LMBR220FT1G thru LMBR2200FT1G
Schottky Barrier Rectifiers
Reverse Voltage 20 to 200V Forward Current 2.0A
FEATURES
* Plastic package has Underwriters Laboratory
Flammability Classification 94V-0
* Low power loss,high efficiency
* For use in low voltage high frequency inverters,
free wheeling,and polarity protection applications
* Guardring for over voltage protection
* High temperature soldering guaranteed:
260°C/10 seconds at terminals
Mechanical Data
Case: SOD123-FL/MINI SMA
molded plastic over sky die
Terminals: Plated leads, solderable per
MIL-STD-750, Method 2026
Polarity: Color band denotes cathode end
Mounting Position: Any
Weight: 0.0155 g
Handling precautin:None
We declare that the material of product is
Haloggen free (green epoxy compound)
1.Electrical Characteristic
Maximum & Thermal Characteristics Ratings at 25°C ambient temperature unless otherwise specified.
Parameter Symbol
symbol
device marking code
LMBR
LMBR
LMBR
220FT1G 230FT1G 240FT1G
LMBR
250FT1G
LMBR
260FT1G
LMBR
280FT1G
LMBR
2100FT1G
LMBR
2150FT1G
LMBR
2200FT1G
Unit
22
23
24
25
26
28
210
215
220
100
150
200
V
Maximum repetitive peak reverse voltage
VRRM
20
30
40
50
60
80
Maximum RMS voltage
VRMS
14
21
28
35
42
56
70
105
140
V
Maximum DC blocking voltage
VDC
20
30
40
50
60
80
100
150
200
V
Maximum average forward rectified
current at TC = 75°C
IF(AV)
2.0
A
Peak forward surge current 8.3ms single
half sine-wave superimposed on rated
load (JEDEC Method)
IFSM
50
A
RθJA
85
°C/W
TJ
–55 to +150
°C
TSTG
–65 to +175
°C
Typical thermal resistance (Note 1)
Operating junction temperature range
storage temperature range
Electrical Characteristics Ratings at 25°C ambient temperature unless otherwise specified.
symbol
LMBR
LMBR
LMBR
220FT1G 230FT1G 240FT1G
Maximum instantaneous forward voltage
at 2.0A
VF
0.50
Maximum DC reverse current at rated
DC blocking voltage TA = 25℃
Tj = 100 ℃
IR
0.5
20
mA
Typical junction capacitance at
4.0V, 1MHz
CJ
160
PF
Parameter Symbol
LMBR
250FT1G
LMBR
260FT1G
0.70
LMBR
280FT1G
LMBR
2100FT1G
0.85
LMBR
2150FT1G
LMBR
2200FT1G
Unit
0.9
0.92
V
NOTES:
1. 8.0mm2 (.013mm thick) land areas
Nov.,2016
Rev.A 1/3
LMBR220FT1G thru LMBR2200FT1G
2.Ratings and Characteristic Curves ( TA = 25°C unless otherwise noted )
Fig. 2 – Maximum Non-repetitive Peak
Forward Surge Current
2.0
1.0
0
Instantaneous Forward Current (A)
100
10
25 50 75 100 125 150 175
CASE TEMPERATURE:Tc(°C)
Fig 3. – Typical Instantaneous Forward
Characteristics
60
30
TJ = 25°C
Pulse width = 300µs
1% Duty Cycle
1
10
Number of Cycles at 60Hz
100
Fig 4. – Typical Reverse Characteristics
10
1.0
1.0
0.1
0.1
0.01
Tj=125
Tj=75
℃
Tj=25
0.001
0.01
0.2
0
20
40
60
80
100
Percent of Rated Peak Reverse Voltage (%)
0.4
0.6
0.8
1.0
1.2
Instantaneous Forward Voltage (V)
Fig 5. –typical transient thermal
impedance
Fig 6. – Typical Junction Capacitance
1000
Junction Capacitance (pF)
100
TJ = TJ max
8.3ms Single Half
Sine-wave
(JEDEC Method)
0
0
Transient thermal impedance(°
Peak forward surge current (A)
60 Hz
Resistive or
Inductive Load
Instantaneous Reverse Current (mA)
Average Forward Rectified Current (A)
Fig. 1 – Forward Current Derating Curve
10
1.0
TJ = 25°C
f = 1.0 MHz
Vsig =
50mVp p
100
10
0.1
0.01
0.1
Nov.,2016
1.0
10
100
t,Pulse duration,sec
0.1
1
10
Reverse Voltage (V)
100
Rev.A 2/3
LMBR220FT1G thru LMBR2200FT1G
3. dimension:
Suggested solder pad layout
Nov.,2016
Rev.A 3/3
Title :
DOC NO.:
Power Diode SMD Package Pa cking Spec
Version: 5
WI-258
Modification: 0
Page:
2
5.1 、SMD Packing Reel Spec & Packing Quantity
5.1.1 Reel Packing
A. Reel Spec
unit:mm
SPEC
SMA 7" reel
SMA13" reel
SMA-FL13" reel
TO277 13" reel
SMB13" reel
SMC13" reel
SOD123FL 7" reel
SOD323HE 7" reel
SMB-FL 13" reel
A
177.0±2.0
330.0±2.0
330.0±2.0
330.0±2.0
330.0±2.0
330.0±2.0
177.0±2.0
177.0±2.0
330.0±2.0
B
54.0±0.5
75.0±0.5
75.0±0.5
75.0±0.5
75.0±0.5
75.0±0.5
50.0±0.5
50.0±0.5
75.0±0.5
C
13.0±0.5
13.0±0.5
13.0±0.5
13.0±0.5
13.0±0.5
13.0±0.5
13.0±0.5
13.0±0.5
13.0±0.5
Quantity/Reel
2K
5K
5K
5K
3K
3K
3K
3K
5K
W
13.2±0.2
13.2±0.2
13.2±0.2
13.2±0.2
13.5±0.5
17.0±0.5
9.4±1.5
9.4±1.5
13.2±0.2
B. 13" reel packing box
unit:mm
A
335±5.0
size
B
335±2.0
as per above packing
Spec
SMA13" reel
SMB13" reel
SMC13" reel
TO277 13" reel
SMB-FL 13" reel
Q'ty/Box
10K
6K
6K
10K
10K
C
40±1.0
Title :
Power Diode SMD Package Packing Spec
DOC NO.:
WI-258
DOC NO.:
WI-258
Page:
3
C. 7" reel packing box
unit:mm
B
188±2.0
C
138±2.0
186±2.0
139±2.0
as per above packing
Q'ty/Box
16K
SMA/SMA-FL
SOD123FL
30K
SOD323HE
30K
unit:mm
185±2.0
SMA/SMA-FL
A
188±2.0
SOD123FL
SOD323HE
D. reel packing carton
A
350±2.0
size
B
340±2.0
C
350±2.0
as per above packing
Spec
SMA/SMA-FL 7" reel
SMA13"reel
SMB13"reel
SMC13"reel
SMA-FL13"reel
TO277 13" reel
SMB-FL 13" reel
Q'ty/Carton
80K
80K
48K
36K
80K
80K
80K
unit:mm
SOD123FL
SOD323HE
A
B
C
455±2.0
400±2.0
410±2.0
as per above packing
Spec
SOD123-FL 7" reel
SOD323HE 7" reel
5.1.2 Tape Spec
A. Cover Tape
unit:mm
A
SMA
/SMA-FL
SMB-FL
/SMB
/TO277
SMC
B
9.5±0.10
0.062±0.007
13.30±0.10
SOD123FL
5.4±0.10
SOD323HE
Q'ty/Carton
360K
360K
Title :
DOC NO.:
Power Diode SMD Package Packing Spec
Version: 5
WI-258
Modification: 0
Page: 4
B. Carrier Tape
Do
P2
Po
t
P1
A
D1
A'
Bo
W
F
E
B'
B
SEC.:B-B'
Cathode(tape
hole side)
Ko
Ao
SEC.:A-A'
Item
W
P1
E
F
D0
D1
P0
P2
10P0
A0
B0
K0
T
SOD323HE
8±0.3
4±0.1
1.75±0.1
3.5±.05
1.55±0.05
1.1±0.1
4±0.1
2±0.05
40±0.2
1.45±0.1
2.75±0.1
0.80±0.1
0.25±0.05
SOD123FL
8±0.3
4±0.1
1.75±0.1
3.5±.05
1.55±0.05
1.1±0.1
4±0.1
2±0.05
40±0.2
1.95±0.1
3.95±0.1
1.30±0.1
0.25±0.05
SMA
12±0.3
4±0.1
1.75±0.1
5.5±.05
1.55±0.05
1.5±0.1
4±0.1
2±0.05
40±0.2
2.79±0.1
5.33±0.1
2.36±0.1
0.25±0.05
SMA-FL
12±0.3
4±0.1
1.75±0.1
5.5±.05
1.55±0.05
1.5±0.1
4±0.1
2±0.05
40±0.2
2.83±0.1
4.75±0.1
1.42±0.1
0.25±0.05
SMB
12±0.3
8±0.1
1.75±0.1
5.5±0.05
1.55±0.05
1.55±0.05
4±0.1
2±0.05
40±0.2
3.8±0.1
5.4±0.1
2.45±0.1
0.25±0.05
SMB-FL
12±0.3
8±0.1
1.75±0.1
5.5±0.05
1.55±0.05
1.55±0.05
4±0.1
2±0.05
40±0.2
3.8±0.1
5.75±0.1
1.4±0.1
0.25±0.05
TO277
12±0.3
8±0.1
1.75±0.1
5.5±.05
1.55±0.05
1.5±0.1
4±0.1
2±0.05
40±0.2
4.3±0.1
6.8±0.1
1.35±0.1
0.25±0.05
SMC
16±0.3
8±0.1
1.75±0.1
7.5±.05
1.55±0.05
1.55±0.05
4±0.1
2±0.05
40±0.2
6.05±0.1
8.31±0.1
2.54±0.1
0.25±0.05
Title :
DOC NO.:
Power Diode SMD Package Packing Spec
Version: 5
WI-258
Modification: 0
Page: 5
5.2、SMD Power Diode General Packing Spec
A. 7" reel
all labels will be at cathode side of reel
;
B
C
A
C
side
front
A:LRC label;
B:Environment Label
C:Halide free label
B. 13" reel
A
B
C
B
C
A
A:LRC label;
B:Environment Labe C:Halide free label
C.Tape lead: face anode side of the reel,upper side is the tape lead position. All labels are at cathode side of the reel.
标题:
DOC NO.:
Power Diode SMD Package Packing Spec
Version: 5
Modification: 0
Page:
C. Label Content :
LRC Label
WI-258
6
Two-dimension code
Manufacturing
it
P/N
`
Lot No.
Date code
Maker
Quantity
lot: 140106049X: 140106---2014/1/6;049----lot number:49;X:product code
Environment Label
Halide-free Label
Green
LMBR220FT1G thru LMBR2200FT1G
Reel packing
PACKAGE
REEL SIZE
REEL
(PCS)
SOD123-FL
7"
3,000
COMPONENT
SPACING
(mm)
4.0
BOX
(pcs)
INNER BOX
(mm)
REEL DIA.
(mm)
CARTON SIZE
(mm)
CARTON
(PCS)
30,000
183*183*123
178
382*262*387
240,000
5.Suggested thermal profile for soldering process
1. Storage environment:Temperature=5~40℃ Humidity=55±25%
2. Reflow soldering of surface-mount device
3. Reflow soldering
Profile Feature
Soldering Condition
Average ramp-up rate(TL to TP)
