M2001-20

MEDICAL GRADE POWER TRANSFORMER M2001 • 60W Sine wave step up 10KHz to 60KHz • Complies with IEC60950 and UL60601 reinforced isolation • Hipot: 4000VRMS (wdg to wdg, wdgs to core) • Operating Temperature: -40°C to +85°C • RoHS Compliant Product • Custom design available upon request ELECTRICAL SPECIFICATION @ 25OC Part No. M200112 14 16 20 Note: • Input Voltage: 20Vp-p to 60Vp-p sine wave • Polarity: 2 and 9 are in phase OCL 10KHz µH ±25% (2-4) 360 360 360 360 LL 100KHz µH Max (2-4) 1.0 1.0 1.0 2.0 DCR Ω Max (2-4) 0.050 0.050 0.050 0.050 Turns Ratio ±5% (2-4 : 9-7) 1:12 1:14 1:16 1:20 IOUT mA Max (9-7) 167 143 125 100 MECHANICAL SCHEMATIC Product performance is limited to specified parameters. Data is subject to change without prior notice. Dimensions Unless otherwise specified, all tolerances are: inch: .XX : ±0.015 .XXX : ±0.004 mm: X,X : ±0,38 X,XX : ±0,10 13200 Estrella Ave., Bldg. B Gardena, CA 90248 Tel: 310-325-1043 Fax: 310-325-1044 www.mpsind.com sales@mpsind.com
