Power Inductors
Power Choke Coil (Automotive Grade)
PCC-M0530M-LP, PCC-M0630M-LP series
PCC-M0840M-LP, PCC-M1040M-LP series
High heat resistance and high reliability using metal composite core (MC)
Industrial property : Patents 3 (Registered 2 / Pending 1)
Features
●High heat resistance
●Low profile
: Operation up to 155 ℃ including self-heating
: ３ｍｍ max. height (PCC-M0530M-LP, PCC-M0630M-LP)
４ｍｍ max. height (PCC-M0840M-LP, PCC-M1040M-LP)
●SMD type
●High-reliability
: High vibration resistance as result of newly developed integral construction ;
under severe reliability conditions of automotive and other strenuous
applications
: Excellent inductance stability using ferrous alloy magnetic material
: Excellent inductance stability over broad temp. range
: A gapless structure achieved with metal composite core
: Low DC resistance of winding and low eddy-current loss of the core
●High bias current
●Temp. stability
●Low audible (buzz) noise
●High efficiency
●Shielded construction
●AEC-Q200 compliant
●RoHS compliant
Recommended applications
●Noise filter for various drive circuitry requiring high temp. operation and peak current handling capability
●Boost-Converter, Buck-Converter DC/DC
Standard packing quantity (Minimum quantity/Packing unit)
●4,000 pcs/box (2 reel) : PCC-M0530M-LP, M0630M-LP
●1,000 pcs/box (2 reel) : PCC-M0840M-LP, M1040M-LP
Explanation of part numbers
1
2
3
4
E
T
Q
P
Product code
5
Classification
6
7
8
9
M
Height
Inductance
Winding
10
11
K
V
Core
Suffix
12
Size
(Example)
Code
4R7
220
R68
Inductance
4.7 μH
22 μH
0.68 μH
Code
P
N
K
C
Size
□ 5 mm
□ 6 mm
□ 8 mm
□ 10 mm
Temperature rating
Operating temperature range
Storage condition
After PWB mounting
Before PWB mounting
Tc : -55 ℃ to +155 ℃ (Including self-temperature rise)
Ta : -5 ℃ to +35 ℃ 85%RH max.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
30-Jun-22
