SP-750-24

ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 750W Single Output Power Supply SP-750 series Features : Universal AC input/Full range AC input active surge current limiting Built-in active PFC function,PF>0.96 Protections:Short circuit, overload, over voltage, over temperature Forced air cooling by built-in DC ball bearing fan 3 High power density 5.48/inch Built-in constant current limiting circuit With power good and fail signal output Built-in remote ON-OFF control Built-in remote sense function 3 years warranty SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT SP-750-5 5V 120A 0 ~ 120A 600W SP-750-12 12V 62.5A 0 ~ 62.5A 750W 120mVp-p 10 ~ 13.5V 1.0% 0.3% 0.5% SP-750-15 15V 50A 0 ~ 50A 750W 120mVp-p 13.5 ~ 16.5V 1.0% 0.3% 0.5% 1500ms, 50ms/115VAC at full load SP-750-24 24V 31.3A 0 ~ 31.3A 751.2W 120mVp-p 22 ~ 26.4V 1.0% 0.2% 0.5% SP-750-27 27V 27.8A 0 ~ 27.8A 750.6W 120mVp-p 24 ~ 30V 1.0% 0.2% 0.5% SP-750-48 48V 15.7A 0 ~ 15.7A 753.6W 120mVp-p 43 ~ 56V 1.0% 0.2% 0.5% RIPPLE & NOISE (max.) Note.2 120mVp-p VOLTAGE ADJ. RANGE 4.75 ~ 5.5V VOLTAGE TOLERANCE Note.3 2.0% LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR (Typ.) 0.5% 2.0% 16ms/230VAC 90 ~ 264VAC 47 ~ 63Hz PF>0.96/230VAC 81% 8.8A/115VAC 27A/115VAC 0.99/115VAC at full load 85% 4.2A/230VAC 45A/230VAC 87% 89% 89% 90% INPUT EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVER LOAD PROTECTION OVER VOLTAGE OVER TEMPERATURE POWER GOOD/FAIL FUNCTION REMOTE CONTROL WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS WITHSTAND VOLTAGE 105 ~ 125% rated output power Protection type : Constant current limiting, unit will Hiccup after 3 sec. 5.75 ~ 6.3V 13.8 ~ 16.2V 18 ~ 21V 27.6 ~ 32.4V Protection type : Shut down o/p voltage, re-power on to recover 85 5 (TSW1 ) Detect on heatsink of power transistor 85 5 31 ~ 36.5V 57.6 ~ 67.2V (TSW2 ) Detect on heatsink of power diode Protection type : Shut down o/p voltage, recovers automatically after temperature goes down 50ms/1ms Note.5 RC+/RC- short power on, open power off -20 ~ +60 (Refer to output load derating curve) 20~90% RH non-condensing -40 ~ +85 , 10 ~ 95% RH 0.05%/ (0 ~ 50 ) 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes UL60950-1, TUV EN60950-1 Approved I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC SAFETY & ISOLATION RESISTANCE EMI CONDUCTION & RADIATION Compliance to EN55011 (CISPR11), EN55022 (CISPR22) Class B EMC HARMONIC CURRENT Compliance to EN61000-3-2,-3 (Note 4) EMS IMMUNITY MTBF OTHERS NOTE Compliance to EN61000-4-2,3,4,5,6,8,11, ENV50204, EN55024, EN61000-6-2, EN61204-3 Heavy industry level, criteria A 769.3K hrs min. MIL-HDBK-217F (25 278*127*63.5mm (L*W*H) 2.9Kg; 6pcs / 18.4Kg / 0.98CUFT ) DIMENSION PACKING 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. 5. The power supply unit will have no output if the shorting connector is not assembled between RC+ & RC-. File Name:SP-750-SPEC 2006-10-17 ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 750W Single Output Power Supply Mechanical Specification 220 16 SP-750 Case No.919A 113 series Unit:mm 7 30 20 4-M3 5 6-M3 L=6 4-M3 Air flow direction 127 I/P 1 2 3 7 240 251 278 5 7 10 113 O/P 1 39 149 33 40.5 11 91 2-M6 220 TOP VIEW 15 BOTTOM VIEW 5 6 7 8 1 2 3 4 2 +V ADJ. 72 CONTROL 24.5 AC Input Terminal Pin. No. Assignment Pin No. 1 2 3 Assignment AC/L AC/N FG DC Output Terminal Pin. No Assignment Pin No. 1 2 Assignment DC OUTPUT +V DC OUTPUT -V Control Pin. No Assignment : MOLEX 5559-NP uses 5558male crimp terminal Pin No. 1 2 3 4 Assignment NC -S G RCPin No. Assignment Mating connector Terminal NC 5 MOLEX 5556 6 PF(Power fail signal) MOLEX 5557-NR Female crimp Terminal +S 7 receptacle RC+ 8 Block Diagram 20 34.5 63.5 4-M3 PFC fosc : 100KHz PWM fosc : 140KHz +S I/P EMI FILTER ACTIVE INRUSH CURRENT LIMITING RECTIFIERS PFC POWER SWITCHING DETECTION CIRCUIT PWM POWER SWITCHING RECTIFIERS & FILTER O.T.P. CURRENT LIMIT +V -V -S O.L.P. DETECTION CIRCUIT O.V.P. PFC CONTROL PWM CONTROL PF O.T.P. REMOTE CONTROL AUX POWER RC FAN FAN LOCK PROTECTION File Name:SP-750-SPEC 2006-10-17 ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 750W Single Output Power Supply Derating Curve Static Characteristics SP-750 series 100 100 90 80 85 70 60 LOAD (%) LOAD (%) 0 10 20 30 40 50 60 70 (HORIZONTAL) 40 60 50 40 20 -20 90 95 100 115 260 AMBIENT TEMPERATURE ( ) INPUT VOLTAGE (VAC) 60Hz Control Terminal Instruction Manual Power Fail Signal PF Signal is the voltage difference between "G" and "PF" pin output G PF Remote Sensing RC+ +S PF NC RC- G -S NC RC+ +S PF NC RC- G -S NC -V +V -V +V LOAD + -S LOAD + Remote Control Power ON: RC+/RC- Short Power OFF: RC+/RC- open RC- RC+ +S RC+ +S PF NC RC- G -S NC -V +V LOAD + F ile Name:SP-750-SPEC 2006-10-17
