UDLT
Input/Output Transformer
6102-1
6102-1 is designed to interface with the Motorola MC145422/26 UDLT (Universal Digital-Loop Transceivers). The MC145422/26 UDLT’s are high-speed data transceivers that provide 80-kbps full-duplex data communications over 26 awg and larger twisted pair cable up to two kilometers in distance.
6102-1 is approved for the MC145422/26 UDLT chip set.
MECHANICAL AND SCHEMATIC (All dimensions in inches)
L
8
H
1 2
LINE
TRANSMIT
7 6
3 4
DOT AT PIN #1
B
RECEIVE
5
Dimensions, Inches (mm)
A W
P/N 6102-1
DIMENSIONS L W H 0.87 0.83 0.63 (22.0) (21.0) (16.0)
A 0.60 (15.3)
B 0.20 (5.1)
C 0.17 (4.3)
S 0.025 (0.64)
ELECTRICAL SPECIFICATION
Line Impedance Turns Ratio
6102-1
12/03/03
Inductance Leakage Inductance DCR
(8 - 7) : (1 (8 - 7) : (6 (7 (7 (1 (8 (6
-
4) 5) 8) 8) 4) 7) 5)
ISSUE: B
Interwind Cap. Dielectric Strength
(1 - 4) to (8 - 5) & (6 - 5)
110 2:1 2:4 > 1.75 < 75 1.2 2.5 4.2 < 50 1500
Ω
mH µH Ω Ω Ω pF V rms
@ 50 mA DC short to 2, 3 to 4 & 5 - 6 nom. nom. nom.
229 Colonnade Road, Ottawa, Ontario, Canada K2E 7K3 Tel: (613) 226-1626 Fax: (613) 226-7124 www.filtran.com
A n ISO 9001 Registered Company
