TSOP39240TR

TSOP39240TR

  • 厂商:

    TFUNK(威世)

  • 封装:

    -

  • 描述:

    SENSOR REMOTE REC 40.0KHZ 45M

  • 数据手册
  • 价格&库存
TSOP39240TR 数据手册
TSOP392.., TSOP394.. www.vishay.com Vishay Semiconductors IR Receiver Modules for Remote Control Systems 4 FEATURES 3 2 • Very low supply current 1 • Photo detector and preamplifier in one package • Internal filter for PCM frequency • Supply voltage: 2.5 V to 5.5 V • Improved immunity against ambient light • Two lenses for high sensitivity • Insensitive to supply voltage ripple and noise • Ultra small top-view PCB footprint • Material categorization: for definitions of compliance please see www.vishay.com/doc?99912 MECHANICAL DATA 22963 Pinning: LINKS TO ADDITIONAL RESOURCES 1, 4 = GND, 2 = VS, 3 = OUT 3D 3D Product Page 3D Models Calculators Marking ORDERING CODE Packages TSOP.9.... - 2400 pieces in 6 bags DESCRIPTION BLOCK DIAGRAM The TSOP39... series are miniaturized receiver modules for infrared remote control systems. Two PIN diodes and a preamplifier are assembled on a leadframe, the epoxy package contains an IR filter. The demodulated output signal can be directly connected to digital circuitry for decoding. 2 VS 30 k Ω 3 The TSOP394.. series devices are optimized to suppress almost all spurious pulses from energy saving lamps like CFLs. The AGC4 used in the TSOP394.. may suppress some data signals. The TSOP392.. series are provided primarily for compatibility with old AGC2 designs. New designs should prefer the TSOP394.. series containing the newer AGC4. Input AGC Band pass OUT Demodulator 1, 4 PIN GND Control circuit 20445-1 These components have not been qualified according to automotive specifications. APPLICATION CIRCUIT 17170-11 R1 IR receiver VS Circuit Transmitter with TSALxxxx + VS C1 μC OUT GND VO GND R1 and C1 recommended to reduce supply ripple for VS < 2.8 V Rev. 1.5, 03-Aug-2021 1 Document Number: 82778 THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 TSOP392.., TSOP394.. www.vishay.com Vishay Semiconductors PARTS TABLE NOISY ENVIRONMENTS AND LONG BURSTS (AGC2) VERY NOISY ENVIRONMENTS AND LONG BURSTS (AGC4) 30 kHz TSOP39230 TSOP39430 33 kHz TSOP39233 TSOP39433 36 kHz TSOP39236 TSOP39436 (1)(2)(3) 38 kHz TSOP39238 TSOP39438 (4)(5) 40 kHz TSOP39240 TSOP39440 56 kHz TSOP39256 TSOP39456 (6)(7) AGC Carrier frequency Package TVCast Pinning 1, 4 = GND, 2 = VS, 3 = OUT Dimensions (mm) 6.8 W x 2.6 H x 5.3 D Mounting Leaded Application Remote control (1) Best choice for Special options RC-5 (2) RC-6 (3) Panasonic (4) NEC (5) Sharp (6) r-step (7) Thomson RCA • Low voltage option: www.vishay.com/doc?82382 ABSOLUTE MAXIMUM RATINGS PARAMETER TEST CONDITION SYMBOL VALUE UNIT VS -0.3 to +6 V mA Supply voltage Supply current IS 3 Output voltage VO -0.3 to (VS + 0.3) V Output current IO 5 mA Junction temperature Storage temperature range Operating temperature range Power consumption Soldering temperature Tj 100 °C Tstg -25 to +85 °C Tamb -25 to +85 °C Tamb ≤ 85 °C Ptot 10 mW t ≤ 10 s, 1 mm from case Tsd 260 °C Note • Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect the device reliability ELECTRICAL AND OPTICAL CHARACTERISTICS (Tamb = 25 °C, unless otherwise specified) PARAMETER TEST CONDITION SYMBOL MIN. TYP. MAX. VS 2.5 - 5.5 V Ev = 0, VS = 3.3 V ISD 0.27 0.35 0.45 mA Ev = 40 klx, sunlight ISH - 0.45 - mA Ev = 0, test signal see Fig. 1, IR diode TSAL6200, IF = 50 mA d - 30 - m VOSL - - 100 mV Supply voltage Supply current Transmission distance Output voltage low mW/m2, IOSL = 0.5 mA, Ee = 0.7 test signal see Fig. 1 UNIT Minimum irradiance Pulse width tolerance: tpi - 5/fo < tpo < tpi + 6/fo, test signal see Fig. 1 Ee min. - 0.08 0.12 mW/m2 Maximum irradiance tpi - 5/fo < tpo < tpi + 6/fo, test signal see Fig. 1 Ee max. 30 - - W/m2 Angle of half transmission distance ϕ1/2 - ± 45 - ° Directivity Rev. 1.5, 03-Aug-2021 2 Document Number: 82778 THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 TSOP392.., TSOP394.. www.vishay.com Vishay Semiconductors TYPICAL CHARACTERISTICS (Tamb = 25 °C, unless otherwise specified) Optical Test Signal Ee 0.8 (IR diode TSAL6200, IF = 0.4 A, 30 pulses, f = f0, t = 10 ms) ton, toff - Output Pulse Width (ms) t tpi * T 10/f0 is recommended for optimal function * tpi Output Signal VO 1) VOH 2) VOL 16110 7/f0 < td < 15/f0 tpi - 5/f0 < tpo < tpi + 6/f0 td 1) tpo 2) ton 0.7 0.6 0.5 toff 0.4 0.3 0.2 λ = 950 nm, optical test signal, fig. 3 0.1 0 0.1 t 20744 1 10 100 1000 10 000 Ee - Irradiance (mW/m²) Fig. 1 - Output Active Low Fig. 4 - Output Pulse Diagram Output pulse width 0.9 0.8 1.2 Input burst length 0.7 Ee min./Ee - Relative Responsivity tpo - Output Pulse Width (ms) 1.0 0.6 0.5 0.4 0.3 λ = 950 nm, Optical test signal, fig. 1 0.2 0.1 0 0.1 1 10 100 1000 10 000 Ee - Irradiance (mW/m²) 20743 1.0 0.8 0.6 0.4 f = f0 ± 5 % Δf(3 dB) = f0/10 0.2 0.0 Fig. 2 - Pulse Length and Sensitivity in Dark Ambient 0.7 Optical Test Signal 600 µs t 600 µs t = 60 ms VO 94 8134 Output Signal, (see Fig. 4) VOH VOL t on 1.1 1.3 Fig. 5 - Frequency Dependence of Responsivity Ee min. - Threshold Irradiance (mW/m²) Ee 0.9 f/f0 - Relative Frequency 16925 t off t Fig. 3 - Output Function 4.0 Correlation with ambient light sources: 3.5 10 W/m² = 1.4 klx (std. illum. A, T = 2855 K) 10 W/m² = 8.2 klx (daylight, T = 5900 K) 3.0 2.5 Wavelength of ambient illumination: λ = 950 nm 2.0 1.5 1.0 0.5 0 0.01 20745 0.1 1 10 100 Ee - Ambient DC Irradiance (W/m²) Fig. 6 - Sensitivity in Bright Ambient Rev. 1.5, 03-Aug-2021 3 Document Number: 82778 THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 TSOP392.., TSOP394.. Vishay Semiconductors Axis Title 3.0 1.0 2.5 f = f0 f = 30 kHz f = 10 kHz f = 100 Hz 2.0 1.5 1.0 0.5 0 1 10 100 1000 10000 0.9 0.8 0.7 1000 0.6 1st line 2nd line 2nd line S(λ)rel. - Relative Spectral Sensitivity Ee min. - Threshold Irradiance (mW/m2) www.vishay.com 0.5 0.4 100 0.3 0.2 0.1 10 1150 0 ΔVS RMS - AC Voltage on DC Supply Voltage (mV) 750 850 1050 λ - Wavelength (nm) 21425 Fig. 7 - Sensitivity vs. Supply Voltage Disturbances 950 Fig. 10 - Relative Spectral Sensitivity vs. Wavelength 0° 1.0 10° 20° 30° Max. Envelope Duty Cycle 0.9 0.8 0.7 40° 0.6 1.0 0.5 TSOP392.. 0.4 TSOP394.. 0.3 0.9 50° 0.8 60° 0.2 70° 0.7 0.1 80° f = 38 kHz, Ee = 2 mW/m² 0 0 20 40 60 80 100 120 0.6 Burst Length (number of cycles/burst) Fig. 8 - Max. Envelope Duty Cycle vs. Burst Length Ee min. - Threshold Irradiance (mW/m2) 0.4 0.2 0 drel - Relative Transmission Distance Fig. 11 - Horizontal Directivity 0° 0.20 10° 20° 30° 0.18 0.16 0.14 40° 0.12 1.0 0.10 0.9 50° 0.8 60° 0.08 0.06 0.04 70° 0.7 0.02 80° 0 -30 -10 10 30 50 70 90 0.6 Tamb - Ambient Temperature (°C) Fig. 9 - Sensitivity vs. Ambient Temperature Rev. 1.5, 03-Aug-2021 0.4 0.2 0 drel - Relative Transmission Distance Fig. 12 - Vertical Directivity 4 Document Number: 82778 THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 TSOP392.., TSOP394.. www.vishay.com Vishay Semiconductors Ee min. - Sensitivity (mW/m2) 0.20 0.18 0.16 0.14 0.12 0.10 0.08 0.06 0.04 0.02 0.00 1 2 3 4 5 VS - Supply Voltage (V) Fig. 13 - Sensitivity vs. Supply Voltage Rev. 1.5, 03-Aug-2021 5 Document Number: 82778 THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 TSOP392.., TSOP394.. www.vishay.com Vishay Semiconductors SUITABLE DATA FORMAT Axis Title This series is designed to suppress spurious output pulses due to noise or disturbance signals. The devices can distinguish data signals from noise due to differences in frequency, burst length, and envelope duty cycle. The data signal should be close to the device’s band-pass center frequency (e.g. 38 kHz) and fulfill the conditions in the table below 10000 7 6 When a data signal is applied to the product in the presence of a disturbance, the sensitivity of the receiver is automatically reduced by the AGC to insure that no spurious pulses are present at the receiver’s output. 1000 1st line 2nd line 2nd line IR Signal Amplitude 5 4 3 100 2 1 Some examples which are suppressed are: 10 0 • DC light (e.g. from tungsten bulbs sunlight) 0 • Continuous signals at any frequency 5 10 15 20 Time (ms) 16920 • Strongly or weakly modulated pattern from fluorescent lamps with electronic ballasts (see Fig. 14 or Fig. 15) Fig. 14 - IR Disturbance from Fluorescent Lamp With Low Modulation Axis Title 10000 40 1000 0 1st line 2nd line 2nd line IR Signal Amplitude 20 -20 100 -40 10 -60 0 5 10 15 20 Time (ms) 16921 Fig. 15 - IR Disturbance from Fluorescent Lamp With High Modulation TSOP392.. TSOP394.. Minimum burst length 10 cycles/burst 10 cycles/burst After each burst of length a minimum gap time is required of 10 to 70 cycles ≥ 10 cycles 10 to 35 cycles ≥ 10 cycles For bursts greater than a minimum gap time in the data stream is needed of 70 cycles > 4 x burst length 35 cycles > 10 x burst length Maximum number of continuous short bursts/second 1800 1500 NEC code Yes Preferred RC5 / RC6 code Yes Preferred Thomson 56 kHz code Yes Preferred Sharp code Yes Preferred Mild disturbance patterns are suppressed (example: signal pattern of Fig. 13) Complex and critical disturbance patterns are suppressed (example: signal pattern of Fig. 14 or highly dimmed LCDs) Suppression of interference from fluorescent lamps Note • For data formats with short bursts please see the datasheet for TSOP393.., TSOP395.. Rev. 1.5, 03-Aug-2021 6 Document Number: 82778 THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 TSOP392.., TSOP394.. www.vishay.com Vishay Semiconductors PACKAGE DIMENSIONS in millimeters 2.6 6.8 (1.6) 5.9 R1.5 R1.5 R1.5 24 ± 0.3 max. (0.6) 4 5.3 Marking area Area not plane 0.9 0.6 max. GND VS Out 1.15 GND 1.27 nom. 0.4 ± 0.1 Technical drawings according to DIN specification. 1.27 nom. 3 x 1.27 = 3.81 2.6 Proposed hole layout from component side (for reference only) (4 x) (Ø 0.75) 0.5 (1.27) (1.27) (1.27) (4 x) (1.4) (3.05) Not indicated tolerances ± 0.2 Drawing-No.: GO-100220.01-4_Rev03_1 issue H: 18.03.16 (1) (4 x) BULK PACKAGING Standard shipping for TVCast is in conductive plastic bags. The packing quantity is determined by weight and the number of components per carton may vary by a maximum of ± 0.3 %. ORDERING INFORMATION T S P O = receiver S = sensor d d IC and package type d AGC d d Frequency Note • d = “digit”, please consult the list of available devices create a valid part number Example: TSOP39438 PACKAGING QUANTITY • 400 pieces per bag (each bag is individually boxed) • 6 bags per carton Rev. 1.5, 03-Aug-2021 7 Document Number: 82778 THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 Legal Disclaimer Notice www.vishay.com Vishay Disclaimer ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE. Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other disclosure relating to any product. Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special, consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular purpose, non-infringement and merchantability. Statements regarding the suitability of products for certain types of applications are based on Vishay's knowledge of typical requirements that are often placed on Vishay products in generic applications. Such statements are not binding statements about the suitability of products for a particular application. It is the customer's responsibility to validate that a particular product with the properties described in the product specification is suitable for use in a particular application. Parameters provided in datasheets and / or specifications may vary in different applications and performance may vary over time. All operating parameters, including typical parameters, must be validated for each customer application by the customer's technical experts. Product specifications do not expand or otherwise modify Vishay's terms and conditions of purchase, including but not limited to the warranty expressed therein. Hyperlinks included in this datasheet may direct users to third-party websites. These links are provided as a convenience and for informational purposes only. Inclusion of these hyperlinks does not constitute an endorsement or an approval by Vishay of any of the products, services or opinions of the corporation, organization or individual associated with the third-party website. Vishay disclaims any and all liability and bears no responsibility for the accuracy, legality or content of the third-party website or for that of subsequent links. Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining applications or for any other application in which the failure of the Vishay product could result in personal injury or death. Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. Product names and markings noted herein may be trademarks of their respective owners. © 2022 VISHAY INTERTECHNOLOGY, INC. ALL RIGHTS RESERVED Revision: 01-Jan-2022 1 Document Number: 91000
