604-324-23-19

PROFESSIONAL LED INDICATORS Ø5.0mm Mounting FEATURES Bright nickel plated brass housing 604 SERIES PACK QUANTITY = 10 PIECES Sealed to IP67 Excellent wide viewing angle characteristics Suitable for high vibration applications Internal reverse protection diode fitted as standard in all voltage models. SPECIFICATION Ordering Information & Typical T echnical Characteristics (T a = 25°C) Mean Time Between Failure = 100,000 Hours. PART NUMBER COLOUR Luminous intensity figures refer to the unmodified discrete LED. VOLTAGE CURRENT LUMINOUS WAVE OPERATING STORAGE LENS DC (Vdc) Vopr DC (mA) lopr INTENSITY lv@20mA (mcd) LENGTH λp (nm) TEMP T opr TEMP T stg HIGH INTENSITY 604-301-04 604-325-04 604-324-04 604-934-04 604-998-04 604-301-23 604-325-23 604-324-23 604-934-23 604-998-23 UNITS Red Yellow Green Blue Cool White Red Yellow Green Blue Cool White Smoked Smoked Smoked Smoked Smoked Smoked Smoked Smoked Smoked Smoked 2.1 2.2 2.2 2.2 2.2 24-28 24-28 24-28 24-28 24-28 Vdc 20 20 20 20 20 20 20 20 20 20 mA 900 4300 7800 2300 4600 900 4300 7800 2300 4600 mcd 660 590 525 470 *see below 660 590 525 470 *see below nm -30 ~ +85^ -30 ~ +85^ -30 ~ +85^ -30 ~ +85^ -30 ~ +85^ -30 ~ +85^ -30 ~ +85^ -30 ~ +85^ -30 ~ +85^ -30 ~ +85^ °C -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 °C Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Other voltages AC/DC available. Please contact our Technical sales. ^ = Products must be derated according to the derating information. Each derating graph refers to specific LEDs. 998 *Typical emission colour cool white 0.283 0.330 0.330 Refer to page 3. x 0.296 Intensities (lv) and colour shades of white (x,y co-ordinates) may vary between LEDs within a batch. y 0.276 0.305 0.339 0.318 How to Order: website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply Approved Manufacturer BS EN ISO 9001:2000 © MARL INTERNATIONAL LTD 2008 : DS 003/08 Issue 1 SAMPLES AVAILABLE Page 1 of 3 604 Series MOUNTING HOLE Dimensions in mm (Typical) Not to scale Anode termination indicated by red lead. Mounting hole to be clean and burr free MATERIALS Body Nut Panel Seal Fresnel lens Encapsulation Lock Washer Bright Nickel Plated Brass Bright Nickel Plated Brass Viton Polycarbonate Epoxy Beryllium Copper TECHNICAL CHARACTERISTICS SERIES MAXIMUM DISSIPATION 604 425 mW * = Current Version POWER MAXIMUM VOLTAGE 3* / 75• Vdc • = Voltage Version REVERSE PANEL NUT MINIMUM MIN/MAX. THICKNESS 1.5-8.0 mm PANEL CUTOUT TORQUE 0.35 Nm MOUNTING CENTRES x,y =10.0 mm MOUNTING 5.0 mm OPTIONAL FLYING LEAD TERMINATIONS ORDER SUFFIX CODE SUPPLY WIRE WIRE NO/DIAMETER CONDUCTORS OF DIAMETER INSULATION Customised lengths available OVER COMMENTS VOLTAGE COLOUR LENGTH 19 DC Products Red-anode / Black-cathode 1000mm 19/0.15mm 1.2mm How to Order: website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply Approved Manufacturer BS EN ISO 9001:2000 © MARL INTERNATIONAL LTD 2008 : DS 003/08 Issue 1 SAMPLES AVAILABLE Page 2 of 3 DERATING INFORMATION 301 & 303 325 324, 934 & 998 ALSO AVAILABLE Part numbers also available in the 604 Series: PART NO. COLOUR VOLTAGE DC (Vdc) Vopr 604-301-23-19 604-303-21 604-312-01 604-312-22 604-324-20-19 604-324-22-19 604-324-23-19 604-325-23-19 UNITS Red Red Green Green Green Green Green Yellow 28 VDC 12 VDC 2mA 24 VDC 5/6 VDC 24 VDC 28 VDC 28 VDC The products listed above illustrate all of the options available to order. These products may have custom modifications that alter their operation beyond the generic information contained within this datasheet. Please contact sales for further information. How to Order: website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply Approved Manufacturer BS EN ISO 9001:2000 © MARL INTERNATIONAL LTD 2008 : DS 003/08 Issue 1 SAMPLES AVAILABLE Page 3 of 3
