P16

P16, PA16 Vishay Sfernice Knob Potentiometer FEATURES • 1 W at 40 °C • Test according to CECC 41300 • P16 - version for professional and industrial applications • PA16 - version for professional audio applications • Compact (integrated) • Minimum clearance required RoHS COMPLIANT • Safety in use due to good insulation: > 104 MΩ 500 VDC The P16 is a revolutionary concept in panel mounted potentiometers. This unique design consists of a knob driving and incorporating a cermet potentiometer. Only the mounting hardware and terminals are situated on the back side of the panel reducing to a minimum the required clearance. • High dielectric strength: 2500 VRMS • Fully sealed and panel sealed • Metallic or plastic knob options • Cermet or conductive plastic DIMENSIONS in millimeters (± 0.5 mm) P16 - PA16 Thickness nut 2 mm washer 1.5 mm b 3 terminals 0.3 Panel sealing ring 1.8 Thread M10 x 0.75 12 wrench PANEL CUTOUT 30 c 8 a 9 ± 0.5 7 13.5 ± 1 15.5 ± 1 + 0.1 8.1 + 0 Panel thickness max.: 3 mm ø 10 + 0.1 +0 Reference mark ø 16 Document Number: 51036 Revision: 19-Dec-07 For technical questions, contact: sfer@vishay.com See also: Application Notes www.vishay.com 127 P16, PA16 Vishay Sfernice Knob Potentiometer ELECTRICAL SPECIFICATIONS P16 Resistive Element Electrical Travel 1.25 P16 LIN. LAW “A” ” 1.00 RETED POWER IN W PA16 conductive plastic 270° ± 10° cermet 270° ± 10° 0.75 P16 LOG. LAWS “L & F” 0.50 & PA16 LIN. LAW 0.25 PA16 LOG. LAWS 20 40 NM Power Rating Chart NP NM NP NM NP 0 0 60 80 100 120 140 AMBIENT TEMPERATURE IN °C a c (3) b (2) cw Circuit Diagram (1) 100 80 F % TOTAL RESISTANCE 60 A L 40 Resistance Laws 20 0 0 20 40 60 80 100 % CLOCKWISE SHAFT ROTATION Resistance Range Standard Series E3 Tolerance Power Rating linear law logarithmic laws standard on request linear logarithmic 22 Ω to 10 MΩ 100 Ω to 2.2 MΩ 1 - 2.2 - 4.7 and on request 1 - 2 - 5 ± 20 % ± 10 % 1 W at + 40 °C 0.5 W at + 40 °C ± 150 ppm/°C 2500 V 350 V ≥ 10 4 M Ω 3 % Rn or 3 Ω 1Ω 106 MΩ 1 kΩ to 1 MΩ 470 Ω to 500 kΩ 1 - 2.2 - 4.7 ± 20 % ± 10 % (1 kΩ to 100 kΩ) 0.5 W at + 40 °C 0.25 W at + 40 °C ± 1000 ppm/°C 2500 V 350 V ≥ 10 4 M Ω 2 % Rn or 3 Ω 1Ω 106 MΩ Temperature Coefficient (Typical) Dielectric Strength (RMS) Limiting Element Voltage (Linear Law) Insulation Resistance (500 VDC) Contact Resistance Variation End Resistance (Typical) Insulation Resistance (500 VDC) www.vishay.com 128 For technical questions, contact: sfer@vishay.com See also: Application Notes Document Number: 51036 Revision: 19-Dec-07 P16, PA16 Knob Potentiometer Vishay Sfernice MECHANICAL SPECIFICATIONS Mechanical Travel Operating Torque End Stop Torque Max. Tightening Torque of Mounting Nut Unit Weight 300° ± 5° 2 Ncm typical 25 Ncm maximum 250 Ncm maximum 4.5 g typical ENVIRONMENTAL SPECIFICATIONS Metallic Knob Temperature Range Climatic Category Sealing Protection Grades - 40 °C to 125 °C 40/100/56 sealed container and panel sealed IP67 Plastic Knob - 40 °C to 85 °C 40/85/56 MARKING • VISHAY trademark • Ohmic value • Tolerance (in %) • Resistance law • Manufacturing date PACKAGING • Carton box of 20 pieces CONTROL KNOB Black metallic knob (NM). Black plastic knob (NP). For white and blue color see ordering information. Other dimensions, shapes, colors of control knobs are manufactured on request - please consult VISHAY. Other reference marks (shapes, colours) and legends can be printed on plastic knob on request - please consult VISHAY. P16 STANDARD RESISTANCE ELEMENT DATA STANDARD MAX. MAX. MAX. MAX. RESIS- POWER MAX. CUR. POWER MAX. CUR. TANCE AT VOLTAGE THROUGH AT VOLTAGE THROUGH VALUES 40 °C WIPER 40 °C WIPER Ω 22 47 100 220 470 1K 2.2K 4.7K 10K 22K 47K 100K 220K 470K 1M 2.2M 4.7M 10M W 1 V 4.69 6.85 10 14.8 21.7 31.6 46.9 68.5 100 148 217 316 350 350 350 350 350 350 mA 213 146 100 67.4 46.1 31.6 21.3 14.6 10 6.74 4.61 3.16 1.59 0.75 0.35 0.16 0.07 0.012 W V mA LINEAR LAW LOG LAW TYP. TCR - 40 °C + 85 °C 10-6/°C PA16 STANDARD RESISTANCE ELEMENT DATA LINEAR LAW LOG LAW STANTYP. DARD MAX. MAX. MAX. MAX. TCR RESIS- POWER MAX. CUR. POWER MAX. CUR. - 55°C TANCE AT VOLTAGE THROUGH AT VOLTAGE THROUGH + 125 °C VALUES 40 °C WIPER 70 °C WIPER Ω 470 1K 2.2K 4.7K 10K 22K 47K 100K 220K 470K 1M W 0.5 V 22.4 33.2 48.5 79.7 105 153 224 332 350 350 mA 22.4 15.1 10.3 7.07 4.77 3.26 2.24 1.51 0.74 0.35 W 0.25 V 10.8 15.8 23.5 34.3 50.0 74 108 158 235 343 mA 23.1 16 11 7 5.0 3.4 2.3 1.6 1.1 0.7 ppm/°C 0.5 1 0.56 0.26 0.12 0.05 0.02 0.01 0.5 0.26 0.12 0.056 7.1 10.5 15.3 22.4 33.2 48.5 70.7 105 153 224 332 350 350 350 71 48 32.6 22.4 15.1 10.3 7.07 4.77 3.26 2.24 1.51 0.74 0.35 0.16 ± 1000 ± 150 0.5 0.26 0.12 0.25 Document Number: 51036 Revision: 19-Dec-07 For technical questions, contact: sfer@vishay.com See also: Application Notes www.vishay.com 129 P16, PA16 Vishay Sfernice Knob Potentiometer PERFORMANCE TESTS CONDITIONS 1000 h at Pn 90'/30' cycle at + 40 °C 56 days 40 °C, 93 % HR 50 g at 11 ms 3 successive shocks in 3 axes 10 - 55 Hz 0.75 mm or 10 g during 6 h 50 000 cycles TYPICAL VALUES AND DRIFTS ΔRT/RT (%) ±5% Insulation resistance: > 104 MΩ Contact res. variation: < 2 % Rn ±2% Insulation resistance: > 104 MΩ ± 0.2 % ΔR1-2/R1-2 (%) ±1% ± 0.5 % Load Life Long Term Damp Heat Shock Vibration Rotational Life ± 0.2 % ±5% Contact res. variation: < 2 % Rn ΔV1-2/ΔV1-3 ≤ ± 0.5 % - SAP ORDERING INFORMATION P 1 6 N P 2 2 3 M A B 1 5 MODEL P16 = Cermet PA16 = Conductive plastic STYLE NM: Metallic black NP: Plastic black WM: Metallic white WP: Plastic white BP: Plastic blue OHMIC VALUE 223 = 22 kΩ for ohmic value range see ELECTRICAL SPECIFICATION TOLERANCE M = ± 20 % on request K = ± 10 % TAPER A: Linear L: Clockwise logarithmic F: Inverse clockwise logarithmic PACKAGING CODE B15 = Box of 20 pieces SPECIAL NUMBER (if applicable) given by VISHAY for custom design PART NUMBER DESCRIPTION (for information only) P16 MODEL NP STYLE 22 kΩ VALUE 20 % TOLERANCE A TAPER SPECIAL BO20 PACKAGING SPECIAL e3 LEAD (Pb)-FREE www.vishay.com 130 For technical questions, contact: sfer@vishay.com See also: Application Notes Document Number: 51036 Revision: 19-Dec-07 Legal Disclaimer Notice Vishay Disclaimer All product specifications and data are subject to change without notice. Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein or in any other disclosure relating to any product. Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any information provided herein to the maximum extent permitted by law. The product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein, which apply to these products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications. Product names and markings noted herein may be trademarks of their respective owners. Document Number: 91000 Revision: 18-Jul-08 www.vishay.com 1
