TPT-18-6006

TPT-18-6006 Temperature Compensated Amplifier 6 GHz - 18 GHz This Amplifier offers exceptional performance over the band 6 GHz to 18 GHz with 23 dBm P1dB output power and 29 dB Gain. Teledyne Microwave amplifiers are balanced or feedback designs and manufactured with the latest MIC & MMIC technology. The GaAs FET’s used in these amplifiers are well established proven devices from multiple sources. Teledyne Microwave offers a complete line of Narrow and broadband Amplifiers covering the frequency range 500 MHz to 40 GHz. These products are available in either connectorized packages or as modules. For a complete list of these products and more, please visit our website. Other products from Teledyne Microwave Transceivers, Synthesizers, and YIG Products include: Specifications: Model Number: TPT-18-6006 Frequency Range: 6 GHz - 18 GHz 29 dB Gain (min): Gain Vs Temp at any Frequency: +/-1.75 dB Noise Figure (max): 8.5 dB 23 dBm Output Power @ 1dB Compression: Gain Flatness Vs Frequency: +/-2 dB 3rd Order Intercept (Typ): 28 dBm Power Supply: Input Voltage: 11.5 to 15 VDC 510 mA Current @ 12 VDC (typ): Current @ 12 VDC (max): 585 mA Case Type (See attached Outline): SX8 Temperature Range: -54 to +90C TELEDYNE MICROWAVE ISO 9001:2000 1274 Terra Bella Avenue, Mountain View, CA 94043 • PHN# 800.832.6869 or +1.650.962.6944 • FAX# 650.962.6845 www.teledynemicrowave.com • microwave@teledyne.com All Specifications are subject to change. Please contact Teledyne Microwave for the latest information on this product 08/05 TPT-18-6006 Temperature Compensated Amplifier 6 GHz - 18 GHz TELEDYNE MICROWAVE ISO 9001:2000 1274 Terra Bella Avenue, Mountain View, CA 94043 • PHN# 800.832.6869 or +1.650.962.6944 • FAX# 650.962.6845 www.teledynemicrowave.com • microwave@teledyne.com All Specifications are subject to change. Please contact Teledyne Microwave for the latest information on this product 08/05
