USB-622X

USER GUIDE NI USB-622x/625x/628x OEM M Series USB-6221/6225/6229/6251/6255/6259/6281/6289 OEM Devices This document provides dimensions, pinouts, and information about the connectors, switch, LEDs, and chassis ground of the National Instruments USB-6221 OEM, USB-6225 OEM, USB-6229 OEM, USB-6251 OEM, USB-6255 OEM, USB-6259 OEM, USB-6281 OEM, and USB-6289 OEM devices. It also explains how to modify the USB device name in Microsoft Windows. Caution There are no product safety, electromagnetic compatibility (EMC), or CE marking compliance claims made for the USB-622x/625x/628x OEM devices. Conformity to any and all compliance requirements rests with the end product supplier. Caution (USB-628x Devices) Exercise caution when placing USB-628x OEM devices inside an enclosure. Auxiliary cooling may be necessary to keep the device under the maximum ambient temperature rating of 45 °C, as specified in the NI 628x Specifications. Figure 1 shows the USB-6221/6251/6281 OEM and USB-6225/6229/6255/6259/6289 OEM devices. USB-6221/6251/6281 USB-6225/6229/6255/6259/6289 Figure 1. USB-622x/625x/628x OEM Devices Refer to the NI 622x Specifications document for USB-6221/6225/6229 specifications, the NI 625x Specifications document for USB-6251/6255/6259 specifications, and the NI 628x Specifications document for USB-6281/6289 specifications. Refer to the M Series User Manual for more information about USB-622x/625x/628x devices. You can find all documentation at ni.com/manuals. Dimensions Figure 2 shows the dimensions of the USB-6221/6251/6281 OEM device. NI USB-622x/625x/628x OEM User Guide 2 ni.com 5.210 (132.33) 5.900 (149.86) 6.013 (152.74) 6.400 (162.56) 6.200 (157.48) 0.000 (0.00) 0.200 (5.08) 0.390 (9.91) 0.918 (23.32) 3.180 (80.77) 3.198 (81.22) 3.220 (81.79) 3.730 (94.74) 3.734 (94.84) 4X Ø 0.110 (2.79) 7X Ø 0.125 (3.18) 6.140 (155.96) 5.290 (134.37) 6.950 (176.53) 4x 6.718 (170.63) 6.270 (159.26) 6.140 (155.96) 5.930 (150.62) 0.396 (10.06) 0.304 (7.72) 0.256 (6.50) 0.116 (2.95) 0.000 (0.00) 0.200 (5.08) 2.072 (52.63) 3.296 (83.72) 0.304 (7.72) 0.200 (5.08) 1.057 (26.85) 1.750 (44.45) 2.300 (58.42) 2.606 (66.19) 0.436 (11.07) 0.392 (9.96) 0.362 (9.19) 0.162 (4.11) 0.062 (1.57) 0.000 (0.00) 0.000 (0.00) 3.080 (78.23) 0.393 (9.98) 0.609 (15.47) 0.515 (13.08) 0.442 (11.23) 6.400 (162.56) NI USB-622x/625x/628x OEM User Guide 2X Ø 0.140 Cutout in Panel for LEDs Ø 0.330 Cutout in Panel for Power Connector Figure 2. USB-6221/6251/6281 OEM Dimensions in Inches (Millimeters) © National Instruments Corporation 3 Figure 3 shows the dimensions of the USB-6225/6229/6255/6259/6289 OEM device. 5.210 (132.33) 5.900 (149.86) 6.013 (152.74) 6.400 (162.56) 6.200 (157.48) 6.400 (162.56) 0.000 (0.00) 0.200 (5.08) 0.390 (9.91) 0.918 (23.32) 3.180 (80.77) 3.198 (81.22) 3.220 (81.79) 3.730 (94.74) 3.734 (94.84) 4X Ø 0.110 (2.79) 7X Ø 0.125 (3.18) 6.140 (155.96) 5.290 (134.37) 6.950 (176.53) 4x 6.718 (170.63) 6.270 (159.26) 6.140 (155.96) 5.930 (150.62) 5.839 (148.31) 5.499 (139.67) 0.396 (10.06) 0.304 (7.72) 0.256 (6.50) 0.116 (2.95) 0.000 (0.00) 2.072 (52.63) 3.296 (83.72) 0.200 (5.08) 0.304 (7.72) 0.200 (5.08) 1.057 (26.85) 1.750 (44.45) 2.300 (58.42) 2.606 (66.19) 0.436 (11.07) 0.392 (9.96) 0.362 (9.19) 0.162 (4.11) 0.062 (1.57) 0.000 (0.00) 0.000 (0.00) 3.080 (78.23) 0.393 (9.98) 0.609 (15.47) 0.515 (13.08) 0.442 (11.23) 2X Ø 0.140 Cutout in Panel for LEDs Ø 0.330 Cutout in Panel for Power Connector Figure 3. USB-6225/6229/6255/6259/6289 OEM Dimensions in Inches (Millimeters) NI USB-622x/625x/628x OEM User Guide 4 ni.com I/O Connector Pinouts Figures 4 through 9 show the connector pinouts for the USB-6221 OEM, USB-6225 OEM, USB-6229 OEM, USB-6251 OEM, USB-6255 OEM, USB-6259 OEM, USB-6281 OEM, and USB-6289 OEM devices. Refer to the M Series User Manual at ni.com/manuals for more information about USB-622x/625x/628x signals and how to connect them. © National Instruments Corporation 5 NI USB-622x/625x/628x OEM User Guide Bank 0 50-Pin Digital Connector +5 V D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND 50 48 46 44 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 49 47 45 43 41 39 37 35 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 Bank 0 +5 V PFI 15 PFI 14 PFI 13 PFI 12 PFI 11 PFI 10 PFI 9 PFI 8 PFI 7 PFI 6 PFI 5 PFI 4 PFI 3 PFI 2 PFI 1 PFI 0 P0.7 P0.6 P0.5 P0.4 P0.3 P0.2 P0.1 P0.0 Bank 0 34-Pin Analog Connector AI GND AI 7 AI 14 AI GND AI 5 AI 12 AI GND AI 3 AI 10 AI GND AI 1 AI 8 AI GND AI GND AI GND AO 1 AO 0 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 15 AI GND AI 6 AI 13 AI GND AI 4 AI 11 AI GND AI 2 AI 9 AI GND AI 0 AI SENSE NC AO GND AO GND AO GND Bank 0 NC = No Connect Figure 4. USB-6221 OEM Connector Pinout NI USB-622x/625x/628x OEM User Guide 6 ni.com Bank 1 50-Pin Analog/Digital Connectors AI 71 AI 78 AI GND AI 77 AI 68 AI 67 AI 74 AI GND AI 73 AI 64 AI 55 AI 62 AI GND AI 61 AI 52 AI 51 AI 58 AI GND AI 57 AI 48 AI 39 AI 46 AI GND AI 45 AI 44 50 48 46 44 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 49 47 45 43 41 39 37 35 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 79 AI 70 AI 69 AI 76 AI GND AI 75 AI 66 AI 65 AI 72 AI GND AI 63 AI 54 AI 53 AI 60 AI GND AI 59 AI 50 AI 49 AI 56 AI GND AI 47 AI 38 AI 37 AI GND AI 36 +5 V D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND Bank 0 50 48 46 44 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 49 47 45 43 41 39 37 35 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 Bank 1 Bank 0 +5 V PFI 15 PFI 14 PFI 13 PFI 12 PFI 11 PFI 10 PFI 9 PFI 8 PFI 7 PFI 6 PFI 5 PFI 4 PFI 3 PFI 2 PFI 1 PFI 0 P0.7 P0.6 P0.5 P0.4 P0.3 P0.2 P0.1 P0.0 Bank 1 34-Pin Analog Connectors AI 43 AI GND AI 42 AI 33 AI 32 AI 31 AI GND AI 30 AI 21 AI 28 AI GND AI 19 AI 26 AI GND AI 17 AI 24 AI GND 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 35 AI 34 AI 41 AI GND AI 40 AI 23 AI 22 AI 29 AI GND AI 20 AI 27 AI GND AI 18 AI 25 AI GND AI 16 AI SENSE 2 AI GND AI 7 AI 14 AI GND AI 5 AI 12 AI GND AI 3 AI 10 AI GND AI 1 AI 8 AI GND AI GND AI GND AO 1 AO 0 Bank 0 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 15 AI GND AI 6 AI 13 AI GND AI 4 AI 11 AI GND AI 2 AI 9 AI GND AI 0 AI SENSE NC AO GND AO GND AO GND Bank 1 Bank 0 NC = No Connect Figure 5. USB-6225 OEM Connector Pinout © National Instruments Corporation 7 NI USB-622x/625x/628x OEM User Guide Bank 1 50-Pin Digital Connectors +5 V D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND 50 48 46 44 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 49 47 45 43 41 39 37 35 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 +5 V P0.31 P0.30 P0.29 P0.28 P0.27 P0.26 P0.25 P0.24 P0.23 P0.22 P0.21 P0.20 P0.19 P0.18 P0.17 P0.16 P0.15 P0.14 P0.13 P0.12 P0.11 P0.10 P0.9 P0.8 +5 V D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND Bank 0 50 48 46 44 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 49 47 45 43 41 39 37 35 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 Bank 1 Bank 0 +5 V PFI 15 PFI 14 PFI 13 PFI 12 PFI 11 PFI 10 PFI 9 PFI 8 PFI 7 PFI 6 PFI 5 PFI 4 PFI 3 PFI 2 PFI 1 PFI 0 P0.7 P0.6 P0.5 P0.4 P0.3 P0.2 P0.1 P0.0 Bank 1 34-Pin Analog Connectors AI GND AI 23 AI 30 AI GND AI 21 AI 28 AI GND AI 19 AI 26 AI GND AI 17 AI 24 AI GND AI GND AI GND AO 3 AO 2 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 31 AI GND AI 22 AI 29 AI GND AI 20 AI 27 AI GND AI 18 AI 25 AI GND AI 16 AI SENSE 2 NC AO GND AO GND AO GND AI GND AI 7 AI 14 AI GND AI 5 AI 12 AI GND AI 3 AI 10 AI GND AI 1 AI 8 AI GND AI GND AI GND AO 1 AO 0 Bank 0 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 15 AI GND AI 6 AI 13 AI GND AI 4 AI 11 AI GND AI 2 AI 9 AI GND AI 0 AI SENSE NC AO GND AO GND AO GND Bank 1 Bank 0 NC = No Connect NC = No Connect Figure 6. USB-6229 OEM Connector Pinout NI USB-622x/625x/628x OEM User Guide 8 ni.com Bank 0 50-Pin Digital Connector +5 V D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND 50 48 46 44 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 49 47 45 43 41 39 37 35 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 Bank 0 +5 V PFI 15 PFI 14 PFI 13 PFI 12 PFI 11 PFI 10 PFI 9 PFI 8 PFI 7 PFI 6 PFI 5 PFI 4 PFI 3 PFI 2 PFI 1 PFI 0 P0.7 P0.6 P0.5 P0.4 P0.3 P0.2 P0.1 P0.0 Bank 0 34-Pin Analog Connector AI GND AI 7 AI 14 AI GND AI 5 AI 12 AI GND AI 3 AI 10 AI GND AI 1 AI 8 AI GND AI GND AI GND AO 1 AO 0 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 15 AI GND AI 6 AI 13 AI GND AI 4 AI 11 AI GND AI 2 AI 9 AI GND AI 0 AI SENSE APFI 0 AO GND AO GND AO GND Bank 0 Figure 7. USB-6251/6281 OEM Connector Pinout © National Instruments Corporation 9 NI USB-622x/625x/628x OEM User Guide Bank 1 50-Pin Analog/Digital Connectors AI 71 AI 78 AI GND AI 77 AI 68 AI 67 AI 74 AI GND AI 73 AI 64 AI 55 AI 62 AI GND AI 61 AI 52 AI 51 AI 58 AI GND AI 57 AI 48 AI 39 AI 46 AI GND AI 45 AI 44 50 48 46 44 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 49 47 45 43 41 39 37 35 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 79 AI 70 AI 69 AI 76 AI GND AI 75 AI 66 AI 65 AI 72 AI GND AI 63 AI 54 AI 53 AI 60 AI GND AI 59 AI 50 AI 49 AI 56 AI GND AI 47 AI 38 AI 37 AI GND AI 36 +5 V D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND Bank 0 50 48 46 44 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 49 47 45 43 41 39 37 35 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 Bank 1 Bank 0 +5 V PFI 15 PFI 14 PFI 13 PFI 12 PFI 11 PFI 10 PFI 9 PFI 8 PFI 7 PFI 6 PFI 5 PFI 4 PFI 3 PFI 2 PFI 1 PFI 0 P0.7 P0.6 P0.5 P0.4 P0.3 P0.2 P0.1 P0.0 Bank 1 34-Pin Analog Connectors AI 43 AI GND AI 42 AI 33 AI 32 AI 31 AI GND AI 30 AI 21 AI 28 AI GND AI 19 AI 26 AI GND AI 17 AI 24 AI GND 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 35 AI 34 AI 41 AI GND AI 40 AI 23 AI 22 AI 29 AI GND AI 20 AI 27 AI GND AI 18 AI 25 AI GND AI 16 AI SENSE 2 AI GND AI 7 AI 14 AI GND AI 5 AI 12 AI GND AI 3 AI 10 AI GND AI 1 AI 8 AI GND AI GND AI GND AO 1 AO 0 Bank 0 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 15 AI GND AI 6 AI 13 AI GND AI 4 AI 11 AI GND AI 2 AI 9 AI GND AI 0 AI SENSE APFI 0 AO GND AO GND AO GND Bank 1 Bank 0 Figure 8. USB-6255 OEM Connector Pinout NI USB-622x/625x/628x OEM User Guide 10 ni.com Bank 1 50-Pin Digital Connectors +5 V D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND 50 48 46 44 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 49 47 45 43 41 39 37 35 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 +5 V P0.31 P0.30 P0.29 P0.28 P0.27 P0.26 P0.25 P0.24 P0.23 P0.22 P0.21 P0.20 P0.19 P0.18 P0.17 P0.16 P0.15 P0.14 P0.13 P0.12 P0.11 P0.10 P0.9 P0.8 +5 V D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND D GND Bank 0 50 48 46 44 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 49 47 45 43 41 39 37 35 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 Bank 1 Bank 0 +5 V PFI 15 PFI 14 PFI 13 PFI 12 PFI 11 PFI 10 PFI 9 PFI 8 PFI 7 PFI 6 PFI 5 PFI 4 PFI 3 PFI 2 PFI 1 PFI 0 P0.7 P0.6 P0.5 P0.4 P0.3 P0.2 P0.1 P0.0 Bank 1 34-Pin Analog Connectors AI GND AI 23 AI 30 AI GND AI 21 AI 28 AI GND AI 19 AI 26 AI GND AI 17 AI 24 AI GND AI GND AI GND AO 3 AO 2 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 31 AI GND AI 22 AI 29 AI GND AI 20 AI 27 AI GND AI 18 AI 25 AI GND AI 16 AI SENSE 2 APFI 1 AO GND AO GND AO GND AI GND AI 7 AI 14 AI GND AI 5 AI 12 AI GND AI 3 AI 10 AI GND AI 1 AI 8 AI GND AI GND AI GND AO 1 AO 0 Bank 0 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1 AI 15 AI GND AI 6 AI 13 AI GND AI 4 AI 11 AI GND AI 2 AI 9 AI GND AI 0 AI SENSE APFI 0 AO GND AO GND AO GND Bank 1 Bank 0 Figure 9. USB-6259/6289 OEM Connector Pinout © National Instruments Corporation 11 NI USB-622x/625x/628x OEM User Guide Attaching External LEDs USB-622x/625x/628x OEM devices have two LEDs that reflect the device state. The green READY LED indicates when the device is powered on and configured as a USB device. The yellow ACTIVE LED indicates USB bus activity. Three connectors on the device allow you to connect an external LED circuit to the device, as shown in Figure 10. To connect an external READY LED, use E1 as the positive connection (+3.3 V) and E2 as the negative connection. To connect an external ACTIVE LED, use E1 as the positive connection and E3 as the negative connection. E1 is current limited with a 100 Ω resistor to the 3.3 V internal supply. This configuration limits the current to approximately 16 mA into a single external LED or approximately 8 mA each when both LEDs are lit. You also can limit this current further by using external resistors, also shown in Figure 10. OEM (On-Board) 3.3 V E3 E3 E2 E1 100 Ω E2 E1 External External READY ACTIVE LED LED Figure 10. Schematic for External LED Circuits NI USB-622x/625x/628x OEM User Guide 12 ni.com Power Switch The power switch on the USB-622x/625x/628x OEM device powers the device on and off. Figure 11 shows the pins on the power switch and circuitry. 100 kΩ to Ground VDC Out VDC In 3 2 SW1 Switch NC NC 1 XF1 J4/J6/J8 100 kΩ Outer Shell SW1 Power to Device 2 1 3 XF1 FUSE J4/J6/J8 Power Connector 100 kΩ Figure 11. Schematic for the Power Switch Pin 1, VDC In, is connected to VDC through the fuse (reference designator XF1). The VDC is the voltage provided by the power supply through the power connector (reference designator J4/J6/J81) and must be 11–30 VDC, 20 W. Pin 2, VDC Out, provides power to the circuitry on the device. When the switch is in the On position, the VDC power supply from pin 1 is routed to pin 2. Pin 3, 100 kΩ to Ground, connects pin 2 to ground through a 100 kΩ resistor when the switch is in the Off position. 1 The power connector is designated as J4 on USB-6225/6255 OEM devices, J6 on USB-6221/6229 OEM devices, and J8 on USB-6251/6259/6281/6289 OEM devices. © National Instruments Corporation 13 NI USB-622x/625x/628x OEM User Guide Connecting the USB-622x/625x/628x OEM Device to Your Chassis The USB-622x/625x/628x OEM device includes several plated mounting holes that are designed for customer grounded connections, as shown in Figure 12. Caution Do not use the holes labeled A in Figure 12 as mounting holes. A A A Mounting Hole Connected to Chassis Ground A Do Not Use These as Mounting Holes Figure 12. Customer Mounting Holes (USB-6225/6229/6255/6259/6289 OEM Shown) Caution (USB-628x Devices) Exercise caution when placing USB-628x OEM devices inside an enclosure. Auxiliary cooling may be necessary to keep the device under the maximum ambient temperature rating of 45 °C, as specified in the NI 628x Specifications. NI USB-622x/625x/628x OEM User Guide 14 ni.com Replacing Fuses USB-622x/625x/628x OEM devices have a replaceable T 2A 250V (5 × 20 mm) fuse that protects the device from overcurrent through the power connector. (USB-628x Devices Only) USB-628x OEM devices also have a replaceable F 2A 125V fuse that protects the device from overcurrent through the +5 V terminal(s). Replacement fuse information can be found in Table 1. To replace a broken fuse in USB-622x/625x/628x OEM devices, complete the following steps. 1. 2. Power down and unplug the device. Replace the broken fuse while referring to Figure 13 for the fuse locations. 2 1 1 T 2A 250V (5 x 20 mm) Fuse 2 F 2A 125V Fuse on USB-628x OEM Devices Figure 13. USB-622x/625x/628x OEM Fuse Locations © National Instruments Corporation 15 NI USB-622x/625x/628x OEM User Guide Device Components Table 1 contains information about the components used for interfacing and interacting with the USB-622x/625x/628x OEM device. Table 1. USB-622x/625x/628x OEM Components Component LEDs 34-pin connectors Reference Designator(s) on PCB DS1 (USB-6221/6251/6281 OEM) J1 (USB-6225/6229/6255/6259/6289 OEM) J1, J2 Manufacturer Dialight 3M Manufacturer Part Number 553-0332 N2534-6002RB 50-pin connectors (USB-6221/6251/6281 OEM) P1 (USB-6225/6229/6255/6259/6289 OEM) P1, P2 3M N2550-6002UB USB connector Power connector J3 (USB-6221/6229 OEM) J6 (USB-6225/6255 OEM) J4 (USB-6251/6259/6281/6289 OEM) J8 AMP Switchcraft 787780-1 722RA Power switch T 2A 250V fuse F 2A 125V fuse 68-pin connectors* SW1 XF1 (USB-6281/6289 OEM) F1 (USB-6221 OEM) J8 (USB-6225/6229/6255 OEM) J7, J8 (USB-6251/6281 OEM) J7 (USB-6259/6289 OEM) J6, J7 ITT Industries, Cannon Littelfuse Littelfuse Honda E101J1A3QE2 218.002XP 0453002 PCS-E68RLMD1+ * Optional mass termination connectors. These are not populated by default. NI USB-622x/625x/628x OEM User Guide 16 ni.com Modifying the USB Device Name in Microsoft Windows You can change how the USB-622x/625x/628x OEM device name appears when users install the device in both the Found New Hardware Wizard that appears when the device is initially installed and in the Windows Device Manager. Windows Vista/XP Users Figure 14 depicts how a USB-6251 OEM device name appears in the Found New Hardware Wizard and Windows Device Manager. Figure 14. USB-6251 OEM Device in the Found New Hardware Wizard and Device Manager (Windows Vista/XP) To modify the device name in the Found New Hardware Wizard and Windows Device Manager in Microsoft Windows Vista/XP, complete the following steps. Note You must have NI-DAQmx 8.7 or later installed on your PC. 1. Locate the OEMx.inf file in the y:\WINDOWS\inf\ directory, where x is the random number assigned to the INF file by Windows, and y:\ is the root directory where Windows is installed. © National Instruments Corporation 17 NI USB-622x/625x/628x OEM User Guide Note New security updates to Microsoft Vista and NI-DAQ 8.6 or later create random INF files for NI hardware. Windows assigns random file numbers to all INF files, which causes the user to search through several INF files until the correct file is located. If you want to revert back, save a copy of this file as OEMx_original.inf in a different location. 2. Edit the device INF file by opening OEMx.inf with a text editor. At the bottom of this file are the descriptors where Windows looks to identify the device. Locate the two lines of text that contain in quotes the descriptors for the device name you are modifying. Change the descriptor on both lines to the new device name, as shown in Figure 15. Original File Modified File Figure 15. INF File Descriptors Changed to “My Device” (Windows Vista/XP) 3. 4. Save and close the INF file. Go to the Windows Device Manager. (Windows Vista) In the Device Manager, notice that the OEM device now appears as My Device, as shown in Figure 16. (Windows XP) In the Device Manager, right-click the OEM device under Data Acquisition Devices, and select Uninstall. Power down the OEM device and disconnect the USB cable from your PC. NI USB-622x/625x/628x OEM User Guide 18 ni.com When you reconnect and power on the device, it appears as My Device in the Found New Hardware Wizard and Windows Device Manager, as shown in Figure 16. Note When the device is initially installed, the Windows alert message may display the following: Found New Hardware: M Series USB 62xx (OEM). This message appears for a few seconds until the custom name appears and the Found New Hardware Wizard is launched. This alert message device name cannot be changed. Figure 16. “My Device” in the Found New Hardware Wizard and Device Manager (Windows Vista/XP) Note Modifying the INF file will not change the USB-622x/625x/628x OEM device name in Measurement & Automation Explorer (MAX). © National Instruments Corporation 19 NI USB-622x/625x/628x OEM User Guide Windows 2000 Users Figure 17 depicts how a USB-6251 OEM device name appears in the Found New Hardware Wizard and Windows Device Manager. Figure 17. USB-6251 OEM Device in the Found New Hardware Wizard and Device Manager (Windows 2000) To modify the device name in the Found New Hardware Wizard and Windows Device Manager in Windows 2000, complete the following steps. Note You must have NI-DAQmx 8.7 or later installed on your PC. 1. Locate the nimioxsu.inf file in the x:\WINNT\inf\ directory, where x:\ is the root directory where Windows is installed. If you want to revert back, save a copy of this file as nimioxsu_original.inf in a different location. NI USB-622x/625x/628x OEM User Guide 20 ni.com 2. Edit the device INF file by opening nimioxsu.inf with a text editor. At the bottom of this file are the descriptors where Windows looks to identify the device. Locate the two lines of text that contain in quotes the descriptors for the device name you are modifying. Change the descriptor on both lines to the new device name, as shown in Figure 18. Original File Modified File Figure 18. INF File Descriptors Changed to “My Device” (Windows 2000) 3. 4. 5. Save and close the INF file. Go to the Windows Device Manager, right-click the OEM device under Data Acquisition Devices, and select Uninstall. Power down the OEM device and disconnect the USB cable from your PC. © National Instruments Corporation 21 NI USB-622x/625x/628x OEM User Guide When you reconnect and power on the device, it appears as My Device in the Found New Hardware Wizard and Windows Device Manager, as shown in Figure 19. Note When the device is initially installed, the Windows alert message may display the following: Found New Hardware: M Series USB 62xx (OEM). This message appears for a few seconds until the custom name appears and the Found New Hardware Wizard is launched. This alert message device name cannot be changed. Figure 19. “My Device” in the Found New Hardware Wizard and Device Manager (Windows 2000) Note Modifying the INF file will not change the USB-622x/625x/628x OEM device name in Measurement & Automation Explorer (MAX). National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation. Refer to the Terms of Use section on ni.com/legal for more information about National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents. © 2006–2007 National Instruments Corporation. All rights reserved. 371910D-01 Dec07
