4053

UNISONIC TECHNOLOGIES CO., LTD 4053 TRIPLE 2-CHANNEL ANALOG MULTIPLEXERS/DEMULTIPLEXERS DESCRIPTION UTC 4053 is triple 2-channel analog multiplexers/demultiplexers for application as digitally–controlled analog switches. The device has three separate digital control inputs and an inhibit input. It feature low ON impedance and very low OFF leakage current. Control of analog signals up to the complete supply voltage range can be achieved. CMOS IC FEATURES * Wide Analog Voltage Range: VDD–VEE = 3V~18V. (Note: VEE must be≦VSS) * Break-Before-Make Switching Eliminates Channel Overlap. * Linearized Transfer Characteristics * Implement an SPDT Switch Effectively. * Pin to Pin Replacement for CD4053 Lead-free: 4053L Halogen-free: 4053G ORDERING INFORMATION Normal 4053-D16-T 4053-P16-R 4053-S16-R Ordering Number Lead Free Plating 4053L-D16-T 4053L-P16-R 4053L-S16-R Halogen Free 4053G-D16-T 4053G-P16-R 4053G-S16-R Package DIP-16 TSSOP-16 SOP-16 Packing Tube Tape Reel Tape Reel www.unisonic.com.tw Copyright © 2009 Unisonic Technologies Co., LTD 1 of 6 QW-R502-036.C 4053 PIN CONFIGURATION Y1 1 Y0 2 Z1 3 Z4 Z0 5 INH 6 VEE 7 VSS 8 UTC 4053 16 VDD CMOS IC 15 Y 14 13 12 X X1 X0 11 A 10 9 B C PIN DESCRIPTION PIN No. 14,15,4 6 7 8 11,10,9 12,13 2,1 5,3 16 SYMBAL X,Y,Z INH VEE VSS A,B,C X0,X1 Y0,Y1 Z0,Z1 VDD NAME AND FUNCTION Commons Input/Output Inhibit Input Supply Voltage Ground Digital Control Inputs A-X Switches Inputs/Outputs B-Y Switches Inputs/Outputs C-Z Switches Inputs/Outputs Positive Supply Voltage UNISONIC TECHNOLOGIES CO., LTD www.unisonic.com.tw 2 of 6 QW-R502-036.C 4053 ABSOLUTE MAXIMUM RATING PARAMETER DC Supply Voltage (Referenced to VEE, VSS≧VEE) SYMBOL VDD RATINGS -0.5 ~ +18 CMOS IC UNIT V Input or Output Voltage (DC or Transient) VIN, VOUT -0.5 ~ VDD +0.5 V (Referenced to VSS for Control Inputs and VEE for Switch I/O) Input Current (DC or Transient), per Control Pin IIN ±10 mA Switch Through Current ISW ±25 mA Power Dissipation 500 mW PD Derating above 65°C 7 mW/°C Junction Temperature TJ 125 °C Operating Temperature Range TOPR -40 ~ +125 °C Storage Temperature Range TSTG -40 ~ +150 °C Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. ELECTRICAL CHARACTERISTICS(Ta=25°C, unless otherwise specified.) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT SUPPLY REQUIREMENTS (Voltages Referenced to VEE) VDD – 3≧VSS≧VEE 3 18 V Power Supply Voltage Range VDD VDD=5V 0.005 5 µA Control Inputs: VIN = VSS or VDD Quiescent Current per Switch I/O: VEE ≦VI/O ≦VDD, IQ VDD=10V 0.010 10 µA Package and ΔVsw≦500mV(Note 2) VDD=15V 0.015 20 µA VDD=5V (0.07 µA/kHz) f + IQ µA Total Supply Current Ta=25°C only (The channel (Dynamic Plus Quiescent, ID(AV) component, (VIN-VOUT)/RON, is VDD=10V (0.20 µA/kHz) f + IQ µA Per Package) excluded) VDD=15V µA (0.36 µA/kHz) f + IQ SWITCHES IN/OUT AND COMMONS OUT/IN -- X, Y, Z (Voltages Referenced to VEE) Recommended Peak–to–Peak Voltage VI/O Channel On or Off 0 VDD VPP Into or Out of the Switch Recommended Static or Dynamic ΔVsw Channel On 0 600 mV Voltage Across the Switch (Note2) Output Offset Voltage VO(OFF) VIN = 0V, No Load 10 µV ΔVsw≦500mV VDD=5V 250 1050 Ω ON Resistance VIN = VIL or VIH (Control), and RON VDD=10V 120 500 Ω VIN = 0 to VDD (Switch) VDD=15V 80 280 Ω ΔON Resistance Between VDD=5V 25 70 Ω Any Two Channels in the VDD=10V ΔRON 10 50 Ω Same Package 10 45 Ω VDD=15V VIN = VIL or VIH (Control) ±0.05 ±100 nA Channel to Channel or Any Off–Channel Leakage Current IOFF One Channel, VDD=15V Capacitance, Switch I/O CI/O Inhibit = VDD 10 pF Capacitance, Common O/I CO/I Inhibit = VDD 17 pF Pins Not Adjacent Capacitance, Feedthrough 0.15 pF CI/O Pins Adjacent (Channel Off) 0.47 Pf CONTROL INPUTS – INHIBIT A, B, C (Voltages Referenced to VSS) VDD=5V 2.25 1.5 V Low Level Input Voltage RON= per spec, IOFF = per spec VIL VDD=10V 4.50 3.0 V VDD=15V 6.75 4.0 V VDD=5V 3.5 2.75 V High Level Input Voltage RON= per spec, IOFF = per spec VIH VDD=10V 7.0 5.50 V VDD=15V 11 8.25 V Input Leakage Current ILEAK VIN= 0 or VDD, VDD=15V ±0.00001 ±0.1 µA Input Capacitance CIN 5.0 7.5 pF UNISONIC TECHNOLOGIES CO., LTD www.unisonic.com.tw 3 of 6 QW-R502-036.C 4053 DYNAMIC ELECTRICAL CHARACTERISTICS (CL = 50pF, Ta=25°C, VEE≦VSS, unless otherwise specified) PARAMETER Propagation Delay Times Switch Input to Switch Output (RL = 10 kΩ) Inhibit to Output SYMBOL tPLH, tPHL VDD–VEE TEST CONDITIONS Vdc tPLH, tPHL =(0.17 ns/pF)CL + 16.5ns 5 10 tPLH, tPHL =(0.08 ns/pF)CL + 4.0ns 15 tPLH, tPHL =(0.06 ns/pF)CL + 3.0ns 5 10 15 5 10 15 10 (RL=10kΩ, VEE=VSS) Output “1” or “0” to High Impedance, or High Impedance to “1” or “0” Level RL = 10 kΩ, VEE = VSS MIN TYP 25 8.0 6.0 275 140 110 300 120 80 0.07 CMOS IC MAX 65 20 15 550 280 220 600 240 160 UNIT ns ns ns ns ns ns ns ns ns % tPHZ, tPLZ tPZH, tPZL tPLH, tPHL THD Control Input to Output Total Harmonic Distortion RL = 10KΩ, f = 1 kHz, Vin = 5 VPP RL = 1kΩ, VIN = 1/2 (VDD–VEE) p–p, Bandwidth BW 10 17 MHz CL = 50pF, 20 Log (Vout/Vin) = -3dB) RL=1KΩ, VIN = 1/2 (VDD–VEE) p–p Off Channel Feedthrough 10 -50 dB Attenuation fIN = 55MHz RL = 1kΩ, VIN = 1/2 (VDD–VEE) p–p Channel Separation 10 -50 dB fIN = 3MHz Crosstalk, Control Input to R1 = 1kΩ, RL = 10kΩ Control 10 75 mV Common O/I tTLH = tTHL = 20ns, Inhibit = VSS Note 1. Data of “TYP” is intended as an indication of the IC’s potential performance. 2. For voltage drops across the switch(ΔVsw)>600mV (>300mV at high temperature), excessive VDD current may be drawn, i.e. the current out of the switch may contain both VDD and switch input components. The reliability of the device will be unaffected unless the Maximum Ratings are exceeded. UNISONIC TECHNOLOGIES CO., LTD www.unisonic.com.tw 4 of 6 QW-R502-036.C 4053 TEST CIRCUIT CMOS IC VDD IN/OUT VDD VDD OUT/IN VEE VDD LEVEL CONVERTED CONTROL IN/OUT OUT/IN VEE CONTROL Switch Circuit Schematic TRUTH TABLE 16 VDD BINARY TO 1 - OF - 2 DECODER WITH INHIBIT Control Inputs Select INHIBIT CBA 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 0 0 1 1 0 0 1 1 x 0 1 0 1 0 1 0 1 x ON Switches UTC 4053 Z0 Z0 Z0 Z0 Z1 Z1 Z1 Z1 Y0 Y0 Y1 Y1 Y0 Y0 Y1 Y1 None X0 X1 X0 X1 X0 X1 X0 X1 INH 6 A 11 B 10 C9 8 X0 12 X1 13 Y0 Y1 Z0 Z1 2 1 5 3 LEVEL CONVERTER VSS 7 VEE 14 X 15 Y 4Z 1 x x = Don’t Care UTC 4053 Functional Diagram UNISONIC TECHNOLOGIES CO., LTD www.unisonic.com.tw 5 of 6 QW-R502-036.C 4053 TYPICAL CHARACTERISTICS CMOS IC "ON" Resistance, RON (Ω) 350 "ON" Resistance, RON (Ω) VDD = 2.5 V 300 VEE = - 2.5 V Ta =25°C 250 200 150 100 50 0 -10 -8.0 -6.0 -4.0 -2.0 0 2.0 4.0 6.0 8.0 10 Input Voltage , VIN (V) UTC assumes no responsibility for equipment failures that result from using products at values that exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other parameters) listed in products specifications of any and all UTC products described or contained herein. UTC products are not designed for use in life support appliances, devices or systems where malfunction of these products can be reasonably expected to result in personal injury. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner. The information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and may be changed without notice. UNISONIC TECHNOLOGIES CO., LTD www.unisonic.com.tw "ON" Resistance, RON (Ω) 6 of 6 QW-R502-036.C
