AR8033 Integrated 10/100/1000 Mbps
Ethernet Transceiver
Data Sheet
80-Y0618-2 Rev A
October 25, 2012
Confidential and Proprietary - Qualcomm Atheros, Inc.
Restricted Distribution. Not to be distributed to anyone who is not an employee of either Qualcomm or a subsidiary
of Qualcomm without the express approval of Qualcomm’s Configuration Management.
Not to be used, copied, reproduced in whole or in part, nor its contents revealed in any manner to others without the
express written permission of Qualcomm Atheros, Inc.
QUALCOMM is a registered trademark of QUALCOMM Incorporated. ATHEROS is a registered trademark of
Qualcomm Atheros, Inc. All other registered and unregistered trademarks are the property of Qualcomm
Incorporated, Qualcomm Atheros, Inc. or their respective owners and used with permission. Registered marks owned
by Qualcomm Incorporated and Qualcomm Atheros, Inc. are registered in the United States of America and may be
registered in other countries.
This technical data may be subject to U.S. and international export, re-export, or transfer (“export”) laws. Diversion
contrary to U.S. and international law is strictly prohibited.
Qualcomm Atheros, Inc.
1700 Technology Drive
San Jose, CA 95110-1383
U.S.A.
Copyright © 2011-2012 Qualcomm Atheros, Inc.
All rights reserved.
Revision history
Revision
Date
Description
1.0
April 2011
Initial release
2.0
November 2011
Electrical Characteristics
3.2 Recommended Operation Conditions: delete DVDDL/AVDDL,
ΨJA; add VDDH_REG, ΨJT, AVDDL/DVDDL (industrial and
commercial); add thermal conditions
3.6 change title from MDIO DC Characteristics to MDIO/MDC DC...;
change VIH min value and VIL max value
3.7 table 3-14: change Jitterpk-pk max value to 100
3.11 Digital pin design guide (new)
Registers
4.2.3 Status Register – Copper page, change bit[8] reset value to
always 1
4.3.4 Hib control and auto-neg test register: change bit[12], [6:5] to
reserved
4.3.5 External loopback selection, change bit[0] to R/W
4.3.7 Power saving control (new)
4.4.75 SGMII Control register 2 (new)
4.4.76 SGMII Control register 3 (new)
80-Y0618-2 Rev A
2
Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Revision
A
Date
October 2012
Description
System change from SharePoint to Agile. Based on SharePoint
document system MKG-15552.
Introduction
Update Features
Update figure functional block diagram
Pin Description
Update Table Mode definition
Update Table Signal to pin descriptions
Function Descriptioin
Update Copper
Update Fiber
Update Auto-negotiation
Update Fault propagation
LED interface: add table BaseX LED status after table 3-5 Default
LED status
Synchronous Ethernet: add CLK_25M output content
Update Function Wake on LAN
Electrical Characteristics
Absolute maximum ratings: add symbol Vmin
Update RGMII characteristics:
Table RGMII DC characteristics — 2.5/3/3V I/O supply: add GND 0.3 to Min of symbol VIL
Table RGMII DC characteristics — 1.8V I/O supply: add 2.1 to Max
for symbol VIH, add GND - 0.3 to Min for symbol VIL, and add 1.9
to Max for symbol VOH
Table RGMII DC characteristics — 1.5V I/O supply: add 1.8 to Max
for symbol VIH, add GND - 0.3 to Min for symbol VIL, and add 1.57
to Max for symbol VOH
Update RGMII characteristics and AC timing diagrams
MDIO timing: change Min from 10 to 0, add Typ 4, and remove Max of
symbol tmdelay in Table MDIO AC characteristic
Clock characteristics: remove symbol Fs and Fo in table
Recommended crystal parameters
Power pin current consumption: update the voltage range from “3.3V
±10%” to “3.3V ±5%” for symbol AVDD33 in table Power pin
consumption
80-Y0618-2 Rev A
3
Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Revision
Date
Description
Update Registers
Add a note to table Register summary
Control register
Status register
Auto-negotiation advertisement register
1000BASE-T status register
Extended status register
Function control register
Smart speed register: add bit[8]: GIGA_DIS_QUAL
Copper/fiber status register
Remove registers Auto-negotiation status, Auto-negotiation XNP
transmit, Auto-negotiation XNP transmit1, Auto-negotiation XNP
transmit2, Auto-negotiation LP XNP ability, Auto-negotiation LP XNP
ability1, Auto-negotiation LP XNP ability2
Add registers PHY control debug register 0, Green feature configure
2, AZ control2, Cld control3, SGMII control register 1
80-Y0618-2 Rev A
4
Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
Contents
1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1
1.2
2
Pin Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.1
2.2
2.3
3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Functional block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Pinout diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pin descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power-on strapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3.1 Mode definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15
15
18
19
Function Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.1
3.2
3.3
3.4
3.5
3.6
Operation modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.1 Copper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.2 Fiber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.3 Media Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.4 Auto-Media Detect (Combo) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmit functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Receive functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.1 Decoder modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.2 Analog-to-Digital converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.3 Echo canceller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.4 NEXT canceller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.5 Baseline wander canceller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.6 Digital adaptive equalizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.7 Auto-negotiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.8 Smartspeed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.9 Automatic MDI/MDIX crossover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.10 Polarity correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loopback modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.1 Digital loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.2 External cable loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.3 Remote PHY loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cable diagnostic test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fiber mode support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21
21
21
22
23
24
24
24
25
25
25
25
25
25
26
26
27
27
27
28
29
29
30
80-Y0618-2 Rev A
5
Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
3.7
3.8
3.9
3.10
3.11
3.12
3.13
3.14
4
Contents
3.6.1 IEEE 802.3 remote fault indication support . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6.2 Fault propagation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LED interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Management interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Timing synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.10.1 Synchronous Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Green ETHOS feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.11.1 Low power modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.11.2 Short cable power mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.11.3 Hibernation mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IEEE 802.3az . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SmartEEE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wake-on-LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.1
4.2
4.3
4.4
4.5
4.6
4.7
4.8
4.9
4.10
Absolute maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended operating conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RGMII characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SerDes and SGMII characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MDIO timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MDIO/MDC DC characteristic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power pin current consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Typical power consumption parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power-on sequence, reset and clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.10.1 Power-on sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.10.2 Reset and clock timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.11 Digital pin design guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
30
30
31
33
35
36
36
38
38
38
38
38
40
40
43
43
44
46
47
48
49
50
50
52
52
52
53
Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5.1
5.2
Register bit type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MII registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2.1 Control register — copper page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2.2 Control register — fiber page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2.3 Status register — copper page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2.4 Status register — fiber page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2.5 PHY identifier 1 register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2.6 PHY identifier 2 register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2.7 Auto-negotiation advertisement register — copper page . . . . . . . . . . . . . . . . .
5.2.8 Auto-negotiation advertisement register — fiber page . . . . . . . . . . . . . . . . . . .
5.2.9 Auto-negotiation link partner ability register — copper page . . . . . . . . . . . . .
5.2.10 Auto-negotiation link partner ability register — fiber page . . . . . . . . . . . . . . .
5.2.11 Auto-negotiation expansion register — copper page . . . . . . . . . . . . . . . . . . . .
55
56
57
58
60
61
63
63
64
66
67
69
70
80-Y0618-2 Rev A
6
Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.3
5.4
Contents
5.2.12 Auto-negotiation expansion register — fiber page . . . . . . . . . . . . . . . . . . . . . . 70
5.2.13 Auto-negotiation next page transmit register — copper page . . . . . . . . . . . . . 71
5.2.14 Auto-negotiation next page transmit register — fiber page for 1000BASE-X,
SGMII 72
5.2.15 Auto-negotiation link partner next page register — copper page . . . . . . . . . . . 72
5.2.16 Auto-negotiation link partner next page register — fiber page for 1000BASE-X,
SGMII 73
5.2.17 1000BASE-T control register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5.2.18 1000BASE-T status register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
5.2.19 MMD access control register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
5.2.20 MMD access data register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
5.2.21 Extended status register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
5.2.22 PHY specific function control register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
5.2.23 PHY specific status register — copper page . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
5.2.24 PHY specific status register — fiber page . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
5.2.25 Interrupt enable register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
5.2.26 Interrupt status register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
5.2.27 Smart speed register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
5.2.28 Cable diagnostic test control register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
5.2.29 LED control register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
5.2.30 Manual LED override register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
5.2.31 Copper/fiber status register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
5.2.32 Cable diagnostic test status register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
5.2.33 Debug port — address offset register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
5.2.34 Debug port — dataport register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
5.2.35 Chip configure register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Debug registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
5.3.1 Analog test control register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
5.3.2 SerDes test and system mode control register . . . . . . . . . . . . . . . . . . . . . . . . . 93
5.3.3 Hibernate control register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
5.3.4 100BASE-TX test mode select register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
5.3.5 External loopback selection register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
5.3.6 10BASE-Tetest mode select register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
5.3.7 PHY control debug register 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
5.3.8 Power saving control register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
5.3.9 Green feature configure 2 register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
MDIO interface registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
5.4.1 MMD3 — PCS control register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
5.4.2 MMD3 — PCS status register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
5.4.3 MMD3 — EEE capability register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
5.4.4 MMD3 — EEE wake error counter register . . . . . . . . . . . . . . . . . . . . . . . . . . 100
5.4.5 MMD3 — Cld control 3 register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
5.4.6 MMD3 — AZ control 2 register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
80-Y0618-2 Rev A
7
Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.4.7
5.4.8
5.4.9
5.4.10
5.4.11
5.4.12
5.4.13
5.4.14
5.4.15
5.4.16
5.4.17
5.4.18
5.4.19
5.4.20
5.4.21
5.4.22
5.4.23
Contents
MMD3 — PTP1588 control register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD3 — Internal MAC address 1 register . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD3 — Internal MAC address 2 register . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD3 — Internal MAC address 3 register . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD3 — RemotePHY loopback register . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD3 — SmartEEE control 1 register . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD3 — SmartEEE control 2 register . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD3 — SmartEEE control 3 register . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD7 — Auto-negotiation control register . . . . . . . . . . . . . . . . . . . . . . . . .
MMD7 — EEE advertisement register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD7 — EEE LP advertisement register . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD7 — EEE ability auto-negotiation result register . . . . . . . . . . . . . . . . .
MMD7 — SGMII control register 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD7 — SGMII control register 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD7 — SGMII control register 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD7 — SGMII control register 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MMD7 — CLK_25M clock select register . . . . . . . . . . . . . . . . . . . . . . . . . .
101
101
102
102
102
102
103
103
104
104
105
106
106
107
107
108
108
6
Package Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
7
Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
8
Top-side Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
80-Y0618-2 Rev A
8
Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Contents
Tables
Table 2-1 Signal to pin descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table 2-2 Not connected pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Table 2-3 Power-on strapping pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 2-4 Mode definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 3-1 AR8031, AR8033, and AR8035 comparison . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table 3-2 Transmit function encoder modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Table 3-3 Receive function decoder mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Table 3-4 Supported MDI pair combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Table 3-5 Default LED status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Table 3-6 BaseX LED status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Table 3-7 Management interface frame fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Table 3-8 Management interface field definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Table 4-1 Absolute maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table 4-2 Recommended operating conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table 4-3 RGMII DC characteristics — 2.5/3.3V I/O supply . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Table 4-4 RGMII DC characteristics — 1.8V I/O supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Table 4-5 RGMII DC characteristics — 1.5 I/O supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Table 4-6 RGMII AC characteristics — no internal delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Table 4-7 RGMII AC characteristics — with internal delay added (default) . . . . . . . . . . . . . . . 46
Table 4-8 Driver DC characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Table 4-9 Receiver DC characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Table 4-10 Driver AC characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Table 4-11 MDIO AC characteristic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Table 4-12 MDIO/MDC DC characteristic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Table 4-13 Recommended crystal parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Table 4-14 External clock input characteristic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Table 4-15 CLK_25M output characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Table 4-16 Power pin consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Table 4-17 Total system power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Table 4-18 Digital pin designs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Table 5-1 Register bit types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Table 5-2 Register summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Table 5-3 Debug register summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Table 5-4 MMD3 register summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Table 5-5 MMD7 register summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Table 6-1 Package dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Table 7-1 Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Table 8-1 Top-side markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
80-Y0618-2 Rev A
9
Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Contents
Figures
Figure 2-1 AR8033 48-pin QFN pinout (top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 3-1 Copper operating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 3-2 Fiber operating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 3-3 Media converter operating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 3-4 Digital loopback in copper mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 3-5 Digital loopback in fiber mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 3-6 External cable loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 3-7 Remote PHY loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 3-8 Fiber fault propagation or re-auto-negotiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 3-9 Reference design for LED, active high . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 3-10 Reference design for LED, active low . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 3-11 Reference design, 2.5/3.3 V RGMII I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Figure 3-12 Reference design, 1.5/1.8 V RGMII I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 3-13 CLK_25M timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 3-14 Operating states — 802.3az LPI mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 3-15 Operating power modes — 802.3az LPI mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Figure 3-16 WoL system application structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Figure 4-1 RGMII input timing diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Figure 4-2 RGMII output AC timing diagram with internal delay added . . . . . . . . . . . . . . . . . . 46
Figure 4-3 MDIO AC timing diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Figure 4-4 External crystal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Figure 4-5 Reset timing diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Figure 6-1 Packag view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Figure 8-1 Top-side markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
80-Y0618-2 Rev A
10 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
1 Introduction
The AR8033 Ethernet transceiver is a single port, 10/100/1000 Mbps tri-speed Ethernet PHY. The
AR8033 Ethernet transceiver supports both RGMII and SGMII to the MAC. The AR8033
Ethernet transceiver belongs to the Arctic™ PHY family which provides a low power, low BOM
cost solution for comprehensive applications including enterprise, carrier and home networks such
as CPE, home gateway, enterprise switch, carrier switch/router, mobile base station and base
station controller, optical module and media converter, industrial automation and measurement.
The AR8033 Ethernet transceiver integrates Green ETHOS® power saving technologies which
significantly save power in both active operation and idle condition. Green ETHOS power saving
schemes include ultra-low power in cable unplugged mode or port power down mode, as well as
automatically optimized power saving based on cable length. The AR8033 Ethernet transceiver
supports standard IEEE 802.3az Energy Efficient Ethernet (EEE) and Qualcomm Atheros
proprietary SmartEEE™. SmartEEE allows legacy MAC and SoC devices without IEEE 802.3az
support to cowork with AR8033 to provide full IEEE 802.3az support. Furthermore, the AR8033
Ethernet transceiver supports Wake-on-LAN (WoL) feature to manage and regulate total system
power requirements.
The AR8033 Ethernet transceiver embeds Cable Diagnostics Test (CDT) technology for
measuring cable length, detecting the cable status, and identifying remote and local PHY
malfunctions, bad or marginal patch cord segments or connectors.
The AR8033 Ethernet transceiver requires only a single 3.3 V power supply. Embedded regulators
are used to generate other required voltages. The AR8033 Ethernet transceiver integrates the
termination circuitry at the line side.
The AR8033 Ethernet transceiver incorporates a 1.25 Gbps SerDes. This interface can be
connected directly to a fiber-optic transceiver for 1000BASE-X/100BASE-FX mode or used as
SGMII with MAC.
The AR8033 Ethernet transceiver supports Synchronous Ethernet by offering recovered clock
output from data on the network-line side.
The AR8033 Ethernet transceiver supports IEEE 802.3az standard. The key features include:
10BASE-Te PHY uses reduced transmit amplitude.
100BASE-TX and 1000BASE-T use Low Power Idle (LPI) mode to turn off unused analog
and digital blocks to save power when data traffic is idle.
1.1 Features
10BASE-Te/100BASE-TX/1000BASE-T IEEE 802.3 compliant
80-Y0618-2 Rev A
11 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Introduction
1000BASE-T PCS and auto-negotiation with next page support
RGMII or SGMII to MAC devices
Fiber and copper combo mode when MAC interface works in RGMII mode
Additional IEEE 1000BASE-X and 100BASE-FX with integrated SerDes
RGMII timing modes support internal delay and external delay on Rx path
Green ETHOS power saving modes with internal automatic DSP power saving scheme
IEEE 802.3az EEE
SmartEEE which allows legacy MAC and SoC devices without IEEE 802.3az support to
cowork with AR8033 to provide full IEEE 802.3az support
Wake-on-LAN (WoL) to detect magic packet and notify the sleeping system to wake up
Fully integrated digital adaptive equalizers, echo cancellers, and Near End Crosstalk (NEXT)
cancellers
Synchronous Ethernet with frequency selectable recovered clock output
Robust Cable Discharge Event (CDE) protection of ±6 kV
Robust operation over up to 140 meters of CAT5 cable
Automatic Channel Swap (ACS)
Automatic MDI/MDIX crossover
Automatic polarity correction
IEEE 802.3u compliant auto-negotiation
Jumbo frame support up to 10 KB (full-duplex)
Multiple loopback modes for diagnostics
Robust surge protection with ±750 V/line-to-line mode and ±4 kV/line-to-ground mode
IEC61000-4-5(2001)
Cable Diagnostic Test (CDT)
Single power supply: 3.3 V, optional for external regulator for core voltage
6 mm × 6 mm, 48-pin QFN package
Industry temperature (I-temp) option available
80-Y0618-2 Rev A
12 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Introduction
1.2 Functional block diagram
DAC
Waveshape
filter
Symbol
encoder
Echo
canceller
PMA
Hybrid
circuit
PGA
ADC
Decision
feedback
equalizer
Next
canceller
Feed
forward
equalizer
RGMII
Symbol
decoder
Deskewer
Trellis
decoder
SGMII/
Serial
SerDes
interface
AGC
Timing and
phase
recovery
DLL
Auto-negotiation
RGMII
Sync-E
MII management
register
PCS
MDIO
MDC
MDIO
80-Y0618-2 Rev A
13 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
2 Pin Descriptions
This section includes a package pinout and signal descriptions.
Nomenclatures for signal names
NC
No signal connection from this pin
_n
Signal name suffix indicating active low signals
_P
Signal name suffix indicating the positive side of a differential signal
_N
Signal name suffix indicating the negative side of a differential signal
Nomenclatures for signal types
D
Open drain
IA
Analog input signal
I
Digital input signal
I/O
Digital bidirectional signal
OA
Analog output signal
O
Digital output signal
P
Power or ground signal
PD
Internal pull-down for input
PU
Internal pull-up for input
80-Y0618-2 Rev A
14 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Pin Descriptions
MDIO
DVDDL
SIP
SIN
AVDDL
SOP
SON
SD
WOL_INT
TXD3
TXD2
TXD1
2.1 Pinout diagram
48
47
46
45
44
43
42
41
40
39
38
37
MDC
1
36 TXD0
RSTn
2
35 GTX_CLK
LX
3
34 TX_EN
VDD33
4
33 RX_CLK
INT
5
XTLO
6
XTLI
7
AVDDL
8
RBIAS
9
AR8033
32 RX_DV
QFN 48-pin
Top View
31 RXD0
30 RXD1
29 VDDIO_REG
28 RXD2
Exposed Ground Pad on Bottom
VDDH_REG 10
27 RXD3
Figure 2-1
14
15
16
17
18
19
20
21
22
23
24
TRXN2
AVDDL
TRXP3
TRXN3
NC
LED_ACT
LED_1000
AVDDL
13
TRXP2
25 CLK_25M
AVDD33
TRXN0 12
TRXN1
26 LED_10_100
TRXP1
TRXP0 11
AR8033 48-pin QFN pinout (top view)
An exposed ground pad is on the back side of the package.
NOTE
2.2 Pin descriptions
Table 2-1
Signal to pin descriptions
Symbol
Pin
Type
Description
MDI
80-Y0618-2 Rev A
15 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 2-1
Pin Descriptions
Signal to pin descriptions (cont.)
Symbol
Pin
Type
Description
TRXP0
11
IA, OA
Media-dependent interface 0, differential 100 Ω transmission line
TRXN0
12
TRXP1
14
IA, OA
Media-dependent interface 1, differential 100 Ω transmission line
TRXN1
15
TRXP2
17
IA, OA
Media-dependent interface 2, differential 100 Ω transmission line
TRXN2
18
TRXP3
20
IA, OA
Media-dependent interface 3, differential 100 Ω transmission line
TRXN3
21
RGMII
GTX_CLK
35
I, PD
RGMII transmit clock, 125 MHz @ 1000 Mbps, 25 MHz @ 100 Mbps,
and 2.5 MHz @ 10 Mbps digital clock input. Adding a 22 Ω damping
resistor is recommended near MAC side.
RX_CLK
33
I/O, PD
RGMII receive clock, 125 MHz @1000 Mbps, 25 MHz @ 100 Mbps,
and 2.5 MHz @ 10 Mbps digital clock output. Adding a 22 Ω damping
resistor is recommended near PHY side.
Power-on strapping input
RX_DV
32
I/O, PD
RGMII receive data valid, RGMII output. Adding a 22 Ω damping
resistor is recommended near PHY side.
Power-on strapping input
RXD0
31
I/O, PD
RGMII receive data 0, RGMII output. Adding a 22 Ω damping resistor
is recommended near PHY side.
Power-on strapping input
RXD1
30
I/O, PD
RGMII receive data 1, RGMII output. Adding a 22 Ω damping resistor
is recommended near PHY side.
Power-on strapping input
RXD2
28
I/O, PD
RGMII receive data 2, RGMII output. Adding a 22 Ω damping resistor
is recommended near PHY side.
Power-on strapping input
RXD3
27
I/O, PD
RGMII receive data 3, RGMII output. Adding a 22 Ω damping resistor
is recommended near PHY side.
Power-on strapping input
TX_EN
34
I, PD
RGMII transmit enable, RGMII input
TXD0
36
I, PD
RGMII transmit data 0, RGMII input
TXD1
37
I, PD
RGMII transmit data 1, RGMII input
TXD2
38
I, PD
RGMII transmit data 2, RGMII input
TXD3
39
I, PD
RGMII transmit data 3, RGMII input
80-Y0618-2 Rev A
16 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 2-1
Pin Descriptions
Signal to pin descriptions (cont.)
Symbol
Pin
Type
Description
SIP
46
IA
SIN
45
1.25 Gbps transmit differential inputs
When this interface is used as a MAC interface, the MAC transmitter
positive output connects to SIP and the MAC transmitter negative
output connects to the SIN.
When this interface is used as a fiber interface, the fiber-optic
transceiver positive output connects to the SIP and the fiber-optic
transceiver negative output connects to the SIN.
SOP
43
OA
SON
42
1.25 Gbps receive differential outputs
When this interface is used as a MAC interface, the MAC receiver
positive input connects to SOP and the MAC receiver negative input
connects to the SON.
When this interface is used as a fiber interface, the fiber-optic
transceiver positive input connects to the SOP and the fiber-optic
transceiver negative input connects to the SON.
SD
41
IA
Signal detect. 1.2 V voltage level. Input signals must not exceed
1.4 V.
High indicates that input signal is valid. Because signal detect is
integrated in SerDes, this pin can be left NC.
SGMII/1000BX
Management interface
MDC
1
I, PU
Management data clock reference
MDIO
48
I/O, D,
PU
Management data, 1.5 kΩ pull-up resistor to 3.3 V/2.5 V
LED_ACT
23
I/O, PU
Parallel LED output for 10BASE-Te/100BASE-TX/1000BASE-T
(copper) and 100BASE-X/1000BASE-X (fiber) activity; LED active
based on power-on strapping.
If pulled up, active low; if pulled down, active high.
LED_1000
24
I/O, PU
Parallel LED output for 1000BASE-T (copper) and 1000BASE-X
(fiber) link; LED active based on power-on strapping.
If pulled up, active low; if pulled down, active high.
LED_10_100
26
I/O, PU
Parallel LED output for 10BASE-Te/100BASE-TX (copper) and
100BASE-FX (fiber) link. LED active based on power-on strapping of
LED_1000.
If LED_1000 is pulled up, this pin is active low; if LED_1000 is pulled
down, this pin is active high.
LED
External PU
External PD
High
10 Mbps
Low
100 Mbps
Low
10 Mbps
High
100 Mbps
For detailed information of LED, see “LED interface” on page 31.
System signal group/reference
CLK_25M
25
O
Synchronous Ethernet recovered clock (25 MHz, 50 MHz, 62.5 MHz,
or 125 MHz) output, frequency can be configured by register.
80-Y0618-2 Rev A
17 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 2-1
Pin Descriptions
Signal to pin descriptions (cont.)
Symbol
Pin
Type
Description
RSTn
2
I
System reset, active low. This pin requires an external pull-up resistor
to 2.5 V or 3.3 V.
XTLI
7
IA
Crystal oscillator input; typical 27 pF capacitor to GND. Support
external 25 MHz 1.2 V swing clock input through this pin.
XTLO
6
OA
Crystal oscillator output; typical 27 pF capacitor to GND
RBIAS
9
OA
External 2.37 kΩ 1% resistor to GND to set bias current
INT
5
I/O, D,
PD
System interrupt output. This pin is OD-gate by default and requires
external 10 kΩ pull-up resistor, active low.
WOL_INT
40
D, PD
Wake-on-LAN interrupt output. This pin is OD-gate by default and
requires external 10 kΩ resistor pull-up. See “Wake-on-LAN” on
page 40 for details.
LX
3
OA
Power inductor pin. Add an external 4.7 µH/500 mA power inductor to
this pin directly.
VDDH_REG
10
OA
2.5 V internal regulator output. Adding a 1 µF capacitor parallel with
this pin and GND is recommended.
VDDIO_REG
29
OA
Regulator output for the RGMII I/O voltage. It can be either 1.5 V
(default) or 1.8 V. If 2.5 V is intended for the RGMII I/O, connect this
pin with the 2.5 V regulator output at pin 10 (VDDH_REG).
AVDDL
8, 13,
19,
44
P
1.1 V analog input. Connect to pin 47 through a bead.
DVDDL
47
P
1.1 V digital core power input. Connect to power inductor directly and
10 µF+0.1 µF ceramic capacitors to GND.
VDD33
4
P
3.3 V input for internal switching regulator
AVDD33
16
P
3.3 V input for PHY, from VDD33 through a bead
Power
In the Type column, PU and PD indicates the pin includes internal weak pull-up and pull-down resistor
respectively.
Table 2-2
Not connected pin
Symbol
NC
Pin
22
2.3 Power-on strapping
Table 2-3 lists the pin-to-PHY core power-on strapping configurations.
80-Y0618-2 Rev A
18 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 2-3
Pin Descriptions
Power-on strapping pins
PHY pin
PHY core
configuration signal
RXD0
PHYADDRESS0
RXD1
PHYADDRESS1
LED_ACT
PHYADDRESS2
Description
Default
internal weak
pull-up/down
LED_ACT and RXD[1:0] set the lower
three bits of the physical address. The
upper two bits of the physical address are
set to 00.
1
0
0
RX_DV
MODE[0]
Mode select bit 0
0
RXD2
MODE[1]
Mode select bit 1
0
RX_CLK
MODE[2]
Mode select bit 2
0
RXD3
MODE[3]
Mode select bit 3
0
An external 10 kΩ pull-down resistor is
required.
1
LED_1000
External interrupt
select
1. 0 = Pull-down, 1 = Pull-up.
2. Power-on strapping pins are latched during power-up reset or warm hardware reset.
3. Because the MAC device input pins can be driven high or low during power-up or reset, PHY power-on
strapping status can be affected by the MAC side. In this case, an external 10 kΩ pull-down or pull-up
resistor is required to ensure stable status.
2.3.1
Mode definition
Table 2-4 lists the mode definition.
Table 2-4
Mode definition
Mode [3:0]
Description
0000
10BASE-Te/100BASE-TX/1000BASE-T, RGMII
0001
10BASE-Te/100BASE-TX/1000BASE-T, SGMII
0010
1000BASE-X, RGMII, 50 Ω
0011
1000BASE-X, RGMII, 75 Ω
0100
Converter mode between 1000BASE-X and 1000BASE-T media, 50 Ω
0101
Converter mode between 1000BASE-X and 1000BASE-T media, 75 Ω
0110
100BASE-FX, RGMII, 50 Ω
0111
Converter mode between 100BASE-FX and 100BASE-TX media, 50 Ω
1011
Copper/fiber auto-detection, RGMII
1110
100BASE-FX, RGMII mode, 75 Ω
1111
Converter mode between 100BASE-FX and 100BASE-TX media, 75 Ω
Others
Reserved
The 50 Ω (typical) or 75 Ω is the single-ended output impedance.
80-Y0618-2 Rev A
19 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
3 Function Description
The AR8033 Ethernet transceiver is an low cost GbE PHY. The highly integrated Analog Front
End (AFE) and Digital Signal Processing (DSP) architecture ensures robust performance
combined with substantial cost reduction. The AR8033 Ethernet transceiver provides physical
layer functions for half/full-duplex 10BASE-Te, 100BASE-TX and full-duplex 1000BASE-T
Ethernet to transmit and receive high-speed data over standard Category 5 (CAT5) un-shielded
twisted pair cable.
The AR8033 10/100/1000 PHY is fully IEEE 802.3ab compliant, and supports Reduced Gigabit
Media-Independent Interface (RGMII) to connect to a Gigabit-capable MAC.
The AR8033 Ethernet transceiver combines echo canceller, Near End Cross Talk (NEXT)
canceller, feed-forward equalizer, joint Viterbi, feedback equalizer, and timing recovery, to
enhance signal performance in noisy environments.
Table 3-1 lists feature comparison among the AR8031, AR8033, and AR8035 family.
Table 3-1
AR8031, AR8033, and AR8035 comparison
Feature
AR8031
AR8033
AR8035
RGMII
Yes
Yes
Yes
SGMII
Yes
Yes
–
Cu Ethernet(2)
Yes
Yes
Yes
EEE (IEEE 802.3az)
Yes
Yes
Yes
Wake-on-LAN
Yes
Yes
Yes
SerDes/Fiber(3)
Yes
Yes
–
1588v2
Yes
–
–
Sync-E
Yes
Yes
–
48-pin
48-pin
40-pin
Packaging
1. AR8031 and AR8033 are pin-to-pin compatible.
2. 10BASE-Te, 100BASE-TX, and 1000BASE-T are supported.
3. 100BASE-FX and 1000BASE-X are supported.
80-Y0618-2 Rev A
20 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
3.1 Operation modes
3.1.1
Copper
Figure 3-1 shows the copper operating mode for AR8033.
SoC or
switch
AR8033
Transformer
MAC interface
- RGMII
- SGMII
Figure 3-1
RJ-45
Media types:
- 10BASE-Te
- 100BASE-TX
- 1000BASE-T
Copper operating mode
SGMII is serial GMII with significantly less signal pins than required for GMII to connect with
MAC/SoC. After copper-side link is established, SGMII passes the copper-side link status (link,
speed, duplex) to MAC side for building the link. SGMII shares the same SerDes with the fiber
port.
MAC requires to configure RGMII (including speed, duplex and pause) according to PHY link
status.
The following ways can be used for MAC to get the information:
Through PHY specific status register — copper page (MII register offset 0x11)
Through interrupt function
Interrupt enable register (MII register offset 0x12) must be enabled and the interrupt status can
be retrieved in Interrupt status register (MII register offset 0x13). When the controller gets the
interrupt, check the interrupt source and link status in MII register 0x11.
Through inband status (RGMII)
Through auto-negotiation (SGMII)
For RGMII, by default AR8033 adds 2 ns delay for RX_CLK reference to RXD to meet the MAC
input setup and hold time. The MAC to PHY direction requires to add 2 ns typical delay of GTX_
CLK reference to TXD for PHY to capture the data.
3.1.2
Fiber
Figure 3-2 shows the fiber operating mode for AR8033.
80-Y0618-2 Rev A
21 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
SoC or
switch
AR8033
Fiber optics
Fiber I/F
- Serial
MAC interface
- RGMII
Figure 3-2
Media types:
- 100BASE-FX
- 1000BASE-X
Fiber operating mode
AR8033 supports both 1000BASE-X and 100BASE-FX modes configured by power-on strapping
pins (see “Power-on strapping” on page 18) or by bits[3:0] MODE_CFG of Chip configure
register. In fiber mode, the TRXP[3:0] and TRXN[3:0] pins can be left floated.
In MII registers, offset addresses (0x0, 0x1, 0x4, 0x5, 0x6, 0x7, 0x8 and 0x11) canbe used as either
copper page or fiber page.
For fiber mode, set 0x1F[15] = 0 to select fiber page. Then check the link status (including link,
speed, duplex and pause) in PHY specific status register — fiber page (MII register offset 0x11).
See “Copper” on page 21 for the other settings.
The fiber interface cannot auto-detect the link speed.
3.1.3
When set to 1000BASE-X mode, AR8033 works only in 1000 Mbps.
When set to 100BASE-FX mode, AR8033 works only in 100 Mbps.
Media Converter
Figure 3-3 shows the media converter operating mode for AR8033.
Fiber interface:
SerDes
AR8033
Media types:
- 100BASE-FX
- 1000BASE-X
Figure 3-3
Transformer
RJ-45
Media types:
- 100BASE-TX
- 1000BASE-T
Media converter operating mode
80-Y0618-2 Rev A
22 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
AR8033 supports the following converter modes:
100BASE-FX fiber to 100BASE-TX copper
1000BASE-X fiber to 1000BASE-T copper
The converter mode can be configured by power-on strapping pins (see “Power-on strapping” on
page 18) or by bits[3:0] MODE_CFG in Chip configure register. The register configuration takes
effect immediately. Three LEDs are used to indicate fiber interface status.
In converter mode, auto-negotiation is running independently on fiber and copper interfaces. The
link status can be checked from copper page and fiber page respectively.
Chip configure register
Bit[15]: BT_BX_REG_SEL
– 1 = Select copper page.
– 0 = Select fiber page.
Offset addresses (0x0, 0x1, 0x4, 0x5, 0x6, 0x7, 0x8 and 0x11) can be used as either fiber page or
copper page. See “Registers” on page 55 for details.
When the fiber and copper interfaces link up to the same speed, packets can go through the PHY.
When 1000M converter mode (BX1000_CONV) is enabled, the copper port can still link to 100M
with a 100M link partner, but packets cannot go through the PHY.
NOTE
Because the two interfaces implement auto-negotiation individually, the controller is
required to ensure that the duplex and pause of two remote link partners are matched.
In converter mode, the RGMII signal can be left floated.
3.1.4 Auto-Media Detect (Combo)
AR8033 supports auto-media detect feature which allows MAC to detect active link partners and
process data from copper or fiber interface according to the priority setting and link status. The
copper and fiber work modes can be enabled simultaneously by setting the mode bit to 1011 by
power-on strapping pin or bits[3:0] MODE_CFG in Chip configure register.
No fiber or cable connection: Both interfaces enter power saving mode.
Fiber connected: RGMII fiber mode. The PHY uses signal detection from SerDes along with
the synchronization state machine to recognize a valid connection.
Copper connected: RGMII copper mode. The PHY recognizes copper connection through
power transmitted over the copper line.
Combo mode: When active link partners over both fiber and copper are detected, the PHY
operation mode is defined by priority setting. Priority is configured by Chip configure register:
Bit[10]: PRIORITY_SEL
– 0 = Copper
80-Y0618-2 Rev A
23 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
– 1 = Fiber
In auto-media detect mode, fiber port can be configured to 1000BASE-X or 100BASE-FX by
Chip configure register:
Bit[8]: FIBER_MODE_AUTO
1 = 1000BASE-X (default)
0 = 100BASE-FX
3.2 Transmit functions
Table 3-2 lists the transmit function encoder modes.
Table 3-2
Transmit function encoder modes
Mode
Description
1000BASE-T
In 1000BASE-T mode, AR8033 scrambles Tx data bytes from the MAC interfaces and
encodes them into 4D five-level PAM signals over the four pairs of CAT5 cable.
100BASE-TX
In 100BASE-TX mode, 4-bit data from the MII is 4B/5B serialized, scrambled, and
encoded to a 3-level MLT3 sequence transmitted by the PMA.
10BASE-Te
In 10BASE-Te mode, AR8033 transmits and receives Manchester-encoded data.
3.3 Receive functions
3.3.1
Decoder modes
Table 3-3 lists the receive function decoder modes.
Table 3-3
Receive function decoder mode
Mode
Description
1000BASE-T
In 1000BASE-T mode, the PMA recovers the 4D PAM signals after accounting for the
cabling conditions such as skew among the four pairs, the pair swap order, and the
polarity of the pairs. The resulting code group is decoded into 8-bit data values. Data
stream delimiters are translated appropriately and data is output to the MAC interfaces.
100BASE-TX
In 100BASE-TX mode, the receive data stream is recovered and descrambled to align
to the symbol boundaries. The aligned data is then parallelized and 5B/4B decoded to
4-bit data. This output runs to the MII receive data pins after data stream delimiters have
been translated.
10BASE-Te
In 10BASE-Te mode, the recovered 10BASE-Te signal is decoded from Manchester
then aligned.
80-Y0618-2 Rev A
24 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
3.3.2
Function Description
Analog-to-Digital converter
Each Rx channel includes an advanced high speed ADC with high resolution for better Signal-toNoise Ratio (SNR) and lower error rates.
3.3.3
Echo canceller
Because hybrid circuit is used to transmit and receive simultaneously on each pair, echo occurs
when the transmitter is not perfectly matched to the line. Connector or cable imperfections, such as
patch panel discontinuity and variations in cable impedance along the twisted pair cable, can also
result in drastic SNR degradation on the Rx signal.
The adaptive digital echo canceller is used to compensate for the varied channel conditions that
result in SNR degradation on the Rx signal.
3.3.4
NEXT canceller
The 1000BASE-T physical layer uses all four twisted pairs to transmit data which incurs
significant high frequency crosstalk occurs between adjacent pairs.
Three parallel NEXT cancellers are thus integrated on each Rx channel to cancel high frequency
crosstalk by subtracting an estimate noise signals from the equalizer output.
3.3.5
Baseline wander canceller
Baseline wander occurs on Ethernet links AC-coupled to the transceiver. When the AC-coupling
cannot maintain voltage levels for a specific time, the transmitted pulses are distorted which
results in erroneous sampled values for affected pulses.
The baseline wander cancellation circuit continuously monitors and compensates for this issue,
minimizing the impact of DC baseline shift on the overall error rate.
3.3.6
Digital adaptive equalizer
The digital adaptive equalizer, using a combination of Feedforward Equalizer (FFE) and Decision
Feedback Equalizer (DFE), removes inter-symbol interference at the receiver by filtering
unequalized signals from ADC output for optimized SNR.
3.3.7 Auto-negotiation
The auto-negotiation function for 10BASE-Te/100BASE-TX/1000BASE-T Copper complies with
IEEE 802.3 clauses 28 and 40.
Auto-negotiation provides a mechanism to exchange information between a pair of link partners to
choose the optimized mode of operation in terms of speed, duplex modes, and master/slave
preference. Auto-negotiation is initiated upon any of the following scenarios:
Power-on reset
80-Y0618-2 Rev A
25 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Hardware reset
Software reset
Auto-negotiation restart
Transition from power-down to power-up
Link down
Function Description
When auto-negotiation is disabled, the operation speed mode can be manually selected using the
IEEE MII register 0.
NOTE
3.3.8
In 10BASE-Te/100BASE-TX, when one end disables auto-negotiation (force mode)
and the other end enables auto-negotiation (advertise half-duplex), the link can be
established and the end with auto-negotiation enabled works in half-duplex mode. So
if the end in force mode is in half-duplex mode, the information transmission between
the two link partners works normally; if the end in force mode is in full-duplex mode,
mismatch occurs between the two link partners. The link cannot be established in
1000BASE-T under similar situation.
Smartspeed
The Smartspeed function is an enhanced feature of auto-negotiation that allows the AR8033
device to downgrade in speed based on cabling conditions. With Smartspeed enabled, after a
configurable number (MII Register 14.4:2) of failed attempts, the PHY automatically downgrades
the highest ability it advertises to the next lower speed: from 1000 to 100 to 10.
The Smartspeed feature is enabled by default. See “Smart speed register” on page 85 for detailed
information.
Bit[5]: SMARTSPEED_EN
1 = Enables Smartspeed (default)
0 = Disables Smartspeed
Bits[4:2]: SMARTSPEED_RETRY_LIMIT
Sets the number of link attempts before adjusting
Bit[1]: BYPASS_SMARTSPEED_TIMER
Timer to determine the stable link condition
NOTE
3.3.9
The Smartspeed enable bit requires a software reset to take effect after writing bit[15]
in Control register — copper page (0x0) to 1. When Smartspeed function is disabled,
write bit[8] in Smart speed register (0x14) to 1, rather than change bit[9] in
1000BASE-T control register (0x9), to disable 1000BASE-T full-duplex link ability.
Automatic MDI/MDIX crossover
During auto-negotiation, the automatic MDI/MDIX crossover function automatically determines
and sets the required MDI configuration, eliminating the need for external crossover cable.
80-Y0618-2 Rev A
26 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
The algorithm described in IEEE 802.3 clause 40.4.4 ensures that only one device performs the
required crossover when the remote device implements automatic MDI crossover as well.
For 1000BASE-T, swap can happen only between pair A and pair B, or pair C and pair D. See
Table 3-4.
Table 3-4
3.3.10
Supported MDI pair combinations
A (1, 2)
B (3, 6)
C (4, 5)
D (7, 8)
Normal MDI
B (3, 6)
A (1, 2)
D (7, 8)
C (4, 5)
Normal MDI-X
A (1, 2)
B (3, 6)
D (7, 8)
C (4, 5)
Normal MDI with pair swap on C and D pair
B (3, 6)
A (1, 2)
C (4, 5)
D (7, 8)
Normal MDI-X with pair swap on C and D pair
Polarity correction
If cable polarity is incorrectly wired, the polarity correction function automatically corrects
polarity errors on the receive pairs in 1000BASE-T, 100BASE-TX, and 10BASE-Te modes.
3.4 Loopback modes
3.4.1
Digital loopback
Digital loopback loops transmitted data back to the receiver using digital circuit in the AR8033
device. Figure 3-4 and Figure 3-5 show the block diagrams for the digital loopbacks.
MAC/
switch
Figure 3-4
MAC/
switch
Figure 3-5
RGMII/
SGMII
PHY
digital
PHY
AFE
Digital loopback in copper mode
RGMII
PHY
digital
SerDes
Digital loopback in fiber mode
80-Y0618-2 Rev A
27 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
Configuring internal loopback
MII register settings for PHY internal digital loopback mode selection:
3.4.2
1000M loopback: register 0x0 = 0x4140
100M loopback: register 0x0 = 0x6100
10M loopback: register 0x0 = 0x4100
External cable loopback
MAC/
switch
Figure 3-6
RGMII/
SGMII
PHY
digital
PHY
AFE
RJ-45
External cable loopback loops RGMII/SGMII Tx to RGMII/SGMII Rx through complete digital
and analog path and an external cable. This function is used to test the digital data paths and the
analog circuits. Figure 3-6 shows a block diagram of external cable loopback.
External cable loopback
Configuring external cable loopback
To configure external cable loopback:
1. Plug in an external loopback cable (1 wiring 3, 2 wiring 6, 4 wiring 7, and 5 wiring 8).
2. Set bit[15] PS_HIB_EN of External loopback selection register (Debug Register offset 0xB) to
0 to disable hibernate (power saving) mode.
3. Set bit[0] EXT_LPBK of External loopback selection register (Debug Register offset 0x11) to
1 to enable external loopback.
4. Set MII Register 0x0 to select loopback modes:
1000M loopback: register 0x0 = 0x8140
100M loopback: register 0x0 = 0xA100
10M loopback: register 0x0 = 0x8100
NOTE
When cable is removed and reconnected to 1000M mode, the register 0x0 must be
configured to 0x8140 again to establish PHY link.
80-Y0618-2 Rev A
28 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
3.4.3 Remote PHY loopback
In remote PHY loopback mode, the data from MDI Rx is looped back to MDI Tx to enable the
remote link partner to detect the connectivity in the loop.
MAC/
switch
Figure 3-7
RGMII/
SGMII
PHY
digital
PHY
AFE
RJ-45
Figure 3-7 shows the block diagram of the remote PHY loopback.
Remote PHY loopback
Configuring remote PHY loopback
To enable remote PHY loopback, set bit[0] of MMD3 — RemotePHY loopback register (MMD3
Register offset 0x805A) to 1.
NOTE
When remote loopback is enabled, packets from link partner still appear at RGMII.
3.5 Cable diagnostic test
The Cable Diagnostic Test (CDT) feature uses Time Domain Reflectometry (TDR) technology to
identify malfunctions in remote and local PHYs, bad or marginal cable, patch cord segments and
connectors.
The following are the problems that can be possibly diagnosed using CDT:
Open
Short
Cable impedance mismatch
Bad connector
Termination mismatch
Bad magnetic
The CDT can be performed when no link partner is present or the link partner is auto-negotiating.
Configuring CDT
To perform the cable diagnostic test:
80-Y0618-2 Rev A
29 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
1. Set bits[9:8] MDI PAIR SELECT of Cable diagnostic test control register (offset 0x16) to
select the MDI pair to be tested.
2. Set bit[0] ENABLE TEST of Cable diagnostic test control register (offset 0x16) to 1 to enable
CDT.
3. Check bits[9:8] STATUS of Cable diagnostic test status register (offset 0x1C) for cable status.
4. Check bits[7:0] DELTA_TIME of Cable diagnostic test status register (offset 0x1C) for delta
time. The distance between the faulty point and PHY is [delta time] × 0.824.
3.6 Fiber mode support
Besides standard 10/100/1000 BASE-T copper port support, AR8033 provides additional IEEE
1000BASE-X and 100BASE-FX support in fiber applications through integrated SerDes. AR8033
can work in RGMII mode to fiber, 100BASE-FX to 100BASE-TX, and 1000BASE-X to
1000BASE-T.
Besides 1000BASE-X and 100BASE-FX support, AR8033 supports IEEE 802.3 remote Fault
Indication and Fault Propagation in fiber application.
3.6.1
IEEE 802.3 remote fault indication support
Remote Fault allows stations on a fiber optic link to detect when a problem occurs on the link.
Without Remote Fault, a station cannot detect a problem that affects only one fiber such as
transmit direction fiber.
With Remote Fault, the loss of a Receive signal (Link) causes the transmitter to send a special
pattern of data indicating that a fault has occurred. 84 “1”s followed by a single “0” is sent three
times, in-band, and is readily detectable by the remote station. This data is constructed not to
satisfy the 100BASE-X carrier sense criterion, so the message is not interpreted as normal traffic.
If the remote station has Remote Fault, the link is dropped. If the remote station does not have
Remote Fault, the special data pattern is ignored.
AR8033 indicates whether or not a Remote Fault pattern has been received from the remote station
using the Remote Fault Status Bit. This Remote Fault Status Bit can be Propagated (see “Fault
propagation” on page 30) to the copper links on both ends of a fiber link. In case of a detected
fault, both ends of the link can be notified of the failure in this way. This is particularly useful
given that the distances fiber links are generally used over.
3.6.2
Fault propagation
In the converter (Fiber to Copper) application, the AR8033 supports the fault propagation
function. This function allows the fault in the Fiber link to be propagated to the twist-pair
connection and enables both sides of PC or router to detect the link down status. With link fault
propagation, system administrators can notice the link failure within a short period of time,
minimizing the loss caused by this problem.
To process fault propagation for 1000BASE-X providing that the two PHYs are both AR8033 in
converter mode:
80-Y0618-2 Rev A
30 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
1. 1000BASE-X restarts auto-negotiation when the Rx path of fiber on media converter-A
detects no signal or is link down.
2. If converter-A fiber keeps link down for about 40 ms, converter-A copper is shut off.
3. Because of fiber of converter-A in auto-negotiation, fiber of converter-B is also link down.
4. If converter-B fiber keeps link down for about 40 ms, converter-B copper is shut off.
To process fault propagation for the 100BASE-FX providing that the two PHYs are both AR8033
in converter mode:
1. The copper is shut off when the Rx path of fiber on media converter-A detects no signal or is
link down for about 40 ms.
2. The media converter-A sends Far-End-Fault message back on Tx fiber to alert right media
converter-B of link loss when the Rx path of its Fiber detects no signal or is link down.
3. The converter-B fiber is link down.
4. The copper is shut off after fiber of converter-B keeps link down for about 40 ms.
Figure 3-8 shows the Fiber Fault mechanism.
TwistedPair
Fiber
Fiber
Far-End-Fault or
Re-auto negotiation
TwistedPair
OFF
RX
TX
RX
TX
TX
RX
TX
RX
OFF
Figure 3-8
Fiber fault propagation or re-auto-negotiation
3.7 LED interface
The LED interface can be controlled by the PHY or manually, independent of the state of the PHY.
The LED pins can be programmed to indicate the following status:
Operation speed
Traffic mode
Link
Figure 3-9 and Figure 3-10 show the reference designs for the LED interface.
80-Y0618-2 Rev A
31 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
AR8033
510 ohm
LED_ACT
470 pF
Figure 3-9
10 kohm
Reference design for LED, active high
VDDH_REG
AR8033
3.3 V
10 kohm
510 ohm
LED_ACT
470 pF
Figure 3-10
Reference design for LED, active low
The active status of LED_ACT and LED_1000 depends on power-on strapping mode. When the
interface is strapped high, the LED interface is active low; when strapped low, the LED interface is
active high.
The active status of LED_10_100 depends on LED_1000 power-on strapping mode and thus
LED_10_100 and LED_1000 use the same LED reference design.
The default LED functions are listed in Table 3-5.
Table 3-5
Default LED status
Symbol
10M link
10M active
100M link
100M active
1000M link
1000M active
LED_10_100
OFF
OFF
ON
ON
OFF
OFF
LED_1000
OFF
OFF
OFF
OFF
ON
ON
LED_ACT
ON
BLINK
ON
BLINK
ON
BLINK
ON = active; OFF = inactive
80-Y0618-2 Rev A
32 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
See Table 3-6 for LED status in RGMII to fiber mode.
Table 3-6
BaseX LED status
Symbol
100Mbps link
100Mbps active
1000Mbps link
1000Mbps active
LED_10_100
ON
ON
OFF
OFF
LED_1000
OFF
OFF
ON
ON
LED_ACT
ON
BLINK
ON
BLINK
ON = active; OFF = inactive
NOTE
In converter mode, the LEDs show the fiber port link and active status only.The LED_
1000 cannot be controlled manually. The LED_ACT and LED_10_100 can be
controlled by MII Registers 0x18 and 0x19.
3.8 Power supplies
One external power supply is required:
3.3 V
Internal power rails are:
3.3 V
2.5 V
1.1 V
1.8/1.5 V
AR8033 integrates a switch regulator to convert 3.3 V to 1.1 V with high efficiency for core power
rail.
Two embedded LDOs are integrated to support 2.5, 1.5/1.8 V RGMII I/O voltages. When working
at 2.5 V RGMII I/O, connect the VDDH_REG pin to VDDIO_REG pin directly. The 2.5 V to
1.5/1.8 V regulator can be set to any mode because the output voltage is same as input which
causes regulator shutdown. When working at 2.5 V RGMII I/O, AR8033 can connect with 3.3 V
RGMII I/O. Because the input can bear 3.3 V logic signal, the output logic VoH and VoL can
satisfy the 3.3 V LVCMOS/LVTTL requirements. See “Electrical Characteristics” on page 43 for
parameter details.
Figure 3-11 shows the reference design for 2.5/3.3 V RGMII voltage level.
80-Y0618-2 Rev A
33 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
0.1uF
4.7uH
10uF 0.1uF
LX
10uF 0.1uF
VDD33
AVDDL
DVDDL
0.1uF
VDDIO_REG
0.1uF
AR8033
2.5V/3.3V
RGMII
Bead
AVDDL
3.3 V
input
0.1uF
0.1uF
Bead
1uF
Figure 3-11
AVDDL
1uF
AVDD33
VDDH_REG
AVDDL
0.1uF
0.1uF
Reference design, 2.5/3.3 V RGMII I/O
When working at 1.5/1.8 V RGMII I/O, disconnect VDDH_REG and VDDIO_REG and set the
internal LDO to output the right voltage. The 1.5 V or 1.8 V selection is configured by bit[3] in
PHY control debug register 0 (debug register 0x1F).
Figure 3-12 shows the reference design for 1.5/1.8 V RGMII voltage level.
80-Y0618-2 Rev A
34 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
0.1uF
LX
10 uF 0.1uF
VDD33
AVDDL
DVDDL
0.1uF
4.7uH
10uF 0.1uF
Function Description
VDDIO_REG
1uF
AR8033
1.5/1.8V
RGMII
Bead
AVDDL
AVDDL
0.1uF
AVDD33
VDDH_REG
AVDDL
0.1uF
0.1uF
3.3 V
input
0.1uF
Bead
1uF
Figure 3-12
0.1uF
Reference design, 1.5/1.8 V RGMII I/O
3.9 Management interface
The management interface, compliance with IEEE 802.3u clause 22, provides access to the
internal registers of PHYs via the MDC and MDIO pins. MDC is sourced by the station
management entity to the PHY as the timing reference for transfer of information on the MDIO
signal.
MDIO is a bidirectional signal between the PHY and the STA. It is used to transfer control
information and status between the PHY and the STA. Control information is driven by the STA
synchronously with respect to MDC and is sampled synchronously by the PHY. Status information
is driven by the PHY synchronously with respect to MDC and is sampled synchronously by the
STA.
MDIO is an open-drain I/O and requires an external 1.5 kΩ pull-up resistor.
Table 3-7 and Table 3-8 describe the management interface format.
Table 3-7
Management interface frame fields
PRE
ST
OP
PHYAD
REGAD
TA
DATA
IDLE
80-Y0618-2 Rev A
35 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 3-7
Function Description
Management interface frame fields (cont.)
READ
1...1
01
10
AAAAA
RRRRR
Z0
DDDDDDDDDDDDDDDD
Z
WRITE
1...1
01
01
AAAAA
RRRRR
10
DDDDDDDDDDDDDDDD
Z
Table 3-8
Management interface field definitions
Field
Definition
PRE
A sequence of 32 contiguous single logic bits on MDIO with corresponding cycles on MDC to
provide PHY with a pattern for synchronization.
ST
2-bit start of frame
OP
2-bit operation code. 10 = read transaction, 01 = write transaction
PHYAD
5-bit PHY device address. The bits[2:0] in the PHY address are configured by power-on
strapping, thus eight PHYs can be connected to a single management interface. The PHYs
connected to the same bus have unique PHY addresses. The first PHY address bit transmitted
and received is the MSB of the address.
REGAD
5-bit register address. The 5-bit register address allows 32 registers to be addressed at each
PHY. The first register address bit transmitted and received is the MSB of the address.
TA
2-bit field to avoid contention during a read operation.
In read operation, both MAC and PHY are at high-impedance state for the first bit time. The PHY
drives a zero during the second bit time of the turnaround.
In write operation, the MAC must drive 10.
DATA
16-bit data from accessed register. MSB is transmitted first.
IDLE
High-impedance without driving state of the MDIO. At least one clocked idle state is required
between frames.
3.10 Timing synchronization
3.10.1
Synchronous Ethernet
Synchronous Ethernet (Sync-E) is a timing synchronization method implemented at the physical
layer.
The AR8033 transceiver supports synchronous Ethernet for 100BASE-TX and 1000BASE-T
applications by offering one recovered clock from the network line-side. This recovered clock
output (CLK_25M) can be configured to 25 MHz (default), 50 MHz, 62.5 MHz or 125 MHz, to
meet the ITU-T recommendations G.8261/Y.1361. The network node can use this recovered clock
to replace local clock sources and drive the local system. Therefore all distributed nodes in the
system use the same network clock to support synchronous and timing sensitive services like
T1/E1 service over Ethernet.
CLK_25M
Figure 3-13 shows the CLK_25M in reference to power-up and reset timing.
80-Y0618-2 Rev A
36 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
3.3V
Reset
CLK_25M
Figure 3-13
< 5ms
CLK_25M timing
When power is stable, CLK_25M is stable in 5 ms.
CLK_25M can output clock for system application. If not used, it can be left floated.
If used in synchronous Ethernet, CLK_25M is divided from the DSP clock recovered from the line
side; if not used in synchronous Ethernet or linked down, the 50, 62.5, or 125 MHz clock is
divided from PLL that references the local clock; the 25 MHz clock is from oscillator directly not
from PLL.
If CLK_25M output is used as a stable system reference, configure AR8033 to PLL ON mode by
setting bit[2] to 1 in PHY control debug register 0 (debug register 0x1F). In PLL OFF mode, when
entering hibernation mode, AR8033 shuts down internal PLL and thus causes CLK_25M output to
drop periodically. The 25 MHz clock does not drop periodically.
CLK_25M outputs 25 MHz clock from local crystal by default. When CLK_25 is configured to
output 50, 62.5 or 125 MHz clock, the output is reset to default 25 MHz after hardware reset.
See “MMD7 — CLK_25M clock select register” on page 108 for details.
In RGMII to fiber (1000BASE-X/100BASE-FX) mode, PHY recovers clock from received data.
This recovered clock is sent out from the RX_CLK pin. The RX_CLK pin can be used as Sync-E
recovered clock that is synchronous with the link partner output reference clock.
In 1000BASE-X mode, RX_CLK outputs 125 MHz; in 100BASE-FX mode, RX_CLK outputs
25 MHz.
NOTE
Clear to default value on hardware reset. If the fiber interface SerDes is not getting
any valid energy for about ten seconds, AR8033 enters hibernation mode (power
saving mode). In hibernation mode, RX_CLK is turned off. To enable RX_CLK to
always output valid clock, write MMD7 Register 0x8005[15] = 0 to turn off SerDes
hibernation mode.
80-Y0618-2 Rev A
37 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
3.11 Green ETHOS feature
3.11.1
Low power modes
The AR8033 device supports the low power mode with software power-down.
To enter the standard IEEE power-down mode, set the bit[11] POWER_DOWN of Control register
— copper page or Control register — fiber page to 1. In this mode, AR8033 ignores all MAC
interface signals except the MDC/MDIO and does not respond to any activity on the media side.
AR8033 cannot wake up on its own and is only waken up by setting the POWER_DOWN bit to 0.
3.11.2
Short cable power mode
Given cable length of less than 30 meters, Qualcomm Atheros proprietary Green ETHOS power
saving technology saves 25% power consumption over standard consumption on 100-meter CAT5
cable.
3.11.3
Hibernation mode
Hibernation mode yields very low power consumption compared with normal operation mode.
When cable is unplugged, AR8033 enters hibernation mode in about 10 seconds. When cable is
reconnected, AR8033 wakes up to restore normal function.
3.12 IEEE 802.3az
IEEE 802.3az provides a mechanism to reduce power consumption between data packets bursts.
Two operating states are supported: active state for normal data transfer, and Low Power Idle (LPI)
state for power saving between the data packet bursts.
The link partners enter LPI state by sending short refresh signals to maintain the link. In the lowpower state, PHY shuts down most of the analog and digital blocks. In Ethernet network where
systems stay in non-burst mode most of time, therefore over 90% power can be saved with LPI
enabled.
During link establishment, both link partners exchange information through auto-negotiation to
determine if both parties are LPI-capable.
Legacy Ethernet products are supported.
The link states for IEEE 802.3az include:
Active: Act in regular mode for transmitting or receiving data.
Sleep: Send specific signal to inform remote link partner of entering low-power state.
Quiet: No signal transmitted on media. Most of the analog and digital blocks are shut down.
80-Y0618-2 Rev A
38 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
Refresh: Periodically send specific training signal to maintain timing recovery and equalizer
coefficients.
Wake: Send specific wake-up signal to remote link partner to inform of entering Active state.
IEEE 802.3az LPI is supported on 100BASE-TX and 1000BASE-T.
100BASE-TX EEE allows asymmetrical operation that allows Tx or Rx to enter the LPI mode
independently.
1000BASE-T EEE requires symmetrical operation that both Tx and Rx must enter the LPI mode
simultaneously.
Figure 3-14 shows the IEEE 802.3az operating states for AR8033.
Operating states
Td
Active
Existing state used for data transmission. Data
packets or IPG/Idle symbols are transmitted
Active
Ts
Tq
Tw
Quiet
Wake
Quiet
Refresh
Refresh
Sleep
Quiet
Tr
New state used during periods of no data
transmission to allow system power reduction
between data packet bursts
Low-power
Td: Decision time, higher-layer control policy timing
Ts: Sleep time, Min. duration Sleep symbols sent before going to Quiet
Tq: Quiet duration, Max. duration PHY remains Quiet before Refresh
Tr: Refresh duration, Min. duration HY sends Refresh symbols
Tw: Wake time, Max. period to permit the receiving system to wake up
Figure 3-14
Operating states — 802.3az LPI mode
Figure 3-15 shows the IEEE 802.3az operating power modes for AR8033.
80-Y0618-2 Rev A
39 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
Low-power
Active
Active
Tr
Quiet
Wake
Quiet
Refresh
Figure 3-15
Tq
Refresh
Sleep
Active
Td Ts
Quiet
Active
Tw
Operating power modes — 802.3az LPI mode
3.13 SmartEEE
Qualcomm Atheros proprietary SmartEEE is compatible with IEEE 802.3az and allows legacy
MAC devices (without IEEE 802.az support) into systems providing full IEEE 802.3az support.
SmartEEE is enabled by default after power-on or hardware reset.
SmartEEE checks egress data flow at a specific interval to see if any packets being transmitted. If
no packet is detected, SmartEEE enters LPI mode. When packets come while the PHY is at LPI
mode, AR8033 takes 16.5 µs (typical) to wake up (as defined by IEEE 802.3az) and sends out the
data after the time configured in the register. AR8033 provides internal buffer for caching egress
data to ensure no packet loss before wakeup.
In SmartEEE mode, the RGMII Rx direction does not generate LPI pattern, thus only normal
packets and idle packets can appear on the RGMII. No Tx LPI pattern is generated for MACs
without EEE capability because LPI is generated inside PHY according to SmartEEE mechanism.
For MACs with EEE capability, SmartEEE control registers can be set to bypass SmartEEE
function MMD3 Register 0x805D[8].
NOTE
For typical application, adjusting the default register setting is not recommended.
The wait time before entering LPI mode is configured by MMD3 — SmartEEE control 2
register and bits[7:0] LPI_TIMER of MMD3 — SmartEEE control 3 register.
The wakeup time from LPI mode to sending out data can be configured by MMD3 —
SmartEEE control 1 register. This setting is used for collaboration with link partner for
customized purpose.
3.14 Wake-on-LAN
Wake-on-LAN (WoL) is a mechanism to manage and regulate the total network power
consumption. AR8033 supports the following WoL features:
Supports automatic detection of a specific frame and notification via dedicated hardware
interrupt pin. The specific frame contains a specific data sequence located anywhere inside the
packet. The data sequence consists of 6 bytes of consecutive 1 (0xFFFFFFFFFFFF), followed
80-Y0618-2 Rev A
40 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
by 16 repetitions of the MAC address of the computer to be waken up. The 48-bit MAC
address is written in MMD3 0x804A, 0x804B, 0x804C registers.
For example, to write a specific MAC address (0xAAAABBBBCCCC) to PHY, write MMD3
0x804A = 0xAAAA, 0x804B = 0xBBBB, and 0x804C = 0xCCCC. The PHY internal MAC
address can be set to any value.
The MAC address is not a real MAC address and is only a symbol to indicate the
content of the frame.
NOTE
Figure 3-16 shows the WoL system application structure.
MDC/MDIO
>=16*MAC address
INT
Controller
ARCTIC
PHY
WOL_INT
Written
MAC address
FF FF FF FF FF FF
MAC address
Fiber/copper
Same address
Figure 3-16
WoL system application structure
Two hardware pins can be used for triggering WoL interrupt:
Active low signal through the INT pin. When the interrupt bit in register 0x12[0] is set to
1, AR8033 generates interrupt at the reception of WoL packet.
Active with pulse width of 32 clock cycles through the WOL_INT pin at the reception of
WoL packet. Clock frequencies for different traffic rates are:
– 1000 Mbps: 125 MHz
– 100 Mbps: 25 MHz
– 10 Mbps: 2.5 MHz
For example, if the link speed is 1000 Mbps, the clock frequency is 125 MHz and the clock
cycle is 8 ns, the WoL is active with a 32 × 8 ns low pulse.
When WoL interrupt occurs, the bit[0] INT_WOL_PTP in Interrupt status register (MII Register
0x13) is set to 1. This bit is cleared after read operation.
When the bit[0] INT_WOL_PTP in Interrupt enable register is set to 1, the external INT pin is
triggered when interrupt occurs. When the bit[0] INT_WOL_PTP is cleared to 0, the external INT
pin cannot be triggered even when interrupt occurs.
NOTE
80-Y0618-2 Rev A
41 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Function Description
Because PHY requires to receive packets from the line side, PHY cannot be powered
down. If the link partner supports Energy Efficient Ethernet function, both ends can use
EEE mode to save more power.
In LPI mode, the controller can use WoL function to turn off unused circuits to save
power. When receiving WoL interrupt from PHY, the controller can wake up to work.
– Control register — copper page or Control register — fiber page (MII Register 0x0)
• Bit[10] ISOLATE: When this bit is set to 1, the RGMII output pins are tri-stated.
The RGMII inputs are ignored. This bit can be used to save more power of PHY in
system power saving mode. When receiving WoL packet, this bit is cleared
automatically.
The bit[5] WOL_EN in MMD3 — PTP1588 control register (MMD3 0x8012) is used to
enable or disable WoL function.
Programming INT work mode and active polarity
1. Power on by default configuration.
If INT is configured as interrupt function by power-on strapping (LED_1000 externally
pulled-down), INT is active low.
If LED_1000 is pulled-up, write MMD7 0x8016[12] = 1 to enable the interrupt function
for the INT pin.
2. Select INT polarity.
Write MMD7 0x801A[13] = 0 to set interrupt active high (by default the value is 1, active
low).
80-Y0618-2 Rev A
42 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
4 Electrical Characteristics
4.1 Absolute maximum ratings
Table 4-1 summarizes the absolute maximum ratings for the AR8033 Ethernet transceiver.
Absolute maximum ratings are those values beyond which damage to the device can occur.
Functional operation under these conditions, or at any other condition beyond those indicated in
the operational sections of this document, is not recommended.
Table 4-1
Absolute maximum ratings
Symbol
Max rating
Unit
3.3 V supply voltage
3.8
V
AVDDL
1.1 V analog supply voltage
1.6
V
DVDDL
1.1 V digital core supply voltage
1.6
V
-65 to 150
°C
VDD33/AVDD33
Parameter
Tstore
Storage temperature
HBM
Electrostatic discharge tolerance — human body model
±2000
V
MM
Machine model
±200
V
Supply voltage min
-0.3
V
Vmin
4.2 Recommended operating conditions
Table 4-2 lists the recommended operating conditions for the AR8033 Ethernet transceiver.
Table 4-2
Recommended operating conditions
Symbol
Parameter
Min
Typ
Max
Unit
VDD33/AVDD33
3.3 V supply voltage
3.15
3.3
3.45
V
VDDH_REG
2.5 V analog/digital
2.4
2.62
2.75
V
AVDDL/DVDDL
1.1 V analog/digital with on-chip
regulator
1.04
1.1
1.17
V
Tambient
Ambient temperature for normal
operation — Commercial chip
version AR8033-AL1A
0
–
70
°C
Ambient temperature for normal
operation — Industrial chip
version AR8033-AL1B
-40
–
85
°C
80-Y0618-2 Rev A
43 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 4-2
Electrical Characteristics
Recommended operating conditions (cont.)
TJ
ΨJT
Junction temperature
Thermal Dissipation Coefficient
-40
–
125
°C
–
3
–
°C/W
NOTE
External regulators are optional for supplying AVDDL/DVDDL. For industrial
version, external AVDDL/DVDDL inputs must be within the range of 1.2 V ± 5%.
For commercial version, external AVDDL/DVDDL inputs must be within the range of
1.1 V - 5% and 1.2 V + 5%.
NOTE
The following condition must be satisfied:
TJmax > TCmax + ΨJT × PTypical
Where:
TJmax = Maximum allowable junction temperature
TCmax = Maximum allowable case temperature
ΨJT =
Thermal dissipation coefficient
PTypical = Typical power dissipation
4.3 RGMII characteristics
Table 4-3 shows the RGMII DC characteristics with 2.5/3.3V I/O supply.
Table 4-3
RGMII DC characteristics — 2.5/3.3V I/O supply
Symbol
Parameter
Min
Max
Unit
IIH
Input high current
–
15
μA
IIL
Input low current
-15
–
μA
VIH
Input high voltage
1.7
3.5
V
VIL
Input low voltage
GND - 0.3
0.7
V
VOH
Output high voltage
2.4
2.8
V
VOL
Output low voltage
GND - 0.3
0.4
V
Min
Max
Unit
Table 4-4 shows the RGMII DC characteristics with 1.8 V I/O supply.
Table 4-4
RGMII DC characteristics — 1.8V I/O supply
Symbol
Parameter
VIH
Input high voltage
1.4
2.1
V
VIL
Input low voltage
GND - 0.3
0.4
V
80-Y0618-2 Rev A
44 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 4-4
Electrical Characteristics
RGMII DC characteristics — 1.8V I/O supply (cont.)
VOH
Output high voltage
1.5
1.9
V
VOL
Output low voltage
–
0.3
V
Min
Max
Unit
Table 4-5 shows the RGMII DC characteristics with 1.5 V I/O supply.
Table 4-5
RGMII DC characteristics — 1.5 I/O supply
Symbol
Parameter
VIH
Input high voltage
1.2
1.8
V
VIL
Input low voltage
GND - 0.3
0.3
V
VOH
Output high voltage
1.3
1.57
V
VOL
Output low voltage
–
0.2
V
Min
Typ
Max
Unit
Figure 4-1 shows the RGMII input AC timing diagram.
TXD[3:0], TX_EN
GTX_CLK
TsetupR
TsetupR
Figure 4-1
TholdR
TholdR
RGMII input timing diagram
Table 4-6 shows the RGMII input AC characteristics.
Table 4-6
Symbol
RGMII AC characteristics — no internal delay
Parameter
TsetupR
Data to clock input setup time (at receiver)
1.0
2.0
–
ns
TholdR
Data to clock input hold time (at receiver)
1.0
2.0
–
ns
1. If the transmitter side (MAC) does not add internal delay or PCB trace delay for GTX_CLK, the input
setup and hold time minimum must be within ±0.5 ns. GTX_CLK precise 2.4 ns delay can be added in
PHY internal by setting bit[8] RGMII_TX_CLK_DLY = 1 in SerDes test and system mode control register
(Debug Register 0x5).
2. For 1000BASE-T, both the rising and falling edges are used to sample the data.
3. For 10BASE-Te/100BASE-TX, only the rising edge is used to sample the data.
RX_CLK hardware reset adds typical 2 ns delay internally by default, so the MAC side has
sufficient setup and hold time for sampling. Figure 4-2 shows the RGMII output AC timing with
internal delay added diagram.
80-Y0618-2 Rev A
45 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Electrical Characteristics
RXC with
internal
delay added
RX_CLK
RXD[3:0], RX_DV
TsetupT
TholdR
Figure 4-2
RGMII output AC timing diagram with internal delay added
Table 4-7 shows the RGMII AC characteristics with delay added.
Table 4-7
RGMII AC characteristics — with internal delay added (default)
Symbol
Parameter
Min
Typ
Max
Unit
TsetupT
Data to clock output setup (at transmitter
— integrated delay)
1.2
2.0
–
ns
TholdT
Clock to data output hold (at transmitter
— integrated delay)
1.2
2.0
–
ns
1. RX_CLK delay can be disabled by setting bit[15] SEL_CLK125M_DSP = 0 in Analog test control register
(Debug Register 0x0).
2. If RX_CLK delay is disabled in PHY, the RX_CLK to RXD edge delay is within ±500 ps requiring the
MAC side to add internal delay or PCB trace delay.
4.4 SerDes and SGMII characteristics
Table 4-8 shows the Driver DC characteristics.
Table 4-8
Driver DC characteristics
Symbol
Parameter
Min
Typical
Max
Unit
Voh
Output voltage high
–
950
1050
mV
Vol
Output voltage low
500
650
–
mV
–
–
10
%
Vring
Output ringing
|Vod|
Output differential voltage
Vos
Output offset voltage
750
800
850
mV
Output impedance
(single-ended)
50ohm termination
40
50
60
ohm
Output impedance
(single-ended)
75ohm termination
60
75
90
ohm
Mismatch in a pair
–
–
10
%
Change in VOD between “0” and “1”
–
–
25
mV
Ro
Delta Ro
Delta VOD
Programmable
300 (default)
mV
80-Y0618-2 Rev A
46 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 4-8
Electrical Characteristics
Driver DC characteristics (cont.)
Symbol
Parameter
Delta Vos
Isa,Isb
Isab
Ixa,Ixb
Min
Typical
Max
Unit
Change in VOS between “0” and “1”
–
–
25
mV
Output current on short to GND
–
–
40
mA
Output current when a, b are shorted
–
–
12
mA
Power off leakage current
–
–
10
mA
Output differential voltage can be configured by register MMD7 0x8011 [15:13].
Table 4-9 shows the Receiver DC characteristics
Table 4-9
Receiver DC characteristics
Symbol
Parameter
Min
Typical
Max
Unit
730
825
930
mV
Vio
Internal offset voltage
Vih
Input single voltage high
–
1050
1150
mV
Vil
Input single voltage low
500
600
–
mV
Vidth
Input differential threshold
-50
–
+50
mV
Vhyst
Input differential hysteresis
25
–
–
mV
Receiver differential input impedance
50ohm termination
80
100
120
ohm
Receiver differential input impedance
75ohm termination
120
150
180
ohm
Min
Max
Unit
Rin
Table 4-10 shows the Driver AC characteristics.
Table 4-10
Driver AC characteristics
Symbol
Parameter
tfall
Vod fall time
(20%-80%)
100
200
ps
trise
Vod rise time
(20%-80%)
100
200
ps
–
20
ps
Tskew1
Skew between two members of a differential
pair
Skew measured at 50% of the transition.
4.5 MDIO timing
Figure 4-3 shows the MDIO AC timing diagram.
80-Y0618-2 Rev A
47 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Electrical Characteristics
tmdc
tmdch
tmdcl
VIH
VIL
MDC
VIH
MDIO
VIL
tmdsu
Figure 4-3
MDIO AC timing diagram
Table 4-11
MDIO AC characteristic
Symbol
Parameter
tmdhold
Min
Typ
Max
Unit
tmdc
MDC period
40
–
–
ns
tmdcl
MDC low period
16
–
–
ns
tmdch
MDC high period
16
–
–
ns
tmdsu
MDIO to MDC rising setup time
10
–
–
ns
tmdhold
MDIO to MDC rising hold time
10
–
–
ns
tmdelay
MDC to MDIO output delay
0
4
–
ns
Min
Max
Unit
4.6 MDIO/MDC DC characteristic
Table 4-12
MDIO/MDC DC characteristic
Symbol
Parameter
VOH
Output high voltage
2.4
–
V
VOL
Output low voltage
–
0.4
V
VIH
Input high voltage
1.7
–
V
VIL
Input low voltage
–
0.7
V
IIH
Input high current
–
0.4
mA
IIL
Input low current
-0.4
–
mA
80-Y0618-2 Rev A
48 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Electrical Characteristics
4.7 Clock characteristics
AR8033 supports both crystal and external clock input as reference. The basic principle for
selecting crystal and load capacitance is to make the oscillation stable at 25 MHz ± 50 ppm.
Crystal with 25 MHz ± 30 ppm frequency tolerance is preferred with two 27 pF NPO ceramic
capacitors. The capacitors can be changed according to actual crystal selection and board level test
results under full application temperature and voltage ranges.
XTLO
25 MHz
2
27 pF
XTLI
AR8033
1
3
27 pF
Figure 4-4
External crystal
Table 4-13
Recommended crystal parameters
Symbol
Parameter
Min
Typ
Max
Unit
–
25
–
MHz
-30ppm
–
+30ppm
MHz
Ff
Crystal fundamental frequency
Ft
Frequency tolerance
Cs
Shunt capacitance
–
7
–
pF
Cl
Load capacitance
–
15
–
pF
Vo
I/O voltage level (for drive level evaluation)
–
1.2
–
V
DL
Drive level
–
300
–
µW
ESR
Equivalent series resistance
–
30
50
Ω
Table 4-14
External clock input characteristic
Symbol
Parameter
T_XI_PER XI Clock Period
Min
Typ
Max
Unit
40.0 - 50ppm
40.0
40.0 + 50ppm
ns
T_XI_HI
XI Clock High
14
20.0
–
ns
T_XI_LO
XI Clock Low
14
20.0
–
ns
T_XI_RISE XI Clock Rise Time, VIL (max) to VIH (min)
–
–
4
ns
T_XI_FALL XI Clock Fall time, VIL (max) TO VIH (min)
–
–
4
ns
V_IH_XI
The XI input high level
0.8
1.2
1.5
V
V_IL_XI
The XI input low level voltage
-0.3
0
0.15
V
–
1
2
pF
CIN
Load capacitance
80-Y0618-2 Rev A
49 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 4-14
Electrical Characteristics
External clock input characteristic (cont.)
JitterRMS
Period broadband RMS jitter
–
–
15
ps
Jitterpk-pk
Period broadband peak to peak jitter
–
–
100
ps
Table 4-15
CLK_25M output characteristics
Symbol
Min
Typ
Max
Unit
-50ppm
25, 50, 62.5, 125
+50ppm
MHz
Output high voltage
2.3
2.62
2.8
V
Output low voltage
GND - 0.3
–
0.4
V
Clock period jitter (peak-to-peak)1)
–
680
–
ps
Clock cycle to cycle period jitter
(peak-to-peak)1)
–
400
–
ps
Frequency
1. Jitter characteristics is for 125 MHz output.
2. Jitter is broadband period jitter with 1000000 samples.
3. Output frequency stability depends on the crystal circuit oscillation frequency or input clock frequency
stability.
4. If CLK_25M is not used, it can be left floated. If it is used, external 22 Ω serial resistor is required for
signal integrity.
5. If it is used as a chip reference clock, pay attention to the input requirement, especially the jitter. For
reliable application such as Giga switch/PHY reference clock, a jitter attenuation circuit is required.
4.8 Power pin current consumption
Table 4-16 shows the current consumption for the power pins.
Table 4-16
Power pin consumption
Symbol
Voltage range
Current (max)
AVDDL
1.1 V ± 5%
50.8 mA
DVDDL
1.1 V ± 5%
113.7 mA
AVDD33
3.3 V ± 5%
63.8 mA
VDDIO_REG
Connect VDDH_REG 2.5 V
20.9 mA
4.9 Typical power consumption parameters
The following conditions apply to the typical characteristics unless otherwise specified:
80-Y0618-2 Rev A
50 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Electrical Characteristics
VCC = 3.3 V (1.1 V switching regulator integrated and 50 mW RGMII power included).
Table 4-17
Total system power
Symbol
Condition
Total current
(mA)
LED
consumption
(mA)
Total power
consumption
without LED (mW)
PLDPS
Link down, power saving mode
3
0
9.9
PPWD
Power down mode
7
0
23.1
1000BASE-T full-duplex line speed
120
2.7
396
1000BASE-T idle
105
4
346.5
100BASE-TX full-duplex line speed
30
3.5
99
100BASE-TX idle
29
4
95.7
10BASE-Te full-duplex line speed
25
1
82.5
10BASE-Te idle
5
1.5
16.5
RGMII + Copper mode
P1000F
P1000idle
P100F
P100idle
P10F
P10idle
RGMII + Copper mode 802.az enabled
P1000idle
1000BASE-T idle
18.5
4
61.1
P100idle
100BASE-TX idle
16.4
4
54.1
Qualcomm Atheros Proprietary Green ETHOS® Power Savings Per Cable Length
P1000F 20m
1000BASE-T full-duplex 20m cable
90
2.7
297
P1000idle 20m
1000BASE-T idle 20m cable
81
4
267.3
P1000F 100m
1000BASE-T full-duplex 100m cable
120
2.7
396
105
4
346.5
135
2.7
445.5
123
4
405.9
1000BASE-X full-duplex line speed
27
2.7
89.1
1000BASE-X idle
25
4
82.6
100BASE-FX full-duplex line speed
17
3.5
56
100BASE-FX idle
17
4
56
1000BASE-T to 1000BASE-X
full-duplex line speed
143
2.7
471.9
1000BASE-T to 1000BASE-X idle
134
4
442.2
100BASE-TX to 100BASE-FX
full-duplex line speed
38
3.5
125.4
100BASE-TX to 100BASE-FX idle
37
4
122.1
P1000idle 100m 1000BASE-T idle 100m cable
P1000F 140m
1000BASE-T full-duplex 140m cable
P1000idle 140m 1000BASE-T idle 140m cable
RGMII + Fiber mode
P1000F
P1000idle
P100F
P100idle
RGMII + Fiber Converter mode
P1000F
P1000idle
P100F
P100idle
80-Y0618-2 Rev A
51 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 4-17
Electrical Characteristics
Total system power (cont.)
Total current
(mA)
LED
consumption
(mA)
Total power
consumption
without LED (mW)
1000BASE-T full-duplex line speed
141
2.7
465.3
1000BASE-T idle
133
4
438.9
100BASE-TX full-duplex line speed
39
4
128.7
100BASE-TX idle
38
4
125.4
Symbol
Condition
SGMII + Copper mode
P1000F
P1000idle
P100F
P100idle
SGMII + Copper mode 802.3az enabled
P1000idle
1000BASE-T idle
27
4
89.1
P100idle
100BASE-TX idle
23
4
75.9
NOTE
Power consumption test results are based on the demo board.
4.10 Power-on sequence, reset and clock
4.10.1
Power-on sequence
AR8033 only requires a single 3.3 V power supply input. The 1.1 V core and 2.5 V, 1.8/1.5 V
voltages are generated by AR8033 internal regulators. So the AR8033 power-on sequence to
establish the power rails stability is met internally.
4.10.2
Reset and clock timing
The AR8033 hardware reset requires the clock to take effect. Input clock including the crystal and
external input clock must be stable for at least 1 ms before RESET can be de-asserted. For chip
reliability, an external clock must be input after the power-on sequence.
Figure 4-5 shows the reset timing diagram.
80-Y0618-2 Rev A
52 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Electrical Characteristics
3.3V
XI clock
Reset
Figure 4-5
NOTE
~
~
> 0ms
>= 1ms
>= 1ms
Reset timing diagram
When using crystal, clock is generated internally after the power is stable. To get
reliable power-on reset, keep asserting the reset low signal long enough to ensure that
the clock is stable and clock-to-reset (1 ms) requirement is satisfied.
4.11 Digital pin design guide
Table 4-18
Pin type
Digital pin designs
Pin description
Reset asserted
Reset de-asserted (Normal working level)
Input
TXD[3:0]
TX_EN
GTX_CLK
Input, internal weak PD
Input, based on RGMII I/O voltage level set
I/O
RXD[3:0]
RX_DV
RX_CLK
Input, internal weak PD
Output, based on RGMII I/O voltage level set
I/O
LED_1000
LED_ACT
LED_10_100
Input, internal weak PU
Output, 2.5 V (VDDH_REG)
Input
MDC
Input, internal weak PU
Input, 2.5 V (3.3 V tolerant)
I/O
MDIO
Input, internal weak PU
I/O, 2.5 V (3.3 V tolerant)
Input
RSTn
Input, no weak PU
Input, 2.5 V (3.3 V tolerant)
Output
INT
WOL_INT
Output, kept driving low
Open drain output (default), based on external
PU voltage level
Output
CLK_25M
Output, output clock
Output, 2.5 V (VDDH_REG)
80-Y0618-2 Rev A
53 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 4-18
Pin type
Electrical Characteristics
Digital pin designs (cont.)
Pin description
Reset asserted
Reset de-asserted (Normal working level)
Output
PPS
Output, kept driving high
2.5 V (VDDH_REG), internal RTC clock output
Input
SD
Input, weak PD
Input, VIH min = 0.7 V, VIL max = 0.4 V. Input
must be lower than 1.4 V.
1. When MDC/MDIO/RESET acts as an input, VIH min is 1.7 V, VIL max is 0.7 V, thus the chip
supports 2.5/3.3 V LVTTL/LVCMOS level signal input.
2. Power-on strapping pins are input when reset is asserted. They are output during normal
operation. External pull-up to VDDIO_REG for RGMII signal, and to 2.5 V (VDDH_REG)
for LED are recommended.
3. RESET and MDIO can be pulled up to 2.5 V (VDDH_REG) or 3.3 V.
4. SD is a backup solution used for signal detection. Because AR8033 integrates the signal
detection function in SerDes, leaving the pin floated is recommended. When the pin is pulled
high, valid signal is detected; when pulled low, no valid signal is detected.
80-Y0618-2 Rev A
54 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
5 Registers
Three types of registers are present on AR8033:
IEEE defined 32 MII registers, referred to as “MII Registers” in this document
MII registers are accessed directly through the management frame.
Debug registers defined by Qualcomm Atheros, referred to as “Debug Registers” in this
document
Write the offset address of debug register to 0x1D.
Read/write the data from/to 0x1E.
IEEE defined MDIO Manageable Device (MMD) register, referred to as “MDIO Interface
(MMD3/MMD7) Registers” in this document
MMD registers are accessed by reading/writing MMD access control register (MII register
0xD) and MMD access data register (MII register 0xE).
Example: Writing 0x8000 to register 0x0 of MMD3
1. Write 0x3 to MII register 0xD to set the device address of the MMD register.
2. Write 0x0 to MII register 0xE to set the offset address of the MMD register.
3. Write 0x4003 to MII register 0xD to keep the device address.
4. Read MII register 0xE to check the data from register 0x0 of MMD3.
5. Write 0x8000 to MII register 0xE, that is register 0x0 of MMD3.
NOTE
Read operation follows the process 1 to 4.
5.1 Register bit type
Table 5-1 shows the register bit types.
Table 5-1
Type
Register bit types
Description
LH
Register field with latching high function. If status is high, then the register is set to one and
remains set until a read operation is performed through the management interface or a reset
occurs.
LL
Register field with latching low function. If status is low, then the register is cleared to a zero and
remains cleared until a read operation is performed through the management interface or a
reset occurs.
80-Y0618-2 Rev A
55 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 5-1
Registers
Register bit types (cont.)
Type
Description
Retain
Value written to a register field takes effect without a software reset.
SC
Self-clear. Writing a one to this register causes the desired function to execute immediately, and
the register field clears to zero when the function is complete.
Update
The value written to the register field does not take effect until a software reset is executed. The
value can still be read after it is written.
5.2 MII registers
Table 5-2
Register summary
Offset
Register
0x00
“Control register — copper page” on page 57
“Control register — fiber page” on page 58
0x01
“Status register — copper page” on page 60
“Status register — fiber page” on page 61
0x02
“PHY identifier 1 register” on page 63
0x03
“PHY identifier 2 register” on page 63
0x04
“Auto-negotiation advertisement register — copper page” on page 64
“Auto-negotiation advertisement register — fiber page” on page 66
0x05
“Auto-negotiation link partner ability register — copper page” on page 67
“Auto-negotiation link partner ability register — fiber page” on page 69
0x06
“Auto-negotiation expansion register — copper page” on page 70
“Auto-negotiation expansion register — fiber page” on page 70
0x07
“Auto-negotiation next page transmit register — copper page” on page 71
“Auto-negotiation next page transmit register — fiber page for 1000BASE-X, SGMII” on
page 72
0x08
“Auto-negotiation link partner next page register — copper page” on page 72
“Auto-negotiation link partner next page register — fiber page for 1000BASE-X, SGMII” on
page 73
0x09
“1000BASE-T control register” on page 74
0x0A
“1000BASE-T status register” on page 76
0x0B
Reserved
0x0C
Reserved
0x0D
“MMD access control register” on page 77
0x0E
“MMD access data register” on page 77
0x0F
“Extended status register” on page 77
0x10
“PHY specific function control register” on page 78
0x11
“PHY specific status register — copper page” on page 79
“PHY specific status register — fiber page” on page 81
80-Y0618-2 Rev A
56 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 5-2
Registers
Register summary (cont.)
Offset
Register
0x12
“Interrupt enable register” on page 82
0x13
“Interrupt status register” on page 83
0x14
“Smart speed register” on page 85
0x15
Reserved
0x16
“Cable diagnostic test control register” on page 86
0x17
Reserved
0x18
“LED control register” on page 86
0x19
“Manual LED override register” on page 87
0x1A
Reserved
0x1B
“Copper/fiber status register” on page 88
0x1C
“Cable diagnostic test status register” on page 90
0x1D
“Debug port — address offset register” on page 90
0x1E
“Debug port — dataport register” on page 90
0x1F
“Chip configure register” on page 91
For most MII Register offset addresses, each address has two pages. One for copper port, and the other for
fiber port.
When 0x1F[15] = 0, the MII register shows fiber page.
When 0x1F[15] = 1, the MII register shows copper page.
For typical application, poll the PHY specific status register to get link/speed/duplex information and then
configure MAC before sending and receiving packets.
5.2.1
Control register — copper page
Offset: 0x00
Bit
15
14
13
Name
RESET
LOOPBACK
SPEED
SELECTION (LSB)
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
SC
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
SW Rst.
PHY Software Reset. Writing 1 to this bit causes
immediate PHY reset. When the operation is done, this
bit is cleared automatically.
1 = PHY reset
0 = Normal operation
When loopback is activated, the transmitter data on
TXD is looped back to RXD internally.
1 = Enable loopback
0 = Disable loopback
Force speed = {bit[6] SPEED SELECTION (MSB),
bit[13] SPEED SELECTION (LSB)}
1
00 = 10 Mbps
Retain 01 = 100 Mbps
10 = 1000 Mbps
11 = Reserved
80-Y0618-2 Rev A
57 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
12
11
10
9
8
7
6
5:0
5.2.2
Name
AUTONEGOTIATION
POWER DOWN
ISOLATE
RESTART AUTONEGOTIATION
DUPLEX MODE
COLLISION TEST
SPEED
SELECTION (MSB)
RESERVED
Type
Registers
Description
Mode
R/W
HW Rst.
1
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W,
SC
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
1
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/O
HW Rst.
0
SW Rst.
0
1 = Enable auto-negotiation process
0 = Disable auto-negotiation process
When the port is switched from power down to normal
operation, software reset and restart Auto-negotiation
are performed even when bit[15] RESET and bit[9]
RESTART AUTO-NEGOTIATION are not set.
1 = Power-down
0 = Normal operation
The RGMII output pins are tri-stated when this bit is 1.
The RGMII inputs are ignored.
1 = Isolate
0 = Normal operation
Auto-negotiation automatically restarts after hardware or
software reset regardless of whether this bit is set or
not.
1 = Restart auto-negotiation process
0 = Normal operation
1 = Full-duplex
0 = Half-duplex
Setting this bit to 1 asserts the COL pin whenever the
TX_EN pin is asserted.
1 = Enable COL signal test
0 = Disable COL signal test
See bit[13] SPEED SELECTION (LSB)
Always 0
Control register — fiber page
Offset: 0x00
Bit
15
Name
RESET
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
SC
PHY software reset. Writing 1 to this bit causes
immediate PHY reset. When the operation is done, this
bit is cleared automatically.
1 = PHY reset
0 = Normal operation
80-Y0618-2 Rev A
58 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
Name
14
LOOPBACK
13
SPEED
SELECTION (LSB)
Type
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
SW Rst.
12
11
AUTONEGOTIATION
POWER DOWN
R/W
HW Rst.
1
SW Rst.
1
Mode
R/W
SW Rst.
9
8
ISOLATE
RESTART AUTONEGOTIATION
DUPLEX MODE
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W,
SC
HW Rst.
0
SW Rst.
SC
Mode
R/W,
SW Rst.
7
6
COLLISION TEST
SPEED
SELECTION (MSB)
For 1000BASE-X, SGMII:
1 = Enable auto-negotiation process
0 = Disable auto-negotiation process
No auto-negotiation in 100BASE-FX
For 100BASE-FX, 1000BASE-X, SGMII mode:
When the port is switched from power-down to normal
0
operation, software reset and restart Auto-Negotiation
Retain are performed even when bit[15] RESET and bit[9]
RESTART AUTO-NEGOTIATION are not set.
1 = Power-down, shut off SerDes
0 = Normal operation
Mode
HW Rst.
100BASE-FX, 1000BASE-X, SGMII loopback. When
loopback is activated, 10-bit TXD to SerDes is looped
back to 10-bit RXD.
1 = Enable loopback
0 = Disable loopback
Only for SGMII
Force speed = {bit[6] SPEED SELECTION (MSB),
0
bit[13] SPEED SELECTION (LSB)}:
Retain 00 = 10 Mbps
01 = 100 Mbps
10 = 1000 Mbps
11 = Reserved
The force speed is valid only when bit[12] AUTONEGOTIATION is 0.
Mode
HW Rst.
10
Description
Mode
HW Rst.
Registers
Not implement
For 1000BASE-X, SGMII:
Auto-negotiation automatically restarts after hardware or
software reset regardless of whether or not this bit is
set.
1 = Restart auto-negotiation process
0 = Normal operation
Takes effect in 1000BASE-X auto-negotiation disable
(bit[12] AUTO-NEGOTIAION = 0) mode, or 100BASE1
FX mode:
Retain 1 = Full-duplex
0 = Half-duplex
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
1
SW Rst.
Retain
N/A
See bit[13] SPEED SELECTION (LSB)
80-Y0618-2 Rev A
59 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.2.3
Bit
Name
5:0
RESERVED
Type
Registers
Description
Mode
R/W
HW Rst.
0
SW Rst.
0
Always 0
Status register — copper page
Offset: 0x01
Bit
Name
15
100BASE-T4
14
13
12
11
10
9
8
7
100BASE-TX
FULL-DUPLEX
100BASE-TX
HALF-DUPLEX
10BASE-T FULLDUPLEX
10BASE-T HALFDUPLEX
100BASE-T2
FULL-DUPLEX
100BASE-T2
HALF-DUPLEX
EXTENDED
STATUS
RESERVED
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
0
SW Rst.
0
100BASE-T4
Always 0
This protocol is not available.
1 = PHY supports 100BASE-T4.
0 = PHY does not support 100BASE-T4.
Always 1
1 = PHY supports 100BASE-TX full-duplex.
0 = PHY does not support 100BASE-TX full-duplex.
Always 1
1 = PHY supports 100BASE-TX half-duplex.
0 = PHY does not support 100BASE-TX half-duplex.
Always 1
1 = PHY supports 10BASE-T full-duplex.
0 = PHY does not support 10BASE-T full-duplex.
Always 1
1 = PHY supports 10BASE-T half-duplex.
0 = PHY does not support 10BASE-T half-duplex.
Always 0
1 = PHY supports 100BASE-T2.
0 = PHY does not support 100BASE-T2.
Always 0
1 = PHY supports 100BASE-T2.
0 = PHY does not support 100BASE-T2.
Always 1
Extended status information in Extended status
register
Always 0
80-Y0618-2 Rev A
60 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
6
5
4
3
2
1
0
5.2.4
Name
MF PREAMBLE
SUPPRESSION
AUTONEGOTIATION
COMPLETE
REMOTE FAULT
AUTONEGOTIATION
ABILITY
LINK STATUS
JABBER DETECT
EXTENDED
CAPABILITY
Type
Registers
Description
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO, LH
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO, LL
HW Rst.
0
SW Rst.
0
Mode
RO, LH
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Always 1
1 = PHY accepts management frames with preamble
suppressed.
0 = PHY does not accept management frames with
preamble suppressed.
1 = Auto-negotiation process completed
0 = Auto-negotiation process not completed
1 = Remote fault condition detected
0 = Remote fault condition not detected
1 = PHY supports auto-negotiation.
0 = PHY does not support auto-negotiation.
This bit indicates whether the link was lost since the
last read. For the current link status, see bit[10] LINK
(REAL-TIME) of register PHY specific status register
— copper page.
1 = Link is up
0 = Link is down
1 = Jabber condition detected
0 = Jabber condition not detected
Always 1
1 = Extended register capabilities
Status register — fiber page
Offset: 0x01
Bit
Name
15
100BASE-T4
14
100BASE-FX
FULL-DUPLEX
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
100BASE-T4
This protocol is not available.
Always 0
1 = PHY supports 100BASE-T4.
0 = PHY does not support 100BASE-T4.
Always 1
1 = PHY supports 100BASE-FX full-duplex.
0 = PHY does not support 100BASE-FX full-duplex.
80-Y0618-2 Rev A
61 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
13
12
11
10
9
8
7
6
5
4
Name
100BASE-FX
HALF-DUPLEX
10BASE-X FULLDUPLEX
10BASE-X HALFDUPLEX
100BASE-T2
FULL-DUPLEX
100BASE-T2
HALF-DUPLEX
EXTENDED
STATUS
RESERVED
MF PREAMBLE
SUPPRESSION
AUTONEGOTIATION
COMPLETE
REMOTE FAULT
Type
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
0
SW Rst.
0
HW Rst.
3
AUTONEGOTIATION
ABILITY
Description
Mode
Mode
Registers
Always 1
1 = PHY supports 100BASE-FX half-duplex.
0 = PHY does not support 100BASE-FX half-duplex.
Always 0
1 = PHY supports 10BASE-X full-duplex.
0 = PHY does not support 10BASE-X full-duplex.
Always 0
1 = PHY supports 10BASE-X half-duplex.
0 = PHY does not support 10BASE-X half-duplex.
Always 0
1 = PHY supports 100BASE-T2.
0 = PHY does not support 100BASE-T2.
Always 0
1 = PHY supports 100BASE-T2.
0 = PHY does not support 100BASE-T2.
Always 1
Extended status information in Extended status register
Always 0
Always 1
1 = PHY accepts management frames with preamble
suppressed.
0 = PHY does not accept management frames with
preamble suppressed.
1 = Auto-negotiation process complete
0 = Auto-negotiation process not complete
RO, LH 1 = Remote fault condition detected
0 = Remote fault condition not detected
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Always 1
1 = PHY supports auto-negotiation.
0 = PHY does not support auto-negotiation.
80-Y0618-2 Rev A
62 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
2
1
Name
Type
LINK STATUS
RO, LL
HW Rst.
0
SW Rst.
0
Mode
HW Rst.
0
5.2.5
EXTENDED
CAPABILITY
Description
Mode
JABBER DETECT
Registers
This bit indicates whether the link is lost since the last
read. For the current link status, see bit[10] LINK
(REAL-TIME) of register PHY specific status register —
fiber page.
1 = Link is up
0 = Link is down
RO, LH 1 = Jabber condition detected
0 = Jabber condition not detected
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Always 1
1 = Extended register capabilities
PHY identifier 1 register
Offset: 0x02
Bit
15:0
5.2.6
Name
ORGANIZATIONALLY
UNIQUE IDENTIFIER
BIT 3:18
Type
Description
Mode
RO
HW Rst.
0x004D
SW Rst.
0x004D
Always 0x004D
Organizationally unique identifier bits[18:3]
PHY identifier 2 register
Offset: 0x03
Bit
15:0
Name
ORGANIZATIONALLY
UNIQUE IDENTIFIER
LSB. MODEL NUMBER
REVISION NUMBER
Type
Description
Mode
RO
HW Rst.
0xD074
SW Rst.
0xD074
Always 0xD074
Organizationally unique identifier bits[19:24]
80-Y0618-2 Rev A
63 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.2.7
Registers
Auto-negotiation advertisement register — copper page
Offset: 0x04
Bit
Name
15
NEXT PAGE
14
13
12
ACK
REMOTE FAULT
XNP_ABLE
Type
Mode
R/W
HW Rst.
0
SW Rst.
Update
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
Update
Mode
R/W
HW Rst.
SW Rst.
11
ASYMMETRIC
PAUSE
Description
The value of this bit is updated immediately after
writing this register. The value written to this bit takes
effect only when any one of the following occurs:
Software reset is asserted (bit[15] RESET of
Control register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART AUTO-NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
If 1000BASE-T is advertised, the required next pages
are automatically transmitted. Bit[15] NEXT PAGE of
Auto-negotiation advertisement register — copper
page must be set to 0 if no additional next pages are
required.
1 = Advertise
0 = Not advertised
Always 0
1 = Set Remote Fault bit
0 = Do not set Remote Fault bit
Extended next page enable control bit:
Always 1 1 = Local device supports transmission of extended
next pages.
Retain 0 = Local device does not support transmission of
extended next pages.
Mode
R/W
HW Rst.
1
SW Rst.
Update
The value of this bit is updated immediately after
writing this register. The value written to this bit takes
effect only when any one of the following occurs:
Software reset is asserted (bit[15] RESET of
Control register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART AUTO-NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
1 = Asymmetric pause
0 = No asymmetric pause
80-Y0618-2 Rev A
64 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
10
9
8
7
Name
PAUSE
100BASE-T4
100BASE-TX
FULL DUPLEX
100BASE-TX
HALF DUPLEX
Type
Registers
Description
Mode
R/W
HW Rst.
1
SW Rst.
Update
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
1
SW Rst.
Update
Mode
R/W
HW Rst.
1
SW Rst.
Update
The value of this bit is updated immediately after
writing this register. The value written to this bit takes
effect only when any one of the following occurs:
Software reset is asserted (bit[15] RESET of
Control register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART AUTO-NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
1 = MAC PAUSE implemented
0 = MAC PAUSE not implemented
Always 0
1 = PHY supports 100BASE-T4.
0 = PHY does not support 100BASE-T4.
The value of this bit is updated immediately after
writing this register. The value written to this bit takes
effect only when any one of the following occurs:
Software reset is asserted (bit[15] RESET of
Control register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART AUTO-NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
1 = Advertise
0 = Not advertised
The value of this bit is updated immediately after
writing this register. The value written to this bit takes
effect only when any one of the following occurs:
Software reset is asserted (bit[15] RESET of
Control register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART AUTO-NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
1 = Advertise
0 = Not advertised
80-Y0618-2 Rev A
65 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
6
5
4:0
5.2.8
Name
10BASE-T FULL
DUPLEX
10BASE-T HALF
DUPLEX
SELECTOR FIELD
Type
Registers
Description
Mode
R/W
HW Rst.
1
SW Rst.
Update
Mode
R/W
HW Rst.
1
SW Rst.
Update
Mode
RO
HW Rst.
1
SW Rst.
1
The value of this bit is updated immediately after
writing this register. The value written to this bit takes
effect only when any one of the following occurs:
Software reset is asserted (bit[15] RESET of
Control register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART AUTO-NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
1 = Advertise
0 = Not advertised
The value of this bit is updated immediately after
writing this register. The value written to this bit takes
effect only when any one of the following occurs:
Software reset is asserted (bit[15] RESET of
Control register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART AUTO-NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
1 = Advertise
0 = Not advertised
Selector field mode
Always 1
1 = IEEE 802.3
Auto-negotiation advertisement register — fiber page
Offset: 0x04
Bit
Name
15
NEXT PAGE
14
ACK
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
Update
Mode
RO
HW Rst.
0
SW Rst.
0
This bit indicates if additional next pages are required.
1 = Advertise
0 = Not advertised
Always 0
80-Y0618-2 Rev A
66 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
13:12
11:9
8
7
6
5
4:0
5.2.9
Name
REMOTE FAULT
RESERVED
ASYMMETRIC
PAUSE
PAUSE
1000BASE-X HALF
DUPLEX
1000BASE-X FULL
DUPLEX
RESERVED
Type
Registers
Description
Mode
R/W
HW Rst.
00
SW Rst.
Update
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
1
SW Rst.
Update
Mode
R/W
HW Rst.
1
SW Rst.
Update
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
1
SW Rst.
Retain
Mode
RO
HW Rst.
0
SW Rst.
0
00 = LINK_OK
01 = OFFLINE
10 = LINK_FAILURE
11 = AUTO_ERROR
–
1 = Asymmetric pause
0 = No asymmetric pause
1 = MAC PAUSE implemented
0 = MAC PAUSE not implemented
1000BASE-X half-duplex ability
1000BASE-X full-duplex ability
Always 0
Auto-negotiation link partner ability register — copper page
Offset: 0x05
Bit
Name
15
NEXT PAGE
14
13
ACK
REMOTE FAULT
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Received code word bit[15]
1 = Link partner supports Next Page
0 = Link partner does not support Next Page
Acknowledge
Received code word bit[14]
1 = Link partner successfully received link code word
0 = Link partner failed to receive link code word
Remote fault
Received code word bit[13]
1 = Link partner detects remote fault
0 = Link partner does not detect remote fault
80-Y0618-2 Rev A
67 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
Name
12
RESERVED
11
10
9
8
7
6
5
4:0
ASYMMETRIC
PAUSE
PAUSE
100BASE-T4
100BASE-TX FULL
DUPLEX
100BASE-TX HALF
DUPLEX
10BASE-T FULL
DUPLEX
10BASE-T HALF
DUPLEX
SELECTOR FIELD
Type
Registers
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Technology ability field
Received code word bit[12]
Technology ability field
Received code word bit[11]
1 = Link partner requests asymmetric pause
0 = Link partner does not request asymmetric pause
Technology ability field
Received code word bit[10]
1 = Link partner supports pause operation
0 = Link partner does not support pause operation
Technology ability field
Received code word bit[9]
1 = Link partner supports 100BASE-T4
0 = Link partner does not support 100BASE-T4
Technology ability field
Received code word bit[8]
1 = Link partner supports 100BASE-TX full-duplex
0 = Link partner does not support 100BASE-TX fullduplex
Technology ability field
Received code word bit[7]
1 = Link partner supports 100BASE-TX half-duplex
0 = Link partner does not support 100BASE-TX halfduplex
Technology ability field
Received code word bit[6]
1 = Link partner support 10BASE-T full-duplex
0 = Link partner does not support 10BASE-T full-duplex
Technology ability field
Received code word bit[5]
1 = Link partner supports 10BASE-T half-duplex
0 = Link partner does not support 10BASE-T half-duplex
Selector field
Received code word bit[4:0]
80-Y0618-2 Rev A
68 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.2.10
Registers
Auto-negotiation link partner ability register — fiber page
Offset: 0x05
Bit
Name
15
NEXT PAGE
14
13:12
11:9
8
7
6
5
4:0
ACK
REMOTE FAULT
RESERVED
ASYMMETRIC
PAUSE
PAUSE
1000 BASE-X
HALF DUPLEX
1000 BASE-X
FULL DUPLEX
RESERVED
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Received code word bit[15]
1 = Link partner supports Next Page
0 = Link partner does not support Next Page
Acknowledge
Received code word bit[14]
1 = Link partner received link code word
0 = Link partner does not have Next Page ability
Remote fault
Received code word bit[13:12]
–
Technology ability field
Received code word bit[8]
1 = Link partner requests asymmetric pause
0 = Link partner does not request asymmetric pause
Technology ability field
Received code word bit[7]
1 = Link partner supports pause operation
0 = Link partner does not support pause operation
Technology ability field
Received code word bit[6]
1 = Link partner supports 1000BASE-X half-duplex
0 = Link partner does not support 1000BASE-X halfduplex
Technology ability field
Received code word bit[6]
1 = Link partner supports 1000BASE-X full-duplex
0 = Link partner does not support 1000BASE-X
full-duplex
–
80-Y0618-2 Rev A
69 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.2.11
Registers
Auto-negotiation expansion register — copper page
Offset: 0x06
Bit
15:5
4
3
2
1
0
5.2.12
Name
RESERVED
PARALLEL
DETECTION
FAULT
LINK PARTNER
NEXT PAGE ABLE
LOCAL NEXT
PAGE ABLE
PAGE RECEIVED
LINK PARTNER
AUTONEGOTIATION
ABLE
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO,
LH
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Always 0
1 = A fault is detected
0 = No fault is detected
1 = Link partner supports Next Page
0 = Link partner does not support Next Page
1 = Local device supports Next Page
0 = Local device does not support Next Page
1 = A new page is received
0 = No new page is received
1 = Link partner supports auto-negotiation
0 = Link partner does not support auto-negotiation
Auto-negotiation expansion register — fiber page
Offset: 0x06
Bit
15:4
3
2
Name
RESERVED
LINK PARTNER
NEXT PAGE ABLE
LOCAL NEXT PAGE
ABLE
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Always 0
For 1000BASE-X, SGMII:
1 = Link partner supports Next Page
0 = Link partner does not support Next Page
For 1000BASE-X, SGMII:
1 = Local device supports Next Page
0 = Local device does not support Next Page
80-Y0618-2 Rev A
70 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
1
0
5.2.13
Name
Type
PAGE RECEIVED
LINK PARTNER
AUTO
NEGOTIATION
ABLE
Registers
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO, LH
HW Rst.
0
SW Rst.
0
For 1000BASE-X, SGMII:
1 = A new page is received
0 = No new page is received
For 1000BASE-X, SGMII:
1 = Link partner supports auto-negotiation
0 = Link partner does not support auto-negotiation
Auto-negotiation next page transmit register — copper page
Offset: 0x07
Bit
15
14
13
12
11
10:0
Name
NEXT PAGE
RESERVED
MESSAGE PAGE MODE
ACK2
TOGGLE
MESSAGE/UNFORMATTED
FIELD
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
1
SW Rst.
1
Mode
R/W
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
1
SW Rst.
1
Transmit code word bit[15]
Transmit code word bit[14]
Transmit code word bit[13]
Transmit code word bit[12]
Transmit code word bit[11]
Transmit code word bits[10:0]
80-Y0618-2 Rev A
71 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Registers
5.2.14 Auto-negotiation next page transmit register — fiber page for
1000BASE-X, SGMII
Offset: 0x07
Bit
15
14
13
12
11
10:0
Name
NEXT PAGE
RESERVED
MESSAGE PAGE MODE
ACK2
TOGGLE
MESSAGE/UNFORMATTED
FIELD
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
1
SW Rst.
1
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
1
SW Rst.
1
Transmit code word bit[15]
Transmit code word bit[14]
Transmit code word bit[13]
Transmit code word bit[12]
Transmit code word bit[11]
Transmit code word bits[10:0]
5.2.15 Auto-negotiation link partner next page register — copper
page
Offset: 0x08
Bit
15
14
Name
NEXT PAGE
RESERVED
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Received code word bit[15]
Received code word bit[14]
80-Y0618-2 Rev A
72 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
13
12
11
10:0
Name
MESSAGE PAGE MODE
ACK2
TOGGLE
MESSAGE/UNFORMATTED
FIELD
Type
Registers
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
0
SW Rst.
0
Received code word bit[13]
Received code word bit[12]
Received code word bit[11]
Received code word bits[10:0]
5.2.16 Auto-negotiation link partner next page register — fiber page
for 1000BASE-X, SGMII
Offset: 0x08
Bit
15
14
13
12
11
10:0
Name
NEXT PAGE
RESERVED
MESSAGE PAGE MODE
ACK2
TOGGLE
MESSAGE/UNFORMATTED
FIELD
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Received code word bit[15]
Received code word bit[14]
Received code word bit[13]
Received code word bit[12]
Received code word bit[11]
Received code word bits[10:0]
80-Y0618-2 Rev A
73 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.2.17
Registers
1000BASE-T control register
Offset: 0x09
Bit
15:13
12
11
Name
TEST MODE
MASTER/SLAVE
MANUAL
CONFIGURATION
ENABLE
MASTER/SLAVE
CONFIGURATION
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
SW Rst.
Mode
HW Rst.
SW Rst.
After exiting the test mode, hardware reset or software
reset (bit[15] RESET of Control register — copper page)
must be issued to ensure normal operation.
000 = Normal Mode
001 = Test mode 1 – Transmit waveform test
010 = Test mode 2 – Transmit jitter test (master mode)
011 = Test mode 3 – Transmit jitter test (slave mode)
100 = Test mode 4 – Transmit distortion test
101, 110, 111 = Reserved
The value of this bit is updated immediately after writing
this register. The value written to this bit takes effect
0
only when any one of the following occurs:
Update Software reset is asserted (bit[15] RESET of Control
register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART_AUTO_NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER_DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
1 = Manual master/slave configuration
0 = Automatic master/slave configuration
R/W
The value of this bit is updated immediately after writing
this register. The value written to this bit takes effect
0
only when any one of the following occurs:
Update Software reset is asserted (bit[15] RESET of Control
register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART_AUTO_NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER_DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
Bit[11] MASTER/SLAVE CONFIGURATION is ignored if
bit[12] MASTER/SLAVE MANUAL CONFIGURATION
ENABLE = 0.
1 = Manual configure as master
0 = Manual configure as slave
80-Y0618-2 Rev A
74 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
Name
10
PORT TYPE
Type
Mode
HW Rst.
SW Rst.
Registers
Description
R/W
The value of this bit is updated immediately after writing
this register. The value written to this bit takes effect
0
only when any one of the following occurs:
Update Software reset is asserted (bit[15] RESET of Control
register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART_AUTO_NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER_DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
Bit[10] PORT TYPE is ignored if bit[12]
MASTER/SLAVE MANUAL CONFIGURATION
ENABLE = 1.
1 = Prefer multi-port device (master)
0 = Prefer single-port device (slave)
9
1000BASE-T
FULL DUPLEX
Mode
HW Rst.
SW Rst.
8
1000BASE-T
HALF-DUPLEX
Mode
HW Rst.
SW Rst.
7:0
RESERVED
R/W
The value of this bit is updated immediately after writing
this register. The value written to this bit takes effect
1
only when any one of the following occurs:
Update Software reset is asserted (bit[15] RESET of Control
register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART_AUTO_NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER_DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
1 = Advertise
0 = Not advertised
R/W
The value of this bit is updated immediately after writing
this register. The value written to this bit takes effect
0
only when any one of the following occurs:
Update Software reset is asserted (bit[15] RESET of Control
register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART_AUTO_NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER_DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
1 = Advertise
0 = Not advertised
Note: The 1000BASE-T/half-duplex is not advertised by
default.
Mode
R/W
HW Rst.
0
SW Rst.
0
–
80-Y0618-2 Rev A
75 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.2.18
Registers
1000BASE-T status register
Offset: 0x0A
Bit
Name
15
MASTER/SLAVE
CONFIGURATION
FAULT
14
13
12
11
10
9:8
7:0
MASTER/SLAVE
CONFIGURATION
RESOLUTION
LOCAL RECEIVER
STATUS
REMOTE
RECEIVER
STATUS
LINK PARTNER
1000 BASE-T FULL
DUPLEX
CAPABILITY
LINK PARTNER
1000 BASE-T
HALF DUPLEX
CAPABILITY
RESERVED
IDLE ERROR
COUNT
Type
Description
Mode
RO, LH
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO, SC
HW Rst.
0
SW Rst.
0
This bit is cleared on a read operation.
1 = Master/Slave configuration fault detected
0 = No fault detected
This bit is valid only when bit[1] PAGE RECEIVED of
Auto-negotiation expansion register — copper page
= 1.
1 = Local PHY configuration resolved to master
0 = Local PHY configuration resolved to slave
1 = Local receiver OK
0 = Local receiver not OK
1 = Remote receiver OK
0 = Remote receiver not OK
This bit is valid only when bit[1] PAGE RECEIVED of
Auto-negotiation expansion register — copper page
= 1.
1 = Link partner supports 1000BASE-T full-duplex
0 = Link partner does not support 1000BASE-T fullduplex
This bit is valid only when bit[1] PAGE RECEIVED of
Auto-negotiation expansion register — copper page
= 1.
1 = Link partner supports 1000 BASE-T half-duplex
0 = Link partner does not support 1000 BASE-T halfduplex
Always 0
MSB of idle error counter
Report the idle error count since the last time this
register was read. The counter counts up to
11111111 and does roll over.
80-Y0618-2 Rev A
76 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.2.19
Registers
MMD access control register
Offset: 0x0D
Bit
15:14
13:5
4:0
5.2.20
Name
Type
FUNCTION
RESERVED
DEVAD
Description
Mode
R/W
00 = Address
01 = Data, no post increment
10 = Data, post increment on read and write operations
11 = Data, post increment on write operation only
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
Update
–
Device address
MMD access data register
Offset: 0x0E
Bit
15:14
Name
Type
ADDRESS
DATA
Mode
R/W
If bits[15:14] FUNCTION = 00 in MMD access control
register, MMD DEVAD is address register.
0
Otherwise, MMD DEVAD is data register indicated by the
Retain contents of its address register.
See “MII registers” on page 56 for detailed information of
accessing MMD registers.
HW Rst.
SW Rst.
13:0
5.2.21
RESERVED
Description
–
–
Extended status register
Offset: 0x0F
Bit
Name
15
1000BASE-X FULL
DUPLEX
14
1000BASE-X
HALF DUPLEX
Type
Description
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
0
SW Rst.
0
Always 1
1 = PHY supports 1000BASE-X full-duple.
0 = PHY does not support 1000BASE-X full-duple.
Always 0
1 = PHY supports 1000BASE-X half-duplex.
0 = PHY does not support 1000BASE-X half-duplex.
80-Y0618-2 Rev A
77 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
13
12
11:0
5.2.22
Name
1000BASE-T
FULL-DUPLEX
1000BASE-T
HALF-DUPLEX
RESERVED
Type
Registers
Description
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Always 1
1 = PHY supports 1000BASE-T full-duplex.
0 = PHY does not support 1000BASE-T full-duplex.
Always 0
1 = PHY supports 1000BASE-T half-duplex.
0 = PHY does not support 1000BASE-T half-duplex.
Always 0
PHY specific function control register
Offset: 0x10
Bit
Name
15:12 RESERVED
11
ASSERT CRS ON
TRANSMIT
Type
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
SW Rst.
10
9:7
6:5
FORCE_LINK
RESERVED
MDI CROSSOVER
MODE
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
RESERVED
–
This bit is valid only in 10BASE-T half-duplex mode:
1
= Assert on Transmitting or receiving
1
0 = Never assert on transmitting, only assert on
Retain receiving
Mode
SW Rst.
4:3
Description
1 = When bit[12] AUTO-NEGOTIATION of Control
register — copper page = 1, force 10BASE-T link up
0 = Normal mode
–
Changes to these bits are disruptive to the normal
operation, therefore any changes to these registers
11
must be followed by a software reset to take effect.
Update 00 = Manual MDI configuration
01 = Manual MDIX configuration
10 = Reserved
11 = Enable automatic crossover for all modes
Mode
RO
HW Rst.
0
SW Rst.
0
–
80-Y0618-2 Rev A
78 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
2
Name
SQE TEST
Type
Mode
SW Rst.
POLARITY
REVERSAL
Mode
5.2.23
DISABLE JABBER
SQE Test is automatically disabled in full-duplex mode
regardless of the state of this bit.
0
1 = SQE test enabled
Retain 0 = SQE test disabled
R/W
HW Rst.
SW Rst.
0
Description
R/W
HW Rst.
1
Registers
If polarity is disabled, the polarity is forced to be normal
in 10BASE-T.
1
1 = Polarity auto reversal enabled:
Retain
To set this bit to 1, write 0.
To set this bit to 0, write 1.
0 = Polarity auto reversal disabled.
Mode
RO
HW Rst.
0
SW Rst.
Retain
Jabber is available in 10BASE-T half-duplex mode only.
1 = Disable jabber function
0 = Enable jabber function
PHY specific status register — copper page
Offset: 0x11
Bit
15:14
Name
SPEED
Type
Mode
HW Rst.
SW Rst.
13
DUPLEX
Mode
HW Rst.
SW Rst.
12
11
10
PAGE RECEIVED
(REAL-TIME)
SPEED AND
DUPLEX
RESOLVED
LINK (REAL-TIME)
Description
RO
These status bits are valid only when bit[11] SPEED
AND DUPLEX RESOLVED = 1. Bit[11] is set when
0
Auto-negotiation is completed or Auto-negotiation is
Retain disabled.
11 = Reserved
10 = 1000 Mbps
01 = 100 Mbps
00 = 10 Mbps
RO
This status bit is valid only when bit[11] SPEED AND
DUPLEX RESOLVED = 1. Bit[11] is set when Auto0
negotiation is completed or Auto-negotiation is
Retain disabled.
1 = Full-duplex
0 = Half-duplex
Mode
RO
HW Rst.
0
SW Rst.
Retain
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
1 = Page received
0 = Page not received
When Auto-negotiation is not enabled, set this bit = 1
for force speed mode.
1 = Resolved
0 = Not resolved
1 = Link up
0 = Link down
80-Y0618-2 Rev A
79 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
9:7
6
Name
RESERVED
MDI CROSSOVER
STATUS
Type
RO
HW Rst.
0
SW Rst.
0
Mode
RO
SW Rst.
5
4
3
WIRESPEED
DOWNGRADE
RESERVED
TRANSMIT PAUSE
ENABLED
RO
HW Rst.
0
SW Rst.
Retain
Mode
RO
HW Rst.
1
SW Rst.
Retain
Mode
RO
HW Rst.
RECEIVE PAUSE
ENABLED
Mode
HW Rst.
SW Rst.
1
0
POLARITY (REALTIME)
JABBER (REALTIME)
Always 0
This status bit is valid only when bit[11] SPEED AND
DUPLEX RESOLVED = 1. Bit[11] is set when Auto0
Negotiation is completed or Auto-negotiation is
Retain disabled.
The value of this bit depends on what is written to
bits[6:5] MDI CROSSOVER MODE of PHY specific
function control register in manual configuration
mode. Bits[6:5] MDI CROSSOVER MODE of PHY
specific function control register are updated with
software reset.
1 = MDIX
0 = MDI
Mode
SW Rst.
2
Description
Mode
HW Rst.
Registers
When Smartspeed function is enable:
1 = Downgrade
0 = No Downgrade
–
This is a reflection of the MAC pause resolution. This
bit is for information purposes and is not used by the
0
device.
Retain This status bit is valid only when bit[11] SPEED AND
DUPLEX RESOLVED = 1. Bit[11] is set when Autonegotiation is completed; while in force mode, this bit
is set to 0.
1 = Transmit pause enabled
0 = Transmit pause disabled
RO
This is a reflection of the MAC pause resolution. This
bit is for information purposes and is not used by the
0
device.
Retain This status bit is valid only when bit[11] SPEED AND
DUPLEX RESOLVED = 1. Bit[11] is set when Autonegotiation is completed; while in force mode, this bit
is set to 0.
1 = Receive pause enabled
0 = Receive pause disabled
Mode
RO
HW Rst.
0
SW Rst.
Retain
Mode
RO
HW Rst.
0
SW Rst.
Retain
1 = Reverted.
0 = Normal
1 = Jabber
0 = No jabber
80-Y0618-2 Rev A
80 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.2.24
Registers
PHY specific status register — fiber page
Offset: 0x11
Bit
15:14
Name
SPEED
Type
Mode
HW Rst.
SW Rst.
13
12
11
10
9
8
7:4
3
DUPLEX
PAGE RECEIVED
(REAL-TIME)
SPEED AND
DUPLEX
RESOLVED
LINK (REAL-TIME)
MR_AN_
COMPLETE
SYNC_STATUS
RESERVED
TRANSMIT PAUSE
ENABLED
Description
RO
11 = Reserved
10
= 1000 Mbps
10
01 = 100 Mbps
Retain
00 = 10 Mbps
Mode
RO
HW Rst.
1
SW Rst.
Retain
Mode
RO
HW Rst.
0
SW Rst.
Retain
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
SW Rst.
1 = Full-duplex
0 = Half-duplex
1 = Page received
0 = Page not received
When Auto-Negotiation is not enabled, set this bit = 1
for force speed mode.
1 = Resolved
0 = Not resolved
For 1000BASE-X, 100BASE-FX:
1 = Link up
0 = Link down
For 1000BASE-X, SGMII:
1 = Auto-negotiation completed
0 = Auto-negotiation not completed
For 1000BASE-X, SGMII
1 = SGMII_BASEX is sync
0 = SGMII_BASEX is not sync
–
This is a reflection of the MAC pause resolution. This
bit is for information purposes and is not used by the
0
device.
Retain This status bit is valid only when bit[11] SPEED AND
DUPLEX RESOLVED = 1. Bit[11] is set when AutoNegotiation is completed; while in force mode, this bit
is set to 0.
1 = Transmit pause enabled
0 = Transmit pause disabled
80-Y0618-2 Rev A
81 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
2
Name
RECEIVE PAUSE
ENABLED
Type
Mode
5.2.25
RESERVED
Description
RO
HW Rst.
SW Rst.
1:0
Registers
This is a reflection of the MAC pause resolution. This
bit is for information purposes and is not used by the
0
device.
Retain This status bit is valid only when bit[11] SPEED AND
DUPLEX RESOLVED = 1. Bit[11] is set when AutoNegotiation is completed; while in force mode, this bit
is set to 0.
1 = Receive pause enabled
0 = Receive pause disabled
Mode
RO
HW Rst.
0
SW Rst.
0
–
Interrupt enable register
Offset: 0x12
Bit
15
14
13
12
11
10
9
Name
AUTONEGOTIATION
ERROR
SPEED CHANGED
RESERVED
PAGE RECEIVED
LINK FAIL
INTERRUPT
LINK SUCCESS
INTERRUPT
FAST LINK DOWN[1]
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
1 = Interrupt enable
0 = Interrupt disable
1 = Interrupt enable
0 = Interrupt disable
–
1 = Interrupt enable
0 = Interrupt disable
1 = Interrupt enable
0 = Interrupt disable
1 = Interrupt enable
0 = Interrupt disable
1 = Interrupt enable, must be enabled with
bit[6] FAST LINK DOWN[0] together
0 = Interrupt disable
80-Y0618-2 Rev A
82 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
8
7
6
5
4
3
2
1
0
5.2.26
Name
LINK_FAIL_BX
LINK_SUCCESS_BX
FAST LINK DOWN[0]
WIRESPEEDDOWNGRADE
INTERRUPT
INT_10MS_PTP
INT_RX_PTP
INT_TX_PTP
POLARITY
CHANGED
INT_WOL_PTP
Type
Registers
Description
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
1 = Interrupt enable
0 = Interrupt disable
1 = Interrupt enable
0 = Interrupt disable
Must be enabled together with bit[9] FAST LINK
DOWN[1]
1 = Interrupt enable
0 = Interrupt disable
1 = Interrupt enable
0 = Interrupt disable
1 = Interrupt enable
0 = Interrupt disable
1 = Interrupt enable
0 = Interrupt disable
1 = Interrupt enable
0 = Interrupt disable
1 = Interrupt enable
0 = Interrupt disable
Wake-on-LAN interrupt
1 = Interrupt enable
0 = Interrupt disable
Interrupt status register
Offset: 0x13
Bit
15
Name
AUTONEGOTIATION
ERROR
Type
Mode
HW Rst.
SW Rst.
Description
RO, LH An error can occur if either MASTER/SLAVE does not
resolve, or no common HCD, or link does not come
0
up after negotiation is completed.
Retain 1 = Auto-negotiation error
0 = No auto-negotiation error
80-Y0618-2 Rev A
83 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
Name
14
SPEED CHANGED
13
12
11
10
9
8
7
6
RESERVED
PAGE RECEIVED
LINK FAIL
INTERRUPT
LINK SUCCESS
INTERRUPT
FAST LINK
DOWN[1]
LINK_FAIL_BX
LINK_SUCCESS_
BX
FAST LINK
DOWN[0]
Type
Mode
4:2
WIRESPEEDDOWNGRADE
INTERRUPT
RESERVED
Description
HW Rst.
RO, LH 1 = Speed changed
0 = Speed unchanged
0
SW Rst.
Retain
Mode
RO, LH –
HW Rst.
0
SW Rst.
Retain
Mode
HW Rst.
RO, LH 1 = Page received
0 = Page not received
0
SW Rst.
Retain
Mode
HW Rst.
RO, LH 1 = BASE-T Link down occurs.
0 = No link is down.
0
SW Rst.
Retain
Mode
HW Rst.
RO, LH 1 = BASE-T Link up occurs.
0 = No link is up.
0
SW Rst.
Retain
Mode
RO, LH Cooperate with bit[6] to show different speed interrupt
HW Rst.
0
SW Rst.
Retain
Mode
HW Rst.
RO, LH 1 = 1000BASE-X/100BASE-FX link down occurs.
0 = No 1000BASE-X/100BASE-FX link is down.
0
SW Rst.
Retain
Mode
HW Rst.
RO, LH 1 = 1000BASE-X/100BASE-FX link up occurs.
0 = No 1000BASE-X/100BASE-FX link is up.
0
SW Rst.
Retain
Mode
HW Rst.
SW Rst.
5
Registers
Mode
RO, LH Work with bit[9] to show fast link down interrupt
[bit9, bit6]
0
00 = Without fast link down
Retain 01 = 10BASE-T fast link down occurs
01 = 100BASE-T fast link down occurs
10 = 1000BASE-T fast link down occurs
HW Rst.
RO, LH 1 = Wirespeed-downgrade detected
0 = No Wirespeed-downgrade detected
0
SW Rst.
Retain
Mode
–
HW Rst.
–
SW Rst.
–
–
80-Y0618-2 Rev A
84 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
1
0
5.2.27
Name
POLARITY
CHANGED
INT_WOL_PTP
Type
Mode
Registers
Description
HW Rst.
RO, LH 1 = Polarity changed
0 = Polarity not changed
0
SW Rst.
Retain
Mode
HW Rst.
RO, LH 1 = Wake-on-LAN packet received
0 = No Wake-on-LAN packet received
0
SW Rst.
Retain
Smart speed register
Offset: 0x14
Bit
15:9
8
7:6
5
Name
RESERVED
GIGA_DIS_QUAL
RESERVED
SMARTSPEED_EN
Type
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
SW Rst.
4:2
SMARTSPEED_
RETRY_LIMIT
Mode
HW Rst.
SW Rst.
1
0
BYPASS_
SMARTSPEED_
TIMER
RESERVED
Description
Always 0
Make PHY to disable GIGA mode. After writing this
bit to 1, bit[9] 1000BASE-T FULL DUPLEX of
1000BASE-T control register = 0.
Always 0
The default value is 1.
When this bit is set to 1, the PHY enables
1
smartspeed function.
Update Writing this bit requires a software reset to update.
R/W
The default value is 3.
If these bits are set to 3, the PHY attempts five times
011
(set value 3 + additional 2) before downgrading. The
Update number of attempts can be changed by these bits.
Mode
R/W
HW Rst.
0
SW Rst.
Update
Mode
RO
HW Rst.
0
SW Rst.
0
The default value is 0.
If this bit is set to 1, the Smartspeed FSM bypasses
the timer used for stability.
Always 0
80-Y0618-2 Rev A
85 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Registers
5.2.28 Cable diagnostic test control register
Offset: 0x16
Bit
15:10
9:8
7:1
0
5.2.29
Name
RESERVED
MDI PAIR
SELECT
RESERVED
ENABLE TEST
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
00
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Always 0
CDT control registers.
Use the CDT control registers to select which MDI
pair is shown in the CDT status register.
00 = MDI[0] pair
01 = MDI[1] pair
10 = MDI[2] pair
11 = MDI[3] pair
Always 0
When set, hardware automatically disables this bit
when CDT is done.
1 = Enable CDT Test
0 = Disable CDT Test
LED control register
Offset: 0x018
Bit
15
14:12
Name
DISABLE LED
LED ON TIME
Type
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
SW Rst.
11
RESERVED
Description
Control LED_10_100, LED_ACT
0 = Enable
1 = Disable
LED_ACT active duty cycle.
000 = 5 ms
011
001 = 10 ms
Retain
010 = 21 ms
011 = 42 ms
100 = 84 ms
101 = 168 ms
110 to 111 = 42 ms
Mode
RO
HW Rst.
0
SW Rst.
0
–
80-Y0618-2 Rev A
86 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
10:8
Name
LED OFF TIME
Type
Mode
HW Rst.
SW Rst.
7:5
4:3
2
1
0
5.2.30
RESERVED
LED_LINK
CONTROL
LED_ACT
CONTROL
RESERVED
RESERVED
Registers
Description
R/W
LED_ACT active duty cycle.
000 = 21 ms
010
001 = 42 ms
Retain
010 = 84 ms
011 = 168 ms
100 = 330 ms
101 = 670 ms
110 to 111 = 168 ms
Mode
RO
HW Rst.
000
SW Rst.
Always
0
Mode
R/W
HW Rst.
00
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
–
00 = Direct LED mode (default)
11 = Disable LED_10_100 only
01, 10 = Reserved
0 = Normal
1 = LED_ACT blinks when linked
–
–
Manual LED override register
Offset: 0x19
Bit
15:13
12
Name
RESERVED
LED_ACT
CONTROL
Type
Description
Mode
R/W
HW Rst.
001
SW Rst.
Retain
Mode
R/W
HW Rst.
SW Rst.
–
1 = link/active. When link is established, LED_ACT is
on. When link is active, LED_ACT blinks.
1
0 = active. When link is established, LED_ACT is off.
Retain When link is active, LED_ACT blinks.
The blink duty cycle is controlled by LED control
register.
80-Y0618-2 Rev A
87 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
11:8
7:6
Name
RESERVED
LED_LINK10_100
CONTROL
Type
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
SW Rst.
5:4
3:2
RESERVED
LED_RX
R/W
HW Rst.
00
SW Rst.
Retain
Mode
R/W
SW Rst.
LED_TX
Mode
–
00 = Normal
01 = Blink
00
10 = LED off
Retain
11 = LED on
LED_ACT status = LED_TX|LED_RX
When both LED_RX and LED_TX are set to 10, LED_
ACT is turned off; when either is set to 01, LED_ACT
blinks; when either is set to 11, LED_ACT is on.
R/W
HW Rst.
SW Rst.
5.2.31
–
00 = normal
01 = LED_ACT blinks
00
10 = LED off
Retain
11 = LED on
LED_ACT can be turned off by bits[3:0] of Manual
LED override register.
Mode
HW Rst.
1:0
Description
Mode
HW Rst.
Registers
00 = Normal
01 = Blink
00
10 = LED off
Retain
11 = LED on
When both LED_RX and LED_TX are set to 10, LED_
ACT is turned off; when either is set to 01, LED_ACT
blinks; when either is set to 11, LED_ACT is on.
Copper/fiber status register
Offset: 0x01B
Bit
15:14
13
Name
RESERVED
TRANSMIT_
PAUSE_EN_BX
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
–
Enable 1000BASE-X transmit pause
80-Y0618-2 Rev A
88 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
Name
12
RECEIVE_PAUSE_
EN_BX
11
10
9:8
7:6
5
4
3
2
1:0
LINK_
ESTABLISHED_BX
FD_MODE_BX
SPEED_MODE_BX
RESERVED
TRANSMIT_
PAUSE_EN_BT
RECEIVE_PAUSE_
EN_BT
LINK_
ESTABLISHED_BT
FD_MODE_BT
SPEED_MODE_BT
Type
Registers
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
Always 1
Mode
RO
HW Rst.
10
SW Rst.
10
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Enable 1000BASE-X receive pause
Link status of fiber
Duplex mode of fiber
Speed_mode of fiber with only 2 cases:
10 = 1000BASE-X
01 = 100BASE-FX
–
Enable 1000BASE-T transmit pause
Enable 1000BASE-T receive pause
Link status of copper
Duplex mode of copper
Speed_mode of copper:
00 = 10 Mbps
01 = 100 Mbps
10 = 1000 Mbps
11 = Reserved
80-Y0618-2 Rev A
89 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.2.32
Registers
Cable diagnostic test status register
Offset: 0x1C
Bit
15:10
9:8
7:0
5.2.33
Name
RESERVED
STATUS
DELTA_TIME
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Always 0
The content of the CDT status registers applies to the
cable pair selected in the CDT control registers.
11 = Test fail
00 = Valid test, normal cable (no short or open in cable)
10 = Valid test, open in cable (impedance > 333 Ω)
01 = Valid test, short in cable (impedance < 33 Ω)
Delta time to indicate distance
Debug port — address offset register
Offset: 0x1D
Bit
15:6
5:0
5.2.34
Name
RESERVED
ADDRESS
OFFSET
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
0
–
The address index of the register to be written or read.
Debug port — dataport register
Offset: 0x1E
Bit
15:0
Name
DEBUG DATA
PORT
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
0
The data port of debug register.
Set the address offset in register “Debug port —
address offset register” on page 90 before accessing
this register.
80-Y0618-2 Rev A
90 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.2.35
Registers
Chip configure register
Offset: 0x1F
Bit
15
Name
BT_BX_REG_SEL
Type
Mode
HW Rst.
SW Rst.
14
13
SMII_IMP_50_75_AUTO
SGMII_RXIMP_50_75
HW Rst.
0
SW Rst.
Retain
Mode
R/W
Mode
HW Rst.
SW Rst.
11
10
9
8
RESERVED
PRIORITY_SEL
RESERVED
FIBER_MODE_AUTO
Power-on strapping pin
Copper page fiber page select bit:
See
Description 1 = Select copper page registers
0 = Select fiber page registers
Retain
R/W
SW Rst.
SGMII_TXIMP_50_75
R/W
Mode
HW Rst.
12
Description
Rx/Tx impedance of SerDes in auto media
select mode.
1 = 75 Ω
0 = 50 Ω
Power-on strapping pin
Rx impedance of SerDes
See
Description 1 = 75 Ω
0 = 50 Ω
Retain
R/W
Power-on strapping pin
Tx impedance of SerDes
See
Description 1 = 75 Ω
0 = 50 Ω
Retain
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
1
SW Rst.
Retain
–
Media preference in auto media select mode.
1 = Prefer fiber
0 = Prefer copper (default)
–
Fiber mode in auto media select mode.
1 = 1000BASE-X fiber
0 = 100BASE-FX fiber
80-Y0618-2 Rev A
91 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
7:4
3:0
Name
MODE_CFG_QUAL
MODE_CFG
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
SW Rst.
Registers
If MODE_CFG is not set to auto media detect
mode (RG_AUTO_MDET), MODE_CFG_
QUAL is equal to MODE_CFG.
If MODE_CFG is set to auto media detect
mode:
When auto media select is completed,
MODE_CFG is set to actual internal mode.
If copper is up, MDOE_CFG_QUAL is
BASET_RGMII; if fiber is up, MODE_CFG_
QUAL is FX100_RGMII_75/50 or BX1000_
RGMII_75/50.
When auto media select is not done, or no
copper or copper link is present, MODE_
CFG_QUAL is RG_AUTO_MDET.
Power-on strapping pin
Chip mode configure bits:
See
Description 0000 = BASET_RGMII
0001 = BASET_SGMII
Retain
1110 = FX100_RGMII_75
0110 = FX100_RGMII_50
1111 = FX100_CONV_75
0111 = FX100_CONV_50
0011 = BX1000_RGMII_75
0010 = BX1000_RGMII_50
0101 = BX1000_CONV_75
0100 = BX1000_CONV_50
1011 = RG_AUTO_MDET
Others: Reserved
5.3 Debug registers
Table 5-3
Offset
Debug register summary
Register
0x00
“Analog test control register” on page 93
0x05
“SerDes test and system mode control register” on page 93
0xB
“Hibernate control register” on page 93
0x10
“100BASE-TX test mode select register” on page 94
0x11
“External loopback selection register” on page 95
0x12
“10BASE-Tetest mode select register” on page 95
0x1F
“PHY control debug register 0” on page 96
0x29
“Power saving control register” on page 96
0x3D
“Green feature configure 2 register” on page 97
80-Y0618-2 Rev A
92 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.3.1
Registers
Analog test control register
Offset: 0x00
Bit
15
14:0
5.3.2
Name
SEL_CLK125M_DSP
RESERVED
Type
Description
Mode
R/W
HW Rst.
1
SW Rst.
Retain
Mode
RO
HW Rst.
0x2EE
SW Rst.
Retain
Control bit for RGMII interface Rx clock delay:
1 = RGMII Rx clock delay enable
0 = RGMII Rx clock delay disable
–
SerDes test and system mode control register
Offset: 0x05
Bit
15
14:9
8
7:0
5.3.3
Name
RESERVED
RESERVED
RGMII_TX_CLK_DLY
RESERVED
Type
Description
Mode
R/W
HW Rst.
See Desc.
SW Rst.
Retain
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
0
Always 0
–
RGMII Tx clock delay control bit:
1 = RGMII Tx clock delay enable
0 = RGMII Tx clock delay disable
–
Hibernate control register
Offset: 0x0B
Bit
15
Name
PS_HIB_EN
Type
Description
Mode
R/W
HW Rst.
1
SW Rst.
Retain
Power hibernate control bit for copper
interface only
1 = Hibernate enable
0 = Hibernate disable
80-Y0618-2 Rev A
93 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
14:13
12
11:7
6:5
4:0
5.3.4
Name
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
Type
Registers
Description
Mode
RO
HW Rst.
1
SW Rst.
Retain
Mode
R/W
HW Rst.
1
SW Rst.
Retain
Mode
R/W
HW Rst.
0x18
SW Rst.
Retain
Mode
RO
HW Rst.
10
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
–
–
–
–
–
100BASE-TX test mode select register
Offset: 0x10
Bit
15:8
7
6
5
4:0
Name
RESERVED
JITTER_TEST
OS_TEST
DCD_TEST
RESERVED
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
RO
HW Rst.
0
SW Rst.
0
–
100BASE-TX jitter test
100BASE-TX over shoot test
100BASE-TX DCD test
–
80-Y0618-2 Rev A
94 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.3.5
Registers
External loopback selection register
Offset: 0x11
Bit
Name
15:1
RESERVED
0
5.3.6
Type
Description
Mode
R/W
HW Rst.
0x3AA9
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
EXT_LPBK
–
1 = Enable the PHY’s external loopback, namely channel
0 channel 1, channel 2 channel 3.
0 = Disable the PHY’s external loopback.
10BASE-Tetest mode select register
Offset: 0x12
Bit
15:6
5
4
3
2
Name
RESERVED
TEST_MODE[2]
RESERVED
RGMII_MODE
RESERVED
Type
Description
Mode
RO
HW Rst.
010011
0000
SW Rst.
Retain
Mode
RO
HW Rst.
0
SW Rst.
Retain
Mode
RO
HW Rst.
0
SW Rst.
Retain
Mode
RO
HW Rst.
1
SW Rst.
Retain
Mode
R/W
HW Rst.
1
SW Rst.
1
–
Bit[2] of TEST_MODE, used together with TEST_
MODE[1:0]
–
Upon hardware reset, this bit depends on CHIP_
SEL and MODE_CFG:
1 = select RGMII interface with MAC.
0 = select GMII/MII interface with MAC.
–
80-Y0618-2 Rev A
95 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
1:0
5.3.7
Name
TEST_MODE[1:0]
Type
Registers
Description
Mode
R/W
HW Rst.
0
SW Rst.
0
Bit[0] and bit[1] of TEST_MODE, used together
with TEST_MODE[2]
001= Packet with all 1, 10 MHz sine wave, for
harmonic test.
010 = Pseudo random, for TP_
IDLE/Jitter/Differential voltage test
011 = Normal link pulse only
100 = 5 MHz sine wave
Others: Normal mode
PHY control debug register 0
Offset: 0x1F
Bit
15:4
3
2
1:0
5.3.8
Name
RESERVED
SEL_1P5_1P8_
POS_REG
PLL ON/OFF
selection
RESERVED
Type
Description
Mode
–
HW Rst.
–
SW Rst.
–
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
–
HW Rst.
–
SW Rst.
–
–
1 = 1.8 V
0 = 1.5 V (default)
1 = PLL ON
0 = PLL OFF (default)
–
Power saving control register
Offset: 0x29
Bit
Name
15
TOP_PS_EN
14:0
RESERVED
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
36DD
SW Rst.
Retain
1 = Top level power saving enable
0 = Top level power saving disable
–
80-Y0618-2 Rev A
96 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.3.9
Registers
Green feature configure 2 register
Offset: 0x3D
Bit
15
14:8
7
6:0
Name
BP_GREEN
RESERVED
GATE_DFSE_EN
RESERVED
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
–
HW Rst.
–
SW Rst.
–
Mode
R/W
HW Rst.
1
SW Rst.
Retain
Mode
–
HW Rst.
–
SW Rst.
–
1 = Bypass green feature, all ec/nc/dfe blocks are
enabled.
0 = Enable green feature
–
1 = When cable is very short, shut down DecisionFeedback Sequence Estimation (DFSE).
0 = Always open DFSE.
–
5.4 MDIO interface registers
MDIO interface registers are categorized to two groups:
MMD3 – MDIO Manageable Device Address 3 for PCS
MMD7 – MDIO Manageable Device Address 7 for auto-negotiation
Table 5-4
MMD3 register summary
Bit
Name
0x0
“MMD3 — PCS control register” on page 98
0x1
“MMD3 — PCS status register” on page 99
0x14
“MMD3 — EEE capability register” on page 100
0x16
“MMD3 — EEE wake error counter register” on page 100
0x8003
“MMD3 — Cld control 3 register” on page 100
0x8009
“MMD3 — AZ control 2 register” on page 101
0x8012
“MMD3 — PTP1588 control register” on page 101
0x804A
“MMD3 — Internal MAC address 1 register” on page 101
0x804B
“MMD3 — Internal MAC address 2 register” on page 102
0x804C
“MMD3 — Internal MAC address 3 register” on page 102
0x805A
“MMD3 — RemotePHY loopback register” on page 102
0x805B
“MMD3 — SmartEEE control 1 register” on page 102
80-Y0618-2 Rev A
97 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 5-4
MMD3 register summary (cont.)
Bit
Name
0x805C
“MMD3 — SmartEEE control 2 register” on page 103
0x805D
“MMD3 — SmartEEE control 3 register” on page 103
Table 5-5
MMD7 register summary
Bit
5.4.1
Registers
Name
0x0
“MMD7 — Auto-negotiation control register” on page 104
0x1
“MMD7 — EEE advertisement register” on page 104
0x16
“MMD7 — EEE advertisement register” on page 104
0x17
“MMD7 — EEE advertisement register” on page 104
0x18
“MMD7 — EEE advertisement register” on page 104
0x19
“MMD7 — EEE advertisement register” on page 104
0x1A
“MMD7 — EEE advertisement register” on page 104
0x1B
“MMD7 — EEE advertisement register” on page 104
0x3C
“MMD7 — EEE advertisement register” on page 104
0x3D
“MMD7 — EEE LP advertisement register” on page 105
0x8000
“MMD7 — EEE ability auto-negotiation result register” on page 106
0x8005
“MMD7 — SGMII control register 0” on page 106
0x8010
“MMD7 — SGMII control register 1” on page 107
0x8011
“MMD7 — SGMII control register 2” on page 107
0x8012
“MMD7 — SGMII control register 3” on page 108
0x8016
“MMD7 — CLK_25M clock select register” on page 108
MMD3 — PCS control register
Device Address = 3; Offset = 0x0
Bit
15
14:11
Name
PCS_RST
RESERVED
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Reset bit, self-clears.
When this bit = 1:
Non-vendor specific registers in MMD3/MMD7 are
reset.
Software reset in MII register 0 bit[15].
Always 0
80-Y0618-2 Rev A
98 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
Name
10
CLOCK_
STOPPABLE
9.0
5.4.2
RESERVED
Type
Registers
Description
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
RO
HW Rst.
0
SW Rst.
0
Not implement.
Always 0
MMD3 — PCS status register
Device Address = 3; Offset = 0x1
Bit
15:12
11
10
9
8
7:0
Name
RESERVED
TX LP IDLE
RECEIVED
RX LP IDLE
RECEIVED
TX LP IDLE
INDICATION
RX LP IDLE
INDICATION
RESERVED
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Always 0
1 = The transmit PCS has received low power idle
signaling one or more times since the register was
last read. Latch High.
1 = The receive PCS has received low power idle
signaling one or more times since the register was
last read. Latch High.
1 = The transmit PCS is currently receiving low
power idle signals.
1 = The receive PCS is currently receiving low
power idle signals.
Always 0
80-Y0618-2 Rev A
99 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.4.3
Registers
MMD3 — EEE capability register
Device address = 3; Offset = 0x14
Bit
15:3
2
1
0
5.4.4
Name
Type
RESERVED
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
1
SW Rst.
1
Mode
RO
HW Rst.
0
SW Rst.
0
1000BT EEE
100BT EEE
RESERVED
Always 0
EEE is supported for 1000 BASE-T.
EEE is supported for 100 BASE-T.
Always 0
MMD3 — EEE wake error counter register
Device address = 3; Offset = 0x16
Bit
15:0
5.4.5
Name
EEE WAKE
ERROR
COUNTER
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Count wake time faults where the PHY fails to complete its
normal wake sequence within the time required for the
specific PHY type.
This counter is cleared after read operation, and held at all
1 in the case of overflow.
MMD3 — Cld control 3 register
Device address = 3; Offset = 0x8003
Bit
15
14:0
Name
BP_CABLE_
LTH_DET_GT
RESERVED
Description
Mode
RO
HW Rst.
0
SW Rst.
Retain
Mode
–
HW Rst.
–
SW Rst.
–
In 1000BASE-T mode, cable length detect to analog:
1 = Bypass cable length detect.
0 = Enable cable length detect.
–
80-Y0618-2 Rev A
100 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.4.6
Registers
MMD3 — AZ control 2 register
Device address = 3; Offset = 0x8009
Bit
Name
15:8
WAKE_TRAINING_
DEBUG
7:0
5.4.7
RESERVED
Type
Description
Mode
RO
HW Rst.
0x20
SW Rst.
Retain
Mode
–
HW Rst.
–
SW Rst.
–
Wake training timer. The default value is 0x20
(4.096 µs).
–
MMD3 — PTP1588 control register
Device Address = 3; Offset = 0x8012
Bit
15:7
6
5
4:0
5.4.8
Name
RESERVED
RESERVED
WOL_EN
RESERVED
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
R/W
HW Rst.
1
SW Rst.
Retain
Mode
–
HW Rst.
–
SW Rst.
–
–
–
0 = Disable wake-on-Lan function.
1 = Enable wake-on-Lan function.
–
MMD3 — Internal MAC address 1 register
Device Address = 3; Offset = 0x804A
Bit
15:0
Name
LOC_MAC_
ADDR[47:32]
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Bits[47:32] of internal address, used in Wake-on-LAN.
80-Y0618-2 Rev A
101 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.4.9
Registers
MMD3 — Internal MAC address 2 register
Device Address = 3; Offset = 0x804B
Bit
15:0
5.4.10
Name
LOC_MAC_
ADDR[31:16]
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Bits[31:16] of internal address, used in Wake-on-LAN.
MMD3 — Internal MAC address 3 register
Device Address = 3; Offset = 0x804C
Bit
15:0
5.4.11
Name
LOC_MAC_
ADDR[15:0]
Type
Description
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Bits[15:0] of internal address, used in Wake-on-LAN.
MMD3 — RemotePHY loopback register
Device Address = 3; Offset = 0x805A
Bit
15:1
0
5.4.12
Name
RESERVED
REM_PHY_LPBK
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
0
SW Rst.
Retain
–
Loopback received data packets to link partner
MMD3 — SmartEEE control 1 register
Device Address = 3; Offset = 0x805B
Bit
15:8
Name
LPI_WT
Type
Mode
HW Rst.
SW Rst.
Description
R/W
1000BASE-T Tw timer. Buffered data is sent after time
out.
0x11
LSB vs time: 1 µs
Retain Default value: 17 µs
80-Y0618-2 Rev A
102 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
7:0
Name
LPI_WT
Type
Mode
HW Rst.
SW Rst.
5.4.13
Registers
Description
R/W
100BASE-T Tw timer. Buffered data is sent after
timeout.
0x17
LSB vs time: 1 µs
Retain Default value: 17 µs
MMD3 — SmartEEE control 2 register
Device Address = 3; Offset = 0x805C
Bit
15:0
Name
LPI_TIMER
Type
Mode
HW Rst.
SW Rst.
5.4.14
Description
R/W
LPI_TIMER[15:0]
0x800 The LPI_TIMER configures the duration from when no
data is being transmitted to entering LPI mode. At
Retain timeout, PHY enters LPI mode.
LSB vs time: 163.84 µs
Default value: 335.544 ms
MMD3 — SmartEEE control 3 register
Device Address = 3; Offset = 0x805D
Bit
15:14
13:12
11:9
8
Name
RESERVED
LPI_TX_DELAY_
SEL
RESERVED
LPI_EN
Type
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
01
SW Rst.
Retain
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
SW Rst.
7:0
LPI_TIMER
Description
Mode
HW Rst.
SW Rst.
–
Select IPG length inserted between packets (for
debug use).
–
Enables or disables SmartEEE
1 = Enable
1
0 = Disable
Retain
If MMD7 register (0x3C) bits[2:1] = 2’b00, this bit is
internally disabled automatically even it is set to 1.
R/W
LPI_TIMER[23:16]
The
LPI_TIMER configures the duration from when
0
no data is being transmitted to entering LPI mode. At
Retain timeout, PHY enters LPI mode.
80-Y0618-2 Rev A
103 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.4.15
Registers
MMD7 — Auto-negotiation control register
Device Address = 7; Offset = 0x0
Bit
15
14
13
Name
AN_RST
RESERVED
XNP_CTRL
Type
Mode
R/W,
SC
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
SW Rst.
12:0
5.4.16
RESERVED
Description
This bit restores the MMD3/MMD7 registers to default
states and triggers a software reset.
1 = Augo-negotiation reset
0 = Normal operation
Always 0.
If MII register 4 bit[12] is set to 0, setting of this bit has
no effect.
1
1 = Local device intends to enable the exchange of
Retain extended next page.
0 = Local device does not intend to enable the
exchange of extended next page.
Mode
RO
HW Rst.
0
SW Rst.
0
Always 0.
MMD7 — EEE advertisement register
Device Address = 7; Offset = 0x3C
Bit
15:3
2
Name
RESERVED
EEE_1000BT
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
R/W
HW Rst.
SW Rst.
Always 0
If Local device supports EEE operation for
1000BASE-T, and EEE operation is required, this bit
1
must be set to 1.
Retain The value of this bit is updated immediately after
writing this register. The value written to this bit takes
effect only when any one of the following occurs:
Software reset is asserted (bit[15] RESET of
Control register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART AUTO-NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
80-Y0618-2 Rev A
104 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Bit
1
Name
EEE_100BT
Type
Mode
HW Rst.
SW Rst.
0
5.4.17
RESERVED
Registers
Description
R/W
If Local device supports EEE operation for
100BASE-T, and EEE operation is required, this bit
1
must be set to 1.
Retain The value of this bit is updated immediately after
writing this register. The value written to this bit takes
effect only when any one of the following occurs:
Software reset is asserted (bit[15] RESET of
Control register — copper page)
Restart Auto-Negotiation is asserted (bit[9]
RESTART AUTO-NEGOTIATION of Control
register — copper page)
Power-down (bit[11] POWER DOWN of Control
register — copper page) transitions from power
down to normal operation
Link goes down
Mode
RO
HW Rst.
0
SW Rst.
0
Always 0
MMD7 — EEE LP advertisement register
Device Address = 7; Offset = 0x3D
Bit
15:3
2
1
0
Name
RESERVED
EEE_1000BT
EEE_100BT
RESERVED
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Always 0
1 = Link partner supports EEE operation for
1000BASE-T, and EEE operation is desired.
0 = Link partner does not support EEE operation for
1000BASE-T, or EEE operation is not desired.
1 = Link partner supports EEE operation for
100BASE-T, and EEE operation is desired.
0 = Link partner does not support EEE operation for
100BASE-T, or EEE operation is not desired.
Always 0
80-Y0618-2 Rev A
105 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.4.18
Registers
MMD7 — EEE ability auto-negotiation result register
Device Address = 7; Offset = 0x8000
Bit
15:3
2
1
0
5.4.19
Name
RESERVED
EEE_1000BT_EN
EEE_100BT_EN
RESERVED
Type
Description
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Mode
RO
HW Rst.
0
SW Rst.
0
Always 0
1 = 1000BASE-T 802.3az enabled. Both sides
support EEE operation for 1000BASE-T and EEE
operation is preferred.
0 = 1000BASE-T 802.3az disabled. Either side does
not support EEE operation for 1000BASE-T or EEE
operation is not preferred.
1 = 100BASE-T 802.3az enabled. Both sides support
EEE operation for 100BASE-T and EEE operation is
preferred.
0 = 100BASE-T 802.3az disabled. Either side does
not support EEE operation for 100BASE-T or EEE
operation is not preferred.
Always 0
MMD7 — SGMII control register 0
Device Address = 7; Offset = 0x8005
Bit
15
14:0
Name
SERDES
HIBERNATION
CONTROL
RESERVED
Type
Description
Mode
R/W
HW Rst.
1
SW Rst.
Retain
Mode
RO
HW Rst.
0x20C6
SW Rst.
0x20C6
1 = Enable hibernation
0 = Disable hibernation
–
80-Y0618-2 Rev A
106 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.4.20
Registers
MMD7 — SGMII control register 1
Device Address = 7; Offset = 0x8010
Bit
15:8
7
6:0
5.4.21
Name
RESERVED
EN_SGMII_AFE
RESERVED
Type
Description
Mode
–
–
HW Rst.
–
SW Rst.
–
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
–
HW Rst.
–
SW Rst.
–
For control signals (SGMII_EN_RX, SGMII_EN_TX,
SGMII_EN_PLL, SGMII_EN_SD, SGMII_CDR_BW,
and SGMII_FIBER_MODE):
0 = Driven by inner state
1 = Driven by register
–
MMD7 — SGMII control register 2
Device Address = 7; Offset = 0x8011
Bit
15:13
Name
SGMII_TXDR_CTRL
Type
Mode
HW Rst.
SW Rst.
12:9
8
7:0
RESERVED
SGMII_EN_TX
RESERVED
Description
R/W
Drive output Vdiff, peak-to-peak.
001 = 600 mV
001
010 = 700 mV
Retain
011 = 800 mV
100 = 900 mV
Others = Reserved
Mode
–
HW Rst.
–
SW Rst.
–
Mode
R/W
HW Rst.
1
SW Rst.
Retain
Mode
–
HW Rst.
–
SW Rst.
–
–
1 = Tx driver is enabled.
0 = Tx driver is in idle and kept in 900 mV.
–
80-Y0618-2 Rev A
107 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
5.4.22
Registers
MMD7 — SGMII control register 3
Device Address = 7; Offset = 0x8012
Bit
15:2
1:0
Name
RESERVED
RF_BX_SEL
Type
Mode
RO
HW Rst.
0x20F1
SW Rst.
0x20F1
Mode
R/W
HW Rst.
SW Rst.
5.4.23
Description
–
Remote fault in 1000BASE-X
01
= Controlled by register and internal state
01
11 = Controlled by register only
Retain
Others = Reserved
MMD7 — CLK_25M clock select register
Device Address = 7; Offset = 0x8016
Bit
15:9
8:7
6:5
4:2
1:0
Name
RESERVED
DR[0]
RESERVED
SELECT_CLK25M
RESERVED
Type
Description
Mode
–
HW Rst.
–
SW Rst.
–
Mode
R/W
HW Rst.
1
SW Rst.
Retain
Mode
–
HW Rst.
–
SW Rst.
–
Mode
R/W
HW Rst.
0
SW Rst.
Retain
Mode
–
HW Rst.
–
SW Rst.
–
–
Driver strength
00 = Full
01 = Half
10/11 = One quarter
–
CLK_25M outputs clock select bits.
000 = 25 MHz from crystal XOUT pad
001 = 25 MHz divided down from DSP 1G clock
010 = 50 MHz from local PLL source
011 = 50 MHz from DSP source
100 = 62.5 MHz from local PLL source
101 = 62.5 MHz from DSP source
110 = 125 MHz from local PLL source
111 = 125 MHz from DSP source
–
80-Y0618-2 Rev A
108 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
6 Package Dimensions
The AR8033 is packaged in a 48-pin 6 × 6 mm QFN package. See Figure 6-1 and Table 6-1 for the
package drawings and dimensions.
D
K
D2
h
L
PIN 1 (Laser Mark)
1
2
E2
K
Ne
E
h
1
2
e
Nd
BOTTOM VIEW
A1
A
c
EXPOSED THERMAL
PAD ZONE
b
Figure 6-1
Packag view
80-Y0618-2 Rev A
109 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
AR8033 Integrated 10/100/1000 Mbps Ethernet Transceiver Data Sheet
Table 6-1
Package Dimensions
Package dimensions
Dimension label
Min.
Typ.
Max.
Unit
A
0.70
0.75
0.80
mm
A1
–
0.01
0.05
mm
b
0.15
0.20
0.25
mm
c
0.18
0.20
0.23
mm
D
5.90
6.00
6.10
mm
D2
3.70
3.80
3.90
mm
e
0.35
0.40
0.45
mm
Ne
4.35
4.40
4.45
mm
Nd
4.35
4.40
4.45
mm
E
5.90
6.00
6.10
mm
E2
3.70
3.80
3.90
mm
K
0.20
–
–
mm
L
0.35
0.40
0.45
mm
h
0.30
0.35
0.40
mm
80-Y0618-2 Rev A
110 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
7 Ordering Information
Table 7-1
Ordering information
Ordering number
Version
Default ordering unit
AR8033-AL1A
Commercial
Tray pack
AR8033-AL1A-R
Commercial
Tape and reel
AR8033-AL1B
Industrial
Tray pack
AR8033-AL1B-R
Industrial
Tape and reel
80-Y0618-2 Rev A
111 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
8 Top-side Marking
Table 8-1
Top-side markings
Ordering number
AR8033-AL1A
Marking
AR8033-AL1A
AR8033-AL1A-R
AR8033-AL1B
AR8033-AL1B-R
AR8033-AL1B
AR8033-AL1A
Figure 8-1
AR8033-AL1B
Top-side markings
80-Y0618-2 Rev A
112 Confidential and Proprietary - Qualcomm Atheros, Inc.
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
工商网监
湘ICP备2023018690号
