HC SERIES Features Common mode chokes with Nanocrystalline cores -Nominal current in each winding (I): from 2A to 30A. -Nominal inductance (L): from 6mH to 28mH. -Rated voltage: 250Vac. -Test voltage: 1.5kVac, winding to winding. -Creepage distance: 3mm, winding to winding. -Ambient temperature: from –40ºC to +50ºC. -Storage temperature: from –40ºC to +120ºC. -Plastic case: UL 94V-0 listed. -According to UL 1283. Common Mode Chokes IZI (Ω) at 100kHz typical 2000 1600 4500 3500 2000 1500 1600 1000 1000 1500 1600 250 1800 370 1600 1000 400 Rdc (mΩ) typical 110 31,5 42 37 20 18 11 10 3 18 10 3 6,6 3 7 5,5 2,5 ØPIN (mm) ±0,1 0,5 0,75 0,7 0,8 0,95 0,9 1,25 1,2 2,2 0,9 1,25 1,6 1,6 1,8 1,7 1,8 2,2 Electrical specifications Code IAC (A) L (mH) at 10kHz +50% / -30% 2 x 14 2 x 6,5 2 x 28 2 x 19 2 x 13 2x9 2 x 11 2x6 2x6 2x9 2 x 11 2 x 1,6 2 x 13 2 x 1,2 2 x 4.9 2 x 3,6 2 x 2,6 L (mH) at 100kHz minimum 2 x 1,5 2 x 0,65 2 x 4,5 2 x 2,7 2 x 1,8 2 x 1,4 2 x 1,3 2 x 2,0 2 x 0,5 2 x 1,4 2 x 1,3 2 x 0,2 2 x 1,2 2 x 0,4 2 x 1,4 2 x 1,1 2 x 0,3 HC140-02V1 HC6R5-04V1 HC280-04V1 HC190-06V2 HC130-08V2 HC9R0-10V2 HC110-13V2 HC6R0-15V3 HC6R0-30V3 HC9R0-10H1 HC110-13H1 HC1R6-20H1 HC130-16H2 HC1R2-25H2 HC4R9-20H3 HC3R6-25H3 HC2R6-32H3 2 4 4.5 6 8 10 13 15 30 10 13 20 16 25 20 25 32 117 HC SERIES Common Mode Chokes Dimensions (in mm) Common mode chokes with Nanocrystalline cores Code HC-V1 HC-V2 HC-V3 A MAX 28,5 37,0 55,0 B MAX 18 22 30 C MAX 30 37 56 D ±0,2 7,62 15,24 20,32 E ±0,2 15,24 25,4 35,56 L ±1,0 4 4 5 Code HC-H1 HC-H2 HC-H3 A MAX 37,5 42,5 55,5 B MAX 23 26 31 C ±0,2 13,5 - D ±0,2 23 - E ±0,2 5 12,5 F ±0,2 5 10 G ±0,2 5 7,5 H ±0,2 5 7,5 I ±0,2 7 4,5 J ±0,2 15 20 L ±1,0 4 5 5 118 HC SERIES Common mode chokes with Nanocrystalline cores Curves: Impedance vs. Frequency Note: Impedance measurements have been obtained with both windings in parallel and at ambient temperature. 119 Common Mode Chokes HC SERIES Common Mode Chokes Common mode chokes with Nanocrystalline cores Note: Impedance measurements have been obtained with both windings in parallel and at ambient temperature. 120 HC SERIES Common mode chokes with Nanocrystalline cores Common Mode Chokes Note: Impedance measurements have been obtained with both windings in parallel and at ambient temperature. 121 SC SERIES Common Mode Chokes Common mode chokes with Ferrite cores - SMD format Features -Nominal current in each winding (I): from 0,4A to 2,5A. -Nominal inductance (L): from 5µH to 4,7mH. -Rated voltage: 42Vac. -Storage temperature: from -40ºC to 120ºC. -Plastic case: UL 94V-0. -Packaging: tape & reel - 600 u. x reel -Suitable for CAN Bus. Electrical specifications Code IAC (A) L (µH) at 10kHz +50% / -30% Lleak (nH) at 100kHz typical Rdc (mΩ) typical Visol (Vac) SC-050-X SC-060-X SC-060-H SC-110-X SC-250-H SC-510-H SC-471-H SC-102-X SC-222-X SC-472-X Notes 1,2 2,5 2,5 0,8 0,8 0,8 0,7 0,7 0,5 0,4 2x5 2x6 2x6 2x11 2x25 2x51 2x470 2x1000 2x2200 2x4700 50 50 400 50 1500 2000 2500 250 250 300 70 20 20 120 130 160 200 200 400 550 180 180 180 180 180 180 550 550 550 550 X: Bifilar windings H: Symmetrical windings Dot on the top of the box indicates pin 1 Dimensions (in mm) SC SERIES 122
