AA-215-06XT

This document was generated on 04/13/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0191210006 Active InsulKrimp™ Flanged Spade Tongue Terminal for 18-22 AWG Wire, Stud Size 6, Length 19.84mm (.781"), Mylar Tape Carrier Documents: Drawing (PDF) Product Specification PS-19902-009 (PDF) RoHS Certificate of Compliance (PDF) Agency Certification CSA UL LR18689 E32244 Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Crimp Quality Equipment Mil-Spec Product Name Type Ring and Spade Terminals 19121 Yes N/A InsulKrimp™ Spade Physical Barrel Type Flammability Insulation Material - Plating Mating Packaging Type Stud Size Wire Insulation Diameter Wire Size AWG Wire Size mm² Closed 94V-2 PVC Tin Adhesive Tape on Reel 6 (M3.5) 3.68mm (.145") 18, 20, 22 0.25 - 1.50 Material Info Old Part Number AA-215-06XT Search Parts in this Series 19121Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Crimp Dies for 0192880023 MTA-100 Tape Applicator used in 3BF Press, MTA-105 Tape Applicator used in TM-2000™ Press, and ATP-301 Air Crimping Press for Mylar Tape Mounted Terminals Mini-Mac™ 0638851300 Applicator Reference - Drawing Numbers Product Specification Sales Drawing PS-19902-009 SD-19121-001 This document was generated on 04/13/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
