IC-MH8_11

iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 1/25 APPLICATIONS o Digital angular sensor technology, 0–360° o Incremental angular encoder o Absolute angular encoder o Brushless motors o Motor feedback o Rotational speed control FEATURES o o o o o o o o o o o o o o o Real-time system for rotation speed up to 120,000 rpm Integrated Hall sensors with automatic offset compensation 4x sensor arrangement for fault-tolerant adjustment Amplitude control for optimum operating point Interpolator with 4096 angular increments/resolution better than 0.1° Programmable resolution, hysteresis, edge spacing, zero position and rotating direction Incremental output of sensor position up to 8 MHz edge rate RS422-compatible AB encoder signals with index Z UVW commutation signals for eight pole EC motor applications Serial interface for data output and configuration SSI-compatible output mode Integrated ZAP diodes for module setup and OEM data, programmable via serial interface Signal error (e.g. magnet loss) can also be read out via serial interface Analogue sine and cosine differential signals Extended temperature range from -40 to +125 °C PACKAGES QFN28 5 x 5 mm² BLOCK DIAGRAM Sine / cosine outputs + 5V VPA PCOUT NCOUT PSOUT NSOUT + 5V VPD A B Binary interpolation factors 1, 2, 4, ... 256, 512, 1024 A B Z B S N Test PTE B B B CONVERSION LOGIC Z TEST HALL SENSOR SINE-TO-DIG RS422 U V 0° Two, four and eight pole commutating signals U 120° SIN + COS 2 2 Loss of magnet, frequency error NERR AMPLITUDE CORRECTION PHASE SHIFT V 240° W INCR INTERFACE W ERROR MONITOR AMPL CONTROL SINE-TO-COM Analog output signals MA SLO 0x00 0x0F 0x10 0x1F 0x77 0x7F ZAP CONTROL iC-MH8 16 Byte ZROM PSOUT NSOUT 0.5 Vpp Data, Programming SLI SERIAL INTERFACE VZAP Programming Voltage 0° NCOUT PCOUT RAM VNA1 BIAS/VREF VND ZAPROM VNA2 C061010-2 180° Angular position a 360° Copyright © 2011 iC-Haus http://www.ichaus.com iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 2/25 DESCRIPTION The iC-MH8 12-bit angular encoder is a position sensor with integrated Hall sensors for scanning a permanent magnet. The signal conditioning unit generates constant-amplitude sine and cosine voltages that can be used for angle calculation. The resolution can be programmed up to a maximum of 4,096 angular increments per rotation. The integrated serial interface also enables the position data to be read out to several networked sensors. And the integrated memory can be written embedded in the data protocol. The incremental interface with the pins A, B and Z supplies quadrature signals with an edge rate of up to 8 MHz. Interpolation can be carried out with maximum resolution at a speed of 120,000 rpm. The position of the index pulse Z is adjustable. The commutation interface with the signals U, V and W provides 120° phase-shifted signals for block commutation of eight pole EC motors. The zero point of the commutation signals is freely definable in increments of 5.625° over 360°. Sine and cosine signals are externally availabe to facilitate adjustement. The RS422-compatible outputs of the incremental interface and the commutation interface are programmable in the output current and the slew rate. In conjunction with a rotating permanent magnet, the iC-MH8 module forms a one-chip encoder. The entire configuration can be stored in the internal parameter ROM with zapping diodes. The integrated programming algorithm assumes writing of the ROM structure. PACKAGES QFN28 5 x5 mm² to JEDEC MO-220-VHHD-1 PIN CONFIGURATION QFN28 5 x 5mm² PSOUT NSOUT nc 28 nc 27 26 25 nc 24 nc 23 W 22 21 20 19 PTE NERR VPA VNA1 SLI MA SLO 1 2 3 4 5 6 7 8 nc 9 nc 10 11 12 13 14 V U VPD VND Z B A MH8 18 17 16 15 C061010-1 nc PCOUT VZAP VNA2 NCOUT PIN FUNCTIONS No. Name Function 1 PTE Test Enable Pin 2 NERR Error output(active low) PIN FUNCTIONS No. Name Function 3 VPA +5 V Supply Voltage (analog) 4 VNA1 Ground (analog) 5 SLI Serial Interface, Data Input 6 MA Serial Interface, Clock Input 7 SLO Serial Interface, Data Output 8,9 nc not connected 10 PCOUT Positive Cosine Output 11 NCOUT Negative Cosine Output 12 VZAP Zener Zapping Programming Voltage 13 VNA2 Ground (analog) 14 nc not connected 15 A Incremental A (+NU) 16 B Incremental B (+NV) 17 Z Index Z (+NW) 18 VND Ground (digital) 19 VPD +5 V Supply Voltage (digital) 20 U Commutation U (+NA) 21 V Commutation V (+NB) 22 W Commutation W (+NZ) 23,24 nc not connected 25 NSOUT Negative Sine Output 26 PSOUT Positive Sine Output 27,28 nc not connected TP Thermal-Pad The Thermal Pad is to be connected to common ground (VNA1, VNA2, VND) on the PCB. Orientation of the logo ( MH8 CODE ...) is subject to alteration. iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 3/25 PACKAGE DIMENSIONS RECOMMENDED PCB-FOOTPRINT 4.70 3.15 15 R0. SIDE 0.90 3.15 4.70 0.50 0.30 TOP 5 BOTTOM 3.15 0.50 0.25 All dimensions given in mm. 0.55 drb_qfn28-2_pack_1, 10:1 3.15 5 0.90 iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 4/25 ABSOLUTE MAXIMUM RATINGS Beyond these values damage may occur; device operation is not guaranteed. Item No. Symbol Parameter Supply voltages at VPA, VPD Zapping voltage Voltages at A, B, Z, U, V, W, MA, SLO, SLI, NERR, PTE Current in VPA Current in VPD Current in A, B, Z, U, V, W Current in MA, SLO, SLI, NERR, PTE ESD-voltage, all pins Storage temperature Chip temperature HBM 100 pF discharged over 1.5 kΩ -40 -40 Conditions Min. -0.3 -0.3 -0.3 -10 -20 -100 -10 Max. 6 8 6 20 200 100 10 2 150 135 V V V mA mA mA mA kV °C °C Unit G001 V() G002 V(VZAP) G003 V() G004 I() G005 I() G006 I() G007 I() G008 Vd() G009 Ts G010 Tj THERMAL DATA Operating conditions: VPA, VPD = 5 V ±10 % Item No. T01 T02 Symbol Ta Rthja Parameter Operating Ambient Temperature Range Thermal Resistance Chip to Ambient surface mounted to PCB, thermal pad linked to cooling area of approx. 2 cm² Conditions Min. -40 40 Typ. Max. 125 °C K/W Unit All voltages are referenced to ground unless otherwise stated. All currents flowing into the device pins are positive; all currents flowing out of the device pins are negative. iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 5/25 ELECTRICAL CHARACTERISTICS Operating conditions: VPA, VPD = 5 V ±10 %, VNA=VND, Tj = -40...125 °C, IBM adjusted to 200 µA , 4 mm NdFeB magnet, unless otherwise noted Item No. 001 002 003 004 005 006 Symbol Parameter Conditions Min. V(VPA), V(VPD) I(VPA) I(VPD) I(VPD) Vc()hi Vc()lo Permissible Supply Voltage Supply Current in VPA Supply Current in VPD Supply Current in VPD Clamp Voltage hi at MA, SLI, SLO, PTE, NERR Clamp Voltage lo at MA, SLI, SLO, PTE, NERR Operating Magnetic Field Strength Operating Magnetic Field Frequency Rotating Speed of Magnet Diameter of Hall Sensor Array Max. Magnet Axis Displacement vs. Center of Hall Sensor Array Chip Placement Error vs. Package Chip Tilt Error vs. Package with QFN28 with QFN28 -0.2 -3 0.4 -55 55 4 1.09 0.92 2 0.2 0.2 +3 PRM = ’0’, without Load PRM = ’1’, without Load Vc()hi = V() − VPD, I() = 1 mA I() = -1 mA 4.5 3 5 2 0.4 -1.5 Typ. Max. 5.5 12 27 20 1.5 -0.3 V mA mA mA V V Unit General Hall Sensors and Signal Conditioning 101 102 Hext fmag at surface of chip 20 100 2 120 000 kA/m kHz rpm mm mm mm Deg mm mV mV Vpp 103 104 105 106 107 108 109 110 111 112 dsens xdis xpac φpac hpac Vos Vos Vopt Vratio Vratio Sensor-to-Package-Surface Dis- with QFN28 tance Trimming range of output offset voltage Trimming range of output offset voltage VOSS or VOSC = 0x7F VOSS or VOSC = 0x3F Optimal differential output voltage Vopt = Vpp(PSIN) − Vpp(NSIN), ENAC = ’0’, see Fig. 6 Amplitude Ratio Amplitude Ratio Vratio = Vpp(PSIN) / Vpp(PCOS), GCC = 0x3F Vratio = Vpp(PSIN) / Vpp(PCOS), GCC = 0x40 Signal Level Control 201 202 203 204 Vpp ton Vt()lo Vt()hi Differential Peak-to-Peak Output Vpp = Vpk(Px) − Vpk(Nx), ENAC = ’1’, see Fig. Amplitude 6 Controller Settling Time to ±10% of final amplitude 1.0 4.8 MINERR Amplitude Error Thresh- see 201 old MAXERR Amplitude Error Threshold Bandgap Reference Voltage Reference Voltage Bias Current CIBM = 0x0 CIBM = 0xF Bias Current adjusted see 201 3.2 4.8 300 2.8 5.8 Vpp µs Vpp Vpp Bandgap Reference 401 402 403 Vbg Vref Iibm 1.18 45 -370 -220 3.65 3 0.3 1.25 50 1.32 55 -100 -200 4.0 3.5 -180 4.3 3.8 V %VPA µA µA µA V V V 404 405 406 VPDon VPDoff VPDhys Turn-on Threshold VPD, System V(VPD) − V(VND), increasing voltage on Turn-off Threshold VPD, System V(VPD) − V(VND), decreasing voltage reset Hysteresis System on/reset iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 6/25 ELECTRICAL CHARACTERISTICS Operating conditions: VPA, VPD = 5 V ±10 %, VNA=VND, Tj = -40...125 °C, IBM adjusted to 200 µA , 4 mm NdFeB magnet, unless otherwise noted Item No. 407 Symbol Vosr Parameter Reference voltage offset compensation System Clock Sinus/Digital-Converter Clock Sinus/Digital-Converter Resolution Absolute Angular Accuracy Relative Angular Accuracy Vpp() = 4 V, adjusted with reference to an output periode at A, B. CFGRES=0x2, ENF=1, PRM=0, HCLH=1, GAING=0x0, Vpp(SIN/COS) = 4 Vpp. see Fig. 17 CFGMTD = 0x0, CFGRES=0x0 CFGMTD = 0x7, CFGRES=0x0 V(SLO) = V(VPD) − V(), I(SLO) = 4 mA I(SLO) = 4 mA to VND V(SLO) = V(VND), 25°C V(SLO) = V(VPD), 25°C CL = 50 pF CL = 50 pF 0.8 140 V() = 0...VPD − 1 V 6 -60 250 30 -30 60 -6 10 Threshold Voltage High VZAP, PTE Threshold Voltage Low VZAP, PTE Hysteresis Threshold Voltage Nozap VZAP Threshold Voltage Zap VZAP Zapping voltage Diode voltage, zapped Diode voltage, unzapped 3 30 with reference to VND I() = 4 mA , with reference to VND with reference to VND Vt()hys = Vt()hi − Vt()lo V(NERR) = 0...VPD − 1 V V(NERR) = V(VPD), Tj = 25°C CL = 50 pF 0.8 140 -800 250 -300 50 -80 80 60 55 2 0.4 with reference to VND with reference to VND Vt()hys = Vt()hi − Vt()lo V() = V(VZAP) − V(VPA), V(VPA) = 5 V ±5 %, at chip temperature 27 °C V() = V(VZAP) − V(VPA), V(VPA) = 5 V ±5 %, at chip temperature 27 °C PROG = ’1’ 6.9 7.0 0.8 140 0.7 1.2 7.1 2 250 2 -90 -50 50 80 60 60 2 -0.35 ± 10 Bias Current adjusted Bias Current adjusted Conditions Min. 475 Typ. 500 Max. 525 mV Unit Clock Generation 501 502 601 602 603 f()sys f()sdc RESsdc AAabs AArel 0.85 13.5 1.0 16 12 0.35 1.2 18 MHz MHz Bit Deg % Sin/Digital Converter 604 f()ab Output frequency at A, B 2.0 0.25 0.4 0.4 MHz MHz V V mA mA ns ns V V mV µA µA MHz V V mV V V V V V kΩ V V V mV µA mA ns Serial Interface, Digital Outputs MA, SLO, SLI 701 702 703 704 705 706 707 708 709 710 711 712 801 802 803 804 805 806 807 808 809 901 902 903 904 905 906 907 Vs(SLO)hi Saturation Voltage High Vs(SLO)lo Saturation Voltage Low Isc(SLO)hi Short-Circuit Current High Isc(SLO)lo Short-Circuit Current Low tr(SLO) tf(SLO) Vt()hi Vt()lo Vt()hys Ipd() Ipu(MA) f(MA) Vt()hi Vt()lo Vt()hys Vt()nozap Vt()zap V()zap V()zpd V()uzpd Rise Time SLO Fall Time SLO Threshold Voltage High: MA, SLI Threshold Voltage Low: MA, SLI Threshold Hysteresis: MA, SLI Pull-Down Current: MA, SLI Zapping and Test Rpd()VZAP Pull-Down Resistor at VZAP Vt()hi Vs()lo Vt()lo Vt()hys Ipu() Isc()lo tf()hilo Input Threshold Voltage High Saturation Voltage Low Input Threshold Voltage Low Input Hysteresis Pull-up Current Source Short circuit current Lo Decay time NERR Output iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 7/25 ELECTRICAL CHARACTERISTICS Operating conditions: VPA, VPD = 5 V ±10 %, VNA=VND, Tj = -40...125 °C, IBM adjusted to 200 µA , 4 mm NdFeB magnet, unless otherwise noted Item No. Symbol Parameter Conditions Min. Vs() = VPD − V(); CfgDR(1:0) = 00, I() = -4 mA CfgDR(1:0) = 01, I() = -50 mA CfgDR(1:0) = 10, I() = -50 mA CfgDR(1:0) = 11, I() = -20 mA CfgDR(1:0) = 00, I() = -4 mA CfgDR(1:0) = 01, I() = -50 mA CfgDR(1:0) = 10, I() = -50 mA CfgDR(1:0) = 11, I() = -20 mA V() = 0 V; CfgDR(1:0) = 00 CfgDR(1:0) = 01 CfgDR(1:0) = 10 CfgDR(1:0) = 11 V() = VPD; CfgDR(1:0) = 00 CfgDR(1:0) = 01 CfgDR(1:0) = 10 CfgDR(1:0) = 11 TRIHL(1:0) = 11 RL = 100 Ω to VND; CfgDR(1:0) = 00 CfgDR(1:0) = 01 CfgDR(1:0) = 10 CfgDR(1:0) = 11 RL = 100 Ω to VND; CfgDR(1:0) = 00 CfgDR(1:0) = 01 CfgDR(1:0) = 10 CfgDR(1:0) = 11 Rl = 50 Ω vs. VPD / 2, see Fig. Cl = 250 pF pin shorten to VPD or VND -12 -125 -125 -60 4 50 50 20 -100 5 5 50 5 5 5 50 5 200 ±200 10 10 50 Typ. Max. Unit Digital Line Driver Outputs P01 Vs()hi Saturation Voltage hi 200 700 700 400 200 700 700 400 -4 -50 -50 -20 12 125 125 60 100 20 20 350 40 20 20 350 40 300 mV mV mV mV mV mV mV mV mA mA mA mA mA mA mA mA µA ns ns ns ns ns ns ns ns mV µV kHz mA P02 Vs()lo Saturation Voltage lo P03 Isc()hi Short-Circuit Current hi P04 Isc()lo Short-Circuit Current lo P05 P06 Ilk()tri tr() Leakage Current Tristate Rise-Time lo to hi at Q P07 tf() Fall-Time hi to lo at Q Analog Outputs PSOUT, NSOUT, PCOUT, NCOUT Q01 Vpk() Q02 Vos() Q03 fc() Q04 Isc()hi,lo Max. Output Signal Amplitude Output Offset Voltage Output Cut-off Frequency Output Short-circuit Current iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 8/25 OPERATING REQUIREMENTS: Serial Interface Operating conditions: VPA, VPD = 5 V ±10 %, Ta = -40...125 °C, IBM calibrated to 200 µA; Logic levels referenced to VND: lo = 0...0.45 V, hi = 2.4 V...VPD Item No. Symbol Parameter Conditions Min. Permissible Clock Period Clock Signal Hi Level Duration Clock Signal Lo Level Duration tout determined by CFGTOS 250 25 25 Max. 2x tout tout tout ns ns ns Unit SSI Protocol (ENSSI = 1) I001 TMAS I002 tMASh I003 tMASl Figure 1: I/O Interface timing with SSI protocol iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 9/25 Registers OVERVIEW Adr 0x00 0x01 0x02 0x03 0x04 z z z z z 1 PRM HCLH DPU DAO CFGTOB Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Hall Signal Conditioning GAING(1:0) ENAC GAINF(5:0) GCC(6:0) VOSS(6:0) VOSC(6:0) CIBM(3:0) RS422 Driver 0x05 z ENSSI CFGPROT CFGO(1:0) TRIHL(1:0) CFGDR(1:0) Sine/Digital Converter 0x06 0x07 0x08 0x09 0x0A 0x0B 0x0D z z z z z z CFGHYS(1:0) CFGDIR ENF CFGMTD(2:0) CFGZPOS(7:0) CFGSU CfgCOM(7:0) CFGPOLE(1:0) CFGAB(1:0) CFGRES(3:0) 0x0C z Test settings 0x0E p 0x0F ENHC res. res. res. TEST(7:0) res. res. res. PROGZAP ZAP diodes (read only) 0x10 .. 0x1F ZAP diodes for addresses 0x00..0x0C and 0x7D..0x7F not used 0x20 .. 0x41 ’invalid adresses’ Profile identification (read only) 0x42 0x43 Profile - 0x0 Profile - 0x2C Data length DLEN not used 0x44 .. 0x75 ’invalid adress’ Status messages (read only; messages will be set back during reading) 0x76 0x77 PROGERR ERRSDATA ERRAMIN ERRAMAX GAIN ERREXT res. res. PROGOK iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 10/25 OVERVIEW Adr 0x78 0x79 0x7A 0x7B 0x7C 0x7D z 0x7E 0x7F z z Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Identification (0x78 bis 0x7B read-only) Device ID - 0x4D (’M’) Device ID - 0x48 (’H’) Revision - 0x38 (’8’) Revision - 0x00 (”) Manufacturer Revision - 0x00 Manufacturer ID - 0x00 Manufacturer ID - 0x00 z: Register value programmable by zapping p: Register value write protected; can only be changed while V(VZAP)> Vt()hi CFGTOS Table 5: Register layout Hall signal processing . . . . . . . . . . . . . . . . . . . . Page 12 GAING: GAINF: GCC: ENAC: VOSS: VOSC: PRM: CIBM: DPU HCLH ENF DAO: Hall signal amplification range Hall signal amplification (1–20, log. scale) Amplification calibration cosine Activation of amplitude control Offset calibration sine Offset calibration cosine Energy-saving mode Calibration of bias current Deactivation of NERR pull-up Activation of high Hall clock pulse Activation of noise filter Disable Analog Outputs Sine/digital converter . . . . . . . . . . . . . . . . . . . . . Page 18 CFGRES: CFGZPOS: CFGAB: CFGPOLE: CFGSU: CFGMTD: CFGDIR: CFGHYS: CFGCOM: Test TEST: ENHC: PROGZAP: Resolution of sine digital converter Zero point for position Configuration of incremental output No. of poles for commutation signals Behavior during start-up Frequency at AB Rotating direction reversal Hysteresis sine/digital converter Zero point for commutation RS422 driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21 CFGDR: TRIHL: CFGO: CFGPROT: ENSSI: Driver property Tristate high-side/low-side driver Configuration of output mode Write/read protection memory Activation of SSI mode Test mode Enable High Current during ZAPDiode Read (iC-MH82 and later) Activation of programming routine iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 11/25 Sensor principle In conjunction with a rotating permanent magnet, the iC-MH8 module can be used to create a complete encoder system. A diametrically magnetized, cylindrical permanent magnet made of neodymium iron boron (NdFeB) or samarium cobalt (SmCo) generates optimum sensor signals. The diameter of the magnet should be in the range of 3 to 6 mm. The iC-MH8 has four Hall sensors adapted for angle determination and to convert the magnetic field into a measurable Hall voltage. Only the z-component of the magnetic field is evaluated, whereby the field lines pass through two opposing Hall sensors in the opposite direction. Figure 2 shows an example of field vectors. The arrangement of the Hall sensors is selected so that the mounting of the magnets relative to iC-MH8 is extremely tolerant. Two Hall sensors combined provide a differential Hall signal. When the magnet is rotated around the longitudinal axis, sine and cosine output voltages are produced which can be used to determine angles. S N z y x B +Bz -Bz C151107-1 Figure 2: Sensor principle Position of the Hall sensors and the analog sensor signal The Hall sensors are placed in the center of the QFN28 package at 90° to one another and arranged in a circle with a diameter of 2 mm as shown in Figure 3. In order to calculate the angle position of a diametrically polarized magnet placed above the device a difference in signal is formed between opposite pairs of Hall sensors, resulting in the sine being VSIN = VPSIN VNSIN and the cosine VCOS = VPCOS - VNCOS . The zero angle position of the magnet is marked by the resulting cosine voltage value being at a maximum and the sine voltage value at zero. Pin 1 Mark 28 27 26 25 24 23 22 21 1 2 3 4 5 6 7 PSIN PCOS 20 19 18 17 NCOS NSIN 11 12 13 14 16 15 (top view) 8 9 10 This is the case when the south pole of the magnet is exactly above the PCOS sensor and the north pole is above sensor NCOS, as shown in Figure 4. Sensors PSIN and NSIN are placed along the pole boundary so that neither generate a Hall signal. C040907-2 Figure 3: Position of the Hall sensors When a magnetic south pole comes close to the surface of the package the resulting magnetic field has a positive component in the +z direction (i.e. from the top of the package) and the individual Hall sensors each generate their own positive signal voltage. When the magnet is rotated counterclockwise the poles then also cover the PSIN and NSIN sensors, resulting in the sine and cosine signals shown in Figure 5 being produced. iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 12/25 28 27 26 25 24 23 22 21 20 19 18 17 16 15 10 11 12 13 14 28 27 26 25 24 23 22 21 20 19 18 17 16 28 27 26 25 24 23 22 21 20 19 18 17 16 15 1 2 3 4 1 2 3 4 5 6 7 8 9 10 S (top view) S 1 2 3 4 5 6 7 5 6 7 N 11 12 13 14 15 8 9 α>0 0 N S N 8 9 10 11 12 13 14 α=0 +2V VSIN= VPSIN- VNSIN VCOS= VPCOS- VNCOS -90° -2V 90° 180° 270° 360° α C041007-3 C040907-1 Figure 4: Zero position of the magnet Figure 5: Pattern of the analog sensor signals with the angle of rotation Hall Signal Processing The iC-MH8 module has a signal calibration function that can compensate for the signal and adjustment errors. The Hall signals are amplified in two steps. First, the range of the field strength within which the Hall sensor is operated must be roughly selected. The first amplifier stage can be programmed in the following ranges: GAING(1:0) 00 01 10 11 5-fold 10-fold 15-fold 20-fold Addr. 0x00; bit 7:6 The second amplifier stage can be varied in an additional range. With the amplitude control (ENAC = ’0’) deactivated, the amplification in the GAINF register is used. With the amplitude control (ENAC = ’1’) activated, the GAINF register bits have no effect. GCC(6:0) 0x00 0x01 ... 0x3F 0x40 ... 0x7F Addr. 0x01; bit 6:0 1,000 1,0015 exp( ln(20) · GCC ) 2048 1,0965 0,9106 exp(− ln(20) · (128 − GCC )) 2048 0,9985 Table 6: Range selection for Hall signal amplification Table 8: Amplification calibration cosine The operating range can be specified in advance in accordance with the temperature coefficient and the magnet distance. The integrated amplitude control can correct the signal amplitude between 1 and 20 via another amplification factor. Should the control reach the range limits, a different signal amplification must be selected via GAING. GAINF(5:0) Addr. 0x00; bit 5:0 0x00 ... 1,000 0x02 0x03 1,048 (20) ... exp( ln64 · GAINF − 2) 0x3F 17,38 The GCC register is used to correct the sensitivity of the sine channel in relation to the cosine channel. The cosine amplitude can be corrected within a range of approximately ±10%. ENAC 0 1 Addr. 0x01; bit 7 amplitude control deactivated amplitude control active Table 9: Activation of amplitude control Table 7: Hall signal amplification The integrated amplitude control can be activated with the ENAC bit. In this case the differential signal amplitude is adjusted to 4 Vss and the values of GAINF have no effect here. iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 13/25 PRM 0 1 Addr. 0x03; bit 7 Energy-saving mode deactivated Energy-saving mode active PSIN−NSIN 4Vss PCOS−NCOS Table 11: Energy-saving mode Figure 6: Definition of differential amplitude After switch-on the amplification is increased until the setpoint amplitude is reached. The amplification is automatically corrected in case of a change in the input amplitude by increasing the distance between the magnet and the sensor, in case of a change in the supply voltage or a temperature change. The sine signals are therefore always converted into highresolution quadrature signals at the optimum amplitude. VOSS(6:0) VOSC(6:0) 0x00 0x01 ... 0x3F 0x40 0x41 ... 0x7F Addr. 0x02; bit 6:0 Addr. 0x03; bit 6:0 0 mV 1 mV ... 63 mV 0 mV -1 mV ... -63 mV In the energy-saving mode the current consumption of the Hall sensors can be quartered. This also reduces the maximum rotating frequency by a factor of 4. CIBM(3:0) 0x0 ... 0x8 0x9 ... 0xF Addr. 0x04; bit 3:0 -40 % ... 0% +5 % ... +35 % Table 12: Calibration of bias current The bias current is factory calibrated to 200 µA. The calibration can be verified in test mode (TEST = 0x43) by measuring the current from Pin B to Pin VNA. HCLH 0 1 Addr. 0x04; bit 7 250 kHz 500 kHz Table 10: Offset calibration for sine and cosine Should there be an offset in the sine or cosine signal that, among other things, can also be caused by an inexactly adjusted magnet, then this offset can be corrected by the VOSS and VOSC registers. The output voltage can be shifted by ±63 mV in each case to compensate for the offset. Table 13: Activation of high Hall clock pulse The switching-current hall sensors can be operated at two frequencies. At 500 kHz the sine has twice the number of support points. This setting is of interest at high speeds above 30,000 rpm. iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 14/25 Test modes for signal calibration For signal calibration iC-MH8 has several test settings which make internal reference quantities and the amplified Hall voltages of the individual sensors accessible at external pins A, B, Z and U for measurement purposes. This enables the settings of the offset (VOSS, VOSC), gain (GAING, GAINF) and amplitude ratio of the cosine to the sine signal (GCC) to be directly observed on the oscilloscope. Test mode can be triggered by connecting pin VZAP to VPD and programming the TEST register (address 0x0E). The individual test modes are listed in the following table: Output signals in test mode Mode TEST Pin A Pin B Normal 0x00 A B Analog SIN 0x20 HPSP HPSN Analog COS 0x21 HPCP HPCN Analog OUT 0x22 PSIN NSIN Analog REF 0x43 VREF IBM Digital CLK 0xC0 CLKD iC-MH8 PSIN B B A B Z B B HPSP HPSN HNSP HNSN VPSIN U VNSIN NSIN HALL SENSORS VNA C021107-1acr Test Mode: Analog SIN Figure 7: Output signals of the sine Hall sensors in test mode Analog SIN Pin Z Z HNSP HNCP PCOS VBG Pin U U HNSN HNCN NCOS VOSR NCOS iC-MH8 PCOS B B A B Z HPCP HPCN HNCP HNCN VPCOS B B U HALL SENSORS VNA VNCOS Table 14: Test modes and available output signals C021107-2acr The output voltages are provided as differential signals with an average voltage of 2.5 V. The gain is determined by register values GAING and GAINF and should be set so that output amplitudes from the sine and cosine signals of about 1 V are visible. Test modes Analog SIN and Analog COS In these test modes it is possible to measure the signals from the individual Hall sensors independent of one another. The name of the signal is derived from the sensor name and position. HPSP, for example, is the (amplified) Hall voltage of sensor PSIN at the positive signal path; similarly, HNCN is the Hall voltage of sensor NCOS at the negative signal path. The effective Hall voltage is accrued from the differential voltage between the positive and negative signal paths of the respective sensor. Test mode Analog OUT In this test mode the sensor signals are available at the outputs as they would be when present internally for further processing on the interpolator. The interpolation accuracy which can be obtained is determined by the quality of signals Vsin and Vcos and can be influenced in this particular test mode by the calibration of the offset, gain and amplitude ratio. Test Mode: Analog COS Figure 8: Output signals of the cosine Hall sensors in test mode Analog COS iC-MH8 PSIN B PCOS B A B Z PSIN NSIN PCOS NCOS VSIN B B U VCOS NCOS NSIN HALL SENSORS VNA C021107-3acr Test Mode: Analog OUT Figure 9: Differential sine and cosine signals in test mode Analog OUT Test mode Analog REF In this mode various internal reference voltages are provided. VREF is equivalent to half the supply voltage (typically 2.5 V) and is used as a reference voltage for iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 15/25 Test Mode: Analog REF VREF IBM VBG VOSR ~ 1.24 V ~ 2.5 V the Hall sensor signals. VBG is the internal bandgap reference (1.24 V), with VOSR (0.5 V) used to generate the range of the offset settings. Bias current IBM determines the internal current setting of the analog circuitry. In order to compensate for variations in this current and thus discrepancies in the characteristics of the individual iC-MH8 devices (due to fluctuations in production, for example), this can be set within a range of -40% to +35% using register parameter CIBM. The nominal value of 200 µA is measured as a short-circuit current at pin B to ground. Test mode Digital CLK If, due to external circuitry, it is not possible to measure IBM directly, by way of an alternative clock signal CLKD at pin A can be calibrated to a nominal 1 MHz in this test mode via register value CIBM. iC-MH8 A B Z U ~ 0.5 V ~ 200 µA C021107-4acr VNA Figure 10: Setting bias current IBM in test mode Analog REF Calibration procedure The calibration procedure described in the following applies to the optional setting of the internal analog sine and cosine signals and the mechanical adjustment of the magnet and iC-MH8 in relation to one another. BIAS SETTING The BIAS setting compensates for possible manufacturing tolerances in the iC-MH8 devices. A magnetic field does not need to be present for this setting which can thus be made either prior to or during the assembly of magnet and iC-MH8. If the optional setup process is not used, register CIBM should be set to an average value of 0x8 (which is equivalent to a change of 0%). As described in the previous section, by altering the value in register CIBM in test mode Analog REF current IBM is set to 200 µA or, alternatively, in test mode Digital CLK signal CLKD is set to 1 MHz. MECHANICAL ADJUSTMENT iC-MH8 can be adjusted in relation to the magnet in test modes Analog SIN and Analog COS, in which the Hall signals of the individual Hall sensors can be observed while the magnet rotates. In test mode Analog SIN the output signals of the sine Hall sensors which are diagonally opposite one another are visible at pins A, B, Z and U. iC-MH8 and the magnet are then adjusted in such a way that differential signals VPSIN and VNSIN have the same amplitude and a phase shift of 180°. The same applies to test mode Analog COS, where differential signals VPCOS and VNCOS are calibrated in the same manner. Vsin +2 V -2 V α +2 V Vcos -2 V C141107-1 Figure 11: Ideal Lissajous curve CALIBRATION USING ANALOG SIGNALS In test mode Analog OUT as shown in Figure 5 the internal signals which are transmitted to the sine/digital converter can be tapped with high impedance. With a rotating magnet it is then possible to portray the differential signals VSIN and VCOS as an x-y graph (Lissajous curve) with the help of an oscilloscope. In an ideal setup the sine and cosine analog values describe a perfect circle as a Lissajous curve, as illustrated by Figure 11. At room temperature and with the amplitude control switched off (ENAC = 0) a rough GAING setting is selected so that at an average fine gain of GAINF = 0x20 (a gain factor of ca. 4.5) the Hall signal amplitudes are as close to 1 V as possible. The amplitude can then iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 16/25 Vsin VOSS be set more accurately by varying GAINF. Variations in the gain factor, as shown in Figure 12, have no effect on the Lissajous curve, enabling the angle information for the interpolator to be maintained. Vsin GAING GAINF α Vcos α C141107-3 Vcos Figure 13: Effect of the sine offset setting Vsin VOSC C141107-2 Figure 12: Effect of gain settings GAING and GAINF α Deviations of the observed Lissajous curve from the ideal circle can be corrected by varying the amplitude offset (register VOSS, VOSC) and amplitude ratio (register GCC). Changes in these parameters are described in the following figures 13 to 15. Each of these settings has a different effect on the interpolated angle value. A change in the sine offset thus has a maximum effect on the angle value at 0° and 180°, with no alterations whatsoever taking place at angles of 90° and 270°. When varying the cosine offset exactly the opposite can be achieved as these angle pairs can be set independent of one another. Setting the cosine/sine amplitude ratio does not change these angles (0°, 90°, 180° and 270°); however, in-between values of 45°, 135°, 225° and 315° can still be influenced by this parameter. Vcos C141107-4 Figure 14: Effect of the cosine offset setting Vsin GCC α Once calibration has been carried out a signal such as the one illustrated in Figure 11 should be available. Vcos In the final stage of the process the amplitude control can be switched back on (ENAC =1) to enable deviations in the signal amplitude caused by variations in the magnetic field due to changes in distance and temperature to be automatically controlled. C141107-5 Figure 15: Effect of the amplitude ratio iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 17/25 distance of the rising edge (equivalent to angle positions of 0° and 180°) at signal A should be exactly half a period (PER). Should the edges deviate from this in distance, the offset of the sine channel can be adjusted using VOSS. The same applies to the falling edges of the A signal which should also have a distance of half a period; deviations can be calibrated using the offset of cosine parameter VOSC. With parameter GCC the distance between the neighboring flanks of signals A and B can then be adjusted to the exact value of an eighth of a cycle (a 45° angle distance). CALIBRATION USING INCREMENTAL SIGNALS If test mode cannot be used, signals can also be calibrated using the incremental signals or the values read out serially. In order to achieve a clear relationship between the calibration parameters which have an effect on the analog sensor signals and the digital sensor values derived from these, the position of the zero pulse should be set to ZPOS = 0x0 and the rotating direction should be set to CFGDIR=0, so that the digital signal starting point matches that of the analog signals. At an incremental resolution of 8 edges per revolution (CFGRES = 0x1) those angle values can be displayed at which calibration parameters VOSS, VOSC and GCC demonstrate their greatest effect. When rotating the magnet at a constant angular speed the incremental signals shown in Figure 16 are achieved, with which the individual edges ideally succeed one another at a temporal distance of an eighth of a cycle (a 45° angle distance). Alternatively, the angle position of the magnet can also be determined using a reference encoder, rendering an even rotational action unnecessary and allowing calibration to be performed using the available set angle values . The various possible effects of parameters VOSS, VOSC and GCC on the flank position of incremental signals A and B are shown in Figure 16. Ideally, the A B Z VOSS VOSC GCC PER Figure 16: Calibration using incremental signals iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 18/25 Sine/Digital Converter The iC-MH8 module integrates a high-resolution sine/digital converter. In the highest output resolution with an interpolation factor of 1024, 4096 edges per rotation are generated and 4096 angular steps can be differentiated. Even in the highest resolution, the absolute position can be calculated in real time at the maximum speed. This absolute position is used to generate quadrature signals (ABZ) and commutation signals (UVW). The zero point of the quadrature signals and the commutation signals can be set seperately. This enables the commutation at other angles based on the index track Z. The resolution of the incremental output signals is programmed with CFGRES. The value of the 12-bit sine-digital converter is available in full resolution in the ’Extended SSI-Mode’ and in a resolution according to CFGRES in the ’SSIMode’. CFGRES(2:0) 0x0 1024 0x1 512 0x2 256 0x3 128 0x4 64 0x5 0x6 0x7 0x8 0x9 0xA 32 16 8 4 2 1 Addr. 0x06; bit 3:0 100% 40% 50% 60% A B Z Figure 17: ABZ signals and relative accuracy The incremental signals can be inverted again independently of the output drivers. As a result, other phase angles of A and B relative to the index pulse Z can be generated. The standard is A and B high level for the zero point, i.e. Z is equal to high. Figure 17 shows the position of the incremental signals around the zero point. The relative accuracy of the edges to each other at a resolution setting of 10 bit is better than 10%. This means that, based on a period at A or B, the edge occurs in a window between 40% and 60%. CFGHYS(1:0) Addr. 0x08; bit 7:6 0x0 0,17° 0x1 0,35° 0x2 0,7° 0x3 1,4° Table 15: Programming interpolation factor Table 17: Programming angular hysteresis After the resolution is changed, a module reset is triggered internally and the absolute position is recalculated. CFGAB(1:0) Addr. 0x08; bit 1:0 0x0 A and B not inverted 0x1 B inverted, A normal 0x2 A inverted, B normal 0x3 A and B inverted Table 16: Inversion of AB signals With rotating direction reversal, an angular hysteresis prevents multiple switching of the incremental signals at the reversing point. The angular hysteresis corresponds to a slip which exists between the two rotating directions. However, if a switching point is approached from the same direction, then the edge is always generated at the same position on the output. The following figure shows the generated quadrature signals for a resolution of 360 edges per rotation (interpolation factor 90) and a set angular hysteresis of 1.4°. iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 19/25 It should be noted then, however, that the maximum rotation speed is reduced. 10° 0° −10° A B Z 0° 1.4° 0° CFGDIR 0 1 Addr. 0x08; bit 5 Rotating direction CCW Rotating direction CW Figure 18: Quadrature signals for rotating direction reversal (hysteresis 1.4°) At the reversal point at +10°, first the corresponding edge is generated at A. As soon as an angle of 1.4° has been exceeded in the other direction in accordance with the hysteresis, the return edge is generated at A again first. This means that all edges are shifted by the same value in the rotating direction. CFGZPOS(7:0) 0x0 0x1 0x2 ... 0xFF Addr. 0x07; bit 7:0 Table 20: Rotating direction reversal The rotating direction can easily be changed with the bit CFGDIR. When the setting is CCW (counterclockwise, CFGDIR = ’0’) the resulting angular position values will increase when rotation of the magnet is performed as shown in figure 5. To obtain increasing angular position values in the CW (clockwise) direction, CFGDIR then has to be set to ’1’. 0° 1,4° 2,8° 360 ·CFGZPOS 256 358,6° Table 18: Programming AB zero position The position of the index pulse Z can be set in 1.4° steps. An 8-bit register is provided for this purpose, which can shift the Z-pulse once over 360°. CFGMTD(2:0) Addr. 0x06; bit 6:4 0 Minimum edge spacing 125 ns at IPO 1024 (max. 2 MHz at A) 1 2 3 4 5 6 7 Minimum edge spacing 250 ns at IPO 1024 Minimum edge spacing 500 ns at IPO 1024 (max. 500 kHz at A) Minimum edge spacing 1 µs at IPO 1024 Minimum edge spacing 2 µs at IPO 1024 Minimum edge spacing 4 µs at IPO 1024 Minimum edge spacing 8 µs at IPO 1024 Minimum edge spacing 16 µs at IPO 1024 The internal analoge sine and cosine signal which are available in test mode are not affected by the setting of CFGDIR. They will always appear as shown in figure 5. CFGSU 0 1 Addr. 0x08; bit 4 ABZ output "111" during startup AB instantly counting to actual position Table 21: Configuration of output startup Table 19: Minimum edge spacing The CFGMTD register defines the time in which two consecutive position events can be output at the highest resolution. The default is a maximum output frequency of 500 kHz on A. This means that at the highest resolution, speeds of 30,000 rpms can still be correctly shown. In the setting with an edge spacing of 125 ns, the edges can be generated even at the highest revolution and the maximum speed. However, the counter connected to the module must be able to correctly process all edges in this case. The settings with 2 µs, and 8 µs can be used for slower counters. Depending on the application, a counter cannot bear generated pulses while the module is being switched on. When the supply voltage is being connected, first the current position is determined. During this phase, the quadrature outputs are constantly set to "111". In the setting CFGSU = ’1’, edges are generated at the output until the absolute position is reached. This enables a detection of the absolute position with the incremental interface. The converter for the generation of the commutation signals can be configured for two, four and eight-pole motors. Three rectangular signals each with a phase shift of 120° are generated. With two-pole commutation, the sequence repeats once per rotation. With a four-pole setting, the commutation sequence is generated twice per rotation. With a eight-pole setting, the commutation sequence is generated four times per rotation. iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 20/25 CFGPOLE(1:0) Addr. 0x8; bit 3,2 00 2 pole commutation 01 4 pole commutation 18 pole commutation PSIN PCOS CFGPOLE=00 iC−MH8 U V W Table 22: Commutation The zero position of the commutation, i.e. the rising edge of the track U, can be set as desired over a rotation. Here 256 possible positions are available. CFGCOM(7:0) 0x00 0x01 ... Addr. 0x09; bit 7:0 CFGPOLE=01 iC−MH8 U V W CFGPOLE=10 iC−MH8 U V W Figure 19: UVW signals for different settings of CFGPOLE 0° -1,4° - 360 · CFGCOM 256 Table 23: Commutation iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 21/25 Output Drivers Six RS422-compatible output drivers are available, which can be configured for the incremental signals and commutation signals. The following table on the CFGO register bits provides an overview of the possible settings. PSIN PCOS A B iC−MH8 Z U V W CFGO(1:0) 00 01 10 11 Addr. 0x05; bit 5:4 Incrementral Diff ABZ (U=NA, V=NB, W=NZ) Incr ABZ + Comm UVW Commutation Diff UVW (A=NU, B=NV, Z=NW) Incr. ABZ + AB4 (U=A4, V=B4, W=0) Figure 20: ABZ differential incremental signals PSIN Table 24: Configuration of output drivers A B PCOS iC−MH8 Z U V W In the differential incremental mode (CFGO = ’00’, Figure 20), quadrature signals are available on the Pins A, B and Z. The respective inverted quadrature signals are available on the pins U, V and W. As a result, lines can be connected directly to the module. Another configuration of the incremental signals is specified in the section "Sine/Digital Converter". Figure 21: ABZ and UVW single ended signals PSIN PCOS A With CFGO = ’01’ (Figure 21) the ABZ incremental signals and the UVW commutation signals are available on the six pins. As long as the current angular position is not yet available during the start-up phase, all commutation signals are at the low level. B iC−MH8 Z U V W With CFGO = ’10’, the third mode (Figure 22) is available for transferring the commutation signals via a differential line. The non-inverted signals are on the pins U, V and W, the inverted signals on A, B and Z. Figure 22: UVW differential commutation signals PSIN PCOS A B iC−MH8 Z U V W The ABZ quadrature signals with an adjustable higher resolution and quadrature signals with one period per rotation are available in the fourth mode (Figure 23). Four segments can be differentiated with the pins U and V. This information can be used for an external period counter which counts the number of scanned complete rotations. Figure 23: ABZ incremental signals / period counter iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 22/25 able a high transmission rate. A lower slew rate is offered by the setting CFGDR = ’10’, which is excellent for longer lines in an electromagnetically sensitive environment. Use of the setting CFGDR = ’11’ is advisable at medium transmission rates with a limited driver capability. TRIHL 00 01 10 11 Addr. 0x05; bit 3:2 Push Pull Output Stage Highside Driver Lowside Driver Tristate The property of the RS422 driver of the connected line can be adjusted in the CFGDR register. CFGDR(1:0) Addr. 0x05; bit 1:0 00 10 MHz 4 mA (default) 01 10 MHz 60 mA 10 300 kHz 60 mA 11 3 MHz 20 mA Table 25: Driver property Signals with the highest frequency can be transmitted in the setting CFGDR = ’00’. The driver capability is at least 4 mA, however it is not designed for a 100 Ω line. This mode is ideal for connection to a digital input on the same assembly. With the setting CFGDR = ’01’ the same transmission speed is available and the driver power is sufficient for the connection of a line over a short distance. Steep edges on the output en- Table 26: Tristate Register The drivers consist of a push-pull stage in each case with low-side and high-side drivers which can each be activated individually. As a result, open-drain outputs with an external pull-up resistor can also be realized. Serial Interface The serial interface is used to read out the absolute position and to parameterize the module. For a detailed description of the protocol, see separate interface specification. CDM MA SLI SLO Ack Start CDS D11 D10 D0 nE nW CRC5 CRC4 CRC0 Stop Timeout Data Range Figure 24: Serial Interface Protocol The sensor sends a fixed cycle-start sequence containing the Acknowledge-, Start and Control-Bit followed by the binary 12 bit sensor data. The low-active error bit nE a ’0’ indicates an error which can be further identified by reading the status register 0x77. The following bit nW is always at ’1’ state. Following the 6 CRC bits the data of the next sensors, if available, are presented. Otherwise, the master stops generating clock pulse on the MA line an the sensor runs into a timeout, indicating the end of communication. Serial Interface Protocol Cycle start sequence Lenght of sensor data CRC Polynom CRC Mode Multi Cycle Data max. Data Rate Mode C Ack/Start/CDS 12 Bit + ERR + WARN 0b1000011 inverted not available 10 MHz Table 27: Interface Protocol ENSSI 0 1 Addr. 0x05; bit 7 Extended SSI-Mode SSI-Mode Table 28: Activation of SSI mode The extended SSI-Mode is active if V(VZAP) = V()ZAP or Bit ENSSI is 0. The extended SSI-Mode must be iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 23/25 With the profile ID, the data format can be requested for the following sensor data cycles in the module. A read operation at address 0x42 results in 0x2C, with is the equivalent to 12-bit single-cycle data. The status register provides information on the status of the module. There are 5 different errors that can be signaled. Following unsuccessful programming of the zapping diodes, the bit PROGERR is set. If an attempt is made to read the current position via the serial interface during the start-up phase, an error is signaled with ERRSDATA, as the actual position is not yet known. The ERRAMAX bit is output to signal that the amplitude is too high, while the ERRAMIN bit signals an amplitude which is too low, caused, for example, by too great a distance to the magnet. If the NERR pin is pulled against VND outside the module, this error is also signaled via the serial interface. The ERREXT bit is then equal to ’1’. The error bits are reset again after the status register is read out at the address 0x77. The error bit in the data word is then also read in the next cycle as ’0’. CFGTOS 0 1 x CFGTOB 0 0 1 Timeout 16 µs 2 µs 2 µs forced by applying V(VZAP) = V()ZAP before changing the value of Bit ENSSI to avoid an aborted register communication. In the SSI mode the absolute position is output with 13 bits according to the SSI standard. (The data is transmitted as Gray code with trailing zeros.) Figure 25: SSI protocol, data GRAY-coded The register range 0x00 to 0x0F is equivalent to the settings with which the IC can be parameterized. The settings directly affect the corresponding switching parts. The range 0x10 to 0x1F is read-only and reflects the contents of the integrated zapping diodes. Following programming the data can be verified via these addresses. After the supply voltage is connected, the contents of the zapping diodes are copied to the RAM area 0x00 to 0x0F. Then the settings can be overwritten via the serial interface. Overwriting is not possible if the CFGPROT bit is set. Errors in the module are signaled via the error message output NERR. This open-drain output signals an error if the output is pulled against VND. If the error condition no longer exists, then the pin is released again after a waiting time of approximately 1 ms. If the integrated pull-up resistor is deactivated with DPU = ’1’, then an external resistor must be provided. With DPU = ’0’ it brings the pin up to the high level again. DPU 0 1 Addr. 0x04; bit 6 Pull-up activated Pull-up deactive Table 30: Timeout for sensor data The timeout can be programmed to a shorter value with the CFGTOS bit. However, this setting is reset to the default value 16 µs again following a reset. The timeout can be permanently programmed for faster data transmission with the CFGTOB register via a zapping diode. Resetting to slower data transmission is then not possible. The registers 0x7D to 0x7F are reserved for the manufacturer and can be provided with an ID so that the manufacturer can identify its modules Table 29: Activation of NERR pull-up OTP Programming CFGPROT 0 1 Addr. 0x05; bit 6 no protection write/read protection ENHC 0 1 Addr. 0x0f; bit 7 Default setting ZAP diode testing: Use a higher current for reading the ZAP diodes memory (0x10-0x1f) Table 31: Write/read protection of configuration Table 32: Enable High Current With CFGPROT = ’0’, the registers at the addresses 0x00 to 0x0F and 0x78 to 0x7F are readable and write- iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 24/25 able. The addresses 0x10 to 0x1F and 0x77 are readonly. With CFGPROT = ’1’, all registers except the addresses 0x7B and 0x7C are write-protected; the addresses 0x77 to 0x7F are readable, while all others are read-protected. 100 nF 100 nF Programming Board + 5V + 7V Serial Interface 100 nF 10 µF VPD VPA VZAP MA SLI SLO iC-MH8 An internal programming algorithm for the ZAP diodes is started by setting the bit PROGZAP. This process can only be successful if the voltage at VZAP is greater than 6.5 V and the test register TEST (2:0) is not set. Following programming, the register is reset internally again. In the process, the bit PROGOK is set in the status register (address 0x77) when programming is successful, and the bit PROGERR if it is not. VND VNA1 VNA2 0V Figure 26: Recommended setup for external programming. A short low impedance path (shown in light red) must be provided directly from pin VZAP to pins VNA1, VNA2. The ZAP memory can be tested by reading the register range 0x10-0x1f. This test can be done with with a higher readout current (Bit ENHC=1) to simulate deteriorated working conditions. For reliable ROM writing, a low impedance connection path as shown in Figure 26 must be established for the VZAP blocking capacitor (about 100 nF) between pin VZAP and pins VNA1, VNA2 to ensure stable VZAP voltage during programming. A further capacitor of 10 µF which may be located externally (e.g. on the programming board) is recommended for additional blocking purpose. Figure 27: Example PCB layout showing low impedance A typical PCB layout may look like the one shown in Figure 27. connection of capacitors to supply voltages (VPA, VPD, VZAP) and common ground iC-Haus expressly reserves the right to change its products and/or specifications. An info letter gives details as to any amendments and additions made to the relevant current specifications on our internet website www.ichaus.de/infoletter; this letter is generated automatically and shall be sent to registered users by email. Copying – even as an excerpt – is only permitted with iC-Haus’ approval in writing and precise reference to source. iC-Haus does not warrant the accuracy, completeness or timeliness of the specification and does not assume liability for any errors or omissions in these materials. The data specified is intended solely for the purpose of product description. No representations or warranties, either express or implied, of merchantability, fitness for a particular purpose or of any other nature are made hereunder with respect to information/specification or the products to which information refers and no guarantee with respect to compliance to the intended use is given. In particular, this also applies to the stated possible applications or areas of applications of the product. iC-Haus conveys no patent, copyright, mask work right or other trade mark right to this product. iC-Haus assumes no liability for any patent and/or other trade mark rights of a third party resulting from processing or handling of the product and/or any other use of the product. As a general rule our developments, IPs, principle circuitry and range of Integrated Circuits are suitable and specifically designed for appropriate use in technical applications, such as in devices, systems and any kind of technical equipment, in so far as they do not infringe existing patent rights. In principle the range of use is limitless in a technical sense and refers to the products listed in the inventory of goods compiled for the 2008 and following export trade statistics issued annually by the Bureau of Statistics in Wiesbaden, for example, or to any product in the product catalogue published for the 2007 and following exhibitions in Hanover (Hannover-Messe). We understand suitable application of our published designs to be state-of-the-art technology which can no longer be classed as inventive under the stipulations of patent law. Our explicit application notes are to be treated only as mere examples of the many possible and extremely advantageous uses our products can be put to. iC-MH8 12 BIT ANGULAR HALL ENCODER y inar im prel Rev A0.9, Page 25/25 ORDERING INFORMATION Type iC-MH8 Package QFN28 Order Designation iC-MH8 QFN28-5x5 For technical support, information about prices and terms of delivery please contact: iC-Haus GmbH Am Kuemmerling 18 D-55294 Bodenheim GERMANY Tel.: +49 (61 35) 92 92-0 Fax: +49 (61 35) 92 92-192 Web: http://www.ichaus.com E-Mail: sales@ichaus.com Appointed local distributors: http://www.ichaus.com/sales_partners
