Frontier Electronics Corp. 667 E. COCHRAN STREET, SIMI VALLEY, CA 93065 TEL: (805) 522-9998 FAX: (805) 522-9989 E-mail: frontiersales@frontierusa.com Web: frontierusa.com RF Coated Chokes (Axial Leads)—1201 series A. Electrical Specifications: Part Number 1201-01M 1201-02M 1201-03M 1201-04M 1201-05K 1201-06K 1201-07K 1201-08K 1201-09K 1201-10K 1201-11K 1201-12K 1201-13K 1201-14K 1201-15K 1201-16K 1201-17K 1201-18K 1201-19K 1201-20K 1201-21K 1201-22K 1201-23K 1201-24K 1201-25K 1201-26K 1201-28K 1201-29K 1201-31J 1201-32J 1201-33J 1201-34J 1201-35J 1201-36J 1201-37J 1201-38J 1201-39J 1201-40J 1201-41J 1201-42J 1201-43J 1201-44J 1201-45J 1201-46J 1201-47J 1201-48J 1201-49J 1201-50J 1201-51J 1201-52J 1201-53J 1201-54J 1201-55J 1201-56J 1201-57J 1201-58J 1201-59J 1201-60J 1201-61J 1201-62J 1201-63J 1201-64J 1201-65J 1201-66J Inductance (uH) 0.15 0.22 0.33 0.47 0.56 0.68 0.82 1.00 1.20 1.50 1.80 2.20 2.70 3.30 3.90 4.70 5.60 6.80 8.20 10 12 15 18 22 24 27 30 33 36 39 43 47 51 56 62 68 75 82 91 100 110 120 130 150 160 180 200 220 240 270 300 330 360 390 430 470 510 560 620 680 750 820 910 1000 Q Min. 50 50 45 45 50 50 50 50 33 33 33 33 33 33 33 33 45 50 50 55 65 65 75 75 60 60 65 65 60 60 60 55 55 55 55 55 55 50 50 50 60 65 65 65 65 65 65 65 65 65 65 65 65 65 65 65 65 65 65 65 65 65 65 65 Test Freq. (MHz) 25.0 25.0 25.0 25.0 25.0 25.0 25.0 25.0 7.90 7.90 7.90 7.90 7.90 7.90 7.90 7.90 7.90 7.90 7.90 7.90 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 0.79 SRF Min. (MHz) 525 450 360 310 280 250 220 200 180 160 150 135 120 110 100 80 60 55 50 45 42 40 34 30 26 25 21 19 15.50 14.50 13.70 13.00 12.70 12.00 11.50 11.00 10.50 10.30 10.00 9.50 8.90 8.70 8.50 8.00 7.50 8.00 6.50 6.20 5.90 5.70 5.40 5.10 4.80 4.50 4.20 3.90 3.70 3.80 3.30 3.10 2.90 2.70 2.50 2.30 DCR (OHM) Max. 0.030 0.055 0.090 0.120 0.135 0.150 0.220 0.290 0.420 0.500 0.650 0.950 1.200 2.00 2.30 0.30 0.32 0.50 0.60 0.90 1.10 1.40 2.25 2.50 2.50 2.60 2.80 3.00 2.50 2.60 2.70 2.75 2.85 3.00 3.15 3.30 3.70 3.90 4.30 4.50 4.90 5.20 5.45 6.05 6.40 6.05 7.10 7.45 7.80 11.00 11.50 12.00 12.50 16.30 17.10 17.90 18.80 19.50 25.90 27.20 28.60 30.00 31.50 33.00 Rated Current (mA) Max. 2740 2020 1580 1370 1290 1220 1020 880 730 670 590 485 430 335 310 480 565 450 410 335 305 271 213 202 202 198 191 185 202 198 194 193 189 184 180 176 166 162 154 151 144 140 137 130 126 130 123 117 115 143 140 136 134 117 115 112 109 107 93 91 88 86 84 82 Note: RoHS compliant; for the ROHS parts, we add “-LFR” at the end of the P/N. Axial Leads Coated Choke P/N 1201 Series Rev. A June 01, 2006 Page 1 of 2 Specifications Frontier Electronics Corp. 667 E. COCHRAN STREET, SIMI VALLEY, CA 93065 TEL: (805) 522-9998 FAX: (805) 522-9989 E-mail: frontiersales@frontierusa.com Web: frontierusa.com RF Coated Chokes (Axial Leads)—1201 series B. Mechanical Dimensions: Mechanical drawing C. General Information: 1. 2. 3. 4. 5. 6. Coil Form Material: Phenolic or Ferrite. Body Size: 10.4 x 4.45 mm. Inductance (Current) ranges: 0.15uH (2.74A) - 1000uH (82mA) Inductance Tolerance: M: ± 20%, K: ± 10%, J:± 5%. DCR: from 0.03 to 33.0 Ohms. Other information: Spec. / Series Operating Temperature: Temp. Rise: Ambient Temperature: Terminal Strength: Marking: Moisture & Heat Resist.: Dielectric Strength: Test Equipment: 1201 to 1211 Series - 20°C to + 80°C 20°C 90°C Max. 3 lb. Color Code in accordance with EIA ∆ L/L < +5% ∆ Q/Q < +10% 1KV rms. L & Q = HP4342A at specified frequency DCR = Milli-Ohm meter, SRF = HP4191A 7. Color Code for RF Coated Chokes: Black Color 0 Digit 1 Multiplier -Tolerance Brown 1 10 -Red 2 100 -Orange Yellow Green 3 4 5 1000 10,000 -3% --Blue Violet Gray White Gold Silver None 6 7 8 9 -------0.1 0.01 -----5% 10% 20% Example foe color code on Molded Inductor: Inductance (µH) 0.68 + 10% 6.8 + 10% 68 + 10% 1st Band Blue Blue Blue 2nd Band 3rd Band Gray Gray Gray Silver Gold Black 4th Band Silver Silver Silver Color Code Note: RoHS compliant; for the RoHS parts, we add “-LFR” at the end of the P/N. Axial Leads Coated Choke P/N 1201 Series Rev. A June 01, 2006 Page 2 of 2
