160A

Bulletin I27502 rev. A 05/03 MT..KB SERIES THREE PHASE BRIDGE Power Modules Features Package fully compatible with the industry standard INT-Apak power modules series High thermal conductivity package, electrically insulated case Outstanding number of power encapsulated components Excellent power volume ratio, outline for easy connections to power transistor and IGBT modules 4000 VRMS isolating voltage UL E78996 approved 130 A 160 A Description A range of extremely compact, encapsulated three phase bridge rectifiers offering efficient and reliable operation. They are intended for use in general purpose and heavy duty applications. Major Ratings and Characteristics Parameters IO @ TC IFSM 2 130MT.KB 160MT.KB 130 (160) 85 (62) 1130 1180 6400 5800 64000 160 (200) 85 (60) 1430 1500 10200 9300 102000 Units A °C A A A2s A2s A2 √ s V °C °C @ 50Hz @ 60Hz It @ 50Hz @ 60Hz I2√t VRRM TSTG TJ range range range 800 to 1600 - 40 to 150 - 40 to 150 www.irf.com 1 130-160MT..KB Series Bulletin I27502 rev. A 05/03 ELECTRICAL SPECIFICATIONS Voltage Ratings Voltage Type number Code 80 100 130-160MT..KB 120 140 160 VRRM , maximum repetitive peak reverse voltage V 800 1000 1200 1400 1600 VRSM , maximum nonrepetitive peak rev. voltage V 900 1100 1300 1500 1700 IRRM max. @ TJ max. mA 10 Forward Conduction Parameter IO IFSM Maximum DC output current @ Case temperature Maximum peak, one-cycle forward, non-repetitive surge current 130MT.KB 160MT.KB Units Conditions 130 (160) 85 (62) 1130 1180 950 1000 160 (200) 85 (60) 1430 1500 1200 1260 10200 9300 7200 6600 102000 0.81 1.04 3.52 3.13 1.49 4000 V V mΩ A2√s V A2s A °C A t = 10ms t = 8.3ms t = 10ms t = 8.3ms t = 10ms t = 8.3ms t = 10ms t = 8.3ms No voltage reapplied 100% VRRM reapplied No voltage reapplied 100% VRRM reapplied Initial TJ = TJ max. 120° Rect conduction angle I2t Maximum I2t for fusing 64000 5800 4500 4100 I2√t Maximum I2√t for fusing 64000 0.78 0.99 4.59 4.17 1.63 4000 t = 0.1 to 10ms, no voltage reapplied (16.7% x π x IF(AV) < I < π x IF(AV)), @ TJ max. (I > π x IF(AV)), @ TJ max. (16.7% x π x IF(AV) < I < π x IF(AV)), @ TJ max. (I > π x IF(AV)), @ TJ max. Ipk = 200A, TJ = 25°C, tp = 400µs single junction TJ = 25°C, all terminal shorted f = 50Hz, t = 1s VF(TO)1 Low level value of threshold voltage VF(TO)2 High level value of threshold voltage rf1 rf2 VFM VINS Low level value of forward slope resistance High level value of forward slope resistance Maximum forward voltage drop RMS isolation voltage Thermal and Mechanical Specifications Parameter TJ Tstg RthJC Max. junction operating temperature range Max. storage temperature range Max. thermal resistance, junction to case 130MT.KB 160MT.KB Units Conditions -40 to 150 -40 to 150 0.16 0.93 0.18 1.08 0.12 0.73 0.15 0.88 0.03 K/W °C °C K/W DC operation per module DC operation per junction 120° Rect condunction angle per module 120° Rect condunction angle per junction Per module Mounting surface smooth, flat and greased A mounting compound is recommended and the torque should be rechecked after a period of 3 hours to allow for the spread of the compound. Lubricated threads. RthCS Max. thermal resistance, case to heatsink T Mounting torque ± 10% to heatsink to terminal wt Approximate weight 4 to 6 3 to 4 176 Nm g 2 www.irf.com 130-160MT..KB Series Bulletin I27502 rev. A 05/03 Ordering Information Table Device Code 16 1 1 - 0 2 MT 3 160 4 K B 5 Current rating code: 13 = 130 A (Avg) 16 = 160 A (Avg) 2 3 4 5 - Three phase diodes bridge Essential part number Voltage code: Code x 10 = VRRM (See Voltage Ratings Table) Generation II Outline Table (without optional barriers) D A B C E F All dimensions in millimeters (inches) NOTE: To order the Optional Hardware see Bulletin I27900 www.irf.com 3 130-160MT..KB Series Bulletin I27502 rev. A 05/03 Outline Table (with optional barriers) D A B C E F All dimensions in millimeters (inches) Maximum Allowable Case Temperature (° C) 150 130MT..KB Series 140 130 120 110 100 90 80 70 60 50 0 20 40 60 80 100 120 140 160 180 Total Output Current (A) 120 ° (Rect) Instantaneous Forward Current (A) 1000 100 T = 25°C J 10 T = 150 °C J 130MT..KB Series Per Junction 1 0 1 2 3 4 5 Instantaneous Forward Voltage (V) Fig. 1 - Current Ratings Characteristics Fig. 2 - Forward Voltage Drop Characteristics 4 www.irf.com 130-160MT..KB Series Bulletin I27502 rev. A 05/03 500 450 Maximum Total Power Loss (W) 400 350 300 250 200 150 100 50 0 0 20 40 60 80 100 120 140 160 0 25 50 75 100 125 150 Total Output Current (A) Maximum Allowable Ambient Temperature (°C) 0.5 K/ W 0.7 K /W 1.5 K/W 130MT..KB Series TJ = 150°C 120 ° (Rect) SA R th 0. 0.2 12 = 05 0. W K/ K/ W K/ W -D 0.3 ta el K/W R Fig. 3 - Total Power Loss Characteristics 1000 900 800 700 600 500 400 300 200 1 10 100 Number Of Equal Amplitude Half Cycle Current Pulses (N) Peak Half Sine Wave Forward Current (A) At Any Rated Load Condition And With Rated VRRM Applied Following Surge. Initial TJ = 150°C @ 60 Hz 0.0083 s @ 50 Hz 0.0100 s Peak Half Sine Wave Forward Current (A) 1200 1100 1000 900 800 700 600 500 400 300 200 0.01 Maximum Non Repetitive Surge Current Versus Pulse Train Duration. Initial T J = 150 °C No Voltage Reapplied Rated VRRM Reapplied 130MT..KB Series 130MT..KB Series 0.1 Pulse Train Duration (s) 1 Fig. 4 - Maximum Non-Repetitive Surge Current 150 160MT..KB Series 140 130 120 110 100 90 80 70 60 50 0 40 80 120 160 200 240 Total Output Current (A) 120 ° (Rect) Instantaneous Forward Current (A) Fig. 5 - Maximum Non-Repetitive Surge Current 1000 Maximum Allowable Case Temperature (°C) 100 T = 25 °C J 10 TJ = 150 °C 160MT..KB Series Per Junction 1 0 1 2 3 4 5 Instantaneous Forward Voltage (V) Fig. 6 - Current Ratings Characteristics Fig. 7 - Forward Voltage Drop Characteristics www.irf.com 5 130-160MT..KB Series Bulletin I27502 rev. A 05/03 600 Maximum Total Power Loss (W) 500 400 300 200 100 0 0 40 80 120 160 0 200 25 50 75 100 125 150 Total Output Current (A) Maximum Allowable Ambient Temperature (°C) 160MT..KB Series TJ = 150 °C 120 ° (Rect) Rt A hS 0. 1 0. 15 K/ W = 05 0. W K/ ta el -D K/ W 0.2 0 .3 0 .5 K/W R K/W K /W /W 1.5 K/W 0. 7 K Fig. 8 - Total Power Loss Characteristics 1300 1200 1100 1000 900 800 700 600 500 400 300 1 10 100 Number Of Equal Amplitude Half Cycle Current Pulses (N) Peak Half Sine Wave Forward Current (A) At Any Rated Load Condition And With Rated VRRM Applied Following Surge. Initial T J = 150 °C @ 60 Hz 0.0083 s @ 50 Hz 0.0100 s Peak Half Sine Wave Forward Current (A) 1500 1400 1300 1200 1100 1000 900 800 700 600 500 400 300 0.01 Maximum Non Repetitive Surge Current Versus Pulse Train Duration. Initial T J = 150 °C No Voltage Reapplied Rated V RRM Reapplied 160MT..KB Series 160MT..KB Series 0.1 Pulse Train Duration (s) 1 Fig. 9 - Maximum Non-Repetitive Surge Current 10 Steady State Value R thJC = 0.93 K/W R thJC = 0.73 K/W 1 (DC Operation) Fig. 10 - Maximum Non-Repetitive Surge Current Transient Thermal Impedance Z thJC (K/W) 130MT..KB Series 160MT..KB Series 0.1 Per Junction 0.01 0.001 0.01 0.1 Square Wave Pulse Duration (s) 1 10 Fig. 11 - Thermal Impedance ZthJC Characteristic 6 www.irf.com 130-160MT..KB Series Bulletin I27502 rev. A 05/03 Data and specifications subject to change without notice. This product has been designed and qualified for Industrial Level. Qualification Standards can be found on IR's Web site. IR WORLD HEADQUARTERS: 2 33 Kansas St., El Segundo, California 90245, USA Tel: (310) 252-7105 TAC Fax: (310) 252-7309 Visit us at www.irf.com for sales contact information. 05 /03 www.irf.com 7
