69002-5001

FEATURES AND SPECIFICATIONS Molex TM-42 Terminating Machine The Molex TM-42 termination machine is an electronically operated, single cycle, flywheel press. It is designed to provide an effective method of applying a wide range of Molex side feed crimp terminals to a pre-stripped discrete wire and cable. The TM-42 also has the ability to terminate FFC and IDT connectors to ribbon cable. The TM-42 is designed for mid-volume, semiautomatic bench operation and cannot be operated if the safety guard is not properly in place. This press has the ability to be mounted onto a wire processing system. Production flexibility is obtained through the use of Molex interchangeable termination dies. These dies are inexpensive because all of the adjustments for crimp height and terminal feed are located in the TM-42 press. These dies will only work in the Molex TM-42 and will not work in the Molex TM-2000 press or any other industry standard press. Features And Benefits n Can utilize the Molex T2 and Terminator Die tooling n Independent conductor and insulation adjustments with position indicators for quick and accurate adjustments n Ability to terminate most terminals from the Molex product line n TM-42 has tooling available which allows for the termination of FFC and IDT connectors n Quick release tooling feature for fast, simple changeover that increase productivity n Ability to remove upper crimp tooling without the need remove lower die n Meets OSHA safety and noise standards plus this press is CE approved for use in Europe n Totally enclosed for operator safety, including power shutoff if guard is not properly in place n Complete press designed to metric standards Electrical 69002-5001: Voltage: 115/230 V AC, 1PH 60Hz, 5.8/2.9A 69002-5000: Voltage: 230V AC, 1Ph 50Hz, 3.8Amp (Europe) Mechanical Dimensions (with reel mounted) Height-1,150mm (45.00”) Width-540.00 (21.20”) Depth-330.00 (13.00”) Dimensions (without reel mounted) Height-950.00mm (36.00”) Width-330.00 (13.00”) Depth-330.00 (13.00”) Weight: Gross-110kg (242 lbs.) Unpacked 100kg (220lbs.) Processing Capability: 2500 terminations per hour, depending on operator’s skill and application Up to 10 AWG (4.0mm2) ORDERING INFORMATION Order No. Description For Use With Voltage/Hz 69002-5001 69002-5000 TM-42 Crimp Press TM-42 Crimp Press T2 and Terminator Dies T2 and Terminator Dies 115/230V AC, 1 Ph, 60/50 Hz 230V AC, 1 Ph, 50 Hz Americas Headquarters Lisle, Illinois 60532 U.S.A. 1-800-78MOLEX amerinfo@molex.com Order No. DHL-0014 Far East North Headquarters Yamato, Kanagawa, Japan 81-462-65-2324 feninfo@molex.com Far East South Headquarters Jurong, Singapore 65-6-268-6868 fesinfo@molex.com Visit our website at www.molex.com Printed in USA/100/JI/JI/2006.05 European Headquarters Munich, Germany 49-89-413092-0 eurinfo@molex.com Corporate Headquarters 2222 Wellington Ct. Lisle, IL 60532 U.S.A. 630-969-4550 Fax:630-969-1352 ©2006, Molex
