1014-6A

1014-6A R2 1014-6A 6 Watts - 28 Volts, Class C Microwave 1000 - 1400 MHz GENERAL DESCRIPTION The 1014-6A is an internally matched, COMMON BASE transistor capable of providing 6 Watts of CW or pulsed RF output power across the band 1000 to 1400 MHz. This hermetically solder-sealed transistor is specifically designed for microwave broadband applications. It utilizes gold metallization and diffused emitter ballasting to provide high reliability and supreme ruggedness. CASE OUTLINE 55LV, STYLE 1 ABSOLUTE MAXIMUM RATINGS Maximum Power Dissipation @ 25oC Maximum Voltage and Current BVces Collector to Emitter Voltage BVebo Emitter to Base Voltage Ic Collector Current Maximum Temperatures Storage Temperature Operating Junction Temperature 19 Watts 50 Volts 3.5 Volts 1.0 Amps - 65 to + 200oC + 200oC ELECTRICAL CHARACTERISTICS @ 25 OC SYMBOL Pout Pg ηc VSWR1 CHARACTERISTICS TEST CONDITIONS Freq = 1400 MHz Vcc = 28 Volts Pin = 1.2 Watts Pulse Width = CW MIN TYP MAX UNITS Power Out Power Gain Collector Efficiency Load Mismatch Tolerance 6 7.0 7.5 40 10:1 Watts dB % FUNCTIONAL CHARACTERISTICS @ 25°C Bvces BVebo θjc1 Collector to Emitter Breakdown Emitter to Base Breakdown Thermal Resistance Ic = 25 mA Ie = 3 mA 50 3.5 9.0 Volts Volts o C/W MICROSEMI CORP. RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE. TO VERIFY THE CURRENT VERSION PLEASE CHECK OUR WEB SITE AT WWW. MICROSEMI.COM OR CONTACT OUR FACTORY DIRECT. Microsemi Corp. 3000 Oakmead Village Drive, Santa Clara, CA 95051-0808 Tel. 408 / 986-8031 Fax 408 /869-2324 1014-6A R2 1014-6A Test Circuit MICROSEMI CORP. RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE. TO VERIFY THE CURRENT VERSION PLEASE CHECK OUR WEB SITE AT WWW. MICROSEMI.COM OR CONTACT OUR FACTORY DIRECT. Microsemi Corp. 3000 Oakmead Village Drive, Santa Clara, CA 95051-0808 Tel. 408 / 986-8031 Fax 408 /869-2324 1014-6A MICROSEMI CORP. RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE. TO VERIFY THE CURRENT VERSION PLEASE CHECK OUR WEB SITE AT WWW. MICROSEMI.COM OR CONTACT OUR FACTORY DIRECT. Microsemi Corp. 3000 Oakmead Village Drive, Santa Clara, CA 95051-0808 Tel. 408 / 986-8031 Fax 408 /869-2324
