S2M

SURFACE MOUNT GLASS PASSIVATED RECTIFIER S2A THRU S2M FEATURES • • • • • • VOLTAGE RANGE CURRENT 50 to 1000 Volts 2.0 Ampere Plastic package has underwrites laboratory flammability Classification 94V-0 For surface mounted applications Low profile package Built-in strain relief, ideal for automated placement Glass Passivated chip junction High temperature soldering guaranteed 250℃/10 second at terminals DO-214AA(SMB) MECHANICAL DATA • • • • Case: JEDED DO-214AA molded plastic over glass passivated chip Terminals: Solder plated, Solderable per MIL-STD-750, method 2026 Polarity: Color band denotes cathode end Weight: 0.002ounce, 0.064 gram Dimensions in inches and (millimeters) MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS • Ratings at 25℃ ambient temperature unless otherwise specified MAXIMUM RATINGS & THERMAL CHARACTERISTICS Maximum Repetitive Peak Reverse Voltage Maximum RMS Voltage Maximum DC Blocking Voltage Maximum Average Forward Rectified Current at TL =100℃ Peak Forward Surge Current 8.3ms single half sine wave superimposed on rated load (JEDEC method) T L=100℃ Typical Thermal Resistance (NOTE 1) Operating and Storage Temperature Range SYMBOLS VRRM VRMS VDC IF(AV) IFSM RθJA RθJL TJ,TSTG S2A 50 35 50 S2B 100 70 100 S2D 200 140 200 S2G 400 280 400 2.0 50 53 16 -55 to +150 S2J 600 420 600 S2K 800 560 800 S2M 1000 700 1000 UNIT Volts Volts Volts Amps Amps ℃/W ℃ ELECTRICAL CHARACTERISTICS Maximum Instantaneous Forward Voltage at 1.5A Maximum DC Reverse Current at rated DC Blocking Voltage Typical Reverse Recovery Time at IF=0.5A, IR=1.0A, IRR=0.25A, Typical junction capacitance at 4.0V, 1MHz T A = 25℃ TA = 125℃ SYMBOLS VF IR Trr S2A S2B S2D S2G 1.15 5.0 125 2.0 S2J S2K S2M UNIT Volts µA µs pF CJ 30 Notes: 1. Thermal resistance from Junction to ambient and from junction to lead mounted on P.C.B.with 0.3×0.3″(8.0 × 8.0mm) copper pad areas. E-mail: sales@cnmic.com Web Site: www.cnmic.com SURFACE MOUNT GLASS PASSIVATED RECTIFIER S2A THRU S2M VOLTAGE RANGE CURRENT 50 to 1000 Volts 2.0 Ampere RATINGS AND CHARACTERISTIC CURVES S2A THRU S2M PEAK FORWARD SURGE CURRENT, F1G.1-FORWARD CURRENT DERATING CURVE AVERAGE FORWARD CURRENT AMPERES 60Hz RESISTIVE OR INDUCTIVE LOAD F1G.2-MAXIMUM NON-REPETITIVE PEAK FORWARD SURGE CURRENT 50 TL =90℃ 8.3ms Single Half Sine-Wave (JEDEC Method) 1.5 40 AMPERES 1.0 30 20 0.5 60 Hz RESISTIVE OR INDUCTIVE LOAD 0.27X0.27″ (7.0X7.0mm) COPPER PAD AREAS 0 50 60 70 80 90 100 110 120 130 140 150 10 0 1 10 100 LEAD TEMPERATURE,(℃) NUMBER OF CYCLES AT 60 Hz 10 INSTANTANEOUS REVERSE CURRENT, MICROAMPERES F1G.3-TYPICAL INSTANTANEOUS FORWARD CHARACTERISTICS INSTANTANEOUS FORWARD CURRENT, AMPERES F1G.4-TYPICAL REVERSE CHARACTERISTICS 10 TJ =25℃ Pulse Width=300us 1% Duty Cycle 1.0 TJ =125℃ 1.0 TJ =100℃ 0.1 0.1 T J =25℃ 0.01 0.4 0.6 0.8 1.0 1.2 1.4 1.6 0.01 0 20 40 60 80 100 INSTANTANEOUS FORWARD VOLTAGE, VOLTS F1G.5-TYPICAL JUNCTION CAPACITANCE JUNCTION CAPACITANCE,(pF) 100 T J =25℃ f=1MHz Vsig=50mVp-p PERCENT OF RATED PEAK REVERSE VOLTAGE,(%) 10 1 0.01 0.1 1.0 10 100 REVRESE VOLTAGE,(V) E-mail: sales@cnmic.com Web Site: www.cnmic.com
