MECHATRO N I C D R I V E S W I T H B L D C M O T O R
P A Nd r i ves
PD- 1 70 - 5 7
57mm dia mete r BLDC Enc oder Mot or w ith Cont roll er / Dri ver a nd Ser ial Inte rfac e
1 0 mm
M A IN CH A R AC T ER IS T IC S
INFO
The PD-170-57 is a full mechatronic solution including a 57 mm brushless DC motor. It combines a convenient servo controller electronic (TMCM-170) and an optical encoder with a range of different motor types. The PD-170-57 offers two motor torque options and can be controlled via RS232, RS485 or CAN interface. The power supply can be connected via screw connectors and the interface and the multi-purpose I/Os can be connected via high density JST connectors. This PANdrive combines the high resolution commonly known from stepper motors with the high dynamic, high velocity and high reliability of a BLDC drive. It integrates a position regulator and a ramp generator. The ramp generators supports parameterized smooth positioning also with an external switch in order to support an absolute position reference.
ELECTRICAL D ATA
• 12V to 48V supply voltage • up to 10A coil current • total length: 144 mm / 156 mm • rated torque: 0.32 / 0.42 Nm • number of poles: 4 • please also refer to the motor datasheet • RS-232, RS-485 or CAN 2.0b host interface • servo drive allows ultra precise and fast positioning • automatic positioning ramp generation with all parameters changeable on-the-fly • different start up-modes for commutation and initialization • high efficiency, low power dissipation electronics • integrated protection: reverse polarity, overload / overtemperature
MOTOR DATA
INTERFACE
FEATURES
RS-232 or RS-485
PD-170-57
Motion Controller
programmable
• 3 channel encoder with 500 CPR giving a resolution of 2000 positions per revolution
MOSFET Driver Stage
BLDC Motor
SOFTWARE
CAN
• stand alone operation (analog control or TMCL program) or remote controlled operation • PC-based demostration software allows setting of all parameters
14..48V DC
5V Power Supply
Encoder Interface
Encoder
OTHER
• Pluggable connectors for interface • RoHS compliant
OR DE R C O DE
D E SC R I P T IO N
PD4-170-57-E (-option) PD5-170-57-E (-option)
OP TI O NS
BLDC servo module with motor QBL5704-94-04-032 BLDC servo module with motor QBL5704-116-04-042
232 485
RS-232 and CAN interface RS-485 and CAN interface
www.trinamic.com – for detailed information and datasheets
