packaging Label Aluminum moisture-proof bag Desiccant Label Everlight Electronics Co., Ltd. Device No. :DES-671-B13 http://www.everlight.com prepared date:16-Feb-2007 Rev. 1 Page: 7 of 10 Prepared by: Josh Chou EVERLIGHT ELECTRONICS CO.,LTD. 67-01/YSC-HT2U1B/2T Reliability Test Items And Conditions The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% No. 1 2 Items Reflow Soldering Temperature Cycle Test Condition Temp. : 260℃±5℃ 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA / 25℃ 85℃/85%RH Test Sample Ac/Re Hours/Cycles Size 6 min 300 Cycles 22 PCS. 22 PCS. 0/1 0/1 3 4 5 6 7 Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity 300 Cycles 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs. 22 PCS. 22 PCS. 22 PCS. 22 PCS. 22 PCS. 0/1 0/1 0/1 0/1 0/1 Everlight Electronics Co., Ltd. Device No. :DES-671-B13 http://www.everlight.com prepared date:16-Feb-2007 Rev. 1 Page: 8 of 10 Prepared by: Josh Chou EVERLIGHT ELECTRONICS CO.,LTD. 67-01/YSC-HT2U1B/2T Precautions For Use 1. Over-current-proof Customer must apply resistors for protection , otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 1 year under 30℃ or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile 1~5 °C / Sec. 260°C. Max. 10 Sec. Max. 1~5 °C / Sec. Pre-heating 180~200°C 60 Sec. Max. Above 220°C 120 Sec. Max. 3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. 4.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. Everlight Electronics Co., Ltd. Device No. :DES-671-B13 http://www.everlight.com prepared date:16-Feb-2007 Rev. 1 Page: 9 of 10 Prepared by: Josh Chou EVERLIGHT ELECTRONICS CO.,LTD. 67-01/YSC-HT2U1B/2T 5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No. :DES-671-B13 http://www.everlight.com prepared date:16-Feb-2007 Rev. 1 Page: 10 of 10 Prepared by: Josh Chou
