A41-25-16

SPECIFICATION FOR APPROVAL Product Name Superworld Part No: Features Power Transformer (Lead Free) A41 (F) Series Page Rev No 1 0 Bobbins and shrould made of material to meet UL94V-0 flammability requirements. Insulating shroud provides 4000V RMS test voltage. Mechanical Drawing Schematic 6 115V 50/60Hz 5 2 115V 50/60Hz 1 12 8 11 7 Mechanical Dimensions VA 25 43 80 130 175 WT 1.25 1.60 2.80 4.10 6.50 L 2.812 3.125 2.500 2.812 3.125 W 1.875 2.062 2.375 2.875 2.875 H A B C T ML MW MTG #6 #6 #6 #8 #8 A A B B B 2.312 2.000 1.125 0.312 0.187 2.375 2.687 2.250 1.125 0.312 0.187 0.187 3.000 - 1.375 0.312 0.187 0.187 2.18 3.375 - 1.625 0.375 0.250 0.250 2.50 3.750 - 1.625 0.375 0.250 0.250 2.50 SUPERWORLD ELECTRONICS (S) PTE LTD SPECIFICATION FOR APPROVAL Product Name Superworld Part No: Electrical Characteristics : Part Number A41-25-10 A41-43-10 A41-80-10 A41-130-10 A41-175-10 A41-25-12 A41-43-12 A41-80-12 A41-130-12 A41-175-12 A41-25-16 A41-43-16 A41-80-16 A41-130-16 A41-175-16 A41-25-20 A41-43-20 A41-80-20 A41-130-20 A41-175-20 A41-25-24 A41-43-24 A41-80-24 A41-130-24 A41-175-24 A41-25-28 A41-43-28 A41-80-28 A41-130-28 A41-175-28 A41-25-36 A41-43-36 A41-80-36 A41-130-36 A41-175-36 A41-25-230 A41-43-230 A41-80-230 A41-130-230 A41-175-230 Power Transformer (Lead Free) A41 (F) Series Size VA 25 43 80 130 175 25 43 80 130 175 25 43 80 130 175 25 43 80 130 175 25 43 80 130 175 25 43 80 130 175 25 43 80 130 175 25 43 80 130 175 Secondary Rms Rating Series 10V C.T. @ 2.50A 10V C.T. @ 4.30A 10V C.T. @ 8.00A 10V C.T. @ 13.00A 10V C.T. @ 17.50A 12.6V C.T. @ 2.00A 12.6V C.T. @ 3.40A 12.6V C.T. @ 6.30A Parallel 5V @ 5.00A 5V @ 8.60A 5V @ 16.00A 5V @ 26.00A 5V @ 35.00A 6.3V @ 4.00A 6.3V @ 6.80A 6.3V @ 12.60A Page Rev No 2 0 12.6V C.T. @ 10.30A 6.3V @ 20.60A 12.6V C.T. @ 14.00A 6.3V @ 28.00A 16V C.T. @ 1.60A 16V C.T. @ 2.70A 16V C.T. @ 5.00A 16V C.T. @ 8.10A 16V C.T. @ 11.00A 20V C.T. @ 1.25A 20V C.T. @ 2.20A 20V C.T. @ 4.00A 20V C.T. @ 6.50A 20V C.T. @ 8.80A 24V C.T. @ 1.00A 24V C.T. @ 1.80A 24V C.T. @ 3.30A 24V C.T. @ 5.40A 24V C.T. @ 7.30A 28V C.T. @ 0.90A 28V C.T. @ 1.50A 28V C.T. @ 2.80A 28V C.T. @ 4.60A 28V C.T. @ 6.25A 36V C.T. @ 0.70A 36V C.T. @ 1.20A 36V C.T. @ 2.20A 36V C.T. @ 3.60A 36V C.T. @ 4.80A 230V C.T. @ 0.11A 230V C.T. @ 0.19A 230V C.T. @ 0.35A 230V C.T. @ 0.57A 230V C.T. @ 0.76A 8V @ 3.20A 8V @ 5.40A 8V @ 10.00A 8V @ 16.20A 8V @ 22.00A 10V @ 2.50A 10V @ 4.40A 10V @ 8.00A 10V @ 13.00A 10V @ 17.60A 12V @ 2.00A 12V @ 3.60A 12V @ 6.60A 12V @ 10.80A 12V @ 14.60A 14V @ 1.80A 14V @ 3.00A 14V @ 5.60A 14V @ 9.20A 14V @ 12.50A 18V @ 1.40A 18V @ 2.40A 18V @ 4.40A 18V @ 7.20A 18V @ 9.60A 115V @ 0.22A 115V @ 0.38A 115V @ 0.70A 115V @ 1.14A 115V @ 1.52A SUPERWORLD ELECTRONICS (S) PTE LTD
