KR Electronics, Inc.
KR Electronics
General Description
www.krfilters.com
KR 2838-30 is a 140 MHz group delay equalized bandpass filter. Features The filter has a passband from 125 MHz to 155 MHz. Other • 140 MHz Center Frequency passband frequencies are available. Please consult the factory. • Sharp Transition to Stopband • Group Delay Equalized • 50 Ω Source and Load
Typical Performance
Passband Amplitude & Group Delay
(1 dB/div and 5 nsec/div)
10 Jun 2008 13:02:40
CH1 CH3 S31 S31 LOG DEL 1 dB/ 5 ns/ REF -3 dB REF 70 ns
CH2 S31 LOG 10 dB/
Overall Response
(10 dB/div)
10 Jun 2008 13:03:56
REF 0 dB
Cor
Smo
Cor
Cor
Avg 16
CENTER
140 . 000
000
MHz
SPAN
200 . 000
000
MHz
CENTER
140 . 000
000
MHz
SPAN
30 . 000
000
MHz
KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2008, KR Electronics, Inc.
Web Email Phone Fax
www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 1
KR Electronics, Inc.
KR Electronics 2838-30
Specifications
Parameter Filter type Insertion Loss Passband (< 2 dB) Passband Ripple Passband Group Delay Ripple 128 MHz to 152 MHz Attenuation at 113 MHz & 167 MHz Attenuation at 104 MHz & 176 Source and Load Specification Bandpass < 5.5 dB ( 4.5 dB typical ) 125 MHz to 155 MHz < 1.5 dB < 5 nsec > 40 dB > 55 dB 50 Ω
www.krfilters.com
Physical Dimensions
Notes: 1. Surface mount package — Metal cover open frame 2. Dimensions in inches 3. Maximum reflow temperature is 230° C for 10 sec maximum. 4. If boards are cleaned after installation, units must be completely dried.
Web Email Phone Fax www.krfilters.com sales@krfilters.com (732) 636-1900 (732) 636-1982 Page 2
KR Electronics, Inc. 91 Avenel Street Avenel, NJ 07001 © 2008, KR Electronics, Inc.
