RM-1318-L

RM-1318 Reduced-miniature Reed Switch Form A, Center Contact, Release AT Configurable All dimensions in mm This reed switch is designed for applications where a size restriction is present, but higher load switching and current carrying capability is required. The blades have a good flexibility, for fast operation and good contact force, and can carry up to 1.5 A. The flattened leads are useful for orienting the internal blades to face one way while soldering, welding etc., for maximum in-group sensitivity. The three differential ranges available, cover a wide range of release specific applications. This reed switch is Lead (Pb) free and RoHS compliant. Formations Available Cropped SMD Welded Soldered Goal post L Formed Applications This reed switch is suitable for use in the following applications and many others: radio transmitters, instant water heaters, defective lamp detection, inclination sensors, pressure gauges, lake current measurement, fuel pumps, electric fishing reels, LEGO sensors... Electrical Sub code Operate Range Release Range Contact Rating (max) Switching Current (max) Carry Current (max) Switching Voltage (max) Switching Voltage (max) Breakdown Voltage (Min) Initial Contact Resistance (max) Insulation Resistance (min) Capacitance (min) Miscellaneous Operate Time (max) Bounce Time (max) Release Time (max) Resonance Frequency Operating Frequency Operating Temperature Test Coil Lead out plating Shock Resistance Vibration (10-2000Hz) AT AT W/ VA A A VDC VAC VDC m  pF L 10 – 40 4 – 20 10.0 0.5 1.50 180 130 200 100 10 11 0.2 M 10 - 40 6 – 25 10.0 0.5 1.50 180 130 200 120 10 11 0.2 H 10 – 40 7.5 – 30 10.0 0.5 1.50 180 130 200 150 10 11 0.2 ms ms ms Hz Hz °C g g 0.5 0.15 0.15 >2000 500 -40 to +200 717 102 004 Sn (Pb free) 30 20 Ordering Code RM-1318-(Sub Code)-(Start (Finish Operate AT) Operate AT)- Example RM-1318-M-10-14 Denotes 10-14 Operate AT band, with a minimum Release AT of 6. Other Configurations Available Dynamic contact resistance limit, Higher insulation resistance, Special release limits, Gold plates leads Please refer to our reed switch usage notes Due to continual improvement, specifications are subject to change without notice www.reed-sensor.com 10 May 2008 Reed Relays and Electronics India Limited  info@reed-switch.com  Tel 91-44-6528-4022
