AA-122-56

This document was generated on 03/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: Documents: Drawing (PDF) 0190690045 Active Krimptite™ Ring Tongue Terminal for 18-22 AWG Wire RoHS Certificate of Compliance (PDF) Agency Certification CSA UL LR18689 E32244 Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Crimp Quality Equipment Mil-Spec Product Name Type Ring and Spade Terminals 19069 Yes N/A Krimptite™ Ring Physical Barrel Type Insulation Material - Plating Mating Packaging Type Stud Size Termination Interface: Style Wire Size AWG Wire Size mm² Closed None Tin Bag 5/16" (M8) Crimp or Compression 18, 20, 22 0.35 - 0.80 Material Info Old Part Number AA-122-56 Search Parts in this Series 19069Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Crimp Tool 0640030100 Crimp Head for the 0640070100 AT-200™ Pneumatic Hand Tool Reference - Drawing Numbers Sales Drawing SD-19069-004 This document was generated on 03/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
