VS-700

VS-700 Voltage Controlled SAW Oscillator Features • Industry Standard Package, 5.0 x 7.5 x 2.5 mm • Output Frequencies from 500 MHz to 850 MHz • 3.3 V Operation • Low Jitter < 0.20 ps-rms across 50 kHz to 80 MHz • LV-PECL Configuration with Fast Transition Times • Complementary Outputs • Output Disable Feature • Fully Compatible for Lead Free Assembly Applications PLL circuits for Clock Smoothing and Frequency Translation Description • 1-2-4 Gigabit Fibre Channel • 10 Gigabit Fibre Channel • 10GbE LAN / WAN • OC-192 • SONET / SDH Vcc COutput Output Standard INCITS 352-2002 INCITS 364-2003 IEEE 802.3ae ITU-T G.709 GR-253-CORE Issue3 SAW Description The VS-700 is a SAW based voltage controlled oscillator that operates at the fundamental frequency of the internal SAW filter. The SAW filter is a high-Q quartz device that enables the circuit to achieve low phase jitter performance over a wide operating temperature range. The oscillator is housed in a hermetically sealed leadless surface mount package offered on tape and reel. It has an output disable to facilitate on-board testing. Vc OD Gnd Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 P age 1 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 17May04 VS-700 Voltage Controlled SAW Oscillator Electrical Performance Parameter Frequency Nominal Frequency Absolute Pull Range Linearity Gain Transfer (See Pg 5) Temperature Stability Supply Voltage Current (No Load) Outputs Mid Level Swing Current Rise Time Fall Time Symmetry Spurious Suppression Jitter (See Pg 5) Control Voltage Input Impedance Modulation Bandwidth Operating Temperature Package Size 1. 2. 3. 4. 5. 6. 7. 8. Symbol fN APR Lin KV fSTAB VCC ICC Minimum Typical 500 - 850 Maximum Units MHz ppm % ppm/V ppm Notes 1,2,3 1,2,3,8 2,4,8 2,8 1,6 2,3 3 2,3 2,3 6 5,6 5,6 2,3 6 6,7 6 6 1,3 ±50 ±5 +390 ±100 3.3 55 VCC-1.3 650 250 250 50 60 0.120 100 500 3.63 70 VCC-1.1 800 20 400 400 55 2.97 V mA V mV-pp mA ps ps % dBc ps-rms kΩ kHz °C mm VCC-1.5 500 IOUT tR tF SYM φJ Zc BW TOP -40 45 50 85 5.0 x 7.5 x 2.5 See Standard Frequencies and Ordering Information (Pg 7). Parameters are tested with production test circuit below (Fig 1). Parameters are tested at ambient temperature with test limits guardbanded for specified operating temperature. Measured as the maximum deviation from the best straight-line fit, per MIL-0-55310. Measured from 20% to 80% of a full output swing (Fig 2). Not tested in production, guaranteed by design, verified at qualification. Integrated across 50 kHz to 80 MHz, per GR-253-CORE Issue3. Tested with Vc = 0.3V to 3.0V. (-1.3V to +2V) Disable, Enable (-1.3V, Open) 1 6 (+2V) 2 5 COutput tR 80% tF SYM = 100 x tA / tB Vcc - 1.0V (-1.3V) 3 4 50Ω Output Vcc - 1.3V 50Ω 20% Vcc - 1.6V Test Circuit Notes: 1) To Permit 50Ω Measurement of Outputs, all DC Inputs are Biased Down 1.3V. 2) All Voltage Sources Contain Bypass Capacitors to Minimize Supply Noise. 3) 50Ω Terminations are Within Test Equipment. tA tB Figure 1. Test Circuit Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 P age 2 of 7 Figure 2. 10K LV-PECL Waveform Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 17May04 VS-700 Voltage Controlled SAW Oscillator Outline Diagram 6 5 4 6.76 [0.266] 0.86 [0.034] 1.68 [0.066] Suggested Pad Layout VS700LG XXX.XXX VI YWW 1 2 7.49±0.15 [0.295±0.006] 1.91 [0.075] 3 5.08±0.15 [0.200±0.006] 2.49±0.18 [0.098±0.007] 1.27 [0.050] 1.70 [0.067] 3.83 5.54 [0.151] [0.218] 2.34 [0.092] 1.27 [0.050] R0.64 [0.025] 2.54 [0.100] 5.08 [0.200] mm [inch] 2.54 [0.100] 5.08 [0.200] mm [inch] Pin Out Pin 1 2 Marking Key Function VCSO Control Voltage Output Disable Disabled = LV-CMOS Logic 0 (or Gnd) Enabled = LV-CMOS Logic 1 (or Open) Case and Electrical Ground VCSO Output VCSO Complementary Output Power Supply Voltage (3.3 V ±10%) Symbol VC OD Position 6 L = LFF Position 7 G = GNN H = HNN 3 4 5 6 GND Output COutput VCC Tape and Reel (EIA-481-2-A) Po ØDo W2 F W D C N A P1 W1 B Tape Dimensions (mm) Dimension Tolerance VS-700 Reel Dimensions (mm) F Typ 7.5 W Typ 16 Do Typ 1.5 Po Typ 4 P1 Typ 8 A Typ 178 B Min 1.5 C Typ 13 D Min 20.2 N Min 50 W1 Typ 16.4 W2 Max 22.4 # Per Reel 200 Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 P age 3 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 17May04 VS-700 Voltage Controlled SAW Oscillator Absolute Maximum Ratings Parameter Power Supply Output Current Voltage Control Range Storage Temperature Soldering Temp/Time Symbol VCC Iout VC TS TLS Ratings 0 to 6 25 0 to VCC -55 to 125 220/10 Unit V mA V °C °C/sec Stresses in excess of the absolute maximum ratings can permanently damage the device. Functional operation is not implied at these or any other conditions in excess of conditions represented in the operational sections of this datasheet. Exposure to absolute maximum ratings for extended periods may adversely affect device reliability. Permanent damage is also possible if OD or Vc is applied before Vcc. Suggested Output Load Configurations +3.3V 0.10 µF 0.01 µF 0.10 µF 0.01 µF 150 Ω 150Ω +3.3V +3.3V Vc 1 OD Gnd 3 4 2 6 5 Vcc COutput Output Z = 50Ω Z = 50Ω 100Ω Vc 1 OD Gnd 3 4 2 6 5 Vcc COutput Output Z = 50Ω Z = 50Ω 40 Ω 40 Ω 49 Ω 49 Ω 240Ω 240Ω LV-PECL to LV-PECL: For short transmission lengths, the power consumption could be reduced by removing the 100Ω resistor and doubling the value of the pull down resistors. LV-PECL to LVDS: Restricted for short transmission lengths. Configuration may require modification depending on LVDS receiver. +3.3V 0.10 µF 0.01 µF 0.10 µF 0.01 µF +2.0V Vc OD Gnd 1 2 3 6 5 4 Vcc COutput Output 0.01 µF 0.01 µF Vc OD -1.3V 1 2 3 6 5 4 Vcc COutput Output 240Ω 240Ω Functional Test: Allows standard power supply configuration. Since AC coupled, the LV-PECL levels cannot be measured. Production Test: Allows direct DC coupling into 50 Ω measurement equipment. Must bias the power supplys as shown. Similar to Figure 1. Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 P age 4 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 17May04 VS-700 Voltage Controlled SAW Oscillator Typical Characteristics 800 At Ambient (22.5 oC) Typical Gain Transfer @ 622.0800 = +390 ppm/V 600 400 Frequency (PPM) 200 0 -200 -400 y = 389.92x - 538.34 -600 622 Vc Pull Linear (622 Vc Pull) -800 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3 Control Voltage (V) Typical Calculated Jitter SONET OC-48 (12kHz-20MHz) = 0.166 ps-rms; 1.16 ps-pp SONET OC-192 (50kHz-80MHz) = 0.118 ps-rms; 0.83 ps-pp Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 P age 5 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 17May04 VS-700 Voltage Controlled SAW Oscillator Reliability VI qualification includes aging at various extreme temperatures, shock and vibration, temperature cycling, and IR reflow simulation. The VS-700 family is capable of meeting the following qualification tests: Environmental Compliance Parameter Mechanical Shock Mechanical Vibration Solderability Gross and Fine Leak Resistance to Solvents Conditions MIL-STD-883, Method 2002 MIL-STD-883, Method 2007 MIL-STD-883, Method 2003 MIL-STD-883, Method 1014 MIL-STD-883, Method 2016 Handling Precautions Although ESD protection circuitry has been designed into the VS-700 proper precautions should be taken when handling and mounting. VI employs a human body model (HBM) and a charged-device model (CDM) for ESD susceptibility testing and design protection evaluation. ESD Ratings Model Human Body Model Charged Device Model Minimum 1500 V 1000 V Conditions MIL-STD 883, Method 3015 JEDEC, JESD22-C101 Reflow Profile (IPC/JEDEC J-STD-020B) Parameter PreHeat Time Ramp Up Time Above 217 oC Time To Peak Temperature Time At 250 oC Ramp Down Symbol tS R UP tL t AMB-P tP R DN 250 Value 60 sec Min, 180 sec Max 3 oC/sec Max 60 sec Min, 150 sec Max 480 sec Max 20 sec Min, 40 sec Max 6 oC/sec Max tL R UP Temperature (DegC) 217 200 tP R DN The device has been qualified to meet the JEDEC standard for Pb-Free assembly. The temperatures and time intervals listed are based on the Pb-Free small body requirements. The VS-700 device is hermetically sealed so an aqueous wash is not an issue. 150 tS t AMB-P 25 Time (sec) Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 P age 6 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 17May04 VS-700 Voltage Controlled SAW Oscillator Standard Frequencies (MHz) 531.2500 644.5313 690.5692 750.0000 569.1964 657.4219 693.4830 777.6000 622.0800 666.5143 693.7500 779.5686 624.7048 669.3266 707.3527 780.8810 625.0000 669.6429 716.5732 781.2500 627.3296 670.8386 718.7500 796.8750 629.9878 672.1627 719.7344 805.6641 637.5000 673.4566 748.0709 809.0635 Other frequencies available upon request Ordering Information VS - 700 - L F F - G N N - xxx.xxx Product Family VS: VCSO Frequency (See Above) 500 - 850 MHz Package 700: 5.0 x 7.5 x 2.5 mm Other (Future Use) N: N/A Input L: 3.3 V Other (Future Use) N: N/A Output F: LV-PECL Absolute Pull Range G: +/- 50 ppm H: +/- 100 ppm Operating Temperature F: -40 to 85 ° C For Additional Information, Please Contact: USA: Vectron International, 267 Lowell Rd, Hudson, NH 03051 . . . . Tel: 1-88-VECTRON-1 Fax: 1-888-FAX-VECTRON EUROPE: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: +49 (0) 3328-4784-17 Fax: +49 (0) 3328-4784-30 ASIA: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: +86-21-28909740 Fax: +86-21-28909240 Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. Vectron International, 267 Lowell Rd, Hudson NH 03051-4916 P age 7 of 7 Tel: 1-88-VECTRON-1 Website: www.vectron.com Rev: 17May04
