Surface Mount
Monolithic Amplifier
50Ω, Broadband,
DC to 2 GHz
Features
• • • • • • •
! NEW
ERA-8SM
wide bandwidth, DC-2 GHz high gain, 31.5 dB at 100 MHz, reduces component count high power output, +12.5 dBm typ. at 1000 MHz low noise improved stability protection against power supply transients patent pending
Applications
CASE STYLE : WW107
• cellular • PCS • communication receivers & transmitters
Electrical Specifications @ 25°C
MODEL NO. FREQ. (GHz)
H
GAIN, dB Typical
0.1 ERA-8SM
5
over frequency, GHz 1 2 3 25 19 15
4 12
Min. @ 2 GHz 17
MAXIMUM POWER (dBm) @1GHz Output (1dB Input Comp.) (no Typ. dmg.) 12.5 13
DYNAMIC RANGE @1GHz NF (dB) Typ. 3.1 IP3 (dBm) Typ. 25
VSWR (:1) Typ. In Out DC-1 1-4 DC-1 1-4 GHz GHz GHz GHz 1.4 1.8 1.8 2.2
MAXIMUM RATING**
DC THERMAL RESISOPERATING TANCE POWER @ Pin 3*** θjc, CurDevice typ. I P rent Volt °C/W mA mW (mA) Typ Min Max 65 250 36 3.7 3.2 4.2 140
PRICE $
Qty. (25) 1.22
DC-2
31.5
Low frequency cutoff determined by external coupling capacitors. ** Permanent damage may occur if any of these limits are exceeded. These ratings are not intended for continuous normal operation. ***Reliability predictions and normal operating conditions are applicable at current specified.
Maximum Ratings
Operating Temperature Storage Temperature -45°C to 85°C -65°C to 150°C
Pin Configuration
RF IN RF OUT DC GND EXT. Marking‡ E8 1 3 3 2,4
Resistor Values "1%" Res. 88.7 118 143 174 200 226 255 280 309
Model Identification
Model ERA-8SM
‡
Typical Biasing Configuration
Vcc 7 8 9 10 11 12 13 14 15
Prefix letter (optional) designates assembly location. Suffix letters (optional) are for wafer identification.
Outline Drawing
Suggested PCB Layout (PL-075)
Outline Dimensions ( inch) mm
A B C D E F G H J K L M N P Q .012 .10 .020 .092 .085 .060 .007 .026 .235 .118 .235 .118 .072 .040 .020 .30 2.54 .51 2.34 2.16 1.52 .18 .66 5.97 3.00 5.97 3.00 1.83 1.02 0.51 wt. grams .015
Mini-Circuits
®
INTERNET http://www.minicircuits.com P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
REV. A M90118 ED-9366/14 ERA-8SM MM/RS/CP 031209
Distribution Centers NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
ISO 9001 CERTIFIED
