AT-260
Digital Attenuator, 31 dB, 5-Bit DC - 2.0 GHz
Features
• • • • • • 1-dB Attenuation Steps to 31 dB Ultra Low DC Power Consumption Low Intermodulation Products: IP3 = 50 dBm SSOP-20 Plastic Package Tape and Reel Packaging Available Temperature Stability: ± 0.15 dB from –40°C to +85°C Rev. V5
Functional Schematic
Description
M/A-COM’s AT-260 is a 5-bit, 1-dB step GaAs MMIC digital attenuator in a low cost SSOP-20 surface mount plastic package. The AT-260 is ideally suited for use where high accuracy, fast switching, very low power consumption and low intermodulation products are required at a low cost. Typical applications include radio and cellular equipment, wireless LANS, GPS equipment and other gain/level control circuits. The AT-260 is fabricated with a monolithic GaAs MMIC using a mature 1-micron process. The process features full chip passivation for increased performance and reliability.
Pin Configuration
Pin No.
1 2 3 4 5 6
Function
VC1 VC1 VC2 VC2 VC3 VC3 VC4 VC4 No Connection VC5
Pin No.
11 12 13 14 15 16 17 18 19 20
Function
RF1 Ground Ground Ground Ground Ground Ground Ground Ground RF2
Ordering Information 1
Part Number
AT-260 AT-260TR
Package
SSOP 20-Lead Forward Tape and Reel
7 8 9 10
1. Reference Application Note M513 for reel size information.
Absolute Maximum Ratings 2,3
Parameter
Input Power: 0.05 GHz 0.5 - 2.0 GHz Control Voltage Operating Temperature Storage Temperature
Absolute Maximum
+27 dBm +34 dBm +5V, -8.5V -40°C to +85°C -65°C to +150°C
2. Exceeding any one or combination of these limits may cause permanent damage to this device. 3. M/A-COM does not recommend sustained operation near these survivability limits. 1
ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 / Fax: 978.366.2266 is considering for development. Performance is based on target specifications, simulated results, • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 and/or prototype measurements. Commitment to develop is not guaranteed. • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Visit www.macomtech.com for additional data sheets and product information. Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed.
changes to the product(s) or information contained herein without notice.
AT-260
Digital Attenuator, 31 dB, 5-Bit DC - 2.0 GHz
Electrical Specifications: TA = 25°C, Z0 = 50 Ω
Parameter
Reference Insertion Loss
Rev. V5
Test Conditions
DC - 0.1 GHz DC - 0.5 GHz DC - 1.0 GHz DC - 2.0 GHz DC - 1.0 GHz DC - 2.0 GHz (Any state) 10% to 90% RF, 90% to 10% RF 50% Control to 90% RF, 50% Control to 10% RF In Band Input Power 0.05 GHz 0.5 - 2.0 GHz 0.05 GHz 0.5 - 2.0 GHz Measured Relative to Input Power (for two-tone input power up to +5 dBm) 0.05 GHz 0.5 - 2.0 GHz Measured Relative to Input Power (for two-tone input power up to +5 dBm)
Units
dB dB dB dB
Min.
— — — —
Typ.
1.6 1.7 1.9 2.2
Max.
1.8 1.9 2.2 2.5
Attenuation Accuracy 4 VSWR Trise, Tfall Ton, Toff Transients 1 dB Compression
± (0.20 dB +3% of Atten Setting in dB) dB ± (0.30 dB +3% of Atten Setting in dB) dB Ratio nS nS mV dBm dBm dBm dBm — — — — — — — — 1.5:1 8 15 2 20 27 45 60 — — — — — — — —
IP 2
IP 3
dBm dBm
— —
34 50
— —
4. Attenuation accuracy specifications apply with negative bias control and low inductance grounding.
Truth Table 5
Control Inputs VC VC VC VC VC VC VC VC VC 5 4 4 3 3 2 2 1 1
1 0 1 1 1 1 0 1 1 0 1 1 1 0 0 0 1 0 0 0 1 1 1 1 0 1 1 0 0 0 0 1 0 0 1 1 1 1 1 0 1 0 0 0 0 0 1 0 1 1 1 1 1 1 0 0 0 0 0 0 0 1 1
Handling Procedures
Please observe the following precautions to avoid damage:
Atten (dB)
Reference 1 dB 2 dB 4 dB 8 dB 16 dB 31 dB
Static Sensitivity
Gallium Arsenide Integrated Circuits are sensitive to electrostatic discharge (ESD) and can be damaged by static electricity. Proper ESD control techniques should be used when handling these devices.
5. 0 = Vin Low = 0 V = 0 to -0.2 V @ 20 μA maximum. 1 = Vin High = -5 V @ 20 µA typical to –8 V @ 200 μA maximum. 2
ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 / Fax: 978.366.2266 is considering for development. Performance is based on target specifications, simulated results, • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 and/or prototype measurements. Commitment to develop is not guaranteed. • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Visit www.macomtech.com for additional data sheets and product information. Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed.
changes to the product(s) or information contained herein without notice.
AT-260
Digital Attenuator, 31 dB, 5-Bit DC - 2.0 GHz
Typical Performance Curves
Insertion Loss
4
Rev. V5
Attenuation Accuracy
1.0
2 dB 4 dB 8 dB 16 dB 31 dB
3
+25°C -40°C +85°C
0.5
2
0.0
1
-0.5
0 0.0
-1.0
0.5 1.0 1.5 2.0
0.0
0.5
1.0
1.5
2.0
Frequency (GHz)
Frequency (GHz)
VSWR
1.6
0 1 2 4 8 16 31
1.5
1.4
1.3
1.2
1.1
1.0 0.0
0.5
1.0
1.5
2.0
Frequency (GHz)
SSOP-20
3
