801

INIATURE MINIATURE FUSEHOLDERS Holder / No. 801/802 Panel Mount for 5x20 mm und 6.3x32 mm Fuses Specifications Packaging Standard Bulk (100 St.) IEC 60127-6 UL 512 CSA C22.2 No. 39 Approvals Mounting 12.7mm diameter D-hole or double D-hole Admissible torque on plastic hex nut is 1.2Nm Solderable or 4.8mm quick connect-fits 0.5mm tab IP 40 (IEC 60529) PC2 (IEC 60127-6) Holder / Cap: Metal Parts: Te r m i n a l s -0,1 Protection Class & Category 12 ø12,7 -0,1 ø12,7 11,7 -0,15 -0,1 Materials Cap / Nr. 815 O 9,2 7 Terminals: Schlitz für Schraubendreher Slot for screw-driver Renkverschlussnase Bayonet-connector-nose Thermoplastic (Polyamide PA 6.6), black, UL94 V-0 Copper alloy, corrosion protected solderable tinned 250 V 6.3 A (VDE/SEMKO) with cap 815 10 A (VDE/SEMKO) with cap 816 2.5 W (VDE/SEMKO) Electrical Data (23ºC) Rated Voltage: Rated Current: 7 Rated Power : Temperature Operating Temperature 1,2 1,5 max. 33,8 -25ºC to +70ºC (consider de-rating) -25 °Y / +70 °C/21 days (IEC 60068-2-1...3) +10ºC to +60ºC relative humidity ≤ 75% yearly average, without dew, maximum value for 30 days - 95% 24 cycles at 15 min. each (IEC 60068-2-6) 10 - 60Hz at 0.75mm amplitude 60 - 2000Hz at 10g acceleration ≤ 5m Ω Test Climatic Test For 5x20mm Fuses Stock Conditions Cap / Nr. 816 Schlitz für Schraubendreher Slot for screw-driver Renkverschlussnase Bayonet-connector-nose Vibration Resistance Contact Resistance Dielectric Strength >1.5 kV O 9,2 7 Impulse Voltage 7 4 kV, 50 Hz, 1 min., dry > 103 MΩ ( 500 VDC, 1 min.) 235ºC, 2 sec. (Wave) 350ºC, 1 sec. (manually) 260ºC, 5 sec. (IEC 60068-2-20) Conductor - 2.5mm 2 1,5 Insulation Resistance max. 33,8 1,2 For 6.3x32mm Fuses Solderability Soldering Heat Resistance Order Information Qty. OrderNumber Series Minimum Cross Section 0000 00 Packaging 0 Marking Series, 250V, Approvals 5.0g (801/802) / 2.5g (815/816) Unit Weight Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand. 0 50909 In our continuing strategy to deliver unparalleled circuit protection solutions, technical expertise and application leadership, we proudly introduce the WICKMANN Group and its products to the Littelfuse portfolio. WebSite www.littelfuse.com
