OPA567 - High-Voltage (100V), High-Current (50mA) OPERATIONAL AMPLIFIERS, G = 1 Stable - Texas Instruments

型  号:
OPA567
大  小:
1138.26KB 共36页
厂  商:
TI[TexasInstruments]
主  页:
http://www.ti.com/
功能介绍:
OPA567 - High-Voltage (100V), High-Current (50mA) OPERATIONAL AMPLIFIERS, G = 1 Stable - Texas Instr...
推荐单价:

无报价

立即购买
Burr Brown Products from Texas Instruments OPA454 SBOS391 – DECEMBER 2007 High-Voltage (100V), High-Current (50mA) OPERATIONAL AMPLIFIERS, G = 1 Stable 1 FEATURES DESCRIPTION The OPA454 is a low-cost operational amplifier with high voltage (100V) and relatively high current drive (25mA). It is unity-gain stable and has a gain-bandwidth product of 2.5MHz. The OPA454 is internally protected against over-temperature conditions and current overloads. It is fully specified to perform over a wide power-supply range of ±5V to ±50V or on a single supply of 10V to 100V. The status flag is an open-drain output that allows it to be easily referenced to standard low-voltage logic circuitry. This high-voltage op amp provides excellent accuracy, wide output swing, and is free from phase inversion problems that are often found in similar amplifiers. The output can be independently disabled using the Enable/Disable Pin that has its own common return pin to allow easy interface to low-voltage logic circuitry. This disable is accomplished without disturbing the input signal path, not only saving power but also protecting the load. Featured in a small exposed metal pad package, the OPA454 is easy to heatsink over the extended industrial temperature range, –40°C to +85°C. Table 1. OPA454 RELATED PRODUCTS PRODUCT Enable/Disable (E/D) • WIDE POWER-SUPPLY RANGE: ±5V (10V) to ±50V (100V) • HIGH OUTPUT LOAD DRIVE: IO > ±50mA • WIDE OUTPUT VOLTAGE SWING: 1V to Rails • INDEPENDENT OUTPUT DISABLE OR SHUTDOWN • WIDE TEMPERATURE RANGE: –40°C to +85°C • PACKAGES: SO and HSOP PowerPAD™ 23 APPLICATIONS • • • • • • • • TEST EQUIPMENT AVALANCHE PHOTODIODE: High-V Current Sense PIEZOELECTRIC CELLS TRANSDUCER DRIVERS SERVO DRIVERS AUDIO AMPLIFIERS HIGH-VOLTAGE COMPLIANCE CURRENT SOURCES GENERAL HIGH-VOLTAGE REGULATORS/POWER Status Flag V+ DESCRIPTION 80V, 15mA 80V, 50mA 60V, 750mA 60V, 3A 60V, 9A 60V, 200mA 5V, 2A 5V, 2.4A OPA445 (1) -IN OPA454 +IN Enable/Disable Common (E/D Com) VVO OPA452 OPA547 OPA548 OPA549 OPA551 OPA567 OPA569 (1) The OPA445 is pin-compatible with the OPA445, except in applications using the offset trim, and NC pins other than open. 1 2 3 Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet. PowerPAD is a trademark of Texas Instruments, Inc. All other trademarks are the property of their respective owners. Copyright © 2007, Texas Instruments Incorporated PRODUCTION DATA information is current as of publication date. Products conform to specifications per the terms of the Texas Instruments standard warranty. Production processing does not necessarily include testing of all parameters. OPA454 SBOS391 – DECEMBER 2007 www.ti.com This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage. ESD damage can range from subtle performance degradation to complete device failure. Precision integrated circuits may be more susceptible to damage because very small parametric changes could cause the device not to meet its published specifications. ORDERING INFORMATION (1) PRODUCT OPA454 OPA454 (1) (2) PACKAGE-LEAD SO-8 HSOP-20 (2) PACKAGE DESIGNATOR DDA DWD PACKAGE MARKING OPA454 OPA454 For the most current package and ordering information see the Package Option Addendum at the end of this document, or see the TI web site at www.ti.com. Available Q2, 2008. ABSOLUTE MAXIMUM RATINGS (1) OPA454 Supply Voltage Signal Input Terminals, Voltage (2) Signal Input Terminals, Current E/D to E/D Com Voltage Output Short-Circuit (3) Operating Temperature Storage Temperature Junction Temperature Human Body Model (HBM) ESD Rating: Charged Device Model (CDM) Machine Model (MM) (1) (2) (3) TJ ISC TJ (2) UNIT V V mA V VS = (V+) – (V–) 120 (V–) – 0.3 to (V+) + 0.3 ±10 +5.5 Continuous –55 to +125 –55 to +125 +150 4000 500 150 °C °C °C V V V Stresses above these ratings may cause permanent damage. Exposure to absolute maximum conditions for extended periods may degrade device reliability. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those specified is not implied. Input terminals are diode-clamped to the power-supply rails. Input signals that can swing more than 0.3V beyond the supply rails should be current limited to 10mA or less. Short-circuit to ground. PIN ASSIGNMENTS DDA PACKAGE SO-8 PowerPAD (TOP VIEW) E/D Com (Enable/Disable Common) -IN +IN V1 2 3 4 PowerPAD Heat Sink (Located on bottom side) (1) DWD PACKAGE(1) HSOP-20 PowerPAD (TOP VIEW) 8 7 6 5 E/D (Enable/Disable) V+ OUT Status Flag VNC NC (3) (3) 1 2 3 4 5 6 7 8 9 10 PowerPAD Heat Sink (Located on top side) (2) 20 19 18 17 16 15 14 13 12 11 VNC NC (3) (3) V+IN Status Flag VOUT V+ NC NC (3) (3) (1) PowerPAD is internally connected to V–. Soldering the PowerPAD to the PCB is always required, even with applications that have low power dissipation. NC (3) -IN NC (3) E/D Com (Enable/Disable Common) V- E/D (Enable/Disable) V- (1) (2) (3) 2 Submit Documentation Feedback Available Q2, 2008. PowerPAD is internally connected to V–. NC = No internal connection Copyright © 2007, Texas Instruments Incorporated Product Folder Link(s): OPA454 OPA454 www.ti.com SBOS391 – DECEMBER 2007 ELECTRICAL CHARACTERISTICS: VS = ±50V Boldface limits apply over the specified temperature range, TA = –40°C to +85°C. At TP (1) = +25°C, RL = 4.8kΩ to mid-supply, VCM = VOUT = mid-supply, unless otherwise noted. OPA454 PARAMETER OFFSET VOLTAGE Input Offset Voltage vs Temperature vs Power Supply INPUT BIAS CURRENT Input Bias Current vs Temperature Input Offset Current NOISE Input Voltage Noise Density, f = 10Hz Input Voltage Noise Density, f = 10kHz f = 0.01Hz to 10Hz Current Noise Density, f = 1kHz INPUT VOLTAGE RANGE Common-Mode Voltage Range Common-Mode Rejection VCM CMRR Linear Operation VS = ±50V, –25V ≤ VCM ≤ +25V VS = ±50V, –45V ≤ VCM ≤ +45V Over Temperature Over Temperature INPUT IMPEDANCE Differential Common-Mode OPEN-LOOP GAIN Open-Loop Voltage Gain (4) AOL (V–) + 1V < VO < (V+) – 1V, RL = 49kΩ, IO = ±1mA (V–) + 1V < VO < (V+) – 1V, RL = 49kΩ, IO = ±1mA (V–) + 1V < VO < (V+) – 2V, RL = 4.8kΩ, IO = ±10mA (V–) + 1V < VO < (V+) – 2V, RL = 4.8kΩ, IO = ±10mA (V–) + 2V < VO < (V+) – 3V, RL = 1880Ω, IO = ±25mA (V–) + 2V < VO < (V+) – 3V, RL = 1880Ω, IO = ±25mA 80 100 100 130 112 115 106 102 84 dB dB dB dB dB dB 1013 || 10 1013 || 9 Ω || pF Ω || pF VS = ±50V, –25V ≤ VCM ≤ +25V VS = ±50V, –45V ≤ VCM ≤ +45V (V–) + 2.5 100 100 80 72 See Note 146 147 88 82 (3) (2) CONDITIONS MIN TYP MAX UNIT VOS dVOS/dT PSRR IO = 0 VS = ±4V to ±60V, VCM = 0V ±0.2 ±1.6 25 ±4 ±10 100 mV µV/°C µV/V pA IB IOS en ±1.4 ±100 See Typical Characteristics ±0.2 ±100 pA 300 35 15 nV/√Hz nV/√Hz µVPP fA/√Hz in 40 (V+) – 2.5 V dB dB dB dB (1) (2) (3) (4) TP is the temperature of the leadframe die pad (exposed thermal pad) of the PowerPAD package. See typical characteristic curve, Offset Voltage Drift Production Distribution (Figure 14). Typical range is (V–) + 1.5V to (V+) – 1.5V. Measured using low-frequency (
