SP-75-7.5

ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 75W Single Output with PFC Function Features : SP-75 series Universal AC input / Full range Built-in active PFC function, PF>0.93 Protections:Short circuit/Over load/Over voltage Built-in constant current limiting circuit Low profile: 33mm thickness LED indicator for power on 100% full load burn-in test Fixed switching frequency at PFC:67KHz PWM:134KHz 3 years warranty SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT VOLTAGE ADJ. RANGE VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR (Typ.) INPUT EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVER LOAD SP-75-3.3 3.3V 15A 0 ~ 15A 49.5W SP-75-5 5V 15A 0 ~ 15A 75W 80mVp-p 2.0% 0.5% 1.0% SP-75-7.5 7.5V 10A 0 ~ 10A 75W 80mVp-p 2.0% 0.5% 1.0% SP-75-12 12V 6.3A 0 ~ 6.3A 75.6W 80mVp-p 2.0% 0.5% 0.5% SP-75-13.5 13.5V 5.6A 0 ~ 5.6A 75.6W 80mVp-p 2.0% 0.5% 0.5% SP-75-15 15V 5A 0 ~ 5A 75W 80mVp-p 2.0% 0.5% 0.5% SP-75-24 24V 3.2A 0 ~ 3.2A 76.8W 100mVp-p 1.0% 0.5% 0.5% SP-75-27 27V 2.8A 0 ~ 2.8A 75.6W 100mVp-p 1.0% 0.5% 0.5% SP-75-48 48V 1.6A 0 ~ 1.6A 76.8W 100mVp-p 1.0% 0.5% 0.5% RIPPLE & NOISE (max.) Note.2 80mVp-p 2.0% 0.5% 1.0% 3.14 ~ 3.63V 4.75 ~ 5.5V 7.13 ~ 8.25V 11.4 ~ 13.2V 12.8 ~ 14.9V 14.3 ~ 16.5V 22.8 ~ 26.4V 25.7 ~ 29.7V 45.6 ~ 52.8V 600ms, 60ms at full load 36ms at full load Note.5 85 ~ 264VAC 120 ~ 370VDC 0.96/115VAC at full load 74% 77% 78% 79% 80% 80% 80% 47 ~ 63Hz PF>0.93/230VAC 68% 72% 1.3A/115VAC 0.7A/230VAC COLD START 30A/230VAC
